- Page 2 +CAM Robot-o HD Quick Start Guide CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE, REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol is intended to alert the user to the presence of uninsulated “dangerous voltage”...
- Page 3 +CAM Robot-o HDQuick Start Guide Regulatory Notices for USA This equipment has been tested and found to comply with the limits for a digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 4: Camera Mounting
+CAM Robot-o HD Quick Start Guide Camera Mounting To mount the +CAM Robot-o HD to the wall, place the camera in a position to ensure the most comprehensive view for video monitoring. Unscrew the base of the camera and remove the plate. The dots on the base of the camera indicate the location of the expansion bolts. -
Page 5: Connect To Power
+CAM Robot-o HDQuick Start Guide 1. iSecurity+ App To get started, download the iSecurity+ app from Apple’s App store or the Google Play Store. 2. Connect to Power Connect the +CAM Robot-o HDto the AC power adapter, then plug your power cord into the electrical outlet. - Page 6 +CAM Robot-o HD Quick Start Guide 3a. Wi-Fi Setup Mode The Setup button will glow the green. The “Wi-Fi Setup” LEDs in the front of the cam will twinkle the green/orange alternatively and the +CAM Robot-o HD will rotate when the camera is ready for setup.
- Page 7 +CAM Robot-o HDQuick Start Guide 3b. Connect device to +CAM Robot-o HD Android Go to your device’s settings -> Under the Wi-Fi setting, connect to the RobotoHDXXXX (last 4 digits of Cam ID)network.
- Page 8 +CAM Robot-o HD Quick Start Guide 4a. Launch iSecurity+ App Once your device establishes its connection to the +CAM Robot-o HD, (usually takes around 30 seconds,) launch the iSecurity+ App. If you don’t see the pop up prompt, please close the app and re-launch it.
- Page 9 +CAM Robot-o HDQuick Start Guide 4b. Setup Wizard Follow the instructions in the Camera SetupWizard to complete installation.
- Page 10 +CAM Robot-o HD Quick Start Guide 4c. Setup Wizard Final Step Camera setup is complete. Press the reset/power button on the back of the camera to turn off Wi-Fi setup mode and to connect to your Wi-Fi network. Restart iSecurity+ and please log in again. Turn off Wi-Fi setup Setup Complete You can use your iOS/ Android devices to...
- Page 11 +CAM Robot-o HDQuick Start Guide 5. Using iSecurity+&Main Features Window Please enter your user name and password, created during the setup process to access your +CAM Robot-o Configure Camera Camera Status Friends’ Recorded Cameras Events Settings...
- Page 12 +CAM Robot-o HD Quick Start Guide 6. iSecurity+ Features – Camera Viewer Swipe directional controls to change the camera Pan & Tilt view. Take a Audio Muting Snapshot Off/On Audio-only Record a Mode video clip...
- Page 13 +CAM Robot-o HDQuick Start Guide 6a. Zoom Function Zooming In - Touch the screen with two fingers and slide inward at an angle and the image will zoom in. Zooming Out - Touch the screen with two fingers and slide outwards at an angle and it will enlarge the image.
- Page 14 +CAM Robot-o HD Quick Start Guide 6a. Audio Talkback 1. To use Audio Talkback, first press the Audio button to initiate sound to listen in. 2. Then press the Audio Talkback button and speak into your device, then let go for the audio to transfer to the camera’s speaker.
-
Page 15: Safety Information
+CAM Robot-o HDQuick Start Guide Safety Information Do not point the camera directly at the sun, or else it will damage the image sensor. Keep the camera away from heat to avoid electric shock. Keep the camera away from rain and moisture. -
Page 16: Troubleshooting
+CAM Robot-o HD Quick Start Guide Troubleshooting LED Status Indicators During Wi-Fi Setup Mode Green:Setup mode on Orange: Setup mode initializing Light Off: Setup mode off During Normal Operation Green: Connected to iSecurity+ Orange: Connected to local Network Flashing Orange: Not connected to any network... - Page 17 Press button for more than 10s to reset factory default. For More Information To get the latest camera driver updates or to learn more about Imogen Studio products, please visit: www.imogenstudio.com To get the latest software updates or to learn more about Seedonk, please visit: www.isecurityplus.com...
- Page 18 Revised May 5, 2014 ©ImogenStudio, 2014...
