INSTRUCTION MANUAL

ver. 1.3.0119

Table of Contents

Need help?

Do you have a question about the MVP-100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Reckeen MVP-100

Page 1 INSTRUCTION MANUAL ver. 1.3.0119...
Page 2: Table Of Contents
..................• Back panel view ..........................• Control Panel MVPKey-100 ......................• How to connect Keyboard MVPKey-100 to the Reckeen system ......... • Calibration of Joystick and T-Bar ....................• Test of adjusting the brightness of the keyboard’s backlight ........
Page 3: Disclaimer Of Product And Services
MVP 100 failure, or when the contents of a recording are lost or damaged as a result of your Reckeen MVP 100 failure or repair undertaken to your Reckeen MVP 100. Reckeen will not restore, recover, or replicate the recorded or streamed contents made to your Reckeen MVP 100, external recording media, or recording devices under any circumstances.
Page 4: Warnings And Precautions
| INSTRUCTION MANUAL Warnings and Precautions 1. Read carefully all of these warnings and save them for later reference. Follow all warnings and instructions marked on this unit. 3. Unplug this unit from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning.
Page 5: Warranty
It is likely that such data, software, or other materials will be lost or reformatted during service and Reckeen will not be responsible for any such damage or loss. Our warranty doesn’t cover damage caused by accidents or unauthorized modifications, installing any other software and repairs, misuse, sand, grit or water.
Page 6: Introduction
Introduction | INSTRUCTION MANUAL Introduction...
Page 7 The device allows you to save all defined settings in 8 memory banks. At any time, the user can restore the settings and start the video production without the need for reconfiguration. MVP-100 is perfect for live production, TV studio, live coverage of field events! Just plug in your cameras and start switching live!
Page 8 We support 8 SDI input You can selected form 8 2 x 4k / 1 x 4k and 4 x 3G Trigger in MVP-100, that Communications port 1 2 G , e v e r y s i n g l e 4 k with 3G format.
Page 9 INSTRUCTION MANUAL | Introduction CAM 1 CAM 1 FULL HD CAM 2 HDMI or SDI 12G SDI 3G FULL HD CAM 2 CAM 3 SDI 3G FULL HD HDMI or SDI 12G CAM 4 SDI 3G FULL HD SDI 3G VIDEO STREAMER CAM 5 FULL HD...
Page 10: System Description
System description | INSTRUCTION MANUAL System description...
Page 11 It is perfect to apply both on the set and during the life coverage of events. In addition, MVP-100 converter is really easy to use. The small size of the device, its user-friendly interface. HOW DOES MVP-100 OPERATE? MVP-100 is able to simultaneously convert signals from two video inputs with resolutions up to UHD (3840x2160).
Page 12 HDMI output Program that shows one of the frames or the transition effect between them. MVP-100 means multiple applications and uses, as this device allows for a variety of effects that will satisfy every professional engaged in production, broadcasting and also events’ live coverage with the use of audiovisual materials!
Page 13: Capabilities, Functionalities And Applications
INSTRUCTION MANUAL | Capabilities, functionalities and applications Capabilities, functionalities and applications...
Page 14 4K resolution. With MVP-100, you can not only change the composition, but also the shots. The end result will resemble the usage of several cameras, and, with your mixer’s help, the transitions between them will be smooth and natural.
Page 15 Video walls are a modern and increasingly popular solution used in entertainment, advertising, marketing, and special events. With its capability to separate the signal from 4K inputs, MVP-100 converter is an excellent tool for creating a video wall by multiplying the signal from one or two 4K sources.
Page 16 4K CAMERA HD PROJECTOR MVP-100 is an invaluable tool in creating a top-notch security systems. It allows you to get eight 3G HD outputs from a single 4K camera. As MVP-100 processes the signal in real time, you obtain the effect of 8 high-quality mobile video cameras –...
Page 17 This functionality additionally significantly increases the utilization of MVP-100 Multi-camera unit converter’s capabilities. A joystick in the external Reckeen MVP Control panel allows the operator to control the virtual camera manually within the selected window. Thus, in each of the eight virtual camera windows, both the software settings - for automatic control, as well as the manual control - using a joystick, can be used.
