- Page 1 Document Symbol Number：HS-AP-PR001 ESL ACCESS POINT HS_C09851 PRODUCT MANUAL Document Version Release Date 2016-09-30 ALL RIGHTS RESERVED...
- Page 2 ESL Access Point HS_C09851 PRODUCT MANUAL arget Audience This document introduces the uses, functions, hardware parameters, performance characteristics and precautions for Electronic Shelf Labels Access Point. This manual is applicable for the below engineers: Test Engineer Technical Support Engineer ...
-
Page 3: Table Of Contents
ESL Access Point HS_C09851 PRODUCT MANUAL Catalog Overview ..........................4 Instruction to ESL Access Point .................... 4 System Architecture and AP Functions ................4 HS-C09851 Characteristics ....................5 PRODUCT ARCHITECTURE ....................5 Overview ..........................5 Configuration and Appearance ..................... 6 2.2.1... -
Page 4: Overview
1 Overview 1.1 Instruction to ESL Access Point HS_C09851 is the second generation of ESL Access Point system developed by HANSHOW. It operates in the 2.4G wireless frequency range and is responsible for data transmission and information exchange between ESL-Working system and ESL system. The second-generation ESL... -
Page 5: Hs-C09851 Characteristics
ESL System architecture diagram Figure 1-1 HS_C09851 is an important part of Hanshow electronic shelf label system, it as a data transmission link responsible for the important task of data forwarding: （1） Forwarding uplink data：The ESL Access Point connected to ESL-Working over a wired network, to sent send the price changes, inventory, templates and other data to ESL;... -
Page 6: Configuration And Appearance
ESL Access Point HS_C09851 PRODUCT MANUAL 2.2 Configuration and Appearance 2.2.1 Basic Configuration HS_C09851 Configuration Power Module Input voltage 12V DC Rated current Rated power Other Overload / overvoltage / over temperature protection Host Processor Module CPUFreq. 720MHz ARMprocessor Storage... -
Page 7: Physical Interface
ESL Access Point HS_C09851 PRODUCT MANUAL Standard IEEE 802.3 , pre-standard(legacy) POE compatible Power consumption Idle state power 12V，300mA consumption Working state 12V，450mA maximum power consumption 2.2.2 Physical interface Appearance of second generation ESL Access Point Figure 2-1 Note ... - Page 8 ESL Access Point HS_C09851 PRODUCT MANUAL Table 2-1 AP interface and function description Interface Name Functional description Power source 12V-1A standard adapter access, Hanshow provide standard adaptor interface 12V adapter Restore factory settings button，Press this button for more than 5 seconds, the configuration can be reset. After reset, the Reset button system automatically loads the default settings;...
- Page 9 ESL Access Point HS_C09851 PRODUCT MANUAL Figure 2-3 ESL Access Point front panel diagram Table 2-2 ESL Access Point front panel Number Name State Meaning The ESL Access Point is connected to esl- working; the number displayed is the ID number Access Point serial of the current ESL Access Point，range 1 –...
-
Page 10: Ap Appearance Parameters
ESL Access Point HS_C09851 PRODUCT MANUAL Caution POE and DC power supported IP address and MAC address are default setting. IP address can be modified on configuration page. 2.2.3 AP Appearance Parameters Table 2-4 ESL Access Point appearance parameters... -
