Cambium PTP 450 series User Manual

Point-to-point wireless equipment
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Cambium PTP 450 User
Guide
System Release 13.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PTP 450 series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cambium PTP 450 series

Summary of Contents for Cambium PTP 450 series

  • Page 1 Cambium PTP 450 User Guide System Release 13.2...

  • Page 2: Ptp 450 Module Essential Information

    PTP 450 module essential information Default IP Address for Management GUI Access 169.254.1.1 Default Administrator Username admin Default Administrator Password (no password) See “Updating the software version and using CNUT” Software Upgrade Procedure in the PMP 450 Configuration and User Guide 1.
  • Page 3 Cambium. License Agreements The software described in this document is the property of Cambium and its licensors. It is furnished by express license agreement only and may be used only in accordance with the terms of such an agreement.

  • Page 4: Safety And Regulatory Information

    Safety and regulatory information This section describes important safety and regulatory guidelines that must be observed by personnel installing or operating PMP 450 equipment. Important safety information To prevent loss of life or physical injury, observe the safety guidelines in this section. Power lines Exercise extreme care when working near power lines.

  • Page 5: Important Regulatory Information

    FCC. In order to comply with these FCC requirements, Cambium supplies variants of the PMP 450 for operation in the USA or Canada. These variants are only allowed to operate with region codes that comply with FCC/IC rule.

  • Page 6: Table Of Contents

    Contents PTP 450 User Guide Contents PTP 450 module essential information ........................ii Safety and regulatory information ................. iv Important safety information ......................... iv Important regulatory information ........................v About This Configuration and User Guide ............xiii General information ............................xiv Problems and warranty ............................
  • Page 7 PTP 450 User Guide Contents Network Time Protocol (NTP) ........................1-24 Wireless Manager (WM) ........................... 1-24 Capacity upgrades ............................. 1-25 Software upgrade ............................1-25 Further reading on system management ....................1-25 Chapter 2: Planning considerations ..............2-26 Regulatory planning ............................2-27 Obeying Regulatory limits ........................
  • Page 8 Ordering components ............................2-95 PTP 450 component part numbers ......................2-95 Chapter 3: Legal information ................3-99 Cambium Networks end user license agreement .................... 3-100 Acceptance of this agreement ........................3-100 Definitions ............................... 3-100 Grant of license ............................3-100 Conditions of use ............................. 3-100 Title and restrictions ..........................
  • Page 9 PTP 450 User Guide Contents Entire agreement ............................3-105 Third party software ..........................3-105 Hardware warranty ............................3-108 Limit of liability .............................. 3-109 Chapter 4: Reference information ..............4-110 Equipment specifications ..........................4-111 BHM specifications ..........................4-111 BHS specifications ..........................4-115 Wireless specifications ............................
  • Page 10 Figure 4 BHM interfaces – 3.5 GHz, 3.6 GHz, 5 GHz ....................1-5 Figure 5 BHM diagnostic LEDs, viewed from unit front ..................1-7 Figure 6 PTP 450 Series BHS ........................... 1-9 Figure 7 BHS interfaces ............................1-10 Figure 8 Connectorized BHS ..........................1-10 Figure 9 BHS diagnostic LEDs, viewed from unit front ..................
  • Page 11 PTP 450 User Guide List of Tables List of Tables Table 1 PTP 450 frequency variants ........................1-4 Table 2 BHM interface descriptions and cabling – 3.5 GHz, 3.6 GHz, 5 GHz ..........1-6 Table 3 BHM interface descriptions and cabling – ........
  • Page 12 List of Tables PTP 450 User Guide Table 35 Link budget details – 5.4GHz PTP 450 BHM and PTP 430 BHS link, 10MHz Channel Bandwidth .. 2- Table 36 Link budget details – 5.4GHz PTP 450 BHM and PTP 430 BHS link, 5MHz Channel Bandwidth 2-56 Table 37 Example 5.8-GHz OFDM channel assignment by sector ..............

  • Page 13: About This Configuration And User Guide

    PTP 450 User Guide About This Configuration and User Guide This guide describes the configuration of the Cambium PTP 450 Series of point-to-point wireless equipment deployment. It is intended for use by the system administrator. After the initial general and legal information, the guide begins with a set of tasks to complete a basic configuration of the equipment.

  • Page 14: General Information

    PTP support website: http://www.cambiumnetworks.com/products/ptp Cambium main website: http://www.cambiumnetworks.com/ Sales enquiries: sales@cambiumnetworks.com Email support: support@cambiumnetworks.com Telephone numbers: For full list of Cambium support telephone numbers, see: http://www.cambiumnetworks.com/support/contact-support Address: Cambium Networks 3800 Golf Road, Suite 360 Rolling Meadows, IL 60008 ptp-450 (July 2014)
  • Page 15 It is recommended that all personnel engaged in such activities be properly trained. Cambium disclaims all liability whatsoever, implied or express, for any risk of damage, loss or reduction in system performance arising directly or indirectly out of the failure of the customer, or anyone acting on the customer's behalf, to abide by the instructions, system parameters, or recommendations made in this document.

  • Page 16: Problems And Warranty

    CNUT Support Capture Tool information Escalate the problem by emailing or telephoning support. See ‘Contacting Cambium Networks’ for URLs, email addresses and telephone numbers. Repair and service If unit failure is suspected, obtain details of the Return Material Authorization (RMA) process from the support website.
  • Page 17 PTP 450 User Guide Warranty Cambium’s standard hardware warranty is for one (1) year from date of shipment from Cambium or a Cambium distributor. Cambium warrants that hardware will conform to the relevant published specifications and will be free from material defects in material and workmanship under normal use and service.

  • Page 18: Security Advice

    Security advice Security advice Cambium Networks systems and equipment provide security parameters that can be configured by the operator based on their particular operating environment. Cambium recommends setting and using these parameters following industry recognized security practices. Security aspects to be considered are protecting the confidentiality, integrity, availability of information and assets.

  • Page 19: Warnings, Cautions And Notes

    Warnings, cautions and notes The following describes how warnings and cautions are used in this document and in all documents of the Cambium Networks document set. Warnings Warnings precede instructions that contain potentially hazardous situations. Warnings are used to alert the reader to possible hazards that could cause loss of life or physical injury.

  • Page 21: Chapter 1: Product Description

    Warnings, cautions and notes PTP 450 User Guide Chapter 1: Product Description This chapter provides a high level description of the PTP 450 product. It describes in general terms the function of the product, the main product variants and typical deployment. It also describes the main hardware components. The chapter consists of the following topics: ...

  • Page 22: Overview Of Ptp 450

    Purpose Cambium PTP 450 Series networks are designed for wireless point-to-point links in the unlicensed 3.5 GHz, 3.6 GHz, 5.4 GHz and 5.8 GHz bands. Users must ensure that the PTP 450 Series complies with local operating regulations. The PTP 450 Series adds dramatically increased network throughput and capacity. The PTP 450 Series enables network operators to grow their business by offering more capacity for data, voice and video applications.

  • Page 23: Typical Deployment

    Even with OFDM, these products should not be expected to penetrate walls or extensive trees and foliage. Typical deployment The PTP 450 Series consists of a Backhaul Master and a Backhaul Slave Module. The radio link operates on a single frequency channel in each direction using Time Division Duplex (TDD).

  • Page 24: Table 1 Ptp 450 Frequency Variants

    PTP 450 User Guide Overview of PTP 450 Product variants The PTP 450 Series is available in the following product variants: Table 1 PTP 450 frequency variants Variant Region Frequency Channel Variant Coverage Bandwidth Notes (MHz) (MHz) 3300 – 3600 3.5 GHz...

  • Page 25: Backhaul Master (Bhm)

    Backhaul Master (BHM) PTP 450 User Guide Backhaul Master (BHM) The BHM is a self-contained unit that houses both radio and networking electronics. The BHM is supplied in a connectorized and radiated configuration. Connectorized units with external antennas can cope with more difficult radio conditions.

  • Page 26: Table 2 Bhm Interface Descriptions And Cabling - 3.5 Ghz, 3.6 Ghz, 5 Ghz

    PTP 450 User Guide Backhaul Master (BHM) Table 2 BHM interface descriptions and cabling – 3.5 GHz, 3.6 GHz, 5 GHz Interface Function Cabling -45 degree RF connection to BHM 3.5 GHz antenna Path A RF -45 degree RF connection to BHM 50 ohm RF cable, N-type 3.6 GHz Port...