Page 18 Capabilities, functionalities and applications | INSTRUCTION MANUAL joystick function very simple here. Reckeen MVP Control panel allows you to control multiple MVP-100 functions without having to use the control software on your computer. Both in the case of operators’ preferences and in many fields of application, it will undoubtedly be appreciated by the users due to the speed and ease of use.
Page 19: Menu Control
INSTRUCTION MANUAL | Menu Control Menu Control...
Page 20 Menu Control | INSTRUCTION MANUAL Press the MENU button to enter the System Configuration Menu. Press the UP, DOWN, LEFT, and RIGHT arrow buttons to navigate the menu options and to change values. Use the OK button to save and confirm any setting that has been amended.
Page 21: Inputs
INSTRUCTION MANUAL | Inputs Inputs...
Page 22 Inputs | INSTRUCTION MANUAL MVP-100 is a small and very compact solution with supporting up to two independent channels A and B. Position Position Animation Animation 4xAUX 4xAUX output output Multiviewer Input A Input B PGM output The user has a possibility to connect the signal in 4 ways to each channel. After pressing the MENU button on the Reckeen MVP 100 KEY, on the Multiviewer the menu will be displayed.
Page 23 INSTRUCTION MANUAL | Inputs After opening this option, the user will check the input format and the genlock status. For the Input A or B, you can choose one the options.
Page 24 Inputs | INSTRUCTION MANUAL HDMI HDMI port in standard 2.0 mostly used in cameras which can transport up to 3840 x 2160 resolution in frame rate 60 progressive. SDI 3G/6G/12G signal The second way is to use one coaxial cable for two inputs with BNC connector as SDI digital interface standard with supporting 3G/6G/12G signal.
Page 25 INSTRUCTION MANUAL | Inputs SDI 3G One of the possibilities is to connect 4 independent SDI signals at a resolution of up to 3G for each channel. At this time, it will not be possible to set virtual frames for each signal from the camera.Each full screen image will be available by pressing the button available on the MVP control panel.
Page 26 Inputs | INSTRUCTION MANUAL CLONE Clone is a function that gives you the ability to set exactly the same content on your channel as on the second input channel. For example, if you connect the 4k signal to channel A and set clone function on channel B, you can expect not only 4 Virtual frames but up to 8 with full animations.
Page 27: Genlock
INSTRUCTION MANUAL | GenLock GenLock...
Page 28 GenLock | INSTRUCTION MANUAL GenLock The user can turn on or off genlock function which allows the specification of the reference signal for output channels synchronization. GenLock termination The user can turn on or off genlock 75 Ohm termination.
Page 29: Input Signal Detection
INSTRUCTION MANUAL | Input signal detection Input signal detection...
Page 30 Input signal detection | INSTRUCTION MANUAL The device can detect the signal and display the right color of the diode on the front panel of the device. There are two types of diode lighting: pulse means that this connector is selected in the user interface and might be used as an input and stable means that the signal is detected while connecting to the device.
Page 31: Program And Preview Rows
INSTRUCTION MANUAL | Program and Preview rows Program and Preview rows...
Page 32 Program and Preview rows | INSTRUCTION MANUAL The Program row of buttons is the active channel, this is the live output. The active channel will appear as the Program Output. You can switch or CUT from one video source to another directly on the Program row.
Page 33: Transitions
INSTRUCTION MANUAL | Transitions Transitions...
Page 34 Transitions | INSTRUCTION MANUAL The user can make a transition from the current program source to the selected preview source. There are two modes of transition possible. MIX as a crossFade transition and FX make a transition depending on the selected option in menu. In the transition/configuration menu, the user can control the RATE, and thus determine the duration of the MIX and FTB effect.
Page 35 INSTRUCTION MANUAL | Transitions In the menu “orientation” the user select the type of Wipe transition. A wipe is a type of transition where one shot replaces another by travelling from one side of the frame to another. Horizontal when the frame goes from the left to right.
Page 36 Transitions | INSTRUCTION MANUAL The last option RATE determine the duration of the FX effect.
Page 37: Virtual Video Aux Outputs
INSTRUCTION MANUAL | Virtual video AUX outputs Virtual video AUX outputs...
