Summary of Contents for Radwin AP0127730
- Page 1 AP0127730, AP0134760 RF Module Operating in the 4.9-5.8 GHz bands REFERENCE GUIDE...
-
Page 2: Regulatory Compliance
This equipment should be installed and operated with a minimum distance of 354cm between the radiator and your body. Warning The module is granted to operate under FCC certification in the 4.9 GHz and 5.8 GHz bands only. Warning AP0127730, AP0134760 Reference Guide... - Page 3 2. Cet appareil doit accepter toute interférence, y compris les interférences qui peuvent causer un mauvais fonctionnement de l'appareil. This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numrique de la classe B est conforme la norme NMB-003 du Canada AP0127730, AP0134760 Reference Guide...
-
Page 4: Condition Of Use
Overview The AP0127730, AP0134760 is an RF module operating in the 4.9 – 5.8 GHz frequency bands. It is a TDD OFDM radio supporting 5 MHz, 10 MHz, 20 MHz and 40 MHz channel bandwidths. The RF module cannot work as a stand-alone device. It can operate and be controlled only when attached to a digital main board and altogether assembled in an enclosure suitable for outdoor use. -
Page 5: Certified Antennas
Certified Antennas Following is the list of antennas certified for use with the AP0127730, AP0134760 RF module: Antenna Max Antenna Type Manufacturer Model Number Gain (dBi) Sector Dual Pole Integrated 120 Deg RADWIN Ltd. MT0128930 Sector Dual Pole 120 Deg RADWIN Ltd. - Page 6 0 to 6 dBi total antenna assembly gain. For systems using higher than 6 dBi total assembly gain antennas the output power will be reduced to comply with 30 dBm EIRP. 5 MHz: 17.24 dBm 10 MHz: 20.03 dBm 20 MHz: 23.06 dBm 40 MHz: 23.92 dBm AP0127730, AP0134760 Reference Guide...
