Summary of Contents for Cub VS-60U024 Series
- Page 1 CUB SENSOR AID DUO TPMS TOOL For VS-60U024 / VS-60U029 Series Brand Name : Cub Model Name : VS60U029 Product Name : Sensor AID DUO TPMS TOOL...
-
Page 2: Table Of Contents
Table of contents Specification Part list 1. Sensor AID DUO TPMS TOOL Introduction………………………. 1.1 Appearance 1.2 Keypad Summary 2. Function………………………………………………………………..…. 2.1 MAKER SELECTION 2.1.1 DIAGNOSE 2.1.2 PROGRAMMING 2.1.3 CHECK UNI-SENSOR 2.1.4 RELEARN INFO 2.1.5 OBD II OPTIONS 2.1.6 TREAD DEPTH 2.2 LAST VEHICLE 2.3 SETTINGS 2.4 UPDATE... -
Page 3: Specification
Specification: Item Specification Operating Frequency 125kHz,2.4Ghz Power Input / Current 5V/2A Operating Current 380 mA(Max 600 mA) 0 ~ 40 ℃ (32 - 104℉) Operating Temperature -20 ~ 60 ℃ (-4 - 140℉) Storage temperature Operating Humidity 20-90% Storage Humidity 20-90% Size(rubber) 210*102*62mm... -
Page 4: Sensor Aid Duo Tpms Tool Introduction
1. Sensor AID DUO TPMS TOOL Introduction Sensor AID DUO TPMS TOOL, henceforth called Sensor AID DUO, is designed to promote CUB Uni-Sensor in the whole world. Sensor AID DUO TOOL can diagnose and interact with tire pressure sensor through wireless (radio frequency) communication to: •... -
Page 5: Function
IDtoPC / updating LED for Camera AF Camera 2. Function Press and hold the power key for 3 seconds to power on the device During power on, The Now the device is at the device display the CUB MAIN MENU logo... -
Page 6: Maker Selection
2.1 MAKER SELECTION NOTE: Definition OK key : Select / Validate / Process Arrow Key : Use arrow keys to browse maker. MAIN MENU: MAKER selection: MODEL selection: Use the arrow key Use the arrow key Use the arrow key to browse function, press to browse automakers, to browse model, press... - Page 7 The picture above is an Use the arrow key to select Sensor AID will now activate example of sensor data diagnose “SINGLE the sensor. Sensor response communication result SENSOR” or “MULTIPLE time may vary depending on SENSORS” and press the sensor type and brand.
-
Page 8: Programming
TREAD DEPTH: To process TREAD DEPTH function (See page xxx). SAVE: To save the existing data to SAVED VEHICLES menu (will be enabled when there is existing data, see page XX). 2.1.2 PROGRAMMING See step 2.1.1, then use arrow key to browse. Press “OK”... - Page 9 2.1.2.2 AUTO DUPLICATE See step 2.1.2, then use An instruction message arrow key to browse. will be displayed during 4 Press “OK” key to enter. seconds, then will automatically disappear DIAGNOSE: If there is no existing data, diagnose all sensors that you wish to duplicate at the beginning DUPLICATE: Will be enabled when at least one sensor is diagnosed.
- Page 10 NOTE Duplicate and Programming functions will only work with CUB’s Sensor-AID and Uni-sensor. Duplicate: To duplicate a manual ID to a Uni-Sensor (will be enabled after keying in first character). HEX to DEC: To change between HEX and DEC ID formats (enabled at the beginning, becomes disabled once first character is keyed in).