  • Page 27: Figure 5 Bhm Diagnostic Leds, Viewed From Unit Front

    Backhaul Master (BHM) PTP 450 User Guide Interface Function Cabling Horizontal RF connection to BHM 5 GHz antenna synchroni zation RJ11 cable, default plug. signaling, Default plug port. Sync / Default Power-over-Ethernet, Ethernet RJ45 cable communications (management and data) Table 3 BHM interface descriptions and cabling – Interface Function Cabling...

  • Page 28: Network Connection

    Network connection The network connection to a PTP 450 Series BHM is made via a 10 BaseT or 100 BaseT Ethernet connection. Power is provided to the BHM over the Ethernet connection using a patented non-standard powering technique. BHM power supply The BHM power supply generates the BHM supply voltage (29 VDC) from the external DC source and injects the supply voltage into the BHM.

  • Page 29: Backhaul Slave (Bhs)

    For mounting PTP 450 BHSs, Cambium Networks offers the SMB1A mounting bracket. Network connection The network connection to a PTP 450 Series BHS is made via a 10 BaseT or 100 BaseT Ethernet connection. Power is provided to the BHS over the Ethernet connection using a patented non-standard powering technique.

  • Page 30: Figure 7 Bhs Interfaces

    PTP 450 User Guide Backhaul Slave (BHS) BHS interfaces Figure 7 BHS interfaces BHS Ground (connectorized models) Ethernet Sync/Default 3.5 GHz and 3.6 GHz BHSs appear a bit different from the existing 5 GHz 450 BHSs. Figure 8 Connectorized BHS External antenna cable, path A (labeled...

  • Page 31: Figure 9 Bhs Diagnostic Leds, Viewed From Unit Front

    Backhaul Slave (BHS) PTP 450 User Guide Interface Function Cabling 3.5 GHz -45 degree antenna connection 50 ohm RF cable, N-type 3.6 GHz -45 degree antenna connection 5 GHz Vertical antenna connection External antenna cable, path B 50 ohm RF cable, N-type 3.5 GHz +45 degree antenna connection 3.6 GHz...

  • Page 32: Table 6 Bhs Diagnostic Led Descriptions

    PTP 450 User Guide Backhaul Slave (BHS) Table 6 BHS diagnostic LED descriptions Status information provided Color BHS in BHS in “Aiming” Notes when “Operating” Mode active Mode Continuously lit when link is LNK/5 green Ethernet link present. Flashes during data transfer. Presence of data activity These five LEDs act ACT/4...

  • Page 33: Cabling And Lightning Protection

    BHMSs provide a grounding lug for grounding to the tower or support structure. The PTP 450 Series is not designed to survive direct lightning strikes. For this reason the unit should not be installed as the highest point in a localized area.

  • Page 34: Wireless Operation

    PTP 450 User Guide Wireless operation Wireless operation This section describes how the PTP 450 wireless link is operated, including modulation modes, power control and security. Time division duplexing The system uses Time Division Duplexing (TDD) – one channel alternately transmits and receives rather than using one channel for transmitting and a second channel for receiving.

  • Page 35: Ofdm And Channel Bandwidth

    MHz. Link operation – Dynamic Rate Adapt PTP 450 Series products offer five levels or speeds of operation – 1x (QPSK), 2x (QPSK-MIMO-B), 4x (16QAM- MIMO-B), 6x (64QAM-MIMO-B), and 8x (256QAM-MIMO-B). If received power is less due to distance between the BHM and the BHS or due to obstructions, or if interference affects the RF environment, the system will automatically and dynamically adjust links to the best operation level.

  • Page 36: Table 7 Link Budget Details - Dynamic Rate Adapt, 5.4 Ghz

    PTP 450 User Guide Wireless operation Table 7 Link Budget Details – Dynamic Rate Adapt, 5.4 GHz Performance Details Product Parameter Modulation QPSK-SISO QPSK-MIMO 16-QAM-MIMO 64-QAM-MIMO 256-QAM-MIMO with Integrated 5.4GHz Max. 4.8 mi / 7.68 km 3.4 mi / 5.44 km 1.5 mi / 2.4 km 0.7 mi / 1.12 km 0.2 mi / 0.32 km...

  • Page 37: Table 8 Link Budget Details - Dynamic Rate Adapt, 5.8 Ghz

    Wireless operation PTP 450 User Guide Table 8 Link Budget Details – Dynamic Rate Adapt, 5.8 GHz Performance Details Product Parameter Modulation QPSK-SISO QPSK-MIMO 16-QAM-MIMO 64-QAM-MIMO 256-QAM-MIMO with Integrated 12.1 mi / 19.36 5.8GHz Max. 8.6 mi / 13.76 km 3.8 mi / 6.08 km 1.6 mi / 2.56 km 0.5 mi / 0.8 km...

  • Page 38: Table 9 Link Budget Details - Dynamic Rate Adapt, 3.5Ghz

    PTP 450 User Guide Wireless operation Table 9 Link Budget Details – Dynamic Rate Adapt, 3.5GHz Performance Details Product Parameter Modulation QPSK-SISO QPSK-MIMO 16-QAM-MIMO 64-QAM-MIMO 256-QAM-MIMO with Integrated 16.1 mi / 25.76 16.1 mi / 25.76 3.5GHz Max. 7.2 mi / 11.52 km 3.2 mi / 5.12 km 1.1 mi / 1.76 km BHS antenna...

  • Page 39: Table 10 Link Budget Details - Dynamic Rate Adapt, 3.6Ghz

    Wireless operation PTP 450 User Guide Table 10 Link Budget Details – Dynamic Rate Adapt, 3.6GHz Performance Details Product Parameter Modulation QPSK-SISO QPSK-MIMO 16-QAM-MIMO 64-QAM-MIMO 256-QAM-MIMO with Integrated 15.3 mi / 24.48 15.3 mi / 24.48 3.6GHz Max. 7.1 mi / 11.36 km 3.2 mi / 5.12 km 1 mi / 1.6 km BHS antenna...

  • Page 40: Adaptive Modulation

    16 bits of throughput data transmitted, an additional bit is used. Encryption The Cambium PTP 450 Series supports optional encryption for data transmitted over the wireless link. The PTP 450 Series supports the following forms of encryption for security of the wireless link: ...

  • Page 41: System Management

    System management PTP 450 User Guide System management This section introduces the PTP 450 management system, including the web interface, installation, configuration, alerts and upgrades, and management software. Management agent PTP 450 equipment is managed through an embedded management agent. Management workstations, network management systems or PCs can be connected to this agent using the module’s Ethernet port or over-the air (BHS).

  • Page 42: Figure 11 Bhm Web-Based Management Screenshot

    PTP 450 User Guide System management Figure 11 BHM web-based management screenshot Web pages The web-based management interfaces provide comprehensive web-based fault, configuration, performance and security management functions organized into the following web-pages and groups: BHM web-pages:  Home: The Home web-page reports the general device status, session status, remote subscriber status, event log information, network interface status, and layer 2 neighbor information.
  • Page 43 System management PTP 450 User Guide  Accounts: These web-pages are used to configure device user accounts.  Quick Start: The Quick Start web-page provides a walkthrough of configuring radio parameters for initial operation.  Copyright: The Copyright web-page displays pertinent device copyright information. Subscriber Module web-pages: ...

  • Page 44: Snmp

    BHM as an NTP server. Wireless Manager (WM) Cambium Networks Wireless Manager 4.0 is recommended for managing PTP 450 networks. You can achieve better uptime through better visibility of your network with the Cambium Wireless Manager. This network...

  • Page 45: Capacity Upgrades

    Cambium’s Wireless Manager 4.0 available for download at: http://www.cambiumnetworks.com/support/management-tools/wireless-manager/ Canopy Network Updater Tool (CNUT) CNUT (Canopy Network Updater Tool) is the stand-alone software update tool for PTP 450 Series products. The Canopy Network Updater Tool:  automatically discovers all network elements ...

  • Page 46: Chapter 2: Planning Considerations

    PTP 450 User Guide System management Chapter 2: Planning considerations This chapter provides information to help the user to plan a PTP 450 network. The following topics are described in this chapter:  Regulatory planning on page 2-27 describes how to plan PTP 450 links to conform to the regulatory restrictions that apply in the country of operation.

  • Page 47: Regulatory Planning

    Regulatory planning PTP 450 User Guide Regulatory planning This section describes how to plan PTP 450 links to conform to the regulatory restrictions that apply in the country of operation. It is the responsibility of the user to ensure that the PTP product is operated in accordance with local regulatory limits.

