Four-Faith F-DPU100 User Manual

Distributed processing unit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
F-DPU100 Distributed
Processing Unit User
Manual
F-DPU100 Distributed Processing Unit
Product Version
V1.2.0
Product Name：F-DPU100
User Manual
The user manual is suitable for the following model:
Model
Xiamen Four-Faith Communication Technology Co., Ltd.
Add: 11th Floor,A-06 Area,No.370,Chengyi Street,Jimei,
Xiamen,Fujian,China.
Tel: +86-592-5907276 / 5907277
Fax: +86-592-5912735
Web: en.fourfaith.com
Product Type
Zip Code: 361021
Page
Total:81

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F-DPU100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Four-Faith F-DPU100

  • Page 1 Total:81 F-DPU100 Distributed Processing Unit User Manual The user manual is suitable for the following model: Model Product Type Xiamen Four-Faith Communication Technology Co., Ltd. Add: 11th Floor,A-06 Area,No.370,Chengyi Street,Jimei, Xiamen,Fujian,China. Zip Code: 361021 Tel: +86-592-5907276 / 5907277 Fax: +86-592-5912735...
  • Page 2 F-DPU100 Distributed Processing Unit User Manual Files Revised Record Date Version Remark Author 2015-6-16 V1.00 Initial version ZBQ/WT 2016-1-20 V1.01 Modify parameter and install picture Harven 2017-8-31 V1.2.0 Modify the parameters Harven Xiamen Four-Faith Communication Technology Co.,Ltd. Page 2 of 86 Add: 11th Floor,A-06 Area,No.370,Chengyi Street,Jimei,Xiamen,Fujian,China.
  • Page 3 Four-Faith Communication Technology Co., Ltd. Without written permission, all commercial use of the files from Four-Faith are forbidden, such as copy, distribute, reproduce the files, etc., but non-commercial purpose, downloaded or printed by individual (all files shall be not revised, and the copyright and other proprietorship notice shall be reserved) are welcome.
  • Page 4 F-DPU100 Distributed Processing Unit User Manual Xiamen Four-Faith Communication Technology Co.,Ltd. Page 4 of 86 Add: 11th Floor,A-06 Area,No.370,Chengyi Street,Jimei,Xiamen,Fujian,China. 361021 Web: en.four-faith.com Tel: +86-592-5907276 / 5907277 Fax: +86-592-5912735...

  • Page 5: Table Of Contents

    F-DPU100 Distributed Processing Unit User Manual Contents Contents Chapter 1 Brief Introduction of Product..................... 7 1.1 General..........................7 1.2 Features and Benefits......................7 1.3 Working Principle.......................9 1.4 Specifications........................9 Chapter 2 Installation Introduction....................12 2.1 General..........................12 2.2 Encasement List....................... 12 2.3 Installation and Cable Connection...................
  • Page 6 F-DPU100 Distributed Processing Unit User Manual 3.3.7.2 Port Range Forward..................57 3.3.7.3 DMZ......................57 3.3.8 QoS Setting......................58 3.3.8.1 Basic......................58 3.3.8.2 Classify......................59 3.3.9 Applications......................59 3.3.9.1 Serial Applications..................59 3.3.9.2 communication gateway................61 3.3.10 Administration......................67 3.3.10.1 Management....................67 3.3.10.2 Keep Alive....................69 3.3.10.3 Commands....................70 3.3.10.4 Factory Defaults..................70...

  • Page 7: Chapter 1 Brief Introduction Of Product

    Chapter 1 Brief Introduction of Product 1.1 General F-DPU100 Distributed Processing Unit is a kind of cellular terminal device that provides Protocol integration and data transfer function by public cellular network. It adopts high-powered industrial 32-bits CPU and embedded real time operating system. It...
  • Page 8 F-DPU100 Distributed Processing Unit User Manual  Support hardware and software WDT  Support auto recovery mechanism, including online detect, auto redial when offline to make device always online  Ethernet port: 1.5KV magnetic isolation protection  RS232/RS485 port: 15KV ESD protection ...

