Telephone Interconnect
3033
H F R A D I O C O M M U N I C A T I O N S
U S E R G U I D E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3033 and is the answer not in the manual?

Questions and answers

Summary of Contents for Codan 3033

  • Page 1 Telephone Interconnect 3033 H F R A D I O C O M M U N I C A T I O N S U S E R G U I D E...
  • Page 2 No part of this guide may be reproduced, transcribed, translated into any language or transmitted in any form whatsoever without the prior written consent of Codan Limited. © Copyright 2008 Codan Limited. Codan part number 15-04156-EN Issue 1, May 2008 ®...

  • Page 3: Table Of Contents

    ..........23 Installing the 3033 Telephone Interconnect ......24 Required equipment and information .
  • Page 4 Setting volume levels......... . 85 Telephone Interconnect 3033 User Guide...
  • Page 5 Networks and channels ........101 Self address of the Codan HF transceiver......102 Address List entries in the transceiver connected to the telephone interconnect.
  • Page 6 About this issue ..........154 Index Telephone Interconnect 3033 User Guide...
  • Page 7 List of figures Figure 1: Basic layout for a Codan telephone station ... 7 Figure 2: Trunked layout for Codan telephone stations..9 Figure 3: The front panel of the 3033 Telephone Interconnect .
  • Page 8 List of figures This page has been left blank intentionally. Telephone Interconnect 3033 User Guide...
  • Page 9 ........147 Telephone Interconnect 3033 User Guide...
  • Page 10 List of tables This page has been left blank intentionally. viii Telephone Interconnect 3033 User Guide...

  • Page 11: Overview Of This Guide

    This guide assumes that HF users are familiar with how to make a Phone call from a Codan HF transceiver (see the Getting Started Guide provided with the equipment), and that telephone users understand how to follow voice prompts.
  • Page 12 HF and telephone users, and how to manually connect calls at the 3033 Section 4 Managing the telephone station—describes how to tailor the setup of your 3033 to meet your specific requirements Section 5 Advanced setup of the Codan HF transceiver—...
  • Page 13 HF transceivers that do not have the Phone call option installed Appendix G Compliance—provides compliance information and safety notices for your 3033 Appendix H Definitions—explains the terms and abbreviations used in this guide Telephone Interconnect 3033 User Guide...
  • Page 14 Introduction This page has been left blank intentionally. Telephone Interconnect 3033 User Guide...
  • Page 15 Overview This section contains the following topics: General (6) Typical layouts (7) Interfaces (10) Call logs (17) Power supply (17) Compatibility (18) Operating modes (19) Telephone Interconnect 3033 User Guide...

  • Page 16: Overview

    Codan HF transceiver at the 3033 telephone station. A PC is required to access the web interface for setting up the 3033 and accessing the call log. It may be connected to the 3033 using either of the following methods: •...

  • Page 17: Typical Layouts

    Overview Typical layouts The 3033 Telephone Interconnect is used in a fixed Codan 3033 telephone station. This station may be either controlled directly, or via a remote control system. For information on controlling any Codan HF NOTE transceiver remotely, contact your Codan representative.
  • Page 18 In the trunked layout, two or more basic layouts are connected via an HF link. This enables two or more separate telephone communication networks, which are not connected by any standard telecommunications infrastructure, to communicate via an HF link. Telephone Interconnect 3033 User Guide...

  • Page 19: Figure 2: Trunked Layout For Codan Telephone Stations

    Overview Figure 2: Trunked layout for Codan telephone stations Remote HF Fixed telephone station transceiver Mobile 3033 Codan HF DTMF-capable Telephone transceiver PSTN Interconnect (required for (required for manual mode Land line access to only) web interface) Telephone communication network...

  • Page 20: Interfaces

    The LCD is a 2-line, 16-character display. The top line shows the operating mode of the 3033 (automatic, manual, off line). The bottom line shows the operating status of the 3033 (on hook, off hook). When the 3033 is OFFLINE, the firmware version of the unit is shown in the bottom line.

  • Page 21: Table 1: Buttons On The Front Panel

    Transceiver Selects the transceiver audio monitor. Phone Selects the telephone audio monitor. LEDs There are five LEDs on the front panel of the 3033 Telephone Interconnect. Table 2: LEDs on the front panel Function Connect Shows that a call between HF and PSTN is currently connected.

  • Page 22: Rear Panel

    Overview Knob There is a Volume knob on the front panel of the 3033 Telephone Interconnect. This is used to adjust the volume of the signal from the speaker in the Monitor frame. Rear panel The rear panel has eight connectors and an earth terminal. For...

  • Page 23: Web Interface

    Table 3: Connectors/ports on the rear panel Connector/port Function Ethernet Connects to a PC for setting up the 3033 via the web interface. For information on specific DHCP and proxy requirements see page 58, Setting up access to the web interface.

  • Page 24: Figure 5: The Web Interface

    You must select the base- level navigation option to see the corresponding page. Click Exit... to return to the previous level. The right panel of the web interface is the area in which each setup page is displayed. Telephone Interconnect 3033 User Guide...

  • Page 25: Figure 6: Basic Menu In The Web Interface

    Telephone Interconnect Time Telephone Call Log Transceiver Call Log Telephone Users HF Users... Call Groups Access Rights Speed Dial... Speed Dial 00..19 Speed Dial 20..39 Speed Dial 40..59 Speed Dial 60..79 Speed Dial 80..99 Advanced... Telephone Interconnect 3033 User Guide...