  • Page 48: Network Migration Planning

    Network migration planning Network migration planning The PTP 450 Series offers current network operators the ability to migrate to PTP 450 for expanded network capacity and capability. The following sections are provided to aid in establishing a planning framework for deploying a PTP 450 system.
  • Page 49 Network migration planning PTP 450 User Guide Term Definition Existing Aggregate Tower Throughput The total amount of throughput, in Mbps, available in the (Mbps) current network deployment. The number of additional frequencies unused by the current Existing Additional Frequencies Available deployment that are available for usage by PTP 450 (MHz) equipment.

  • Page 50: Sector Capacity

    PTP 450 User Guide Network migration planning Sector capacity Deployment scenario 1 – Replacing PTP 100 Equipment (20 MHz Channel Bandwidth) In Deployment scenario 1, it is presumed that the existing network is comprised of PTP 1x0 equipment (i.e. PTP 100, PTP 120, etc.), with the configuration listed below in Table 12.

  • Page 51: Table 13 Scenario 1 Spectrum Usage

    Network migration planning PTP 450 User Guide Table 13 Scenario 1 spectrum usage Beginning Resulting frequency usage (assuming frequency usage no interference at band edges) 5725 5730 5735 FSK (A) MIMO (A) 5.740 GHz 5740 5745 5750 5755 FSK (B) MIMO (B) 5.760 GHz 5760 5765...
  • Page 52 PTP 450 User Guide Network migration planning Deployment scenario 1 migration procedure In Deployment scenario 1 migration procedure, it is presumed that that there are no temporary frequencies available and that the PTP 450 BHMs will replace the existing BHMs. Procedure 1a Deployment scenario 1 migration procedure Identify proximity to potential system interferers by running a spectrum analysis scan where the PTP 450 equipment is deployed.

  • Page 53: Table 14 Deployment Scenario 2

    Network migration planning PTP 450 User Guide Deployment scenario 2 – Replacing PTP 230 equipment (10 MHz Channel Bandwidth) In Deployment scenario 2, it is presumed that that the existing network is comprised of PTP 230 equipment with the configuration listed below in Table 14.

  • Page 54: Table 15 Deployment Scenario 2 Spectrum Usage

    PTP 450 User Guide Network migration planning Table 15 Deployment scenario 2 spectrum usage Beginning PTP 430 frequency usage Resulting PTP 450 frequency usage 5725 5730 5735 OFDM (A) MIMO (A) 5.740 GHz 5740 5745 OFDM (B) MIMO (B) 5.750 GHz 5750 5755 OFDM (C)

  • Page 55: Site Planning

    2-35. Maximum cable lengths When installing PTP 450 Series BHMs or BHSs, the maximum permitted length of the shielded copper Ethernet interface cable is 330 feet (100m) from BHM/BHS to their associated power supplies or uGPS. When receiving synchronization signalling from a uGPS module, see table below for maximum synchronization cable lengths.

  • Page 56: Wind Loading

    PTP 450 User Guide Site planning Wind loading Ensure that the site is not prone to excessive wind loading. Antennas and equipment mounted on towers or buildings will subject the mounting structure to significant lateral forces when there is appreciable wind. Antennas are normally specified by the amount of force (in pounds) for specific wind strengths.

  • Page 57: Table 18 Lateral Force - Us

    Lateral force (lb) at wind speed feet) (miles per hour) 0.29 (BHS) Capabilities of the PTP 450 Series The structure and mounting brackets of the BHM are capable of withstanding wind speeds up to:  190 kph (118 mph) – 5 GHz Sector Antennas ...

  • Page 58: Link Planning

    This information is necessary in order to achieve an accurate link feasibility assessment. The PTP 450 Series is designed to operate in Near-Line-of-Sight (nLOS), Non-Line-of-Sight (NLOS) and Line-of- Sight (LOS) environments. An NLOS environment is one in which there is no optical line-of-sight, that is, there are obstructions between the antennas.

  • Page 59: Table 19 Link Budget Details - 5.8 Ghz Ptp 450 Link, 20 Mhz Channel Bandwidth

    Link planning PTP 450 User Guide Table 19 Link budget details – 5.8 GHz PTP 450 link, 20 MHz Channel Bandwidth Range Details Product Parameter QPSK-MIMO- 16QAM- 64QAM-MIMO- 256QAM- Modulation QPSK-SISO MIMO-B MIMO-B with Integrated BHS 12.1 mi / 19.36 8.6 mi / 13.76 3.8 mi / 6.08 1.6 mi / 2.56 km...

  • Page 60: Table 20 Link Budget Details - 5.8 Ghz Ptp 450 Link, 10 Mhz Channel Bandwidth

    PTP 450 User Guide Link planning Table 20 Link budget details – 5.8 GHz PTP 450 link, 10 MHz Channel Bandwidth Range Details Product Parameter 16QAM- 64QAM-MIMO- 256QAM- Modulation QPSK-SISO QPSK-MIMO-B MIMO-B MIMO-B with Integrated BHS 17.7 mi / 28.32 12.5 mi / 20 km 5.5 mi / 8.8 km 2.5 mi / 4 km...

  • Page 61: Table 21 Link Budget Details - 5.8 Ghz Ptp 450 Link, 5 Mhz Channel Bandwidth

    Link planning PTP 450 User Guide Table 21 Link budget details – 5.8 GHz PTP 450 link, 5 MHz Channel Bandwidth Range Details Product Parameter QPSK-MIMO- 16QAM- 64QAM-MIMO- 256QAM- Modulation QPSK-SISO MIMO-B MIMO-B with Integrated BHS 20.3 mi / 32.48 14.4 mi / 23.04 7.3 mi / 11.68 3.6 mi / 5.76 km...

  • Page 62: Table 22 Link Budget Details - 5.4 Ghz Ptp 450 Link, 20 Mhz Channel Bandwidth

    PTP 450 User Guide Link planning Table 22 Link budget details – 5.4 GHz PTP 450 link, 20 MHz Channel Bandwidth Range Details Product Parameter 16QAM-MIMO- 64QAM-MIMO- 256QAM- Modulation QPSK-SISO QPSK-MIMO-B MIMO-B with Integrated BHS 4.8 mi / 7.68 km 3.4 mi / 5.44 km 1.5 mi / 2.4 km 0.7 mi / 1.12 km...

  • Page 63: Table 23 Link Budget Details - 5.4 Ghz Ptp 450 Link, 10 Mhz Channel Bandwidth

    Link planning PTP 450 User Guide Table 23 Link budget details – 5.4 GHz PTP 450 link, 10 MHz Channel Bandwidth Range Details Product Parameter 16QAM-MIMO- 64QAM-MIMO- 256QAM- Modulation QPSK-SISO QPSK-MIMO-B MIMO-B with Integrated BHS 4.3 mi / 6.88 km 3.1 mi / 4.96 km 1.6 mi / 2.56 km 0.7 mi / 1.12 km...

  • Page 64: Table 24 Link Budget Details - 5.4 Ghz Ptp 450 Link, 5 Mhz Channel Bandwidth

    PTP 450 User Guide Link planning Table 24 Link budget details – 5.4 GHz PTP 450 link, 5 MHz Channel Bandwidth Range Details Product Parameter 16QAM-MIMO- 64QAM-MIMO- 256QAM- Modulation QPSK-SISO QPSK-MIMO-B MIMO-B with Integrated BHS 4 mi / 6.4 km 2.8 mi / 4.48 km 1.4 mi / 2.24 km 0.9 mi / 1.44 km...

  • Page 65: Table 25 Link Budget Details - 3.5 Ghz Ptp 450 Link, 20 Mhz Channel Bandwidth

    Link planning PTP 450 User Guide Table 25 Link budget details – 3.5 GHz PTP 450 link, 20 MHz Channel Bandwidth Range Details Product Parameter QPSK-MIMO- 16QAM- 64QAM- 256QAM- Modulation QPSK-SISO MIMO-B MIMO-B MIMO-B with Integrated 16.1 mi / 25.76 16.1 mi / 25.76 7.2 mi / 11.52 3.2 mi / 5.12...

  • Page 66: Table 26 Link Budget Details - 3.5 Ghz Ptp 450 Link, 10 Mhz Channel Bandwidth

    PTP 450 User Guide Link planning Table 26 Link budget details – 3.5 GHz PTP 450 link, 10 MHz Channel Bandwidth Range Details Product Parameter QPSK-MIMO- 16QAM- 64QAM- 256QAM- Modulation QPSK-SISO MIMO-B MIMO-B MIMO-B with Integrated 22.7 mi / 36.32 22.7 mi / 36.32 10.1 mi / 16.16 5.1 mi / 8.16...