  • Page 9: Working Principle

    F-DPU100 Distributed Processing Unit User Manual 1.3 Working Principle The principle chart of the F-DPU100 is as following: Cellular Embedded processing DATA Interface Module system User interface RS232/ 4 ports 10/100/ Power WIFI Indicator 1000M RS485 HOST switch lights 1.4 Specifications...
  • Page 10 F-DPU100 Distributed Processing Unit User Manual TX power 20dBm(11n),24dBm(11g),26dBm(11b)，18dBm（11ac） RX sensitivity <-72dBm@54Mpbs Hardware System Item Content Industrial 32bits CPU FLASH 512MB DDR2 512MB Interface Type Item Content 1 10/100/1000 Mbps WAN port(RJ45), auto MDI/MDIX, 1.5KV magnetic isolation protection 4 10/100 /1000 Mbps Ethernet ports(RJ45), auto MDI/MDIX, 1.5KV...
  • Page 11 F-DPU100 Distributed Processing Unit User Manual Power Input Item Content Standard Power DC 12V/1.5A Power Range DC 5~36V Consumption Item Content Standard power DC 12V/1.5A Power range DC 5~36V Communication 3G：<640mA (12V) 4G：<720mA (12V) Standby 3G：<530mA (12V) 4G：<600mA (12V) Physical Characteristics...

  • Page 12: Chapter 2 Installation Introduction

    F-DPU100 Distributed Processing Unit User Manual Chapter 2 Installation Introduction 2.1 General The F-DPU100 must be installed correctly to make it work properly. Warning: Forbid to install the F-DPU100 when powered! 2.2 Encasement List Name Quantity Remark F-DPU100 host Cellular antenna (Male SMA)
  • Page 13 F-DPU100 Size Installation of SIM/UIM card: Firstly power off the F-DPU100, and press the out button of the SIM/UIM card outlet with a needle object. Then the SIM/UIM card sheath will flick out at once. Put SIM/UIM card into the card sheath (Pay attention to put the side which has metal point outside), and insert card sheath back to the SIM/UIM card outlet.
  • Page 14 Screw the SMA male pin of the cellular antenna to the female SMA interface of the F-DPU100 with sign “ANT-M” and “ANT-A”. Screw the SMA female pin of the WIFI antenna to the male SMA interface of the F-DPU100 with sign “WIFI”.
  • Page 15 F-DPU100 Distributed Processing Unit User Manual Insert the RJ45 end of the console cable into the RJ45 outlet with sign “console”, and insert the DB9F end of the console cable into the RS232 serial interface of user’s device. The signal connection of the console cable is as follows:...

  • Page 16: Power

    Warning: When we use other power, we should make sure that the power can supply power above 8W. We recommend user to use the standard DC 12V/1.5A power. 2.5 Indicator Lights Introduction The F-DPU100 provides following indicator lights: “Power”, “System”, “Online”, “SIM”, “Local Network”, “WAN”, “WIFI”, “Signal Strength”. Indicator State...

  • Page 17: Reset Button Introduction

    F-DPU100 Distributed Processing Unit User Manual The corresponding interface of switch is not connected LAN1~ ON / The corresponding interface of switch is connected LAN4 BLINK /Communicating The interface of WAN is not connected ON / The interface of WAN is connected /Communicating...

  • Page 18: Chapter 3 Configuration And Management

    192.168.1.1 on address bar, then press the botton of Enter to visit page Web management tool of the F-DPU100. The users login in the web page at the first name, there will display a page shows as blow to tip users to modify the default user name and password of the F-DPU100. Users have to click "change password"...
  • Page 19 F-DPU100 Distributed Processing Unit User Manual After access to the information main page Users need to input user name and password if it is their first time to login. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 19 of 86 Add: 11th Floor,A-06 Area,No.370,Chengyi Street,Jimei,Xiamen,Fujian,China. 361021 Web: en.four-faith.com...

