Hog Slat GrowerSelect HS593 Installation Manual

Grow-Flex™ Feed System
General Installation Notes:
Make sure that power is disconnected from system prior to servicing.
Installation of this equipment and related OEM equipment should be in accordance with these instructions, OEM's
installation instructions and local codes (if applicable). Failure to follow specified instructions may cause damage to
equipment and/or personal injury or death.
Take special note of any Warnings or Safety Decals on the equipment and in manuals.
Always wear protective clothing and any applicable Personal Protective Equipment (Safety Glasses and/or Ear
Plugs) when working with the equipment.
Discarded materials, equipment and boxes should be recycled in accordance with local and national codes.
Unless otherwise specified, all Feed Delivery Systems (Diameters) are installed similarly.
Note: Control Unit is to be wired in accordance with all applicable local and national electrical wiring codes. All wiring sizes and fuse
capacities are to be sized according to applicable electrical code specifications or other regulations.
Safety Instructions:
Read all safety messages in this manual and on equipment safety decals. Follow recommended precautions and
safe operating practices.
Ground all electrical equipment for safety.
Ground all non-current carrying metal parts to guard against electrical shock.
Always keep safety decals in good condition and replace missing or damaged decals.
Overview:
The GrowerSELECT HS593 Control Unit is designed for use with a flexible auger feed system where control of an
auger drive motor is required. Power to the auger drive motor is done through feed pressure being applied to a
diaphragm coupled to an electrical switch internal to the control unit housing. This switch is used to control the
auger drive motor by turning off the power when feed is present and turning on the power when feed has been
removed from the control unit housing.
The sensitivity of the electrical switch is not adjustable.
MAXIMUM LOAD RATING: 1 ½ HP @ 230VAC
A red indicator light on the side of the switch housing will illuminate when the diaphragm has been pressed
(MOTOR OFF) and the switch has been activated.
The ON/OFF switch is used to enable or disable the Control Unit.
DISCONNECTING MEANS FOR SERVICING.
Hog Slat Inc. Newton Grove, NC USA
HS593
Feed Line Control Unit – 230V Single Phase
June 2017
DO NOT USE THIS SWITCH AS
1