  • Page 67: Table 27 Link Budget Details - 3.5 Ghz Ptp 450 Link, 5 Mhz Channel Bandwidth

    Link planning PTP 450 User Guide Table 27 Link budget details – 3.5 GHz PTP 450 link, 5 MHz Channel Bandwidth Range Details Product Parameter QPSK-MIMO- 16QAM- 64QAM- 256QAM- Modulation QPSK-SISO MIMO-B MIMO-B MIMO-B with Integrated 27.9 mi / 44.64 27.9 mi / 44.64 14.1 mi / 22.56 7.2 mi / 11.52...

  • Page 68: Table 28 Link Budget Details - 3.6 Ghz Ptp 450 Link, 20 Mhz Channel Bandwidth

    PTP 450 User Guide Link planning Table 28 Link budget details – 3.6 GHz PTP 450 link, 20 MHz Channel Bandwidth Range Details Product Parameter QPSK-MIMO- 16QAM- 64QAM- 256QAM- Modulation QPSK-SISO MIMO-B MIMO-B MIMO-B with Integrated 15.3 mi / 24.48 15.3 mi / 24.48 7.1 mi / 11.36 3.2 mi / 5.12...

  • Page 69: Table 29 Link Budget Details - 3.6 Ghz Ptp 450 Link, 10 Mhz Channel Bandwidth

    Link planning PTP 450 User Guide Table 29 Link budget details – 3.6 GHz PTP 450 link, 10 MHz Channel Bandwidth Range Details Product Parameter QPSK-MIMO- 16QAM- 64QAM- 256QAM- Modulation QPSK-SISO MIMO-B MIMO-B MIMO-B with Integrated 21.8 mi / 34.88 21.8 mi / 34.88 9.7 mi / 15.52 5.4 mi / 8.64...

  • Page 70: Table 30 Link Budget Details - 3.6 Ghz Ptp 450 Link, 5 Mhz Channel Bandwidth

    PTP 450 User Guide Link planning Table 30 Link budget details – 3.6 GHz PTP 450 link, 5 MHz Channel Bandwidth Range Details Product Parameter QPSK-MIMO- 16QAM- 64QAM- 256QAM- Modulation QPSK-SISO MIMO-B MIMO-B MIMO-B with Integrated 28.4 mi / 45.44 28.4 mi / 45.44 14.2 mi / 22.72 5.7 mi / 9.12...

  • Page 71: Table 31 Link Budget Details - 5.8Ghz Ptp 450 Bhm And Ptp 430 Bhs Link, 20Mhz Channel Bandwidth

    Link planning PTP 450 User Guide Table 31 Link budget details – 5.8GHz PTP 450 BHM and PTP 430 BHS link, 20MHz Channel Bandwidth Range Details Product Parameter Modulation QPSK-SISO 16-QAM-SISO 64-QAM-SISO with Integrated 9.9 mi / 15.84 km 4.4 mi / 7.04 km 1.7 mi / 2.72 km BHS antenna with CLIP that...

  • Page 72: Table 32 Link Budget Details - 5.8Ghz Ptp 450 Bhm And Ptp 430 Bhs Link, 10Mhz Channel Bandwidth

    PTP 450 User Guide Link planning Table 32 Link budget details – 5.8GHz PTP 450 BHM and PTP 430 BHS link, 10MHz Channel Bandwidth Range Details Product Parameter Modulation QPSK-SISO 16-QAM-SISO 64-QAM-SISO with Integrated 12.4 mi / 19.84 km 6.2 mi / 9.92 km 2.4 mi / 3.84 km BHS antenna with CLIP that...

  • Page 73: Table 33 Link Budget Details - 5.8Ghz Ptp 450 Bhm And Ptp 430 Bhs Link, 5Mhz Channel Bandwidth

    Link planning PTP 450 User Guide Table 33 Link budget details – 5.8GHz PTP 450 BHM and PTP 430 BHS link, 5MHz Channel Bandwidth Range Details Product Parameter Modulation QPSK-SISO 16-QAM-SISO 64-QAM-SISO with Integrated 19.1 mi / 30.56 km 7.6 mi / 12.16 km 3 mi / 4.8 km BHS antenna with CLIP that adds...

  • Page 74: Table 34 Link Budget Details - 5.4Ghz Ptp 450 Bhm And Ptp 430 Bhs Link, 20Mhz Channel Bandwidth

    PTP 450 User Guide Link planning Table 34 Link budget details – 5.4GHz PTP 450 BHM and PTP 430 BHS link, 20MHz Channel Bandwidth Range Details Product Parameter Modulation QPSK-SISO 16-QAM-SISO 64-QAM-SISO with Integrated BHS 6.3 mi / 10.08 km 2.9 mi / 4.64 km 1 mi / 1.6 km antenna...

  • Page 75: Table 35 Link Budget Details - 5.4Ghz Ptp 450 Bhm And Ptp 430 Bhs Link, 10Mhz Channel Bandwidth

    Link planning PTP 450 User Guide Table 35 Link budget details – 5.4GHz PTP 450 BHM and PTP 430 BHS link, 10MHz Channel Bandwidth Range Details Product Parameter Modulation QPSK-SISO 16-QAM-SISO 64-QAM-SISO with Integrated BHS 5.3 mi / 8.48 km 2.7 mi / 4.32 km 1 mi / 1.6 km antenna...

  • Page 76: Table 36 Link Budget Details - 5.4Ghz Ptp 450 Bhm And Ptp 430 Bhs Link, 5Mhz Channel Bandwidth

    PTP 450 User Guide Link planning Table 36 Link budget details – 5.4GHz PTP 450 BHM and PTP 430 BHS link, 5MHz Channel Bandwidth Range Details Product Parameter Modulation QPSK-SISO 16-QAM-SISO 64-QAM-SISO with Integrated BHS 6.7 mi / 10.72 km 2.9 mi / 4.64 km 0.9 mi / 1.44 km antenna...

  • Page 77: Path Loss Considerations

    Link planning PTP 450 User Guide Path loss considerations Path loss is the amount of attenuation the radio signal undergoes between the two ends of the link. Calculating path loss The path loss is the sum of the attenuation of the path if there were no obstacles in the way (Free Space Path Loss), the attenuation caused by obstacles (Excess Path Loss) and a margin to allow for possible fading of the radio signal (Fade Margin).

  • Page 78: Calculating Link Loss

    PTP 450 User Guide Link planning Calculating Link Loss The link loss is the total attenuation of the wireless signal between two point-to-multipoint units. The link loss calculation is presented below: Link Loss (dB) = Transmit power of the remote wireless unit (dBm) − Tx Cable loss (dB) − Received power at the local unit (dBm) –...

  • Page 79: Calculating Fade Margin

    Analyzing the RF Environment PTP 450 User Guide Calculating Fade Margin Free space path loss is a major determinant in Rx (received) signal level. Rx signal level, in turn, is a major factor in the system operating margin (fade margin), which is calculated as follows: ...

  • Page 80: Anticipating Reflection Of Radio Waves

    PTP 450 User Guide Analyzing the RF Environment After 10 seconds, the results are displayed: Travel to another location in the area. Click Start Timed Spectrum Analysis Repeat Steps 6 and 7 until the area has been adequately scanned and logged. As with any other data that pertains to your business, a decision today to put the data into a retrievable database may grow in value to you over time.

  • Page 81: Multiple Ofdm Bhm Clusters

    Analyzing the RF Environment PTP 450 User Guide Multiple OFDM BHM Clusters When deploying multiple BHM clusters in a dense area, consider aligning the clusters as shown below. However, this is only a recommendation. An installation may dictate a different pattern of channel assignments. Figure 13 Example layout of 16 BHM sectors (ABCD), 90 degree sectors An example for assignment of frequency channels is provided in the following table.

  • Page 82: Figure 14 Example Layout Of 16 Bhm Sectors (Abc), 60 Degree Sectors

    PTP 450 User Guide Analyzing the RF Environment Figure 14 Example layout of 16 BHM sectors (ABC), 60 degree sectors An example for assignment of frequency channels and sector IDs is provided in the following table. See section Network migration planning on page 2-28 for more information on migrating to a PTP 450 network.

  • Page 83: Planning For Co-Location And Using The Ofdm Frame Calculator Tool

    BHM Receive Start for all collocated BHMs are within 300 bit times; if possible, within 150 bit times. In Cambium Point-to-Multipoint systems, 10 bit times = 1 µs. The calculator does not use values in the module or populate its parameters. It is merely a convenience application that runs on a module.

