Conventions
To help you understand the information in this guide, a consistent set of documentation
conventions are used to represent certain material.
Used in this
The following table describes the typographic conventions used in this guide to help you
Guide
locate and interpret information.
Convention
Italic text
Courier font
"Text enclosed in
quotes".
Picture of key from
front panel
Home
Arm
Reset
iv
Description
Indicates a parameter that you can set.
E
XAMPLE
DiaLog accepts a return call as an acknowledgement of all
alarms if you enable the Call In Acknowledge feature. The call
must come during the 30-second Between Calls Delay, or
DiaLog calls the next number on the list.
Indicates messages shown on the DiaLog display or information
printed on reports.
E
XAMPLE
If parameters for channel 7 were set up as follows, then this
message appears on the pager's display:
NORTHWEST FACILITY-7 NO 2 TANK LEVEL HI 101.5
GALS
Indicates messages that DiaLog speaks.
E
XAMPLE
The power on diagnostics take about 45 seconds to complete,
followed by the voice announcing:
"This is DiaLog Elite. Program mode activated. System is
armed. System ready. Enter selection."
These keys are used when a special key on the front panel must
be pressed to accomplish a task.
E
XAMPLE
2
1 # Ack
, , , ,
Prog Run Enter
Clear
0 5
Disarm
, , ,
Status SpkrPh
Bksp
Press
Version 1.2
:
:
:
:
2
to enter RUN mode.