  • Page 26: Figure 7: Advanced Menu In The Web Interface

    Voice Prompt Languages Telephone Line Configuration... Telephone Line Configuration Files Manual Configuration... Telephone Line Configuration—Country and Timeouts Telephone Line Configuration—Dial Tone Telephone Line Configuration—Ringback Tone Telephone Line Configuration—Busy Tone Factory Defaults Firmware Upgrade Web Interface Passwords Telephone Interconnect 3033 User Guide...

  • Page 27: Call Logs

    Transceiver call log The transceiver call log records details of all calls made to the 3033 by an HF user. It includes the date and time of the call, the address of the calling transceiver, the requested telephone number, the dialled telephone number, the status of the call, and the duration of the call.

  • Page 28: Compatibility

    JPS RTU–292, you can set up the 3033 Telephone Interconnect to operate in an RTU–292 Compatibility Mode. When this mode is set, the 3033 uses a set of voice prompts that mimic the functionality of the RTU–292 Radio/Telephone Interface. The 3033 also accepts RTU–292 commands directly.

  • Page 29: Operating Modes

    Automatic When the automatic operating mode is selected using the Mode button on the front panel of the 3033, the unit does not have to be manned. It answers telephone calls from the PSTN and patches them, under instructions from the telephone user, to the HF user.
  • Page 30 Overview This page has been left blank intentionally. Telephone Interconnect 3033 User Guide...

  • Page 31: Installation

    Installation This section contains the following topics: Unpacking the equipment (22) Setting up the RS232 [15way] Mode/Speed for the Codan HF transceiver (23) Installing the 3033 Telephone Interconnect (24) Performing a functional test on the installation (33) Performing an operational test on the installation (34)

  • Page 32: Unpacking The Equipment

    Make sure that all equipment itemised on the packing list is present before you start installing the 3033 into your telephone station. Open the carton and examine the contents for any signs of damage.

  • Page 33: Setting Up The Rs232 [15Way] Mode/Speed For The Codan Hf Transceiver

    You must log in as administrator to access the NOTE Control List. For help see the documentation provided with your Codan HF transceiver. To set the RS232 [15way] Mode/Speed: Switch on the transceiver. Access the Control List in the transceiver.

  • Page 34: Installing The 3033 Telephone Interconnect

    Installation Installing the 3033 Telephone Interconnect These installation instructions assume the following: • The Codan HF transceiver at the telephone station has an appropriate power supply and antenna system connected, and all modules within the transceiver system are functioning correctly.

  • Page 35: Installing The Telephone Interconnect

    Codan HF transceiver that has system capability, that is, a 2010 RF Unit with a 2030 Junction Box, a 2012 RF Unit, or a 2110 Manpack Transceiver with an interface adaptor. The 3033 is 3 RU high, and is designed to be mounted in a ″ rack.

  • Page 36: Figure 8: 3033 Telephone Interconnect With A 2010 Rf Unit

    Installation Figure 8: 3033 Telephone Interconnect with a 2010 RF Unit, 2030 Junction Box and handset Speaker 2030 Junction 2020 Handset Antenna earth strap 08-04515 CIB 08-05610-006 2010 RF Unit earth braid 05-06767 3020 Transceiver Supply earth strap 08-04515 3033 Telephone Interconnect...

  • Page 37: Figure 9: 3033 Telephone Interconnect With A 2012 Rf Unit

    Installation Figure 9: 3033 Telephone Interconnect with a 2012 RF Unit and handset Speaker 2020 Handset Antenna 2012 RF Unit earth braid 05-06767 3020 Transceiver Supply earth strap 08-04515 3033 Telephone Interconnect crossover Ethernet cable 67-90800 (2 m) 67-90801 (10 m)

  • Page 38: Switching On The Telephone Interconnect

    3033 to read the values. The LCD on the 3033 is blank during its one-minute initialisation period.
  • Page 39 Installation If you intend to use the 3033 in manual mode, the station address of the 3033 is not used. HF calls are made to the Codan HF transceiver, then manually connected via the 3033 to an established telephone call. If these HF calls are Selective calls, then the Codan HF transceiver requires a self address.
  • Page 40 HF transceiver may PTT and remain in the transmit state due to background noise. To set the VOX levels: Place a telephone call to the 3033, then follow the voice prompts to make a manual voice call to the Codan HF transceiver.
  • Page 41 Installation When the PTT LED is off, the 3033 is ready to receive from HF. Speak into the telephone, taking note of what happens to the PTT LED. Log into the web interface at admin or installer level (see page 63, Logging into the web interface).
  • Page 42 On Level and Off Level values in small steps. In the VOX Hang Time field, enter the length of time that you want the 3033 to hold the VOX after a voice signal ends. Click Save Configuration.

  • Page 43: Performing A Functional Test On The Installation

    To perform a functional test on the installation: Press Mode in the Status frame on the front panel of the 3033 until the LCD shows that the unit is in automatic mode. Press Transceiver in the Monitor frame on the front panel of the 3033.

  • Page 44: Performing An Operational Test On The Installation

    Installation Performing an operational test on the installation You should perform an operational test on the 3033 telephone station before leaving it unmanned in automatic mode. To perform an operational test: Check that the 3033 is in automatic mode. Make a telephone call to the 3033, enter the default...
  • Page 45 This section contains the following topics: General (36) Call activity at a remote HF transceiver (39) Call activity at a telephone within a PSTN (42) Connecting calls manually (47) Monitoring the telephone interconnect (49) Using the call logs (50) Telephone Interconnect 3033 User Guide...