  • Page 84: Figure 15 Ofdm Frame Calculator Tab

    Downlink Data parameter of all BHMs in the cluster. PTP 450 Series BHMs offer a range of 15% to 85%, and default to 75%. The value that you set in this parameter has the following interaction with...

  • Page 85: Table 40 Ofdm Calculated Frame Results Attributes

    Analyzing the RF Environment PTP 450 User Guide The Calculated Frame Results display several items of interest: Table 40 OFDM Calculated Frame Results attributes Attribute Meaning Modulation The type of radio modulation used in the calculation (OFDM for PTP 450) Total Frame Bits The total number of bits used in the calculated frames Data Slots (Down/Up)

  • Page 86: Selecting Sites For Network Elements

    PTP 450 User Guide Selecting Sites for Network Elements To use the Frame Calculator to ensure that all BHMs are configured to transmit and receive at the same time, follow the below procedure: Procedure 4 Using the Frame Calculator Populate the OFDM Frame Calculator parameters with appropriate values as described above.

  • Page 87: Surveying Sites

    Selecting Sites for Network Elements PTP 450 User Guide Surveying Sites Factors to survey at potential sites include  what pre-existing wireless equipment exists at the site. (Perform spectrum analysis.)  whether available mounting positions exist near the lowest elevation that satisfies line of site, coverage, and other link criteria.

  • Page 88: Calculating The Aim Angles

    PTP 450 User Guide Selecting Sites for Network Elements Calculating the Aim Angles The proper angle of tilt can be calculated as a factor of both the difference in elevation and the distance that the link spans. Even in this case, a plumb line and a protractor can be helpful to ensure the proper tilt. This tilt is typically minimal.

  • Page 89: Diagramming Network Layouts

    Diagramming Network Layouts PTP 450 User Guide Diagramming Network Layouts Avoiding Self Interference The following section includes information maximizing tower performance by minimizing self-interference. Physical Proximity Two BHM clusters co-located on the same tower require a CMM. The CMM properly synchronizes the transmit start times of all modules to prevent interference and de-sensing of the modules.

  • Page 90: Avoiding Other Interference

    PTP 450 User Guide Diagramming Network Layouts Avoiding Other Interference Where signal strength cannot dominate noise levels, the network experiences  packet errors and retransmissions.  lower throughput (because bandwidth is consumed by retransmissions) and high latency (due to resends). Regular spectrum analysis is critical to RF planning.

  • Page 91: Grounding And Lightning Protection

    Structures, equipment and people must be protected against power surges (typically caused by lightning) by conducting the surge current to ground via a separate preferential solid path. The actual degree of protection required depends on local conditions and applicable local regulations. Cambium recommends that PTP 450 installation is contracted to a professional installer.

  • Page 92: General Protection Requirements

    PTP 450 User Guide Grounding and lightning protection Assess locations on masts, towers and buildings to determine if the location is in Zone A or Zone B:  Zone A: In this zone a direct lightning strike is possible. Do not mount equipment in this zone. ...

  • Page 93: Protection Requirements For A Mast Or Tower Installation

    Grounding and lightning protection PTP 450 User Guide Figure 18 Grounding cable minimum bend radius and angle Protection requirements for a mast or tower installation If the BHM or BHS is to be mounted on a metal tower or mast, then in addition to the general protection requirements (above), the following requirements must be observed: ...

  • Page 94: Protection Requirements On A High Rise Building

    PTP 450 User Guide Grounding and lightning protection Protection requirements on a high rise building If the BHM is to be mounted on a high rise building, it is likely that cable entry is at roof level (Figure 20) and the equipment room is several floors below (Figure 21).

  • Page 95: Figure 21 Grounding And Lightning Protection Inside High Building

    Grounding and lightning protection PTP 450 User Guide Protection inside a high rise building The following protection requirements must be observed inside multi-story or high rise buildings (Figure 21):  The drop cable shield must be bonded to the building grounding system at the entry point to the building. ...

  • Page 96: Configuration Options For Tdd Synchronization

    PTP 450 User Guide Configuration options for TDD synchronization Configuration options for TDD synchronization The PTP 450 system uses Time Division Duplexing (TDD) - one channel alternately transmits and receives - rather than using one channel for transmitting and a second channel for receiving. To accomplish TDD, the BHM must provide sync to its BHSs –...

  • Page 97: Figure 22 One Unsynchronized Bhm In Cluster Resulting In Self-Interference

    Configuration options for TDD synchronization PTP 450 User Guide Figure 22 One unsynchronized BHM in cluster resulting in self-interference Time The result is self-interference. In this scenario, the self-interference can be avoided only by synchronizing the TDD transmit cycles of all BHMs that operate in the same frequency band. An BHM that is isolated by at least 5 miles (8 km) from any other equipment can generate and pass sync pulse without GPS timing and not risk that interference will result from the generated sync.

  • Page 98: Data Network Planning

    PTP 450 User Guide Data network planning Data network planning This section describes factors to be considered when planning PTP 450 data networks. Understanding addresses A basic understanding of Internet Protocol (IP) address and subnet mask concepts is required for engineering your IP network.

  • Page 99: Network Address Translation (Nat)

    IP addresses to devices that are connected to the Ethernet/wired side of the BHS. In the Cambium system, NAT supports many protocols, including HTTP, ICMP (Internet Control Message Protocols), and FTP (File Transfer Protocol). For virtual private network (VPN) implementation, L2TP over IPSec (Level 2 Tunneling Protocol over IP Security) and PPTP (Point to Point Tunneling Protocol) are supported.

  • Page 100: Developing An Ip Addressing Scheme

    DHCP enables a device to be assigned a new IP address and TCP/IP parameters, including a default gateway, whenever the device reboots. Thus DHCP reduces configuration time, conserves IP addresses, and allows modules to be moved to a different network within the Cambium system. In conjunction with the NAT features, each BHS provides ...

  • Page 101: Translation Bridging

    Data network planning PTP 450 User Guide Example IP address and subnet mask Figure 25 the first 16 bits of the 32-bit IP address identify the network: Figure 25 Example of IP address in Class B subnet Octet 1 Octet 2 Octet 3 Octet 4 IP address 169.254.1.1...

  • Page 102: Engineering Vlans

    PTP 450 User Guide Data network planning This is the Translation Bridging feature, which you can enable in the General tab of the Configuration web page in the BHM. When this feature is disabled, the setting of the Send Untranslated ARP parameter has no effect, because all packets are forwarded untranslated (with the source MAC address intact).

  • Page 103: Table 42 Vlan Filters In Point-To-Multipoint Modules

    Data network planning PTP 450 User Guide PTP modules provide the VLAN frame filters that are described in Table Table 42 VLAN filters in point-to-multipoint modules then a frame is discarded if… Where VLAN is active, entering the bridge/ because of this VLAN if this parameter NAT switch through…...

  • Page 104: Table 43 Q-In-Q Ethernet Frame

    PTP 450 User Guide Data network planning Q-in-Q DVLAN (Double-VLAN) Tagging (802.1ad) PTP modules can be configured with 802.1ad Q-in-Q DVLAN (Double-VLAN) tagging which is a way for an operator to put an 802.1Q VLAN inside of an 802.1ad VLAN. A nested VLAN, which is the original 802.1Q tag and a new second 802.1ad tag, allows for bridging of VLAN traffic across a network and segregates the broadcast domains of 802.1Q VLANs.

  • Page 105: Security Planning

    Security planning PTP 450 User Guide Security planning This section describes how to plan for PTP 450 networks to operate in secure mode. Isolating BHMs from the Internet Ensure that the IP addresses of the BHMs in your network  are not routable over the Internet.

  • Page 106: Table 44 Identity-Based User Account Permissions - Bhm

    PTP 450 User Guide Security planning From the factory default state, configure passwords for both the root and admin account at the ADMINISTRATOR permission level, using the Account => Change Users Password tab. (If you configure only one of these, then the other will still require no password for access into it and thus remain a security risk.) If you are intent on configuring only one of them, delete the admin account.
  • Page 107 Security planning PTP 450 User Guide Overload DHCP Relay Pass Through Statistics DNS Statistics Tools Link Capacity Test OFDM Frame Calculator BH Configuration Link Status Remote Spectrum Analyzer Sessions DNS Test BHM Sessions Accounts Change User Password Add User Delete User Quick Start Quick Start Region Settings...

