Duali DE-630 Hardware User Manual

Nfc contactless card interface device
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DE-630 Hardware User's Manual
DUALi Inc.
Document Version: 1.0
Last Revised Date: 30 Nov. 2010
Copyright ⓒ 2009 DUALi Inc. All rights reserved. You are strictly prohibited to copy, disclose, distribute, or use
this document in part or as a whole for any purposes other than those for which this document is disclosed. This
document is copyrighted and contains confidential information and other intellectual property rights of DUALi Inc.
Any unauthorized use, copy, disclosure or distribution constitutes infringement of DUALi's intellectual property
rights.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DE-630 and is the answer not in the manual?

Questions and answers

Related Manuals for Duali DE-630

Summary of Contents for Duali DE-630

  • Page 1 Last Revised Date: 30 Nov. 2010 Copyright ⓒ 2009 DUALi Inc. All rights reserved. You are strictly prohibited to copy, disclose, distribute, or use this document in part or as a whole for any purposes other than those for which this document is disclosed. This document is copyrighted and contains confidential information and other intellectual property rights of DUALi Inc.
  • Page 2 DUALi Inc. reserves the right to make changes to its applications or services or to discontinue any application or service at any time without notice. DUALi provides customer assistance in various technical areas, but does not have full access to data concerning the use and applications of customer's products.
  • Page 3 DE-630 Hardware User’s Guide Revision History  2010.11.30(Ver. 1.0) : First Release  2011.04.07(Ver. 1.1) : RJ-48 Pin Configuration Change Version : 1.1 DUALi Inc. (http://www.duali.com)

  • Page 4: Table Of Contents

    Contents Summary........................5 Structure......................... 6 The Structure of equipment..................6 The block diagram of DE-630 ................7 Description of main Module ................... 8 Description of Surface ..................... 9 The picture of device surface ................. 9 Communication Cable(RS-232 and RS-485)............9 The size of terminal....................

  • Page 5: Summary

    DE-630 Hardware User’s Guide Summary ITEM 사양 비고 STM32F103ZCT6 (ARM Cortex_M3, 144pin) Program Memory 256KBytes FLASH (default) On chip Up to 8Mbytes external Flash Option (1M,2M,4M,8M) Data Memory 48KBytes SRAM (default) On chip Up to 8Mbytes external PSRAM Option (1M,2M,4M,8M)

  • Page 6: Structure

    DE-630 Hardware User’s Guide Structure The Structure of equipment - DE-630 itself contains all circuits include antenna, 4 SAM connectors. - User can order RS-232 version or RS-485 version.(Communication Cable is different) (RS-232 or RS-485) (Adaptor) (OR) Host PC Version : 1.1 DUALi Inc.

  • Page 7: The Block Diagram Of De-630

    DE-630 Hardware User’s Guide The block diagram of DE-630 POWER ANTENNA (DC 12V) Buzzer LCD(128*64 graphic) Battery RF CHIP(U9) STM32F103 RC632 Tamper (256Kbytes Flash, 4 * 상태 switch 48Kbytes SRAM, 84bytes Battery backup SRAM Nor Flash 4 * SAM 13.56 PSRAM 32.768...

  • Page 8: Description Of Main Module

    SAM part: It can control 4 SAMs. And each slot can be operated independently. LED: It has 4 LEDs to display status of communication and card process. LCD : DE-630 has 128*64 graphic LCD Module Battery: It maintains RTC and battery backup SRAM while power is not supplied.

  • Page 9: Description Of Surface

    DE-630 Hardware User’s Guide Description of Surface The picture of device surface Communication Cable(RS-232 and RS-485) (Connector for RS-232 and RS-485 version)  Default: RS-232 version  Option1: RS-485 version  Cable assembly from this connector to POS is optional.

  • Page 10: Connector Pin Assignment

    DE-630 Hardware User’s Guide Connector Pin Assignment RS-232 Connector and Cable RJ-48 Pin No. Description DC POWER(DC 12V) To DC Jack DC POWER(DC 5V) TxD(to Host Rx) RxD(to Host Tx) To DC Jack DC JACK Diameter = 2mm DC + (12V) Diameter = 6.5mm...
  • Page 11 DE-630 Hardware User’s Guide order. - Its default communication method is RS-232. - DC jack’s connection is same with RS-232 version. Version : 1.1 DUALi Inc. (http://www.duali.com)

  • Page 12: Description Of Electricity

    DE-630 Hardware User’s Guide Description of Electricity The Description of power Input power1 : 12V Adaptor (higher than 300mA) The using electric current Normal 12V, 130mA under 12V, 200mA under The Description of RS-232 communication 115200bps, 8 data, no parity, 1 stop bit...
  • Page 13 DE-630 Hardware User’s Guide This product is CE marked according to the provision of the R&TTE Directive (99/5/EC). Here by DUALi Inc. declares that this product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.
