Summary of Contents for Rockville REQ20
- Page 1 OWNER’S MANUAL REQ20 DUAL 10 BAND GRAPHIC EQUALIZER...
- Page 2 Thank you for purchasing this Rockville REQ20 Dual 10 Band Graphic Equalizer. Please read this installation guide carefully for proper use of your REQ20. Should you need technical assistance please call our technical help line at 1-646-758-0144, Monday through Friday, 9am to 5pm EST.
-
Page 3: Features & Specifications
REQ20 Features / Specifications • Dual 10 Band Graphic Equalizer (20 Bands Total) • Frequency Response: 20Hz–20KHz • Dual VU Meters Level Monitor • Blue LED on each Equalizer Slide Control • Stereo RCA Line Input • Stereo RCA Line Output •... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS • To reduce risk of electric shock, never open the unit. There are no user serviceable parts, refer service to an authorized Rockville service center. • Do not expose this unit to any kind of moisture. •... - Page 5 REQ20 1. Power Switch 11. Audio signal in 2. Left channel bass control 12. Audio signal out to amplifier 3. Left channel midrange control 13. Audio out to recording device or mixer 4. Left channel treble control 14. Voltage selector switch (110v USA) 5.
-
Page 6: Federal Communications Commission Compliance Information
Inwood, NY 11096 Hereby declares that the product(s) REQ20 Dual 10 Band Graphic Equalizer complies with FCC rules as mentioned in the following paragraph: This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 7 REQ20...
- Page 8 RockvilleAudio.com © 2019 ROCKVILLE // Features and specifications are subject to change and or improvement without notice.
Need help?
Do you have a question about the REQ20 and is the answer not in the manual?
Questions and answers
I don't understand how the meters are supposed to work or what they are supposed to show. Unless I really push the level of the audio going into the REQ20, the meters don't even move. I have to feed the highest level possible and turn up the EQ's volume controls all the way to see any meter movement. Is it supposed to be like this?