  • Page 108: Table 45 Identity-Based User Account Permissions - Bhs

    PTP 450 User Guide Security planning Table 45 Identity-based user account permissions - BHS Menu Menu Tab ADMIN INSTALLER TECH Home General Status Event Log Network Interface Layer2 Neighbors Configuration General Radio SNMP Quality of Service (QoS) Security VLAN VLAN Membership DiffServ Protocol Filtering Port Configuration...

  • Page 109: Filtering Protocols And Ports

    Security planning PTP 450 User Guide Alignment Link Capacity Test BHM Evaluation OFDM Frame Calculator BER Results Alignment Tool Link Status DNS Test Logs NAT Table BHS Session PPPoE Session Log Accounts Change User Password Add User Delete User Quick Status Spectrum Results (PDA) Information BHM Evaluation...
  • Page 110 PTP 450 User Guide Security planning  To block a subscriber from access to SNMP, you can filter Ports 161 and 162 (the SNMP ports) for both the TCP and UDP protocols. NOTE: In only the SNMP case, filtering occurs before the packet interacts with the protocol stack. Protocol and Port Filtering with NAT Disabled Where NAT is disabled on the BHS, you can filter both protocols and the three user-defined ports.

  • Page 111: Figure 26 Categorical Protocol Filtering

    Security planning PTP 450 User Guide Figure 26 Categorical protocol filtering BootP BootP Server Client IPv4 SNMP Multica Other IPv4 User Defined Port 1 User User Defined Defined Port 2 Port 3 PPPoE Others The following are example situations in which you can configure protocol filtering where NAT is disabled: ...

  • Page 112: Port Lockdown

    Security planning Port Lockdown Cambium devices support access to various communication protocols and only the ports required for these protocols are available for access by external entities. Operators may change the port numbers for these protocols via the radio GUI or SNMP.

  • Page 113: Configuring Management Ip By Dhcp

    IP tab of the Configuration web page, but only if the Network Accessibility parameter in the IP tab is set to Public. Planning for airlink security Cambium fixed wireless broadband IP systems employ the following form of encryption for security of the wireless link: ...

  • Page 114: Planning For Snmp Security

    PTP 450 User Guide Security planning Planning for SNMP security Canopy modules provide the following Configuration web page parameters in the SNMP tab. These govern SNMP access from the manager to the agent:  Community String, which specifies the password for security between managers and the agent. ...

  • Page 115: Ordering Components

    PTP 450 User Guide Ordering components This section describes how to select components for PTP 450 Greenfield network or PTP 450 network migration. It specifies Cambium part numbers for PTP 450 components. PTP 450 component part numbers Table 48 PTP 450 components...
  • Page 116 PTP 450 User Guide Ordering components C036045C006A 3.6 GHz PTP 450 Connectorized Subscriber Module, 10 Mbps C036045C007A 3.6 GHz PTP 450 Connectorized Subscriber Module, 20 Mbps C036045C008A 3.6 GHz PTP 450 Connectorized Subscriber Module, Uncapped C054045A001A 5 GHz PTP 450 Connectorized BHM C054045A002A 5 GHz PTP 450 Connectorized BHM, US only C054045A003A...
  • Page 117 Ordering components PTP 450 User Guide 600SSH SURGE PROTECTOR 1096H UNIVERSAL GPS MODULE BHS Optional Equipment ACPSSW-09B POWER SUPPLY,13.6W, 29.5V, 100-240VAC/50-60HZ ACPSSW-10B POWER SUPPLY,13.6W,29.5V,100-240VAC/50-60HZ+ARG ACPSSW-11B POWER SUPPLY, 13.6W,29.5V,100-240VAC/50-60HZ+AUS ACPSSW-12C POWER SUPPLY,ASSY,P/S,29.5V90-240VAC/50-60HZ PS ACPSSW-13B POWER SUPPLY,13.6W,29.5V,100-240/50-60+FIXED US ACPSSW-14A POWER SUPPLY,13.6W,29.5V,100-240VAC/50-60HZ+BRAZ C050000D001A 5 GHz CLIP (Cassegrain Lens for Improved Performance) HK2022A 53CM OFFSET, REFLECTOR DISH KIT,4PK...
  • Page 118 PTP 450 User Guide Ordering components PTP450 BHM Extended Warranty, 1 Additional Year PTP450 BHM Extended Warranty, 2 Additional Years SG00TS4025A PTP450 BHM Extended Warranty, 4 Additional Years SG00TS4010A PTP450 BHS Extended Warranty, 1 Additional Year SG00TS4018A PTP450 BHS Extended Warranty, 2 Additional Years SG00TS4026A PTP450 BHS Extended Warranty, 4 Additional Years ptp-450 (July 2014)

  • Page 119: Chapter 3: Legal Information

    Any such modifications could void the user’s authority to operate the equipment and will void the manufacturer’s warranty. The following topics are described in this chapter:  Cambium Networks end user license agreement on page 3-100 ...

  • Page 120: Cambium Networks End User License Agreement

    In connection with Cambium’s delivery of certain proprietary software or products containing embedded or pre- loaded proprietary software, or both, Cambium is willing to license this certain proprietary software and the accompanying documentation to you only on the condition that you accept all the terms in this End User License Agreement (“Agreement”).

  • Page 121: Title And Restrictions

    Title and copyrights to the Software and Documentation and any copies made by you remain with Cambium and its licensors. You will not, and will not permit others to: (i) modify, translate, decompile, bootleg, reverse engineer, disassemble, or extract the inner workings of the Software or Documentation, (ii) copy the look-and-feel or functionality of the Software or Documentation;...

  • Page 122: Confidentiality

    Except as required in “Conditions of use”, you will not, during the term of this Agreement or thereafter, use any trademark of Cambium, or any word or symbol likely to be confused with any Cambium trademark, either alone or in any combination with another word or words.

  • Page 123: Maintenance

    Cambium Networks end user license agreement PTP 450 User Guide Maintenance Except as provided above, Cambium is not responsible for maintenance or field service of the Software under this Agreement. Disclaimer CAMBIUM DISCLAIMS ALL WARRANTIES OF ANY KIND, WHETHER EXPRESS, IMPLIED, STATUTORY, OR IN ANY COMMUNICATION WITH YOU.

  • Page 124: U.s. Government

    Software will terminate immediately without notice upon a breach of this Agreement by you. Within 30 days after termination of this Agreement, you will certify to Cambium in writing that through your best efforts, and to the best of your knowledge, the original and all copies, in whole or in part, in any form, of the Software and all related material and Documentation, have been destroyed, except that, with prior written consent from Cambium, you may retain one copy for archival or backup purposes.

  • Page 125: Entire Agreement

    Entire agreement This agreement contains the parties’ entire agreement regarding your use of the Software and may be amended only in writing signed by both parties, except that Cambium may modify this Agreement as necessary to comply with applicable laws.
  • Page 126 PTP 450 User Guide Cambium Networks end user license agreement Modernizr Copyright Notice MIT License Copyright © 2009-2010 Faruk Ates Permission is hereby granted, free of charge, to any person obtaining a copy of this software and associated documentation files (the "Software"), to deal in the Software without restriction, including without limitation the...
  • Page 127 Cambium Networks end user license agreement PTP 450 User Guide  The name Michael Bostock may not be used to endorse or promote products derived from this software without specific prior written permission. THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS "AS IS" AND...

  • Page 128: Hardware Warranty

    Hardware warranty Hardware warranty Cambium’s standard hardware warranty is for one (1) year from date of shipment from Cambium or a Cambium Point-To-Point Distributor. Cambium warrants that hardware will conform to the relevant published specifications and will be free from material defects in material and workmanship under normal use and service. Cambium shall within this time, at its own option, either repair or replace the defective product within thirty (30) days of receipt of the defective product.

  • Page 129: Limit Of Liability

    PTP 450 User Guide Limit of liability IN NO EVENT SHALL CAMBIUM NETWORKS BE LIABLE TO YOU OR ANY OTHER PARTY FOR ANY DIRECT, INDIRECT, GENERAL, SPECIAL, INCIDENTAL, CONSEQUENTIAL, EXEMPLARY OR OTHER DAMAGE ARISING OUT OF THE USE OR INABILITY TO USE THE PRODUCT (INCLUDING, WITHOUT...

  • Page 130: Chapter 4: Reference Information

    PMP 450 Configuration and User Guide Glossary Chapter 4: Reference information This chapter contains reference information and regulatory notices that apply to the PTP 450 Series products. The following topics are described in this chapter:  Equipment specifications on page...