Page 38 Virtual video AUX outputs | INSTRUCTION MANUAL You can define 4 AUX OUTPUTS windows on every UHD source signal. On the back panel of the MVP device, the user can find 8 SDI connectors signed to virtual frames. For the 1st input channel, the resolution (size before scaler) of a window 1 can be up to 3860x2160, while 2, 3 and 4 support resolution of windows up to 1920x1080 pixels.
Page 39 INSTRUCTION MANUAL | Virtual video AUX outputs PTZ JOYSTICK CONTROL Note: Before attempting to use the joystick to PAN, TILT or ZOOM a selected window, first make sure the LOCK button is not enabled. If the LOCK button LED is ON, the joystick is locked; press the LOCK button to unlock the joystick.
Page 40: Animation
Animation | INSTRUCTION MANUAL Animation...
Page 41 INSTRUCTION MANUAL | Animation Every window can be animated. Motion is made by defining the Start and End positions, along with their transition mode (single, loop, ping-pong) During the motion, every window can change its size. This feature simulates the digital zoom. ANIMATION CONTROL 8 buttons to control animation on every virtual source.
Page 42 Animation | INSTRUCTION MANUAL You will see the motion as a movement of the virtual camera window. Press the MENU button and press the left arrow to navigate through the menu options until the “Animation triggers” option is selected with a blue frame. Press OK to go to the next options.
Page 43: Output Video Format
INSTRUCTION MANUAL | Output video format Output video format...
Page 44 Output video format | INSTRUCTION MANUAL The program output is provided on the rear panel of the Reckeen MVP device as an HDMI connector. The user can choose the video format in the menu for Program channel (HDMI output) and 8 SDI AUX outputs.
Page 45: Audio
INSTRUCTION MANUAL | Audio Audio...
Page 46 Audio | INSTRUCTION MANUAL After pressing the MENU button on the Reckeen MVP 100 KEY the user can navigate to Audio settings. There are two options presented in the picture below. The “MIX” (mixing) function gives users the opportunity to hear the sound from booth inputs A and B on the program output.
Page 47: Sdi 3G Output
INSTRUCTION MANUAL | SDI 3G output SDI 3G output...
Page 48 SDI 3G output | INSTRUCTION MANUAL In case of selection in menu the output format as 1080p50,59 or 60 the user can define for 8 SDI outputs the signal type. There are two option 3 Gb/s level A or B.
Page 49: Frame Limit
INSTRUCTION MANUAL | Frame Limit Frame Limit...
Page 50 Frame Limit | INSTRUCTION MANUAL For each input, the user can select a virtual window. Using the joystick can set the position and reduce the size. The option called “frame limit” gives the option of reducing the window to the selected value. It is a function that prevents unexpected reduction of the resolution.
Page 51: Output Assignment
INSTRUCTION MANUAL | Output assignment Output assignment...
Page 52 Output assignment | INSTRUCTION MANUAL The MVP 100 device has 8 SDI connectors that display 8 virtual frames in the default state. Thanks to the “assignment of output” option, the user can change the content sent to the SDI output. Each of them can display each virtual frame or be dependent on the selection of the frame in the program or preview line.
Page 53 INSTRUCTION MANUAL | Output assignment MVP 100 interface gives a 3 ways of preview for the operator. The main window is split up on two section. Top section depends on the selected function, and bottom section which represents each view from the AUX output.
Page 54 Output assignment | INSTRUCTION MANUAL The MV2 function is slightly different, because the top left view determines which frame is currently selected in the preview line. Depending on the selected frame, the view shows the full input 1 or 2 screen. Frames 1-4 belong to input 1 and 5-8 belong to input 2.
Page 55 INSTRUCTION MANUAL | Output assignment The last multi viewer will be displayed after pressing MV1 button on the keyboard MVP. This type of view was created to facilitate the work of animation setting. Pressing one of the buttons located in preview section user choose one frame which is signed to Input A or B.
Page 56: Store/Funt
Rescue mode | INSTRUCTION MANUAL Rescue mode...
