Woker- - Attandance Device of Construction Site

Woker

Attandance Device of Construction Site

RFID&Biometrics

Gateware- - FVS

Gateware

Gateware- - FVS

Gateware

User Manual

System

FVS

ver. – – 1.0

ver.

ver. – – 1.0

ver.

1.0

Need help?

Do you have a question about the Gateware FVS and is the answer not in the manual?

Questions and answers

Summary of Contents for Doalltech Gateware FVS

Page 1 Woker Woker- - Attandance Device of Construction Site Attandance Device of Construction Site RFID&Biometrics RFID&Biometrics RFID&Biometrics RFID&Biometrics System System System System Gateware Gateware- - FVS Gateware Gateware- - FVS ver. ver. – – 1.0 ver. ver. – – 1.0 User Manual User Manual User Manual User Manual...
Page 2 Doalltech GATEWARE-EM Contents User Manual User Manual Matters that require attention Matters that require attention ----------------- 3 ----------------- 3 Product Explanation Product Explanation ----------------- 6 ----------------- 6 Starting Starting 1. Check of the supply items 1. Check of the supply items...
Page 3 Doalltech GATEWARE-EM Matters that require attention– Sign explanation, Power supply ØSign explanation v Please read this manual and keep the using method because for prot ecting risks or damages on property by using the product correctly. l This is composed of contents on the possibility of death or &...
Page 4 Doalltech GATEWARE-EM Matters that require attention warning Ø Please don’t use a damaged plug or loose outlet § It causes fire & electronic shock & & Ø Please do not use a lot of plugs into one outlet. Ø Please do not use a lot of plugs into one outlet.
Page 5 Doalltech GATEWARE-EM Matters that require attention caution Ø Don’t make DC Power supply (Adapter) device wet & keep away from water § It causes fire & electronic shock & & Ø Don’t put the Power supply device or Power supply wire around heater.
Page 6 Doalltech GATEWARE-EM Product summary Summary Summary The entry control management using The entry control management using RFID card & Finger Vein Pattern. RFID card & Finger Vein Pattern. Real-time confirmation on the entry situation Real-time confirmation on the entry situation...
Page 7 Doalltech GATEWARE-EM 1. Composition item check Gateware FVS Main body Gateware FVS Main body Main body holder Main body holder Main body Adapter Main body Adapter Main body Key Main body Key SD Memory SD Memory USB Memory USB Memory...
Page 8 Doalltech GATEWARE-EM 2. Installation method Holder ① ② Holder Holder ③ ③ Back of the Gateware device EX) In case of installing at gate guard post ① Please confirm the installation position after matching up per end of the fixing board and eye level of the worker.
Page 9 Doalltech GATEWARE-EM 3. Each part name & function (Front) FRONT FRONT Each part name Function 1.Camera When workers scan the card,it takes a photo 2.FLASH Flash is working as the Time zone of User setting for card check 3.LCD Camera view & Product status(Reference to 7page) 4.RFID REGISTER...
Page 10 Doalltech GATEWARE-EM 3. Each part name & function(Bottom) BOTTOM BOTTOM 1 2 3 Each part name Each part name Function Function 1.ON/OFF Product ON/OFF button 2.PWR Connection terminal of Power supply Adapter 3.RESET Product default setting 4.Screen in/output Installation pot of Additional camera...
Page 11 Doalltech GATEWARE-EM Screen UI Explanation ① Company name, construction work, type of occupations, name and information of the card number are marked after card rec ognitions. ② The resident registration number is showed in case of setting k eypad input.
Page 12 Doalltech GATEWARE-EM Keypad control explanation Save Save MENU ① MENU This displays button Menu. ② Setting Menu is displayed in the default screen. In t he Setting menu, please move with the Save button ③ This makes get out of current screen.