  • Page 20: Management And Configuration

    The Setup screen is the first screen users will see when accessing the F-DPU100. Most users will be able to configure the F-DPU100 and get it work properly using only the settings on this screen. Some Internet Service Providers (ISPs) will require users to enter specific information, such as User Name, Password, IP Address, Default Gateway Address, or DNS IP Address.
  • Page 21 F-DPU100 Distributed Processing Unit User Manual Forbid the setting of WAN port connection type Static IP WAN IP Address: Users set IP address by their own or ISP assigns Subnet Mask: Users set subnet mask by their own or ISP assigns...
  • Page 22 This function is used to detect whether the Internet connection is active, if users set it and when the F-DPU100 detect the connection is inactive, it will redial to users' ISP immediately to make the connection active. If the network is busy or the user is in...
  • Page 23 Local IP Address: IP address of the F-DPU100 Subnet Mask: the subnet mask of the F-DPU100 Gateway: set internal gateway of the F-DPU100. If default, internal gateway is the address of the F-DPU100 Local DNS: DNS server is auto assigned by network operator server. Users enable to use their Xiamen Four-Faith Communication Technology Co.,Ltd.
  • Page 24 The F-DPU100 can serve as a network DHCP server. DHCP server automatically assigns an IP address for each computer in the network. If they choose to enable the F-DPU100's DHCP server option, users can set all the computers on the LAN to automatically obtain an IP address and DNS, and make sure no other DHCP server in the network.

  • Page 25: Dynamic Dns

    DNS Server IP address. If users wish to utilize another, enter that IP address in one of these fields. Users can enter up to three DNS Server IP addresses here. The F-DPU100 will utilize them for quicker access to functioning DNS servers.

  • Page 26: Clone Mac Address

    DDNS Status shows connection log information 3.3.1.3 Clone MAC Address Some ISP need the users to register their MAC address. The users can clone the F-DPU100 MAC address to their MAC address registered in ISP if they do not want to re-register their MAC address Xiamen Four-Faith Communication Technology Co.,Ltd.

  • Page 27: Advanced F-Dpu100

    MAC address and LAN port MAC address. 3.3.1.4 Advanced F-DPU100 Operating Mode: Gateway and F-DPU100 If the F-DPU100 is hosting users' Internet connection, select Gateway mode. If another F-DPU100 exists on their network, select F-DPU100 mode. Dynamic Routing Dynamic Routing enables the F-DPU100 to automatically adjust to physical changes in the network's layout and exchange routing tables with other F-DPU100s.

  • Page 28: Vlans

    Subnet Mask: the Subnet Mask determines which portion of an IP address is the network portion, and which portion is the host portion Gateway: IP address of the gateway device that allows for contact between the F-DPU100 and the network or host.

  • Page 29: Networking

    F-DPU100 Distributed Processing Unit User Manual VLANs function is to divide different VLAN ports by users' will. The system supports 15 VLAN port from VLAN1-VLAN15. However there is only 5 time ports (1 WAN port and 4 LAN port) divided by users themselves,and LAN port and WAN port disable to divide into one VLAN port meanwhile.
  • Page 30 F-DPU100 Distributed Processing Unit User Manual Bridging - Assign to Bridge: allows users to assign any valid interface to a network bridge. Consider setting the Wireless Interface options to Bridged if they want to assign any Wireless Interface here. Any system specific bridge setting can be overridden here in this field.
  • Page 31 F-DPU100 Distributed Processing Unit User Manual To make br1 bridge has the same function with DHCP assigned address, users need to set multiple DHCP function, see the introduction of multi-channel DHCPD: Port Setup: Set the port property, the default is not set...

  • Page 32: Wireless

    F-DPU100 Distributed Processing Unit User Manual Multiple DHCPD: using multiple DHCP service. Click 'Add' in multiple DHCP server to appear relevant configuration. The first means the name of port or bridge (do not be configured as eth0), the second means whether to on DHCP. Start means start address, Max means maximum assigned DHCP clients, Leasetime means the client lease time, the unit is second, click 'Save' or 'Apply' to put it into effect after setting.
  • Page 33 Network Configuration： Bridged：Bridge to the F-DPU100, under normal circumstances, please select the bridge. Unbridged：There is no bridge to the F-DPU100, IP addresses need to manually configure. Virtual Interfaces：Click Add to add a virtual interface. Add successfully, click on the remove, you can remove the virtual interface。...

  • Page 34: Wireless Security

    F-DPU100 Distributed Processing Unit User Manual AP Isolation：This setting isolates wireless clients so access to and from other wireless clients are stopped. Note ： Save your changes, after changing the "Wireless Mode", "Wireless Network Mode", "wireless width", "broadband" option, please click on this button, and then configure the other options.
  • Page 35 F-DPU100 Distributed Processing Unit User Manual characters. Valid hexadecimal characters are "0"-"9" and "A"-"F". ASCII/HEX: ASCII, the keys is 5 bit ASCII characters/13bit ASCII characters. HEX, the keys is 10bit/26 bit hex digits. Passphrase：The letters and numbers used to generate a key.

