Fosera POWER LINE User Manual

Care and maintenance

When the fan is not in usage, it should be stored in a dry
location.
Always unplug the fan before cleaning or disassembling.
Clean the outside surfaces of the fan with a damp cloth
and mild detergent - do not allow water to enter.

Technical Specification

Nominal voltage 13 V
Voltage range 12V +/- 3V
Power 8.5 W
Current 653 mA
Airflow
30.4 m
Speed setting (high/med/low)
Blade diameter 16"
Cable 6 m
Height (max. height) 125 cm
Weight (net/gross) 3.93 kg / 4.5 kg
Contact:
Fosera Solarsystems GmbH & Co. KGaA
Beim Mühlbach 3
89171 Illerkirchberg
+ 49 (0) 7346 924 69 73
info@fosera.com
/ min
3
Standing Fan
User Manual
Medium-Power
With the Fosera Standing Fan a pleasant indoor climate can be
achieved, and the life quality significantly improved. In hot and dry
areas of the world, solar powered cooling and ventilation
substantially increase home comfort.
It is the perfect product extension for our POWER LINE. Mobile
standing fans are adequate for focusing the air jet where it is
most desired. Following Fosera's plug-and-play philosophy,
connect the Standig Fan to the Fosera LSHS or to the Fosera
EVO and move it where convenient to enjoy its pleasant breeze.
Please read the safety warnings below carefully before using this
product.
Timer
High-Power
Low-Power
On / O switch
