- Page 1 Embedded Solutions MODEL USB-DIO-96 USB 96 CHANNEL DIGITAL INPUT/OUTPUT MODULE USER MANUAL FILE: MUSB-DIO-96.A1f ADL Embedded Solutions Inc., 4411 Morena Blvd., Suite 101, San Diego, CA 92117-4345 P. +1 858 490-0597 F. +1 858 490-0599 e-mail: sales@adl-usa.com; web: www.adl-usa.com...
- Page 2 ADL Embedded Solutions Inc., nor the rights of others. IBM PC, PC/XT, and PC/AT are registered trademarks of the International Business Machines Corporation. Printed in USA. Copyright 2001, 2006 by ADL Embedded Solutions Inc., 4411 Morena Blvd. Suite 101, San Diego, CA 92117. All rights reserved. WARNING!! ALWAYS CONNECT AND DISCONNECT YOUR FIELD CABLING WITH THE COMPUTER POWER OFF.
-
Page 3: Table Of Contents
DIO_Configure(DeviceIndex, bTristate, pOutMask, pData)....12 unsigned long DIO_WriteAll(DeviceIndex,pData) ............12 unsigned long DIO_ReadAll(DeviceIndex,Buffer) ............12 Chapter 6: Connector Pin Assignments................. 13 Table 6-1: 50-Pin Connector Pin Assignments ............13 Chapter 7: Specifications....................14 Customer Comments ............Error! Bookmark not defined. Manual USB-DIO-96... -
Page 4: Chapter 1: Introduction
Laboratory Automation • Robotics • Machine Control • Security Systems, Energy Management • Relay Monitoring and Control • Parallel Data Transfer to PC • Sensing Switch Closures or TTL, DTL, CMOS Logic • Driving Indicator Lights or Recorders Manual USB-DIO-96... -
Page 5: Functional Description
Unlike most USB digital I/O products which primarily use a human interface device (HID) driver, we provide an easy to use, Windows-based, custom function driver optimized for maximum data throughput. This approach exposes the full functionality of the hardware along with maximizing the advantage of using the high-speed USB 2.0 bus. Manual USB-DIO-96... -
Page 6: Ordering Guide
Figure 1-1: Block Diagram Ordering Guide USB-DIO-96 USB 96-channel digital input/output module Model Options • -OEM Board only version with no enclosure • -DIN DIN rail mounting bracket for integrating into existing DIN rail systems • On-board DC power circuitry and external power AC/DC adapter •... -
Page 7: Included With Your Board
DIN rail One foot length of SNAP-TRACK with • four clips, for mounting up to two STB-50 DIN-SNAP screw terminal boards on a DIN rail DIN-rail mounting adapter plate for • MP104-DIN affixing any USB/104 module to a DIN-rail Manual USB-DIO-96... -
Page 8: Chapter 2: Installation
The board can be installed in any USB 2.0 or USB 1.1 port. Please refer to the USB I/O Quick Start Guide which can be found on the CD, for specific, quick steps to complete the hardware and software installation. Manual USB-DIO-96... -
Page 9: Chapter 3: Hardware Details
USB port or, if needed for higher source current applications, an external power supply can be used. Embedded USB Connector Micro 5-pin header in parallel with type B connector to provide a compact interface within embedded devices. Manual USB-DIO-96... -
Page 10: Led
Each connector's digital bits can be pulled up or down, or left floating, when in input mode or tristated. For pull-ups (most common), install these jumpers in the +5V position. For pull- downs, install these jumpers in the GND position. For neither, remove these jumpers. Manual USB-DIO-96... -
Page 11: Chapter 4: Usb Address Information
The VID is “0x1605" while the 96 bit board PID is “0x8003". The Device Index is determined by how many of the devices you have in your system, and provides a unique identifier allowing you to access a specific board. Manual USB-DIO-96... -
Page 12: Chapter 5: Programming
*Buffer - pointer to the first element of an array of bytes. Each port will be read, and the reading stored in the corresponding byte in the array. Note that the size of "all" is the same as the size of the data given under DIO_Configure. Manual USB-DIO-96... -
Page 13: Chapter 6: Connector Pin Assignments
I/O 02 I/O 26 I/O 50 I/O 74 GROUND I/O 01 I/O 25 I/O 49 I/O 73 GROUND I/O 00 I/O 24 I/O 48 I/O 72 GROUND +5VDC +5VDC +5VDC +5VDC GROUND Table 6-1: 50-Pin Connector Pin Assignments Manual USB-DIO-96... -
Page 14: Chapter 7: Specifications
Operating Temperature: 0 °C. to 70 °C. • Storage Temperature: -40 °C. to +85 °C. • Humidity: 0 to 90% RH, non-condensing. • Board Dimension: 3.550 x 3.775 inches. • Box Dimension: 4.00 x 4.00" x 1.25 inches. Manual USB-DIO-96... -
Page 15: Customer Comments
Please detail any errors you find and include your mailing address so that we can send you any manual updates. Embedded Solutions ADL Embedded Solutions Inc., 4411 Morena Blvd., Suite 101, San Diego, CA 92117-4345 P. +1 858 490-0597 F. +1 858 490-0599 e-mail: sales@adl-usa.com; web: www.adl-usa.com...