  • Page 46: Making And Receiving Calls

    DTMF tones, transceiver commands, and specific timeouts. There are protocols for ending calls immediately, but if these are not used, the 3033 returns to the on-hook status after an inactivity timeout. When the 3033 is set up for manual operation, it does not answer calls made to it from HF or a telephone.
  • Page 47 3033 has the voice encryptor option enabled, you can use this feature over the HF part of the communication. When you make an HF call to the 3033, and security is enabled for your station address pattern (see...
  • Page 48 HF transceivers that have the frequency hopping option fitted. If the communication network of Codan HF transceivers associated with the 3033 has the frequency hopping option fitted, you can use this feature over the HF part of the communication. Frequency hopping is switched on by the telephone user via the call options menu.

  • Page 49: Call Activity At A Remote Hf Transceiver

    Call activity at a remote HF transceiver Making an HF call to a telephone Making a call to a telephone from a Codan HF transceiver is described in detail in the documentation provided with the transceiver. The transceiver can be programmed to make this call automatically, or you can enter information as prompted by the transceiver.
  • Page 50 Some PABX systems do not send a hangup signal to the far end of the line when the receiver is placed on the hook. In this case, the call remains active at the 3033 until the NOTE inactivity timeout passes. To avoid any...

  • Page 51: Receiving A Call

    Making and receiving calls Receiving a call When you receive a call at your HF transceiver from a 3033, the transceiver rings. To answer the call: Hold down PTT, then speak. If required, go secure with the required secure index and secure PIN (if supported).

  • Page 52: Call Activity At A Telephone Within A Pstn

    Call activity at a telephone within a PSTN Making a call to an HF transceiver Making a call from a telephone through the 3033 is managed via the voice prompt menu. Prepare yourself for the telephone call by viewing the voice...
  • Page 53 To make a call to a remote HF transceiver from a telephone: Dial the telephone number for the 3033. If the 3033 has been set up for multiple languages, listen to the welcome message, followed by the prompts for changing the language.
  • Page 54 To control frequency hopping, press 6. To hang up call, press 9. Press *9 to end the call. You can make another call via the 3033, if required. Hang up the telephone to disconnect from the 3033. Telephone Interconnect 3033 User Guide...

  • Page 55: Leaving A Call-Back Telephone Number At A Remote Hf Transceiver

    Calls In log see the documentation provided with the Codan HF transceiver. Receiving an HF call When you receive an HF call via a 3033 at your telephone, the telephone rings. On answering the telephone call, a voice prompt immediately informs you that you are receiving an HF transceiver call.
  • Page 56 Some PABX systems do not send a hangup signal to the far end of the line when the receiver is placed on the hook. In this case, the call remains active at the 3033 until the NOTE inactivity timeout passes. To avoid any...

  • Page 57: Connecting Calls Manually

    HF or the connected PSTN. If you are a telephone caller, you call the 3033, speak with an operator who manually makes an HF call, then patches your telephone call to the HF end.
  • Page 58 Place a call to the requested number using the telephone connected to the 3033. When both parties are on line, announce the connection, press Connect on the front panel of the 3033, then hang up the telephone. The Connect LED switches on.

  • Page 59: Monitoring The Telephone Interconnect

    Making and receiving calls Monitoring the telephone interconnect You can listen to the audio signals from the transceiver and/or the telephone using the speaker in the front panel of the 3033. You can select the audio from both sources at NOTE the same time.

  • Page 60: Using The Call Logs

    3033 from a telephone • transceiver call log: calls made to the 3033 from an HF transceiver You can view the logs in the web interface. If you want to process the logs further, you may download them to the connected PC as a CSV file.

  • Page 61: Using The Information In The Call Logs

    Time Date and time of the start of the call. Type A PSTN event is the initial call to the 3033 and access code entry. An event is any calling activity that occurs after the access code entry until the 3033 is disconnected from the PSTN.

  • Page 62: Table 6: Transceiver Call Log

    Automatically assigned identifier for the incoming HF call. Time Date and time of the start of the call. Type A transceiver event is a call to the 3033 from an HF transceiver. Calling Station The address of the calling HF transceiver.

  • Page 63: Managing The Telephone Station

    Setting up inactivity timeouts (82) Setting up speed dial telephone numbers (83) Setting volume levels (85) Setting up the telephone line (87) Backing up the setup (94) Upgrading firmware (95) Changing web interface passwords (96) Telephone Interconnect 3033 User Guide...

  • Page 64: Planning Considerations

    PSTNs (see Figure 2 on page By default, any telephone users that call the 3033 must enter the access code 1234 to proceed with further calling activity. This access code provides traceability of the call in the telephone call log.

  • Page 65: Table 7: Default Call Groups

    Managing the telephone station Call groups Call groups are the types of telephone calls that may be made via the 3033 Telephone Interconnect, from HF to a PSTN. The default call groups in the 3033 are listed in Table 7. For help...
  • Page 66 If you want to bar a particular remote HF transceiver from using the 3033, you can do so by adding the specific address to the bottom of the list, but without assigning any call groups. For more information see page 76, Controlling access of HF users.
  • Page 67 Some voice encryption modules support the use of a PIN during a secure session. If a PIN is nominated in the web interface of the 3033, this identical PIN must be used by remote HF users. Voice encryption may also be switched on by the telephone user via the call options menu.

  • Page 68: Setting Up Access To The Web Interface

    Figure 9 on page To enable DHCP: Connect a crossover CAT5 Ethernet cable between the Ethernet port on the rear panel of the 3033 and a spare Ethernet connector on a PC. From the Start menu of the PC, select Control Panel, then Network Connections.
  • Page 69 Click OK to close the LAN Settings dialog. Click OK to close the Internet Options dialog. You can now log into the web interface. For NOTE more information see page 63, Logging into the interface. Telephone Interconnect 3033 User Guide...