Page 57 INSTRUCTION MANUAL | Rescue mode Rescue mode is a service function that the user should not turn on. You can enter rescue mode by switch POWER button more than 10 sec. during power off sequence. If you accidentally turned on the rescue mode, switch to the normal operation have to be done in the same way.
Page 58: Rescue Mode
Rescue mode | INSTRUCTION MANUAL Rescue mode...
Page 59 INSTRUCTION MANUAL | Rescue mode Rescue mode is a service function that the user should not turn on. You can enter rescue mode by switch POWER button more than 10 sec. during power off sequence. If you accidentally turned on the rescue mode, switch to the normal operation have to be done in the same way.
Page 60: Mvp-100 Firmware Update Procedure
MVP-100 firmware update procedure | INSTRUCTION MANUAL MVP-100 firmware update procedure...
Page 61 INSTRUCTION MANUAL | MVP-100 firmware update procedure Connections 1. Connect MVP-100 to Ethernet network (1). Picture below. MVP-100 by default use DHCP server to assign its IP address. In case of no DHCP set default IP: 192.168.1.10 2. Connect MVP Control panel (2) and switch its power ON – upgrade procedure will change its firmware as well.
Page 62 MVP-100 firmware update procedure | INSTRUCTION MANUAL Press Update button (1). Picture below. 1. See the app status (2). Update info also are displayed on MV output. 1 Press Update button 2 See the app status Update finished . Picture below...
Page 63: Back Panel View
INSTRUCTION MANUAL | Back panel view Back panel view...
Page 64 Back panel view | INSTRUCTION MANUAL Display port input 1 - not active HDMI port input 1 Tally out GPIO port RS-232 for MVPkey100 Key source inputs HDMI Multiviewer output RS-422 control interface - not used HDMI port input 2 Grounding point DSK source inputs Power supply...
Page 65 GPIO pins can be used as inputs. Thanks to GPIO Interface it is possible to broadenMVP-100 device’s functionalities resulting from cooperation with external devices. An external device can activate a trigger in MVP-100, that is windows’ motion control (a virtual camera). You can program up to 8 windows, each with a different type of motion (single, loop, ping-pong, zoom etc.).
Page 66 Back panel view | INSTRUCTION MANUAL CON_GPIn 330R 5-12V Trigger_N P6SMB12 IS355 LED P1 LED N1 LED P2 LED N2 LED P3 LED N3 LED P4 LED N4 LED P1 LED RED TALLY LED N1 LED P8 LED N8 LED RED LED P8 LED N8 LED N7...
Page 67 INSTRUCTION MANUAL | Back panel view RS422 GENLOCK Genlock allows the specification of the reference signal for output channels synchronization. ETHERNET AUDIOLINK...
Page 68 Back panel view | INSTRUCTION MANUAL POWER GROUNDING...
Page 69: Control Panel Mvpkey-100
USER GUIDE | Control Panel MVPKey-100 Control Panel MVPKey-100...
Page 70 Reckeen MVPKey100 Control Panel – Precise control over real-time video operations for professional use. With Reckeen MVPKey 100, you can have control over multiple functions of the Reckeen MVP100. We have designed it to be operators’ working environment friendly, functional, modern and reliable, but also to be affordable.
Page 71 R S 2 3 2 - t o calibration functions - voltage. connect to the Reckeen these functions allow Studio system. precise calibration of b o t h h a n d l e s a t a n y time.
Page 72 Control Panel MVPKey-100 | INSTRUCTION MANUAL CAM 1 CAM 1 FULL HD CAM 2 HDMI or SDI 12G SDI 3G FULL HD CAM 2 CAM 3 SDI 3G FULL HD HDMI or SDI 12G CAM 4 SDI 3G FULL HD VIDEO STREAMER SDI 3G CAM 5...
Page 73: How To Connect Keyboard Mvpkey-100 To The Reckeen System
USER GUIDE | How to connect Keyboard MVPKey-100 to the Reckeen system How to connect Keyboard MVPKey-100 to the Reckeen system...
Page 74 How to connect Keyboard MVPKey-100 to the Reckeen system | INSTRUCTION MANUAL The full set of configurations includes: • MVPKey100 Keyboard • RS 232 communication cable with DB9 connector. • Power supply unit and adapterst Connect the keyboard to the system using RS 232 communication cable with DB9 connector. Plug the end of the cable to the MVP100 device.
