Agate Logic RocKid-EB2-1F4C User Manual

Hide thumbs
1
2
3
4
5
6
7
8
9

Advertisement

Table of Contents

Welcome to Agate Logic Angelo family Development Kit: RocKid. Whether you just
want to learn about the Agate Logic device design, or have a specific design
implementation to complete, the kit provides a perfect environment to help you start
designing with and evaluating the powerful features of Agate Logic Angelo Devices
quickly and efficiently.
Overview
RocKid-EB2-1F4C with the board version 1.0
AG1F4-BA device on it. It enables users to use all the powerful features of AG1F4-BA
devices without having to worry about how to design the complex circuitry for power
supply and configuration; Also, RocKid-EB2-1F4C users can access all the available
AG1F4-BA I/Os without having to worry about how to create and manufacture the
complex PCB board.
This document mainly describes features and operation of RocKid-EB2-1F4C.
Features
The important features of RocKid-EB2-1F4C are listed below:
Agate Logic Angelo device with QFP208 package
Provides 118 user I/O pins
Two headers (on the top and bottom sides) to ease the layout design of user's own
mother board
Easy configuration via JTAG with the data transfer up to 1MB per second
Various configuration schemes
JTAG-based configuration
AS SPI configuration from serial configuration device M25P80
Provides a PLCC44 socket for 8051 MCU
Provides one on-board clock oscillator
Provides one chip reset push button and two user push buttons
Provides four DIP switch, two for mode select and two for user.
Provides two LEDs
Power jack for power and power switch
Agate Logic
RocKid-EB2-1F4C
Development Board User Guide
is an Angelo module board with an
User Guide
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RocKid-EB2-1F4C and is the answer not in the manual?

Questions and answers

Summary of Contents for Agate Logic RocKid-EB2-1F4C

  • Page 1 User Guide Welcome to Agate Logic Angelo family Development Kit: RocKid. Whether you just want to learn about the Agate Logic device design, or have a specific design implementation to complete, the kit provides a perfect environment to help you start designing with and evaluating the powerful features of Agate Logic Angelo Devices quickly and efficiently.

  • Page 2: Block Diagram

    The whole table is divided into three parts of different colours. The part with words in blue describes components on RocKid-EB1-MA mother board whose signals are connected to RocKid-EB2-1F4C. The part with words in red defines components on RocKid-EB2-1F4C only. The part with black words are headers unspent.
  • Page 3 RocKid-EB2-1F4C Development Board User Guide Table 1 Pin Assignment of the Connectors Header on Header on AG1F4-BA Pin Signal Description RocKid-EB2-1F4C RocKid-EB2-MA J4-1 J9-1 J4-2 J9-2 +3.3V J4-3 J9-3 +3.3V J4-4 J9-4 J4-41 J9-41 J4-42 J9-42 J4-79 J9-79 J4-80 J9-80...
  • Page 4 RocKid-EB2-1F4C Development Board User Guide Table 1 Pin Assignment of the Connectors Header on Header on AG1F4-BA Pin Signal Description RocKid-EB2-1F4C RocKid-EB2-MA IO89 CAN_INT J4-75 J9-75 Data direction IO84 CAN_DIR J4-70 J9-70 control IO117 DIG3 J3-56 J10-56 IO116 DIG2 J3-57...
  • Page 5 RocKid-EB2-1F4C Development Board User Guide Table 1 Pin Assignment of the Connectors Header on Header on AG1F4-BA Pin Signal Description RocKid-EB2-1F4C RocKid-EB2-MA IO91 RS232_TX1 J4-77 J9-77 RS-232 IO92 RS232_RX1 J4-78 J9-78 I2C clock IO63 J4-49 J9-49 signal EEPROM IO64 J4-50...
  • Page 6 RocKid-EB2-1F4C Development Board User Guide Table 1 Pin Assignment of the Connectors Header on Header on AG1F4-BA Pin Signal Description RocKid-EB2-1F4C RocKid-EB2-MA SRAM_DQ3 J3-39 J10-39 IO138 SRAM_DQ4 J3-32 J10-32 IO139 SRAM_DQ5 J3-31 J10-31 IO140 SRAM_DQ6 J3-30 J10-30 IO141 SRAM_DQ7 J3-29...
  • Page 7 Plug the 5VDC power plug in the power jack and push down the power switch SW4. Connect your computer and the RocKid-EB2-1F4C board using USB -> JTAG cable, and then you can debug your design. Push down the Chip_Rst push button on RocKid-EB2-1F4C to reset the chip. Agate Logic...

  • Page 8: Technical Support Assistance

    RocKid-EB2-1F4C Development Board User Guide About Agate Logic Agate Logic is the global pioneer and leader of the innovative Adaptable Programmable Gate Array (APGA) technologies. The company offers a full spectrum of programmable logic devices, software design tools, intellectual property (IP) and design services.
  • Page 9 RocKid-EB2-1F4C Development Board User Guide Copyright © 2005‐2009 Agate Logic, Inc. All rights reserved. No part of this document may be copied,  transmitted,  transcribed,  stored  in  a  retrieval  system,  or  translated  into  any  language  or  computer  language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or  otherwise, without the written permission of Agate Logic, Inc. All trademarks are the property of their  respective companies.  Agate Logic...