Page 13 Doalltech GATEWARE-EM Keypad control explanation Save Save SHIFT ① SHIFT This makes the button to next stage. The focus moves to the position of flash end Ti – me when locating in flash start Time. . ② This deletes box contents of button text.
Page 14 Doalltech GATEWARE-EM Keypad control explanation Save Save ① When inputting Keypad 1~0 in Menu setting text box, you can input ② In main screen, Keypad 2,4 button : Controlling Volume up & down ③ In main screen, Keypad 4,6 button Controlling Screen brightness ④...
Page 15 Doalltech GATEWARE-EM 1. Menu setting – Enter the Menu ① This is Main Screen. Camera image is displayed MENU ② Push the MENU button ③ Password prompt is displayed ④ After pushing the Password + ENTER you can see the Product setting Menu This image is just for reference.
Page 16 Doalltech GATEWARE-EM 2. Setting Menu – Selecting item 1. Setting view 2. Default setting 3. Serial Pot setting Menu2 4. Relay setting 5. Special setting 6. LAN setting ② ENTER next page 7. USB use 8. Time setting 9. password setting ENTER next page ④...
Page 17 Doalltech GATEWARE-EM 3. Menu setting – Status check Device Status info, network status info. Project codeIBDD2008 IP use status DHCP Attendance IN/OUT IP Address 192.168.1.100 Camera use 1 Channel Default Gateway 192.168.1.1 Pot1 13.56Mhz Subnet Mask 255.255.255.0 Pot2 Not Use DNS 1 168.126.63.1...
Page 18 Doalltech GATEWARE-EM 4. Menu setting - Default setting Device Default setting Project code IBDD2008 Input data in English Device number 1 Attendance IN/OUT Camera use 1 Channel Save ① Default setting Screen of the Product ② Enter the project code When inputting English in project code, –...
Page 19 Doalltech GATEWARE-EM 5. Menu setting – Serial Pot setting Serial Pot setting Pot1 13.56Mhz Pot2 Not Use Pot3 Not Use Pot4 Not Use Save ① This is setting Screen of the RFID Serial Pot ② Set the RFID Serial Pot ③...
Page 20 Doalltech GATEWARE-EM 6. Menu setting – Relay setting Relay setting Relay1 Allow Port 1 Relay2 Deny Port 1,2 Relay3 Not Use Relay4 Not Use Save ① Relay setting Screen ② After selecting the Allow(registration), Set the Pot ③ After selecting Deny(rejection), Not applied even though set the Pot ④...
Page 21 Doalltech GATEWARE-EM 7. Menu setting – Special setting Device special setting Flash Start Time 17 Flash End Time 09 Local Server Keypad input Use short period key input Save ① Flash start Time& End Time setting ② Enter the IP of Local Server ③...
Page 22 Doalltech GATEWARE-EM 8. Menu setting – LAN setting LAN setting change DHCP/STATIC IP ADDRESS SUBNET MASK DEFAULT GATEWAY DNS 1 DNS 2 Save ① Select the DHCP/STATIC use or not ② STATIC Application situation, set the IP ADDRESS ③ Set the SUBNET MASK ④...
Page 23 Doalltech GATEWARE-EM 9. Menu setting – by using USB Data in&output Save worker Data copy to attendance Data USB ① USB application setting Screen ② Connect the USB memory to product ③ Save the worker data by pushing the Worker data save button ④...
Page 24 Doalltech GATEWARE-EM 10. Menu setting – Time setting Current Time & Time zone setting 2009 year month 14 day hour 15 min 30 sec (GMT+09:00)Seoul Korea Standard Time Save ① Enter the current year, month, day ② Enter the current hour, min, second ③...
Page 25 Doalltech GATEWARE-EM 11. Menu setting – Password Password change Save ① Product password setting ② Pushing the Save button to save the password ③ If you push the ESC button, you can return to setting Menu This image is just for reference. So it’ can be different from real situation Screen &...