Page 75 INSTRUCTION MANUAL | How to connect Keyboard MVPKey-100 to the Reckeen system Next bolt the locking screw and connect the power supply unit to the electrical outlet. Picture below. To turn the device on, press the power button. Picture below.
Page 76: Calibration Of Joystick And T-Bar
Calibration of Joystick and T-Bar| USER GUIDE Calibration of Joystick and T-Bar...
Page 77 USER GUIDE | Calibration of Joystick and T-Bar Simultaneously press the following buttons: SINGLE , PING + and and LOCK like the picture below. 5 buttons will light up signaling execution of a test for example, communication F1. Picture below. The second test is JOYSTICK’s calibration.Move it to the right and to the left to its extreme positions.
Page 78 Calibration of Joystick and T-Bar | USER GUIDE Now let’s move the joystick up and down to its extreme positions.When you complete that, the F3 LED will light up in white. Picture below. F4 is the JOYSTICK’s knob calibration.We turn it several times to the right and to the left to the extreme positions.When you complete that, the F4 LED will light up in white.
Page 79 USER GUIDE | Calibration of Joystick and T-Bar F5 test is the T-BAR’s calibration. Move the T-BAR to its extreme positions. Picture below. After several movements, all the LEDs will go out. This way, the keyboard has been calibrated and has returned to its normal operation mode.
Page 80: Test Of Adjusting The Brightness Of The Keyboard's Backlight
Test of adjusting the brightness of the keyboard’s backlight | USER GUIDE Test of adjusting the brightness of the keyboard’s backlight...
Page 81 USER GUIDE | Test of adjusting the brightness of the keyboard’s backlight Simultaneously press the following buttons: SINGLE, LOOP and LOCK like picture bellow. The keyboard shows the current brightness of the keys. Pressing TAKE key several times decreases the backlight’s brightness.
Page 82: Mvpkey-100 Dimensions
MVPKey-100 dimensions | USER GUIDE MVPKey-100 dimensions...
Page 83 USER GUIDE | MVPKey-100 dimensions All measurements in millimetres (mm)
Page 84: Mvpkey-100 Specification
MVPKey-100 specification | USER GUIDE MVPKey-100 specification...
Page 85 USER GUIDE | MVPKey-100 specification MVPKey-100 Specifications Communication Interface RS-232 Baud Rate 38400 Power DC12V Power Consumption Working Temperature 0 °C ~ +40 °C Storage Temperature -20 °C ~ +60 °C Relative Humidity ≤ 90% (non-condensation) Net Weight 2,850 kg RS-232 Transmission Cable Accessories DC In Power Adaptor...
Page 86: Mvp-100 Specification
MVP-100 specification | INSTRUCTION MANUAL MVP-100 specification...
Page 87 INSTRUCTION MANUAL | MVP-100 specification 31.75...
Page 88 MVP-100 specification | INSTRUCTION MANUAL Inputs • Input A • SDI • QUAD SDI • HDMI • 4xSDI • CLONE • Input B • SDI • QUAD SDI • HDMI • 4xSDI • CLONE • Genlock • On • Off •...
Page 89 INSTRUCTION MANUAL | MVP-100 specification • OUTPUT ASSIGNMENT • SDI Out 1-8 • IN 1-8, PGM, PRV Transitions • MIX RATEI • VALUE 0 - 5 • FTB RATEI • VALUE 0.25 - 5 • WIPE FXI • ORIENTATION • HORIZONTAL •...
Page 90 MVP-100 specification | INSTRUCTION MANUAL • FW • GENLOCK • FPGA MVP-100 Accessory List Item MVP-100 Unit DC 12V power adaptor USB stick with user manual Power cable Reckeen holder T4K-K1U-03-01 Fastening screw for the holder M4x6 Imbus, black finish...
Page 91 INSTRUCTION MANUAL | MVP-100 specification...
Page 92 © Copyright 2018 Reckeen. All rights reserved. ‘Reckeen’ is registered trademark. All other company and product names may be trade marks of their respective companies with which they are associated.