  • Page 36: Services

    DNSmasq and DHCP service if chose above. Static Leases: if users want to assign certain hosts a specific address then they can define them here. This is also the way to add hosts with a fixed address to the F-DPU100's local DNS service (DNSmasq).
  • Page 37 RO Community: SNMP RO community name, the default is public, Only to read. RW Community: SNMP RW community name, the default is private, Read-write permissions SSHD Enabling SSHd allows users to access the Linux OS of their F-DPU100 with an SSH client Xiamen Four-Faith Communication Technology Co.,Ltd. Page 37 of 86 Add: 11th Floor,A-06 Area,No.370,Chengyi Street,Jimei,Xiamen,Fujian,China.
  • Page 38 Telnet: enable a telnet server to connect to the F-DPU100 with telnet. The username is the password is the F-DPU100's password. Note: If users use the F-DPU100 in an untrusted environment (for example as a public hotspot), it is strongly recommended to use SSHd and deactivate telnet.

  • Page 39: Vpn

    Force MPPE Encryption: enable of disable force MPPE encryption of PPTP data DNS1/DNS2/WINS1/WINS2: set DNS1/DNS2/WINS1/WINS2 Server IP: input IP address of the F-DPU100 as PPTP server, differ from LAN address Client IP(s): IP address assigns to the client, the format is xxx.xxx.xxx.xxx-xxx CHAP Secrets: user name and password of the client using PPTP service Note: client IP must be different with IP assigned by F-DPU100 DHCP.

  • Page 40: L2Tp

    L2TP Server Force MPPE Encryption: enable or disable force MPPE encryption of L2TP data Server IP: input IP address of the F-DPU100 as PPTP server, differ from LAN address Client IP(s): IP address assigns to the client, the format is xxx.xxx.xxx.xxx-xxx.xxx.xxx.xxx CHAP Secrets: user name and password of the client using L2TP service Note: client IP must be different with IP assigned by F-DPU100 DHCP.

  • Page 41: Openvpn

    3.3.4.3 OPENVPN OPENVPN Server Start Type: WAN UP----start after on-line, System----start when boot up Config via: GUI----Page configuration, Config File----config File configuration Server mode: F-DPU100 (TUN)-route mode, Bridge (TAP)----bridge mode F-DPU100 (TUN): Xiamen Four-Faith Communication Technology Co.,Ltd. Page 41 of 86 Add: 11th Floor,A-06 Area,No.370,Chengyi Street,Jimei,Xiamen,Fujian,China.
  • Page 42 F-DPU100 Distributed Processing Unit User Manual Network: network address allowed by OPENVPN server Netmask: netmask allowed by OPENVPN server Bridge (TAP): DHCP-Proxy mode: enable or disable DHCP-Proxy mode Pool start IP: pool start IP of the client allowed by OPENVPN server...
  • Page 43 F-DPU100 Distributed Processing Unit User Manual Use LZO Compression: enable or disable use LZO compression for data transfer Redirect default Gateway: enable or disable redirect default gateway Allow Client to Client: enable or disable allow client to client Allow duplicate cn: enable or disable allow duplicate cn...
  • Page 44 F-DPU100 Distributed Processing Unit User Manual Additional Config: additional configurations of the server CCD-Dir DEFAULT file: other file approaches TLS Auth Key: authority key of Transport Layer Security Certificate Revoke List: configure some revoke certificates OPENVPN Client Server IP/Name: IP address or domain name of OPENVPN server...
  • Page 45 F-DPU100 Distributed Processing Unit User Manual Use LZO Compression: enable or disable use LZO compression for data transfer NAT: enable or disable NAT through function Bridge TAP to br0: enable or disable bridge TAP to br0 Local IP Address: set IP address of local OPENVPN client...