  • Page 70: Connecting A Pc Via A Modem To The Telephone Interconnect

    A typical layout for connecting a PC via a modem to the telephone is shown in Figure 10. An appropriate power supply to each device is assumed. Figure 10: Remote connection to telephone interconnect 3033 Telephone Interconnect Line Modem PSTN Line Modem serial port cable 08-06034-001 Telephone Interconnect 3033 User Guide...
  • Page 71 Setting up a dial-up connection To connect to the 3033 via a standard line modem: Connect a line modem to the Data connector on the 3033 via a standard serial cable. Connect the line modem to a land line in the PSTN.
  • Page 72 Managing the telephone station Connecting to the telephone interconnect To connect to the 3033 via a dial-up modem: From the Start menu of the PC, select Control Panel, then Network Connections. Open the Codan 3033 Telephone Interconnect Connection. It may be convenient for you to create a...

  • Page 73: Logging Into The Web Interface

    Select Login in the basic menu. Enter one of the default login usernames and passwords provided in Table 8, then click Login. Table 8: Default usernames and passwords for the web interface Username Password admin admin installer installer calllog Telephone Interconnect 3033 User Guide...

  • Page 74: Setting Up Call Log Parameters

    63, Logging into the web interface). Select Call Logs... in the basic menu, then Telephone Interconnect Time. NOTE The 3033 operates on a 24-hour clock. Enter the local time and date for the 3033. Click Set Time. Telephone Interconnect 3033 User Guide...

  • Page 75: Setting Up Telephone Users

    In the Description field, enter a meaningful description of this telephone user or group of users. Click Add User. The new telephone user (or group) appears in the User List table in the numerical sequence of the User ID number. Telephone Interconnect 3033 User Guide...
  • Page 76 Log into the web interface at admin or installer level (see page 63, Logging into the web interface). Select Telephone Users in the basic menu. Click Delete for the telephone user that you want to delete from the User List table. Telephone Interconnect 3033 User Guide...

  • Page 77: Setting Up Hf User Call Groups

    Short-distance calls that connect within your local region. National Calls Long-distance calls that connect the regions within your country. International Calls Long-distance calls that connect to other countries. Mobile Calls Calls to any defined mobile telephone. Telephone Interconnect 3033 User Guide...
  • Page 78 Replaces any number of * permits calls to any number of any digits. length. Click Insert. If you want to add another telephone number pattern, enter the pattern in the lowermost field, then click Insert. Click Update. Telephone Interconnect 3033 User Guide...
  • Page 79 63, Logging into the web interface). Select HF Users... in the basic menu, then HF User Call Groups. Click Delete for the call group that you want to delete from the HF User Call Group Rights table. Telephone Interconnect 3033 User Guide...

  • Page 80: Setting Up Hf User Access Rights

    An HF user may be managed as part of a larger group using a broad pattern definition of its self address to filter access to the 3033. Each group of HF users is then assigned a set of call groups that they are permitted to use. If voice encryption is used in your HF communication network, security information must also be set up in the 3033.
  • Page 81 A to Z or any in the range MOB0 to MOB9, and single digit in the range 0 MOBA to MOBZ to use the 3033. to 9 required in that position in the number. Matches the separate...
  • Page 82 Managing the telephone station Character Description Example Replaces any number of * permits any stations to use the 3033. digits. Defines specific networks MOBd@ALE permits stations with an with an address. address in the range MOB0 to MOB9 calling via the ALE network to use the 3033.
  • Page 83 Managing the telephone station If the HF users in this group have access to voice encryption on their Codan HF transceivers, do the following in the Security fields: • Select the Enabled box. • In the Index field, enter the 2-digit secure index number that contains the secure key that you want to use (if supported).
  • Page 84 63, Logging into the web interface). Select HF Users... in the basic menu, then HF User Access Rights. Click Delete for the group of users that you want to delete from the HF User Access Rights table. Telephone Interconnect 3033 User Guide...

  • Page 85: Controlling Access To The Telephone Interconnect

    When you set up a telephone user, you must assign them a unique access code. You can set up whether or not they need to enter this access code when they call the 3033. HF users are controlled by the address of their transceiver.
  • Page 86 If you want to bar a group of HF users, ensure that the most specific station address pattern is lowest in the list. Check that there are no call groups enabled for the HF user. Click Insert. Telephone Interconnect 3033 User Guide...

  • Page 87: Setting Up How The Telephone Interconnect Receives Calls

    Managing the telephone station Setting up how the telephone interconnect receives calls To set the number of times that the 3033 rings before answering the call: Log into the web interface at admin or installer level (see page 63, Logging into the web interface).

  • Page 88: Setting Up How The Telephone Interconnect Makes Calls

    (#) at the end of a number to send the call. Select the mode of dialling from the Dial Mode drop list. The 3033 may wait for a dial tone, or dial the number immediately. If the 3033 cannot recognise your local or NOTE regional dial tone, select Immediate.
  • Page 89 3033, you can disable the corresponding voice prompts in the voice prompt menus. The call systems available in the Codan HF transceiver govern what may actually be used via the 3033.
  • Page 90 Address List of the Codan HF transceiver connected to the 3033. Manual Voice Call Enables or disables voice Menu prompting for making manual voice calls from a telephone to an HF transceiver. Telephone Interconnect 3033 User Guide...
  • Page 91 Scroll to the bottom of the page, then click Save Configuration. Select General Configuration in the advanced menu. If you have set up the Codan HF transceiver connected to the 3033 with Address List entries, check that the Address Lookup Prefix matches the prefix used in the transceiver.

