SMART REMOTE PRO
Regain complete control of your air conditioning costs with the
Aircon Off Smart Remote PRO
The most advanced energy saving universal remote in the world.
SET UP AND INSTRUCTION MANUAL
V12 10.1
Distributed by:
Reduction Revolution Pty Ltd
www.reductionrevolution.com.au
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Smart Remote Pro and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aircon Off Smart Remote Pro

Summary of Contents for Aircon Off Smart Remote Pro

  • Page 1 SMART REMOTE PRO Regain complete control of your air conditioning costs with the Aircon Off Smart Remote PRO The most advanced energy saving universal remote in the world. SET UP AND INSTRUCTION MANUAL V12 10.1 Distributed by: Reduction Revolution Pty Ltd...
  • Page 2 How to Set the Min & Max Temperature Settings How To Set Up the Placebo Effect Function How to Pair the Smart Remote Pro with your AC How to Use the “Off” Timers Changing the Display between Celsius and Fahrenheit...

  • Page 3: Energy Saving

    The Energy Saving Features of this remote will work with any AC. Programmable Temperature Ranges The Smart Remote Pro is preset to allow the AC to operate at an energy saving 2 -30 ° for Cooling and 17-23° for Heating. By using the Set Up Function you can change these temperature ranges if required.

  • Page 4: Installing Batteries

    SMART REMOTE PRO Installing Batteries Remove the battery cover on the back of the Smart Remote Pro. Insert two AAA (VM-4, R03) batteries. Should the remote not operate, Slide down the keypad cover and use a pen or a point to press hold and release the ‘RESET”...
  • Page 5 How to Set Maximum Temperature for Heat Mode. If necessary unlock the Set Up Function. 1. Simultaneously press both the “SELECT” button & the “TEMP +” (Up) button for 3 seconds. The screen will flash “Hi”, then release. 2. Press and release “iHEAT” button. The “HEAT” symbol will flash. Then enter chosen maximum temperature for Heat Mode by using the Temp “+”...
  • Page 6 How to Pair the Smart Remote Pro with your Air Conditioner The Smart Remote Pairing Code list on page lists all major brands of air conditioners and the associated Smart Remote Brand Codes. These Smart Remote Codes do not relate to specific air conditioner model numbers.
  • Page 7 How to Use the “Off” Timers This remote operates by direct line of sight to the AC wall unit. For the timers to operate correctly the remote must be pointing at the AC at the exact moment it sends the “Off” signal. Test the correct operation of the On Off signal before fixing the wall bracket in place.
  • Page 8 How to Set the Daily “Time of Day Off” Timer The remote will transmit the Power “Off” signal at the pre programmed time of day, 7 days a week. Step 1 Turn On the Clock In order to save battery life the clock function should only be switched on if the Time of Day Off Timer is being used.
  • Page 9 Batteries Always use high quality Alkaline batteries., lf it is not intended to use the Smart Remote Pro for an extended period, remove the batteries to avoid battery leakage which will damage the unit.

  • Page 10: Troubleshooting

    If necessary unlock the Set Up Function again. During Set Up. If only certain functions are available If the Smart Remote Pro has been supplied with the Option “Factory Set and Locked” the Temperature Range and Placebo Function are preset and not adjustable. Only the Pairing Function...

  • Page 11: Smart Remote

    ® SMART REMOTE UNIVERSAL POWER SAVING AC REMOTE CONTROL BRAND Smart Remote Code BRAND Smart Remote Code ACSON  KANGLI  0234  0374, 0375, 0654, 1399,1910  AGREE  0107, 0108  KELON  0282‐0287, 0473,0485‐0488  0151, 0197, 0203, 0619, 1007, 1024, 1133 AGER  0489, 0785  KELVINATOR  AIRWELL  0529, 0555,0556  KLIMATAIR  0225, 0226, 0452, 0737‐0738,1761  ALPIN  0252, 0253, 0617, 0764, 0765, 1277, 1789  KOLIN  0416‐0418, 1441, 1952  ARENA  0206, 0212, 0229, 0718, 0724, 0741  KONKA ...
  • Page 12 UNI‐AIR  0222‐0224, 0450, 0734‐0735, 1986  HUABAO  0336‐0344, 0848‐0855, 1360,1878  WAN BAO  0138‐0152, 0666, 0905, 0995,1177  HUAKE  0408, 0493‐0498, 0920,1944  WEILI  0393‐0396, 0907‐0908, 1420,1929  HUAMEI  0402, 0460‐0465, 1426,1999  WHIRLPOOL  0164‐0170, 0502, 0677‐0678, 1760  0317‐0325, 0452, 0964  HUALING  HUIFENG  0370, 0882, 0568, 0441-0443, 1392, 1979  HUIKANG  0202, 0433, 0480, 0550, 0551, 0609, 1226,1969               WINIA  0481, 0550,0993  HYUNDAI  0373, 0440, 0952,1909  JDC  XILENG 0411, 0412, 0923‐0924,1947  0169, 0170  YANGZI(YAIR)  0403, 0488‐0493, 0915  JET AIR  JIANGNAN  0432, 1456  YINYAN  258, 259, 326‐331, 0770, 0838‐0844  YORK  0002, 0107, 0238‐0243, 0501, 0502, 0573, ...