  • Page 46: Ipsec

    F-DPU100 Distributed Processing Unit User Manual 3.3.4.4 IPSEC Connect Status and Control Show IPSEC connection and status of current F-DPU100 on IPSEC page. Name: the name of IPSEC connection Type: The type and function of current IPSEC connection Common name: local subnet, local address, opposite end address and opposite end subnet of...
  • Page 47 F-DPU100 Distributed Processing Unit User Manual Name: to indicate this connection name, must be unique Enabled: If enable, the connection will send tunnel connection request when it is reboot or re-connection, otherwise it is no need if disable Local WAN Interface: local addresss of the tunnel Remote Host Address: IP/domain name of end opposite;...

  • Page 48: Gre

    F-DPU100 Distributed Processing Unit User Manual ESP Keylife: set ESP keylife, current unit is hour, the default is 0 IKE aggressive mode allowed: negotiation mode adopt aggressive mode if tick; it is main mode if non-tick Negotiate payload compression: Tick to enable PFS, non-tick to diable PFS Authentication: choose use share encryption option or certificate authentication option.

  • Page 49: Security

    F-DPU100 Distributed Processing Unit User Manual Local Netmask：Netmask of local network Keepalive：Enable or disable GRE Keepalive function Retry times：GRE keepalive detect fail retries Interval：The time interval of GRE keepalive packet sent Fail Action：The action would be exec after keeping alive failed Click on “View GRE tunnels”...
  • Page 50 IP . Any new access request will be automatically dropped. Limit L2TP Server Access: When build a L2TP Server in the F-DPU100, this feature limits the access request from the WAN by ssh, and per minute up to accept two connection requests on the same IP.
  • Page 51 Options: When select Enable, the corresponding connection will be recorded in the journal, the disabled are not recorded. Incoming Log: To see a temporary log of the F-DPU100's most recent incoming traffic, click the Incoming Log button. Outgoing Log: To see a temporary log of the F-DPU100's most recent outgoing traffic, click the Outgoing Log button.

  • Page 52: Access Restrictions

    F-DPU100 Distributed Processing Unit User Manual 3.3.6 Access Restrictions 3.3.6.1 WAN Access Use access restrictions, you can block or allow specific types of Internet applications. You can set specific PC-based Internet access policies. This feature allows you to customize up to ten different Internet Access Policies for particular PCs, which are identified by their IP or MAC addresses.
  • Page 53 F-DPU100 Distributed Processing Unit User Manual Website Blocking by URL Address: You can block access to certain websites by entering their URL. Website Blocking by Keyword: You can block access to certain website by the keywords contained in their webpage set up Internet access policy 1.

  • Page 54: Url Filter

    3.3.3.2 Turn off the power of the F-DPU100 or reboot the F-DPU100 can cause a temporary failure 。 After the failure of the F-DPU100, if can not automatically synchronized NTP time server, you need to recalibrate to ensure the correct implementation of the relevant period control function.

  • Page 55: Packet Filter

    F-DPU100 Distributed Processing Unit User Manual only discard the matching URL address Discard packets conform to the following rules: in the list . receive only with custom Accept only the data packets conform to the following rules: rules of network address, discarded all other URL address.

  • Page 56: Nat

    When users send this type of request to your network via the Internet, the F-DPU100 will forward those requests to the appropriate PC. If you want to forward a whole range of ports, see Port Range Forwarding.

  • Page 57: Port Range Forward

    Internet access to perform functions such as videoconferencing or online gaming. When users send this type of request to your network via the Internet, the F-DPU100 will forward those requests to the appropriate PC. If you only want to forward a single port, see Port Forwarding.

  • Page 58: Qos Setting

    QoS Setting 3.3.8.1 Basic Bandwidth management prioritizes the traffic on your F-DPU100. Interactive traffic (telephony, browsing, telnet, etc.) gets priority and bulk traffic (file transfer, P2P) gets low priority. The main goal is to allow both types to live side-by side without unimportant traffic disturbing more critical things.

  • Page 59: Classify

    There is a console port on F-DPU100. Normally, this port is used to debug the F-DPU100. This port can also be used as a serial port. The F-DPU100 has embedded a serial to TCP program. The data sent to the serial port is encapsulated by TCP/IP protocol stack and then is sent to the destination server.
  • Page 60 Enable Serial TCP Function: Enable the serial to TCP function Protocol Type: The protocol type to transmit data. UDP(DTU) – Data transmit with UDP protocol , work as a Four-Faith IP MODEM device which has application protocol and hear beat mechanism.