  • Page 131: Equipment Specifications

    5 GHz Channel Width 5 MHz (3.5 GHz, 3.6 GHz and 5.8 GHz only), 10 MHz or 20 MHz Interface MAC (Media Access Cambium Proprietary Control) Layer Physical Layer 2x2 MIMO OFDM Ethernet Interface 10/100BaseT, half/full duplex, rate auto negotiated (802.3 compliant)
  • Page 132 PMP 450 Configuration and User Guide Glossary Category Specification VLAN 802.1ad (DVLAN Q-inQ), 802.1Q with 802.1p priority, dynamic port VID Performance Nominal Receive Sensitivity 3.5 GHz OFDM: 1x = -89 dBm, 2x = -89 dBm, 4x = -83 dBm, 6x = -76 dBm, 8x = -68 (w/ FEC) @ 5 MHz 3.6 GHz...
  • Page 133 PMP 450 Configuration and User Guide Glossary Category Specification 5 GHz Up to 40 km (25 mi) Subscribers Per Sector Up to 238 Cyclic Prefix 1/16 Modulation Levels QPSK, QPSK (MIMO-B), 16-QAM (MIMO-B), 64-QAM (MIMO-B), 256- (Adaptive) QAM (MIMO-B) Latency 3 - 5 ms Packets Per Second 12, 500...
  • Page 134 PMP 450 Configuration and User Guide Glossary Category Specification Temperature -40ºC to +55ºC (-40ºF to +131ºF) Weight 3.5 GHz 15 kg (33 lbs) with antenna 2.5 kg (5.5 lbs) without antenna 3.6 GHz 15 kg (33 lbs) with antenna 2.5 kg (5.5 lbs) without antenna 5 GHz 5.9 kg (13 lbs) with antenna 2.5 kg (5.5 lbs) without antenna...

  • Page 135: Bhs Specifications

    5470 – 5875 MHz (dependent upon Region Code setting) 5 GHz Channel Width 5 MHz (3.5GHz, 3.6GHz and 5.8GHz only), 10 MHz or 20 MHz Interface MAC (Media Access Cambium Proprietary Control) Layer Physical Layer 2x2 MIMO OFDM Ethernet Interface 10/100BaseT, half/full duplex, rate auto negotiated (802.3 compliant)
  • Page 136 PMP 450 Configuration and User Guide Glossary Category Specification Maximum Deployment 3.5 GHz Up to 40 km (25 mi) with reflector dish Range 3.6 GHz Up to 40 km (25 mi) with reflector dish 5 GHz Up to 40 km (25 mi) with reflector dish Cyclic Prefix 1/16 Modulation Levels...
  • Page 137 PMP 450 Configuration and User Guide Glossary Category Specification Environmental IP55 Temperature -40ºC to +55ºC (-40ºF to +131ºF) Weight 0.45 kg (1 lb) 30 x 9 x 9 cm (11.75” x 3.4” x 3.4”) Dimensions (H x W x D) Maximum Power 12 W Consumption...

  • Page 138: Wireless Specifications

    PMP 450 Configuration and User Guide Glossary Wireless specifications This section contains specifications of the PTP 450 wireless interface. These specifications include RF bands, channel bandwidth, spectrum settings, maximum power and link loss. General wireless specifications Wireless specifications that apply to all PTP 450 variants are listed in Table Table 51 PTP 450 wireless specifications Item...

  • Page 139: Data Network Specifications

    PMP 450 Configuration and User Guide Glossary Data network specifications This section contains specifications of the PTP 450 Ethernet interface. Ethernet interface The PTP 450 Ethernet port conforms to the specifications listed in Table Table 52 PTP 450 Ethernet bridging specifications Ethernet Bridging Specification Protocol...

  • Page 140: Compliance With Safety Standards

    PMP 450 Configuration and User Guide Glossary Compliance with safety standards This section lists the safety specifications against which the PTP 450 has been tested and certified. It also describes how to keep RF exposure within safe limits. Electrical safety compliance The PTP 450 hardware has been tested for electrical safety specifications compliance listed in Table Table 53 PTP 450 safety compliance specifications...
  • Page 141 PMP 450 Configuration and User Guide Glossary  US FCC limits for the general population. See the FCC web site at http://www.fcc.gov, and the policies, guidelines, and requirements in Part 1 of Title 47 of the Code of Federal Regulations, as well as the guidelines and suggestions for evaluating compliance in FCC OET Bulletin 65.
  • Page 142 PMP 450 Configuration and User Guide Glossary Calculated distances and power compliance margins The calculated minimum separation distances, recommended distances and resulting margins for each frequency band and antenna combination is shown in Table 55. These are conservative distances that include compliance margins.

  • Page 143: Table 55 Power Compliance Margins

    PMP 450 Configuration and User Guide Glossary Table 55 Power Compliance Margins Frequency Antenna Variable Recommended Power Band Separation Compliance Distance Margin 5 GHz OFDM Integrated BHS, 9 0.158 W 10 W/m 10 cm 20 cm 40.27 dBi patch (22 dBm) (9 dB) (8 in) or 1 mW/cm...

  • Page 144: Compliance With Radio Regulations

    Compliance with radio regulations This section describes how the PTP 450 complies with the radio regulations that are enforced in various countries. Changes or modifications not expressly approved by Cambium could void the user’s authority to operate the system. Type approvals This system has achieved Type Approval in various countries around the world.

  • Page 145: Dfs For 5.4 Ghz Radios

    PMP 450 Configuration and User Guide Glossary DFS for 5.4 GHz Radios Dynamic Frequency Selection (DFS) is a requirement in several countries and regions for 5 GHz unlicensed systems to detect radar systems and avoid co-channel operation. DFS and other regulatory requirements drive the settings for the following parameters, as discussed in this section: ...

  • Page 146: Table 57 Ofdm Dfs Operation Based On Country Code Setting

    PMP 450 Configuration and User Guide Glossary Table 57 OFDM DFS operation based on Country Code setting Region Country Band Weather Code Code Radar Notch- ETSI EN 301 893 ETSI EN 301 893 Vietnam 5.4-GHz v1.6.1 DFS v1.6.1 DFS Asia India, Vietnam, 5.8-GHz...

  • Page 147: Country Codes And Available Spectrum

    PMP 450 Configuration and User Guide Glossary Region Country Band Weather Code Code Radar Notch- 5.8-GHz No effect No effect ETSI EN 301 893 ETSI EN 301 893 5.4-GHz v1.6.1 DFS v1.6.1 DFS Other-ETSI ETSI EN 302 502 ETSI EN 302 502 5.8-GHz v1.2.1 DFS v1.2.1 DFS...

  • Page 148: Table 58 Center Channel Details Based On Country Code, 3.5 Ghz

    PMP 450 Configuration and User Guide Glossary Table 58 Center channel details based on Country Code, 3.5 GHz # of Non- # of Center overlapping center Range of Center Center Channel Band Edges Channels (based channels (based Region Country Frequencies Channel Size (MHz)

  • Page 149: Table 59 Bhm Default Combined Tx Power Per Country Code And Channel Bandwidth, 3.5 Ghz

    PMP 450 Configuration and User Guide Glossary Table 59 BHM Default combined Tx power per Country Code and Channel Bandwidth, 3.5 GHz. Country Antenna Device Country Gain (dBi) Code Setting (Level 2) 5 MHz Channel 10 MHz Channel 20 MHz Channel Bandwidth (dBm) Bandwidth (dBm) Bandwidth (dBm)

  • Page 150: Table 60 Center Channel Details Based On Country Code, 3.6 Ghz

    PMP 450 Configuration and User Guide Glossary Table 60 Center channel details based on Country Code, 3.6 GHz # of Non- # of Center overlapping center Range of Center Center Channel Band Edges Channels (based channels (based on Region Country Frequencies Channel Size...

