Summary of Contents for Moticon OpenGo
- Page 1 Instructions OPENGO SENSOR INSOLE...
- Page 2 Warnings WARNING See the detailed product information and tutorial videos in the support section of the moticon homepage www.moticon.com/support Do not use a sharp object to remove user-replaceable coin cells. Contact your local waste disposal department to properly recycle the coin cells.
- Page 3 Store the sensor insole only without coin cells. The coin cell compartment must face down when inserting a sensor insole into a shoe. The sensor insole does not need maintenance and must only be cleaned as described here www.moticon.com/support...
- Page 4 Warnings NOTICE ON RISKS ON HEALTH The OpenGo sensor insole is no orthotic. In case an orthotic is used, consult your doctor if it can be replaced by a OpenGo sensor insole. Only wear a left and a right sensor insole in order to avoid asymetric gait.
- Page 5 Do not wear OpenGo sensor insoles with open foot ulcers or wounds. Do not wear OpenGo sensor insoles for driving cars or climbing ladders. Do not wear OpenGo sensor insoles if strong foot sweat appears and do not...
- Page 6 OpenGo sensor insole overview The OpenGo sensor insole is a fully integrated sensor insole. It is completely wireless wireless and hence does not interfere the wearer‘s motion. The sensor insole measures the plantar precise pressure distribution, total loads and the acceleration of the foot.
-
Page 7: Specifications
Specifications Coin cell type User-replaceable PD2032 (rechargeable), 3.7 volts Coin cell life Up to 29 hours, depending on operation mode Operating From 10°C to 40°C temperature range Radio frequency/ 2.4 GHz ANT wireless protocol communications protocol Water resistance No, cleaning with liquid sanitizer... -
Page 8: Power Supply
Power supply Coin cell charger Coin cells OpenGo sensor insoles should exclusively be operated with rechargeable coin cells ! Primary coin cells (batteries) may cause mal- function due to a much faster voltage drop ! Coin cell Coin cell charger... - Page 10 Installing the coin cell Remove the lid by lifting the lid nose with Take the sensor insole upside down. your thumbnail.
- Page 11 Installing the coin cell Prepare the coin cell with the positive side Slide the coin cell under the positive battery facing up in the displayed insole orientation. contact flap.
- Page 12 Installing the coin cell Place the lid with the nose inwards and Snap in the lid by pressing on it with your centrical on the coin cell compartment. thumb.
- Page 14 Pairing the OpenGo sensor insole with a PC Before you can connect your OpenGo sensor insoles wirelessly to your PC and view data in the analysis software Beaker, you must pair the sensor insoles with your PC.
- Page 15 Pairing the OpenGo sensor insole with a PC Put the sensor insole next to the ANT stick, Shake the sensor insole to wake it up. upside down to activate the pairing mode.
- Page 16 Pairing the OpenGo sensor insole with a PC Activate the pairing function in the Type in a name for your sensor insoles Beaker PC software. in the Beaker PC software. After pairing has succeeded, put the sensor insole back upside up.
- Page 17 Installing the sensor insole The intended use of the OpenGo sensor insole is inshoe measurement. Many different shoe types may be used. NOTICE Do not use the sensor insoles for measurements outside a shoe.
- Page 18 Installing the sensor insole Take out the original insole and slide in Put your hand under the sensor insole the front part of the sensor insole. for inserting it entirely into the shoe.
- Page 19 Installing the sensor insole Push the heel part of the sensor insole For taking the sensor insole out of a shoe, carefully down into the shoe. grab its underneath and pull it carefully out. NOTICE Make sure you do not bend or tort the middle part of the sensor insole while putting it in or taking it out from a shoe.
- Page 20 Misuse of the OpenGo sensor insoles CAUTION CAUTION CAUTION CAUTION Do not tort! Do not cut the Do not stitch! Do not bend Atypical tortion sensor insoles! Sharp elements midfoot! destroys the This will damage cause severe Atypical bending electronics.
-
Page 21: Fcc Compliance
FCC compliance This device complies with part 15 of the This equipment has been tested and found to FCC Rules. Operation is subject to the comply with the limits for a Class B digital following two conditions: device, pursuant to part 15 of the FCC rules. 1. - Page 22 FCC compliance However, there is no guarantee that by one of the following measures: • Reorient or relocate the receiving antenna. interference will not occur in a particular • Increase the separation between the installation. If this equipment does cause harmful interference to radio or equipment and the receiver.
- Page 23 FCC compliance Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
- Page 24 © 2014 Moticon GmbH Moticon GmbH Machtlfinger Str. 21, 81379 Munich, Germany Date: Sept. 17th, 2014 Document version: 01.00.02...