  • Page 61: Communication Gateway

    F-DPU100 Distributed Processing Unit User Manual Custom Heartbeat Packet : This item is valid when Protocol Type is “TCST” Custom Registration Packets: This item is valid when Protocol Type is “TCST” 3.3.9.2 communication gateway Select Channel:Select the channels that need to be used, each of which can be used as a collection service or a data service mode.
  • Page 62 F-DPU100 Distributed Processing Unit User Manual tcp/udp protocols. Description of the Modbus protocol Slave address: the address of the device that needs to be accessed. (0~255). Data name:Create data points for interconversion between different protocols. Read coils (function code 1):Each bit in the response message is divided into a coil according to each bit in the data domain.
  • Page 63 F-DPU100 Distributed Processing Unit User Manual BACTNET MSTP MAC:the address of the device that needs to be accessed. (0~255). Device Number:Indicate the number of the device. The IEC power agreement Link Addr:Used for equipment addressing. Common address:The same as the link address, as the terminal address.
  • Page 64 F-DPU100 Distributed Processing Unit User Manual Usr2call cycle:Teleconnection and telemetry are usually circulatory. Electricity Call cycle: Get data tiring regularly. Link Test cycle:When the link does not interact with the data, it is necessary to send the link test message regularly to see if the detection link is disconnected.
  • Page 65 F-DPU100 Distributed Processing Unit User Manual Server Addr: the IP address or domain name of the data service center that communicates with the TCP program that is communicated with the F-DPU100's serial port. Server Port: the port that the data service center program listens to.
  • Page 66 F-DPU100 Distributed Processing Unit User Manual mainly provides the forwarding data service. Protocol: protocol used for communication between devices. The supported protocols are: Modbus RTU, MODBUS ASCII, Modbus TCP, BACnet MSTP, BACnet BIP, IEC101, IEC104. Modbus Data configure It is mainly related to the data points based on the different functional codes of the Modbus protocol.

  • Page 67: Administration

    3.3.10 Administration 3.3.10.1 Management The Management screen allows you to change the F-DPU100's settings. On this page you will find most of the configurable items of the F-DPU100 code. The new password must not exceed 32 characters in length and must not include any spaces.
  • Page 68 Internet. To disable this feature, keep the default setting, Disable. To enable this feature, select Enable, and use the specified port (default is 8080) on your PC to remotely manage the F-DPU100. You must also change the F-DPU100's default password to one of your own, if you haven't already.

  • Page 69: Keep Alive

    F-DPU100 Distributed Processing Unit User Manual Remote Upgrade: custom-developed remote management server for this station F-DPU100 monitoring and management, configuration parameters, WIFI advertising updates. 3.3.10.2 Keep Alive Schedule Boot&Shutdown The user can set the startup or shutdown time: For example,the user want to set the start time at 8:07 and boot time at 9:07.

  • Page 70: Commands

    Run Command：You can run command lines via the web interface. Fill the text area with your command and click Run Commands to submit. Startup：You can save some command lines to be executed at startup's F-DPU100. Fill the text area with commands (only one command by row) and click Save Startup.

  • Page 71: Firmware Upgrade

    Upgrading firmware may take a few minutes. Do not turn off the power or press the reset button! After flashing, reset to： If you want to reset the F-DPU100 to the default settings for the firmware version you are upgrading to, click the Firmware Defaults option.

  • Page 72: Status

    F-DPU100 Distributed Processing Unit User Manual Backup Settings ： You may backup your current configuration in case you need to reset the F-DPU100 back to its factory default settings.Click the Backup button to backup your current configuration. Restore Settings： Click the Browse... button to browse for a configuration file that is currently saved on your PC.Click the Restore button to overwrite all current configurations with the ones in...
  • Page 73 Total Available: the room for total available of RAM (that is physical memory minus some reserve and the kernel of binary code bytes) Free: free memory, the F-DPU100 will reboot if the memory is less than 500kB Used: used memory, total available memory minus free memory...