  • Page 92: Setting Up Inactivity Timeouts

    Setting up inactivity timeouts Once you have established contact with the 3033 Telephone Interconnect by telephone or by HF call, the 3033 monitors aspects of the call to determine whether or not it is still active. This includes inactivity after voice prompts, inactivity during the call, and total call time.

  • Page 93: Setting Up Speed Dial Telephone Numbers

    78, Setting up the telephone interconnect for telephone calls. Enter any other required full telephone numbers against the remaining abbreviated numbers. Scroll to the bottom of the page, then click Save Numbers. Telephone Interconnect 3033 User Guide...
  • Page 94 Replace the telephone number in the Full Telephone Number field with the 2-digit number from the Abbreviated Number field. Clear the corresponding Include Pre/Postfixes box. Scroll to the bottom of the page, then click Save Numbers. Telephone Interconnect 3033 User Guide...

  • Page 95: Setting Volume Levels

    Listen to: • the transmitted voice signal at the Codan HF transceiver and at the telephone • the speaker on the 3033 when an HF signal is received, and when a telephone signal is received (see page 49, Monitoring the telephone interconnect) •...
  • Page 96 200%. Use the information in the following table as a guide. Field Description HF Transceiver Telephone audio sent via the 3033 Volume to the Codan HF transceiver. Telephone Volume Codan HF transceiver audio sent via the 3033 to the telephone.

  • Page 97: Setting Up The Telephone Line

    • Navigate to the folder in which the telephone line configuration file is located, select the file, then click Open. • Click Upload. • Select the new telephone line configuration file from the Telephone Line Configuration Template drop list, then click Apply. Telephone Interconnect 3033 User Guide...

  • Page 98: Setting Up Telephone Line Values For Your Region

    Setting up telephone line values for your region If a telephone line configuration file is not available for your region, you must manually set up the 3033 to recognise dial, ringback and busy tones, and other levels. You may be able to...
  • Page 99 You may set a value between 0 and 120000 ms. In the Inter-ringback field, set the length of time expected between ringback tones. If this time is exceeded, then the 3033 assumes that the call has been answered, as ringback tones cease once a call is answered.
  • Page 100 Sets the detection threshold for the power level of the call Min. Level Tone 2 progress tone. If the tone has a power level below this threshold, the tone detector in the 3033 is not triggered. You may enter a value between –100 and 0 dBm. Twist (rel amp) Sets the permitted difference in power levels between two frequencies in a call progress tone.
  • Page 101 You may enter a value between 0 and 30 dB. Glitch Sets the permitted duration of a non-standard tone. After this time, the 3033 registers a change in the tone state. You may enter a value between 0 and 100 ms. Click Save Tone Configuration.
  • Page 102 You may enter a value between 0 and 1000 ms. If a new transition state is not detected, the timing sequence restarts. Click Append Transition. Telephone Interconnect 3033 User Guide...
  • Page 103 Dial Tone, Ringback Tone or Busy Tone, as required. Scroll to the Tone State Transitions table. Click Delete for the tone state transition that you want to delete from the Tone State Transitions table. Telephone Interconnect 3033 User Guide...

  • Page 104: Backing Up The Setup

    Managing the telephone station Backing up the setup When you back up the 3033 Telephone Interconnect, the current firmware and the system settings are saved. To back up the system: Log into the web interface at admin level (see page 63, Logging into the web interface).

  • Page 105: Upgrading Firmware

    Upgrading firmware When you upgrade the firmware, the default settings for the 3033 Telephone Interconnect may replace any settings that you have changed. If you are using this process to load an earlier version of firmware that you have backed up, the settings that were saved with that firmware are loaded.

  • Page 106: Changing Web Interface Passwords

    Provides access to the basic menu, and the general configuration item under the advanced menu. Provides access to changing the date and time of the 3033, and downloading and deleting call logs. To change the password to an access level in the web interface:...
  • Page 107 Codan HF transceiver This section contains the following topics: Channel names (98) Networks and channels (101) Self address of the Codan HF transceiver (102) Address List entries in the transceiver connected to the telephone interconnect (103) Telephone Interconnect 3033 User Guide...

  • Page 108: Advanced Setup Of The Codan Hf Transceiver

    If you have channel names in your existing networks that have the same numeric suffix (such as Codan 01, Codan 02, Night 01, Night 02), these channels are easily used with the 3033. To use these existing channels you must define a specific channel...
  • Page 109 Advanced setup of the Codan HF transceiver Defining a channel prefix In the following discussions, you must log into the Codan HF transceiver connected to the 3033 as administrator to see the Control List. For information on logging in as administrator see...
  • Page 110 Codan 1 Codan 1 Save the entry, or if you are using NSP, program the Codan HF transceiver connected to the 3033 with the updated profile. Restart the Codan HF transceiver connected to the 3033 so that the command in the RS232 [15way] Startup is read.

  • Page 111: Networks And Channels

    A station address may be allocated to a specific network or to all networks. Therefore, if you want to restrict 3033 traffic to a number of channels only, create a network for the particular calling system you want to use, add the channels to this...

  • Page 112: Self Address Of The Codan Hf Transceiver

    HF transceivers to make a call to it. If a remote HF transceiver needs to be called via the 3033, the self address entered into the remote HF transceiver must be numeric and between 3 and 15 digits long (up to 10 digits only for a Selcall network).