Page 26 Doalltech GATEWARE-EM 1. External Interlocking device - Turn-Gate Turnstile Gate System Turnstile Gate System CCTV for Safety management 13.56Mhz READER 13.56Mhz READER Finger Vein READER Finger Vein READER Photo 1 Turnstile Gate System Photo 1. ①Using Various RFID TYPE(13.56Mhz) and Finger Vein TYPE at the same time is available ②When worker check the scan card, device takes a picture by...
Page 27 Doalltech GATEWARE-EM 2. External Interlocking device – Composition item External Interlocking product External Interlocking product External External Speaker Monitor Crossing Finger Vein Camera1 barrier for car READER Flashlight Camera2 RFID Turnstile Gate 13.56Mhz Camera3 System Can interlock with another various devices...
Page 28 Doalltech GATEWARE-EM 1. Additional function Transmission of field pictures through network aft Transmission of field pictures through network aft • • er image capturing of 1/4 channel camera. er image capturing of 1/4 channel camera. This is a use example. This can be composed differently in case of actual application.
Page 29 Doalltech GATEWARE-EM 2. F A Q Case 1 System is not working → Please check the Power supply connection → Please check the Battery charge status Case 2 Data down and upload don't work. → Please check the internet connection →...
Page 30 Doalltech GATEWARE-EM 2. F A Q Case 6 LCD Screen is monotonous in the state of ash or black color. → push the RESET or power switch to restart → When being occurred same symptom after re-start, please contact to Doall...
Page 31 Doalltech GATEWARE-EM 3. Before A/S Request Error type Cause and Solution Please check the Power supply cable. In case of Power Please check the 220 volt as right voltage supply failure Please check the electronic status of receptacle Please check the System Power supply Cable...
Page 32 Doalltech GATEWARE-EM 3. Before A/S Request Error type Cause and Solution Please network setting in LAN setting Menu In case internet is not working Please check LAN cable connection Please contact with internet company Please check the router motion lamp, Power supply cable &...
Page 33 Please confirm whether RFID recognition of RFID recognition is correct lamp do not turned Please confirm whether the system is turned on. Please after shutting down, restart In case other operations are not Please after checking error type, contact correct with doalltech...
Page 34 Doalltech GATEWARE-EM 4. Product Size - Hardware Hardware CPU Processor Marvell PXA320-P (ARM11 Core 806Mhz) RAM 133Mhz DDR SDRAM 512MByte Memory Nand Flash NAND Flash 128MByte EPLD Lattice isp MACH LC4128V Display 800 X 480 (7” Wide TFT Color LCD)
Page 35 Sensor Li-ion 14V, 8800 mAh Li-ion 14V, 8800 mAh Battery Color LED x 3 Light Flash x 2 Flash Software O/S Windows CE 5.0 Core Application Doalltech GatewareEM / GatewareCS Product specification can be changed for high quality improvement Reference...
Page 36 Doalltech GATEWARE-EM 4. Product Size – Block Diagram Int. Serial Port x1 (13.56Mhz RFID) Ext. Serial port x3 (13.56Mhz RFID Reader, Finger Vein Reader) Debugger port x1 Photo Sensor, Photo Sensor, Relay X4 Relay X4 Roof Coil Sensor Roof Coil Sensor...
Page 37 Doalltech GATEWARE-EM 5. FCC RF INTERFERENCE STATEMENT FCC RF INTERFERENCE STATEMENT FCC RF INTERFERENCE STATEMENT NOTE : NOTE : This equipment has been tested and found to comply with the limits for a Class B This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 38 Doalltech GATEWARE-EM 5. FCC RF INTERFERENCE STATEMENT Product specification can be changed for high quality improvement Reference...
Page 39 Doalltech GATEWARE-EM Additional charge item Battery AV LCD MONITOR Internet homepage Contact 0707-018-5900 www.doalltech.com 02) 555-9779 Ubiquitous team Picture size of each item can be different from real product size,, Some part items can be changed depending on the situation...