-
Page 11: Check Uni-Sensor
2.1.2.5 L <-> R See step 2.1.2, then use arrow key to browse. Press “OK” key to enter. Function immediately Once source ID is The above message starts scanning for a detected, select side to confirms the successful source sensor whose program to side programming. -
Page 12: Relearn Info
Function immediately Once detected, the See step 2.1.1 then use starts scanning for a screen above is arrow key to browse. displayed. Press “OK” Press “OK” key to enter. Uni-Sensor. key to scan the next sensor, or “ESC” to go back 2.1.4 RELEARN INFO. - Page 13 2.1.5.1 READ ID Press “OK” key to enter. Press “OK” key to enter. 2.1.5.2 WRITE ID Press “OK” key to enter. Press “OK” key to enter. 2.1.5.3 UNLOCK ECU for some certain vehicles( Toyota )
-
Page 14: Tread Depth
2.1.5.4 CLEAR DTC 2.1.5.5 BACK Back to MAKER SELECTION 2.1.6 TREAD DEPTH Alarm: Do not use the Tread Depth function on anyone’s eyes, which can cause visual impairment. You may retake a Place tool with tread See step 2.1.1 then use measurement at any depth device in line with arrow key to browse. -
Page 15: Settings
( LEXUS CT 06/2014-12/2016) 2.3 SETTINGS See step 2.1,then use arrow key to browse. Press “OK” key to enter. 2.3.1 PRESSURE UNIT Use the arrow keys Press the “OK” key to to browse units, press the select. “OK” key to select. 2.3.2 TEMPERATURE UNIT Use the arrow keys Press the “OK”... - Page 16 2.3.3 ID FORMAT Press the “OK” key to Use the arrow keys select. to browse formats, press the “OK” key to select. 2.3.4 AUTO OFF Use the arrow keys Press the “OK” key to to browse options, press select. the “OK” key to select. 2.3.5 LANGUAGE Press the “OK”...
- Page 17 2.3.7 MUTE Use the arrow keys Press the “OK” key to Press the “OK” key to to browse options, press select. select. the “OK” key to select. 2.3.8 VOLUME Press the “OK” key to Use the arrow keys to browse volume levels, select.
-
Page 18: Update
2.3.11 BT OBD II PAIRING Connect the Cub BLE OBD The pairing process begins Wait for the process to II Module to the OBD port of immediately; it may take complete. the vehicle, then turn ACC several seconds. on. In the Sensor AID,... - Page 19 2.4.1 WIRE UPDATE by PC software Enter 2.Extract the file [Cub] TPMS Tool & OBD-II Module Update Platform v1.7 (beta2)(lite).zip 3.Execute Cub Updater.exe 4. Connect Mico usb to TOOL and PC usb port. Appear connect 5. Click “Download” for auto update 5.1 SN is invalid.
- Page 20 5.2 SN is valid. Download file from server Transmit file to tool Transmit completed. Disconnect usb cable. Wait for tool update. 2.4.2 BT OBD II module UPDATE Note: Before you do the OBDII update, please plug OBD II module into an OBD II connector of any vehicle in order to have the power source for the OBDII module.
-
Page 21: Saved Vehicles
Update Complete 2.5 SAVED VEHICLES DEL ALL DEL OLDEST DEL SELECTED See step 2.1, then use Use arrow keys to select arrow key to browse. saved vehicle, press “OK” Press “OK” key to enter. key to enter. There are three options underneath: DEL ALL –... -
Page 22: Warranty
CUB autoparts will repair or replace the product. Product will not be replaced or repaired if damaged from misuse or incorrect application. To obtain repair or replacement of the product under warranty, contact local distributor. - Page 23 INTERFERENCE All wireless devices may be susceptible to interference, which could affect performance. CONNECTING TO OTHER DEVICES When connecting to any other device, read its user guide for detailed safety instructions. Do not connect incompatible products. QUALIFIED SERVICE Only qualified personnel may install or repair this device. RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
- Page 24 15.21 You are cautioned that changes or modifications not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment. 15.105(b) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules.
- Page 25 CUB ELECPARTS INC No.6, Lane 546, Sec. 6, Chang Lu Rd., Fuhsin Hsiang,Chang Hua County, Taiwan http://www.cubautoparts.com To obtain repair or replacement of the product under warranty, or general inquiries, assistance, please refer to CUB information card to contact our local distributor.