  • Page 113: Address List Entries In The Transceiver Connected To The Telephone

    You can set up the Codan HF transceiver connected to the 3033 with a series of entries in the Address List that may be used by a telephone user to call remote HF transceivers via an Address List call.
  • Page 114 You cannot set this to <blank>. Network? • select the network you want to use to make the call If you leave this blank, the Codan HF transceiver NOTE uses standard network selection rules to select the network for the call.
  • Page 115 Advanced setup of the Codan HF transceiver You must insert all relevant information into the Address List entry to prevent the Codan HF transceiver prompting for NOTE information during the call. The telephone cannot receive call prompting from the transceiver.
  • Page 116 Advanced setup of the Codan HF transceiver This page has been left blank intentionally. Telephone Interconnect 3033 User Guide...

  • Page 117: Troubleshooting

    (see page 30, transmitting. Setting the VOX levels). 3033 does not 3033 is switched off, or in Switch on the 3033, and select answer. manual mode. automatic mode. Transceiver is off, or not Switch on the transceiver and connected correctly.
  • Page 118 Codan HF transceiver. To view the current firmware version of the 3033 Telephone Interconnect: Press Mode on the front panel of the 3033 until the unit is OFFLINE. The current firmware version is shown in the bottom line of the LCD.

  • Page 119: Appendix A-Voice Prompts

    Appendix A—Voice prompts This section contains the following topics: Overview (110) Menu for voice prompts (111) Creating your own voice prompts (113) Loading your own voice prompts (123) Telephone Interconnect 3033 User Guide...

  • Page 120: Overview

    Voice prompts Overview When you make a telephone call to the 3033 Telephone Interconnect, a voice prompt menu assists you to place a call to an HF transceiver. By default, the voice prompts are in English. However, you may record your own voice prompts under specific file names, then load these into the 3033 Telephone Interconnect via the web interface.

  • Page 121: Menu For Voice Prompts

    Calls made to remote HF Compatibility Selcall from Address List transceiver Mode Selective Call Telephone call Selective Call Telephone call Channel Test Call ALL Call using Selcall using Selcall using ALE using ALE Interconnect Mode Telephone Interconnect 3033 User Guide...
  • Page 122 Voice prompts This page has been left blank intentionally. Telephone Interconnect 3033 User Guide...

  • Page 123: Creating Your Own Voice Prompts

    When you make your own recordings, they are stored in a specific language directory. When these are loaded into the 3033, all languages are stored separately and may be changed and used via the voice prompt menu. Recording your voice prompts Record all of the voice prompts except for the language_selection_prompt.wav file.

  • Page 124: Table 12: Voice Prompts

    Enter the address, followed by the hash key. add_call_message.wav Address List call. ale_call_allcall_message.wav ALL call. ale_call_enter_intcon_message.wav Link established. Press star for options. ale_call_phonecall_message.wav Telephone call using ALE. ale_call_select_message.wav Selective call using ALE. ale_menu_allcall_prompt.wav To place an ALL call, press 2. Telephone Interconnect 3033 User Guide...
  • Page 125 To enable hopping, press 1. To disable hopping, press 2. To change the hop plan, press 3. intcon_hopping_menu_prompt.wav To control hopping, press 6. intcon_hopping_plan_prompt.wav Enter the hop plan number, followed by the hash key. intcon_menu_message.wav Connect options. Telephone Interconnect 3033 User Guide...
  • Page 126 Telephone busy. main_menu_addcall_prompt.wav To place an Address List call, press 3. main_menu_alecall_prompt.wav To place a call using ALE, press 2. main_menu_mancall_prompt.wav To place a manual voice call, press 4. main_menu_message.wav Main menu. Telephone Interconnect 3033 User Guide...
  • Page 127 To place a call to another telephone, press 3. place_call_message.wav Placing call. Press star to abort. proceed_with_call_prompt.wav To proceed with the call, press the hash key. pstn_link_established_message.wav HF transceiver call. request_failed_message.wav Requested action failed. rtu_292_acknowledge_message.wav Ready. Telephone Interconnect 3033 User Guide...
  • Page 128 Press star to abort. sel_call_phonecall_message.wav Telephone call using Selcall. sel_call_select_message.wav Selective call using Selcall. sel_call_test_message.wav Channel test. sel_call_test_proceed_prompt.wav To proceed with the channel test, press the hash key. sel_menu_chan_test_prompt.wav To perform a channel test, press 2. Telephone Interconnect 3033 User Guide...
  • Page 129 Interconnect. Setting up the <language>.xml file The english.xml file is included with the empty NOTE wave files on the 3033 Telephone Interconnect To set up the <language>.xml file: Check that the english.xml file is in the <language> folder. Rename the english.xml file in the <language> folder to the language in which you have recorded the voice prompts.
  • Page 130 Change the title English Language Specification File to <Language> Language Specification File. Change id value from 0 to 1, or if you are using multiple languages at the 3033, the next consecutive integer value. Ensure that the id value is not duplicated in CAUTION any other <language>.xml file.
  • Page 131 Set the wave file properties to 8 kHz sampling rate, 16 bit sampling size, mono. Record the voice prompt as determined above, then save the file. Copy this file to any other <language> folders that you have created for use on the same 3033. Telephone Interconnect 3033 User Guide...
  • Page 132 Check that the path to the files is included in the zipping process. Create the zip file. You must use an identical naming and capitalisation convention for the NOTE <language> folder name, the <language>.xml file, and the <language>.zip file. Telephone Interconnect 3033 User Guide...