  • Page 74: Wan

    F-DPU100 Distributed Processing Unit User Manual Active IP Connections: total active IP connections Protocol: connection protocol Timeouts: connection timeouts, unit is second Source Address: source IP address Remote Address: remote IP address Service Name: connecting service port Status: displayed status 3.3.11.2 WAN...
  • Page 75 F-DPU100 Distributed Processing Unit User Manual IP Address: IP address of F-DPU100 WAN Subnet Mask: subnet mask of F-DPU100 WAN Gateway: the gateway of F-DPU100 WAN DNS1, DNS2, DNS3: DNS1/DNS2/DNS3 of F-DPU100 WAN Remaining Lease Time: remaining lease time of IP address in DHCP way...

  • Page 76: Lan

    F-DPU100 Distributed Processing Unit User Manual Total Flow: flow from power-off last time until now statistics, download and upload direction Monthly Flow: the flow of a month, unit is MB Last Month: the flow of last month Next Month: the flow of next month...
  • Page 77 Conn. Count: connection count caused by the client Ratio: the ratio of 4096 connection DNCP Server: enable or disable the F-DPU100 work as a DHCP server DHCP Daemon: the agreement allocated using DHCP including DNSMasq and uDHCPd Starting IP Address: the starting IP Address of the DHCP server’s Address pool Ending IP Address: the ending IP Address of the DHCP server’s Address pool...
  • Page 78 F-DPU100 Distributed Processing Unit User Manual MAC Address: MAC address of the client Expires: the expiry the client rents the IP address Delete: click to delete DHCP client Interface: the interface assigned by dial-up system User Name: user name of PPPoE client...

  • Page 79: Wireless

    F-DPU100 Distributed Processing Unit User Manual User Name: user name of the client Local IP: tunnel IP address of PPTP client Remote IP: IP address of PPTP client Delete: click to delete PPTP client 3.3.11.4 Wireless MAC Address: MAC address of wireless client...

  • Page 80: Bandwidth

    F-DPU100 Distributed Processing Unit User Manual Interface: interface of wireless client Uptime: connecting uptime of wireless client TX Rate: transmit rate of wireless client RX Rate: receive rate of wireless client Signal: the signal of wireless client Noise: the noise of wireless client...
  • Page 81 F-DPU100 Distributed Processing Unit User Manual Bandwidth Monitoring-LAN Graph abscissa axis: time vertical axis: speed rate Bandwidth Monitoring-WAN Graph abscissa axis: time vertical axis: speed rate Xiamen Four-Faith Communication Technology Co.,Ltd. Page 81 of 86 Add: 11th Floor,A-06 Area,No.370,Chengyi Street,Jimei,Xiamen,Fujian,China. 361021 Web: en.four-faith.com...

  • Page 82: Sys-Info

    Bandwidth Monitoring-Wireless (W10) Graph abscissa axis: time vertical axis: speed rate 3.3.11.6 Sys-Info F-DPU100 Name: the name of the F-DPU100 F-DPU100 Model: the model of the F-DPU100 LAN MAC: MAC address of LAN port WAN MAC: MAC address of WAN port Xiamen Four-Faith Communication Technology Co.,Ltd.
  • Page 83 F-DPU100 Distributed Processing Unit User Manual Wireless MAC: MAC address of the wireless WAN IP: IP address of WAN port LAN IP: IP address of LAN port Radio: display whether radio is on or not Mode: wireless mode Network: wireless network mode...
  • Page 84 Total Available: the room for total available of RAM (that is physical memory minus some reserve and the kernel of binary code bytes) Free: free memory, the F-DPU100 will reboot if the memory is less than 500kB Used: used memory, total available memory minus free memory...

  • Page 85: Appendix

    F-DPU100 Distributed Processing Unit User Manual Appendix The following steps describe how to setup Windows XP Hyper Terminal. 1. Press “Start””Programs””Accessories””Communications””Hyper Terminal” 2. Input connection name, choose “OK” 3. Choose the correct COM port which connects to modem, choose “OK”...

  • Page 86: Xiamen Four-Faith Communication Technology Co.,Ltd

    F-DPU100 Distributed Processing Unit User Manual Stop bits: 1 Flow control: None 5. Complete Hyper Terminal operation, It runs as following Note: If the user is using the win7 system, you can download a win7 super terminal on the internet. Universal serial interface or other similar software.
