Summary of Contents for Innosys IDB-02S
- Page 1 User manual Bluetooth Low Energy products BLE Dongle / IDB-02S www.innosys-tech.com...
-
Page 2: Table Of Contents
CONTENTS 1. BLE Dongle Description ..........................3 1.1 Introduction ..............................3 1.2 Product Information ..........................4 1.3 Product Configuration ..........................5 2. App to use it ..............................6 2.1 Information ..............................6 2.2Password Setting ............................7 2.3 Lighting registration ..........................8 2.4 General Operation ........................... -
Page 3: Ble Dongle Description
1.1 Introduction - IDB-02S BLE Dongle / IDB-02S is a controller that controls the output of the SMPS and can control the color temperature and brightness. It uses the Low Energy Bluetooth 4.0 specification and is supported by both Android and IOS. -
Page 4: Product Information
1.2Product Information SPECIFICATION Division IDB-02S Remarks Input Power DC 3.3V Current Consumption Max. 30mA Bluetooth Ver. Bluetooth Low Energy 4.0 Communication distance Max. 50m Output PWM-4CH 1.56KHz Storage Temperature -40 ~ 85℃ Operating Temperature -10 ~ 45℃ Certification KC, CE, FCC, ROHS... -
Page 5: Product Configuration
3. Insert the BLE dongle into the J1 connector of the gender board fixed to the Lighting. * NOTICE: The protrusion of IDB-02S connector must be correctly aligned with the hole groove of the gender board. Please reference to the following figures. -
Page 6: App To Use It
2. App to use it 2.1Information It is an application that controls brightness and color temperature of LED lighting using Bluetooth function of smart phone. The lighting in the room, such as living room, kitchen, study room, etc…,and the smart phones APP are connected using Bluetooth. -
Page 7: Password Setting
2.2Password Setting Before using the application, the user must set the password of the application to be compatible with the HS dongle(IDB-02S). ① Click [Register Lighting] when connected for the first time. ② Set up the user's password. ③ Confirm the entered password once again. -
Page 8: Lighting Registration
2.3Lighting registration After the process of setting the password, connection with the HS dongle is possible through registration of the lighting. You can register the desired HS dongle by clicking the registration light, This means that the lighting can be controlled by the application. - Page 9 - Multiple lighting registration Multiple lighting registration means registering multiple lights on one icon button. How to register is as follows. ① With one light already registered, click “register light”. ② Select the desired HS dongle from the list of HS dongles whose power is ON.
-
Page 10: General Operation
2.4 General Operation After the lighting registration is completed, The LED lighting with the dongle installed can be operated through the application operation. The general operation is as follows. - When using basic lighting After registering the basic lighting, the LED lights up when you click the icon. - Page 11 - When multiple multiple lights After registering the basic lighting, click on the icon and the registered LED lights will turn on all at once. An illuminated LED light sends a signal to the application that it is on, and an application that receives this signal indicates that the LED light is active on the icon.
-
Page 12: Lighting Control
2.5Lighting control In the lighting control in the connection state, it’s possible to turn on/off the led lighting. You can fine tune the color temperature and brightness of a directly connected light. You can register the lighting settings according to the situation. - Page 13 - Brightness control You can control the brightness of registered LED lights through the lighting control function. The color brightness can be adjusted from 0%(off) to 100%(turn on). The color brightness can be fine-tuned by operating the wheel button.
-
Page 14: App Settings Initialization
2.6 App settings initialization When the position of the registered light in the app is changed or deleted, or You initialize the passwords registered in the app, App setting initialization is used. How to reset app settings ①Click the Menu button. -
Page 15: Appendix
3. Appendix 3.1Manufacturer Information Manufacturer : INNOSYS CO,.LTD Address :INNOSYS CO,.LTD, 1-1107, Ace Dongbaek Tower, 16-4, Dongbaekjungang-ro 16beon-gil, Giheung-gu, Yongin-si, Gyeonggi-do, Republic of Korea. (Zip code : 17015) Contacts: +82-70-5099-3132 Company Website: www.innosys-tech.com Location: INNOSYS CO,.LTD, 1-1107, Ace Dongbaek Tower 3.2 A/S... - Page 16 CE Statement Hereby, we declare that this device is in compliance with the essential requirements and other relevant provisions of directive 1999/5/EC. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions.