  • Page 133: Loading Your Own Voice Prompts

    Click Upload. The new language appears in the Installed Languages table. If the 3033 goes off line, there are errors in the <language>.zip file. Do the following: • delete the language from the 3033 • correct the errors in the <language>.zip file Typical errors are: •...
  • Page 134 Voice prompts This page has been left blank intentionally. Telephone Interconnect 3033 User Guide...
  • Page 135 These may be restored in individual groups. The tables below may be used to record the NOTE settings in your 3033, in the event of having to re-establish settings. To restore factory defaults: Log into the web interface at admin level (see...

  • Page 136: Appendix B-Factory Defaults

    Number of Rings Before Answer 2 Access Code Required Enabled Number of Access Code Attempts 3 On Level –30 dB Off Level –35 dB VOX Hang Time 800 ms Volume Controls All volume controls 100% Telephone Interconnect 3033 User Guide...

  • Page 137: Table 14: Factory Defaults For Telephone Users

    Prompt Repeat Timeout 10 s Maximum Inactivity Timeout 120 s Maximum Call Timeout 600 s Table 14: Factory defaults for Telephone Users (including Access Codes) Field Default value Access Code 1234 Description Default Telephone User Group Telephone Interconnect 3033 User Guide...

  • Page 138: Table 15: Factory Defaults For Hf Users

    Emergency Only (000, 999, 112, 911) ID 9 Unrestricted Access Rights Description Anyone Station Address Pattern Security Disabled Groups Table 16: Factory defaults for Speed Dial Field Default value Full Telephone Number Same as Abbreviated Number Include Pre/Postfixes Disabled Telephone Interconnect 3033 User Guide...

  • Page 139: Table 17: Factory Defaults For Telephone Line Configuration

    Bandwidth Tone 1 100 Hz Min. Level Tone 1 –40 dBm Frequency Tone 2 0 Hz Bandwidth Tone 2 0 Hz Min. Level Tone 2 0 dBm Twist (rel amp) 0 dB 10 dB Glitch 40 ms Telephone Interconnect 3033 User Guide...

  • Page 140: Table 18: Factory Defaults For Web Interface Passwords

    0 ms 0 ms 0 ms Falling 0 ms 320 ms 440 ms Rising 0 ms 320 ms 440 ms Table 18: Factory defaults for Web Interface Passwords Field Default value Username admin|installer|log Password admin|installer|calllog Telephone Interconnect 3033 User Guide...

  • Page 141: Appendix C-Specifications

    483 mm W × 338 mm D × 133 mm H (19 in W × 13.3 in D × 3 RU (5.25 in) H) (Depth dimension does not include handle or connector projections) Weight 10.6 kg (23.4 lb) Telephone Interconnect 3033 User Guide...

  • Page 142: Table 20: Telephone Interface Specifications

    8 bit, ADC to DAC sampling @ 8 kHz characteristics Frequency 300 to 3400 Hz response: Transmit/receive User-programmable software gain range: Signal processing Cut-through DTMF 0 to 9, *, # characteristics detection: Caller On-hook/off-hook detection identification: Telephone Interconnect 3033 User Guide...

  • Page 143: Appendix D-Connectors

    Transceiver connector The Transceiver connector is a 15-way D-type male connector that provides control and communication signals between the transceiver and the 3033. Figure 12: External view of the Transceiver connector Table 21: Pinouts of the Transceiver connector Pin no.
  • Page 144 Table 21: Pinouts of the Transceiver connector (cont.) Pin no. Function Input/output Signal level Output Open collector, active low Rx audio input Input 1 V p–p, approx., return transformer coupled Rx audio input Input Tx audio output Output return Telephone Interconnect 3033 User Guide...

  • Page 145: Table 22: Dtmf Commands For Rtu-292 Compatibility

    3033 Telephone Interconnect. Alternatively, you may enter the DTMF commands provided Table 22 directly. HF users that use a 3033 Telephone Interconnect that is in RTU–292 Compatibility Mode should make a Phone call as usual. Table 22: DTMF commands for RTU–292 Compatibility...
  • Page 146 Table 22: DTMF commands for RTU–292 Compatibility Mode (cont.) Event Description Command VOX on Switches VOX on and places transceiver in receive VOX off Switches VOX off Key/Unkey Toggles transceiver between transmit and receive if VOX is not switched on Telephone Interconnect 3033 User Guide...
  • Page 147 Phone call type (Telcall in older Codan HF transceivers), you can still make Selective calls through the 3033 by setting up a wildcard address to receive these HF calls through a Selcall network. Setting up a wildcard address...
  • Page 148 To make an HF call using the wildcard address from a remote transceiver that does not support Phone calls: Start a Selective call to the wildcard address of the 3033, replacing the wildcard digits (..) with the abbreviated number stored in the speed dial pages.
  • Page 149 Support for non-Phone call transceivers To manually hang up the 3033 from the remote HF transceiver: Start a Selective call to the wildcard address of the 3033, replacing the wildcard digits with 99. For example, if you set up a wildcard station address in the 3033 of 12.., and a remote HF transceiver sends a...
  • Page 150 Support for non-Phone call transceivers This page has been left blank intentionally. Telephone Interconnect 3033 User Guide...
  • Page 151 Appendix G—Compliance This section contains the following topics: Introduction (142) European R&TTE Directive (142) EMC and safety notices (144) FCC compliance (145) A-tick compliance (146) Register of hazardous substances (147) Telephone Interconnect 3033 User Guide...

  • Page 152: Appendix G-Compliance

    Compliance Introduction This section describes how to ensure the 3033 Telephone Interconnect complies with the European Electromagnetic Compatibility Directive 89/336/EEC and the European Low Voltage Directive 73/23/EEC as called up in the European R&TTE Directive 1999/5/EC. This section also contains the requirements for FCC compliance and A-Tick approval.
  • Page 153 Compliance Declaration of Conformity The CE Declaration of Conformity for the product is listed on page 154, Associated documents. This document can be made available upon request to Codan or a Codan-authorised supplier. Telephone Interconnect 3033 User Guide...

  • Page 154: Emc And Safety Notices

    Electrical safety To ensure compliance with the European Low Voltage Directive is maintained, you must install and use the 3033 Telephone Interconnect in accordance with the instructions in this guide. Earth symbol A chassis earth connection point is provided on the 3033 Telephone Interconnect.

  • Page 155: Fcc Compliance

    Part 15 of the FCC rules. The 3033 Telephone Interconnect has been tested and found to comply with the limits for a Class B device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 156: A-Tick Compliance

    Compliance A-tick compliance The 3033 Telephone Interconnect has been tested and complies with the A-tick standards. Required settings To ensure compliance with A-tick standards, you must use the telephone line configuration file Australia_PSTN (see page 87, Setting up the telephone line).

  • Page 157: Register Of Hazardous Substances

    Register of hazardous substances Table 24: 有毒有害物质列表 (Register of hazardous substances) 零件项目 有毒有害物质或元素 (Component Name) (Hazardous Substances or Elements) 3033 电话转接器 (3033 Telephone Interconnect) 机箱 (Chassis) 内部电缆 (Internal Cables) 内置控制电脑 (Embedded Control PC) 接口电路板组件 (Interface PCB Assembly) Telephone Interconnect 3033 User Guide...
  • Page 158 份 A= 十月份 , B= 十一月份 ,C= 十二月份 . The second character of the serial number provides the month of manufacture, that is, 1 to 9, A to C; A=10 month, B=11 month and C= 12 month. Telephone Interconnect 3033 User Guide...

  • Page 159: Appendix H-Definitions

    CAUTION lead to loss of data, privacy or signal quality the text provided next to this icon may be of NOTE interest to you a step to follow Telephone Interconnect 3033 User Guide...

  • Page 160: Acronyms And Abbreviations

    DTMF dual-tone multi-frequency data terminal ready electromagnetic compatibility ETSI European Telecommunications Standards Institute Federal Communications Commission ground high frequency local area network light-emitting diode lower sideband not connected NGT system programmer Telephone Interconnect 3033 User Guide...
  • Page 161 PSTN public switched telephone network press-to-talk R&TTE radio and telecommunications terminal equipment request to send receive receive data signal-to-noise ratio transmit transmit data universal serial bus, upper sideband voice-operated switching Telephone Interconnect 3033 User Guide...

  • Page 162: Glossary

    Codan HF Any local or remote Codan HF transceiver. transceiver If it is connected directly to the 3033, it must be a 2010 RF Unit with a 2030 Junction Box, a 2012 RF Unit, or a 2110 Manpack Transceiver with an interface adaptor.

  • Page 163: Units

    Units Measurement Unit Abbreviation Current ampere Distance metre (inch) (in) Frequency hertz Mass gram Temperature degrees Celsius °C (degrees Fahrenheit) (°F) Time second Voltage volt Unit multipliers Unit Name Multiplier milli 0.001 deci kilo 1000 Telephone Interconnect 3033 User Guide...

  • Page 164: About This Issue

    Definitions About this issue This is the first issue of the Telephone Interconnect 3033 User Guide. Associated documents Other publications associated with the 3033 Telephone Interconnect are: • NGT Transceiver Getting Started Guide (Codan part number 15-04127-EN) • NGT Transceiver Reference Manual (Codan part number 15-04126-EN) •...
  • Page 165 Definitions • Manpack Transceiver 2110M Getting Started Guide (Codan part number 15-04153-EN) • Manpack Transceiver 2110M Reference Manual (Codan part number 15-04152-EN) • Declaration of Conformity for the 3033 Telephone Interconnect (Codan part number 19-40320) Telephone Interconnect 3033 User Guide...
  • Page 166 Definitions This page has been left blank intentionally. Telephone Interconnect 3033 User Guide...

  • Page 167: Index

    13, 133 transceiver to telephone 39, 48 Transceiver 133 call inactivity 82 country 88 call log 17, 50 current accessing 50 consumption 131 deleting 51 loop 132 description 51 downloading 50 parameters 64 time 64 Telephone Interconnect 3033 User Guide Index-1...
  • Page 168 132 web 13 front panel inter-ringback 89 buttons 11 knob 12 LCD 10 LEDs 11 knob 12 full telephone number 83 functional test 33 layout basic 7 glitch 91 trunked 8 glossary 152 Index-2 Telephone Interconnect 3033 User Guide...
  • Page 169 84 alternative 17 standards and icons 149 prefix 78, 83 station address 29, 137 proxy 59 multiple for 3033 29 PSTN station address pattern 56 call activity 42 supply voltage 131 Telephone Interconnect 3033 User Guide Index-3...
  • Page 170 138 deleting 93 editing 93 transceiver Codan HF Address List entries 103 channel 101 name 98 prefix 99 network 101 RS232 15way Startup entry 99 self address 102 transceiver call log 17 Index-4 Telephone Interconnect 3033 User Guide...
  • Page 171 81 Graves Street Newton SA 5074 AUSTRALIA Telephone +61 8 8305 0311 Facsimile +61 8 8305 0411 asiasales@codan.com.au Codan (UK) Ltd Gostrey House Union Road Farnham Surrey GU9 7PT UNITED KINGDOM Telephone +44 1252 717 272 Facsimile +44 1252 717 337 uksales@codan.com.au...