  • Page 151: Table 61 Bhm Default Combined Tx Power Per Country Code And Channel Bandwidth, 3.6 Ghz

    PMP 450 Configuration and User Guide Glossary Table 61 BHM Default combined Tx power per Country Code and Channel Bandwidth, 3.6 GHz. Country Antenna Device Country Gain (dBi) Code Setting (Level 2) 5 MHz Channel 10 MHz Channel 20 MHz Channel Bandwidth (dBm) Bandwidth (dBm) Bandwidth (dBm)

  • Page 152: Table 62 Center Channel Details Based On Country Code, 5.4 Ghz

    PMP 450 Configuration and User Guide Glossary Table 62 Center channel details based on Country Code, 5.4 GHz Region # of Non- Country Code # of Center Code Range of overlapping Center Channels Channel Band Edges Center center channels Channel (based on PTP Size (MHz)
  • Page 153 PMP 450 Configuration and User Guide Glossary Region # of Non- Country Code # of Center Code Range of overlapping Center Channels Channel Band Edges Center center channels Channel (based on PTP Size (MHz) Frequencies (based on PTP Spacing 450 available Level 1 Level 2 Available (MHz)

  • Page 154: Table 63 Center Channel Details Based On Country Code, 5.8 Ghz

    PMP 450 Configuration and User Guide Glossary Table 63 Center channel details based on Country Code, 5.8 GHz OFDM Country Channel Band Edges Range of Center Center # of Center # of Non- Radio Size (MHz) Frequencies Channel Channels overlapping center Model Available (MHz) Spacing...
  • Page 155 PMP 450 Configuration and User Guide Glossary 20 MHz 5835 - 5865 5 MHz 5727.5 – 5847.5 Brazil, Vietnam 10 MHz 5725 – 5850 5730 – 5845 20 MHz 5735 - 5840 5 MHz 5727.5 – 5822.5 Indonesia 10 MHz 5725 - 5825 5730 –...

  • Page 156: Table 64 Default Combined Transmit Power Per Country Code - 5.4 Ghz Band

    PMP 450 Configuration and User Guide Glossary Table 64 Default combined transmit power per Country Code – 5.4 GHz band Combined Combined Antenna BHM EIRP BHM EIRP TX Default TX Default Gain (dBi) Limit Limit Device Country Setting Setting Country (18 dBi –...
  • Page 157 PMP 450 Configuration and User Guide Glossary Combined Combined Antenna BHM EIRP BHM EIRP TX Default TX Default Gain (dBi) Limit Limit Device Country Setting Setting Country (18 dBi – Code Setting 1dB cable 10 MHz Channel Bandwidth 20 MHz Channel loss) (dBm) Bandwidth (dBm)

  • Page 158: Table 65 Default Combined Transmit Power Per Country Code - 5.8 Ghz Band

    PMP 450 Configuration and User Guide Glossary Table 65 Default combined transmit power per Country Code – 5.8 GHz band Country Antenna Device Gain Country (dBi) Code Setting (18 dBi – 5 MHz Channel 10 MHz Channel 20 MHz Channel 1dB cable Bandwidth Bandwidth (dBm)
  • Page 159 Once it detects beacon, the BHS/BHS begins a Channel Availability Check on that frequency. Regulatory Note: A PTP 450 Series BHM with a Country Code set to United States will not be configurable to another Country Code by installers or end users. This is in response to FCC KDB 594280 and ensures that end users and professional installers will not have access to settings which could allow a radio to be configured to operate in a manner other than that which was specified in the FCC equipment authorization grant.

  • Page 160: Fcc Compliance Testing

    Notwithstanding that Cambium has designed (and qualified) the PTP 450 products to generally meet the Class B requirement to minimize the potential for interference, the PTP 450 product range is not marketed for use in a residential environment.
  • Page 161 PMP 450 Configuration and User Guide Glossary FCC ID Industry Module Frequencies Antenna Maximum Canada Families (OFDM) Combined Cert Tx Output Number Power 10 MHz channels, centered on 3455 – 3645 in 50 kHz increments (within the 3300 – 3600 MHz ISM band) 5 MHz channels, centered on 3452.5 - 3647.5 in 50 kHz increments (within the 3300 –...
  • Page 162 PMP 450 Configuration and User Guide Glossary FCC ID Industry Module Frequencies Antenna Maximum Canada Families (OFDM) Combined Cert Tx Output Number Power 20 MHz channels, centered on 5480 – 5590; 5660 – 5715 in 2.5 MHz 13 dBm increments (within the 5470 – 5600; 5650 –...
  • Page 163 PMP 450 Configuration and User Guide Glossary FCC ID Industry Module Frequencies Antenna Maximum Canada Families (OFDM) Combined Cert Tx Output Number Power 8 dBi Integrated 25 dBm 8 dBi Integrated 20 MHz channels, centered on 3560 – with 11 dBi 25 dBm 3690 in 50 kHz increments (within the Reflector Dish...
  • Page 164 PMP 450 Configuration and User Guide Glossary FCC ID Industry Module Frequencies Antenna Maximum Canada Families (OFDM) Combined Cert Tx Output Number Power 9 dBi Integrated with 5.5 dBi LENS 9 dBi Integrated with 8 dBi CLIP 9 dBi Integrated 9 dBi Integrated with 14 dBi Reflector Dish...

  • Page 165: Listen Before Talk (Lbt) For 3.6 Ghz Radios

    PMP 450 Configuration and User Guide Glossary Listen Before Talk (LBT) for 3.6 GHz Radios In the Unites States the 3650-3700 MHz band is licensed on a non-exclusive basis. Operators have the responsibility to minimize the potential of interference to deployed systems. Standards In FCC Part 90, Subpart Z , the FCC requires that all systems implement a contention-based protocol...
  • Page 166 PMP 450 Configuration and User Guide Glossary LBT detection threshold calculation The energy detection threshold used for LBT is proportional to the maximum transmit power of the transmitter. For a 23 dBm EIRP transmitter the detection threshold is -73 dBm/MHz at the receiver’s input (assuming a 0 dBi receive antenna).

  • Page 167: Notifications

    PMP 450 Configuration and User Guide Glossary Notifications This section contains notifications of compliance with the radio regulations that are enforced in various regions. PTP 450 regulatory compliance The PTP 450 complies with the regulations that are enforced in the USA and Canada. The relevant notifications are specified in this section.
  • Page 168 Hereby, Cambium declares that the 5.4 and 5.8 GHz product complies with the essential requirements and other relevant provisions of Directive 1999/5/EC. The relevant Declaration of Conformity can be found at http://www.cambiumnetworks.com/support/ec-doc.
  • Page 169 5470 to 5725 MHz U-NII band with 5600 to 5650 MHz excluded. Cambium Radio equipment operating in the 5470 to 5725 MHz band are categorized as “Class 1” devices within the EU in accordance with ECC DEC(04)08 and are “CE” marked to show compliance with the European Radio &...
  • Page 170 PMP 450 Configuration and User Guide Glossary Luxembourg Notification 5.4GHz products can only be used for mobile services. Czech Republic Notification 5.4 GHz products can be operated in accordance with the Czech General License No. GL-30/R/2000. Italy Notification In Italy, there is a regulation which requires a general authorization of any 5.4 GHz radio link which is used outside the operator’s own premises.

  • Page 171: Appendix A: Glossary

    169.254.1.1 IP address default in Cambium fixed wireless broadband IP network modules. 255.255.0.0 Subnet mask default in Cambium fixed wireless broadband IP network modules and in Microsoft and Apple operating systems. 802.3 An IEEE standard that defines the contents of frames that are transferred through Ethernet connections.
  • Page 172 Committed Information Rate. For an BHS or specified group of BHSs, a level of bandwidth that can be guaranteed to never fall below a specified minimum (unless oversubscribed). In the Cambium implementation, this is controlled by the Low Priority Uplink CIR, Low Priority Downlink CIR, High Priority Uplink CIR, and High Priority Downlink CIR parameters.
  • Page 173 The value is a numeric code point. Cambium modules map each of 64 code points to values of 0 through 7. Three of these code points have fixed values, and the remaining 61 are settable.
  • Page 174 PMP 450 Configuration and User Guide Glossary Dynamic Frequency A requirement in certain countries and regions for systems to detect interferences from Selection other systems, notably radar systems and to avoid co-channel operation with these systems. Dynamic Host See DHCP. Configuration Protocol Electronic Serial...
  • Page 175 PMP 450 Configuration and User Guide Glossary Global Positioning Network of satellites that provides absolute time to networks on earth, which use the System time signal to synchronize transmission and reception cycles (to avoid interference) and to provide reference for troubleshooting activities. Global Positioning System.
  • Page 176 The cap applied to the bandwidth of an BHS or specified group of BHSs. In the Information Rate Cambium implementation, this is controlled by the Sustained Uplink Data Rate, Uplink (MIR) Burst Allocation, Sustained Downlink Data Rate, and Downlink Burst Allocation parameters.
  • Page 177 PMP 450 Configuration and User Guide Glossary Network Address Translation defined in RFC 1631. A scheme that isolates Subscriber Modules from the Internet. See http://www.faqs.org/rfcs/rfc1631.html. National Electrical Code. The set of national wiring standards that are enforced in the U.S.A. NetBIOS Protocol defined in RFC 1001 and RFC 1002 to support an applications programming interface in TCP/IP.
  • Page 178 PMP 450 Configuration and User Guide Glossary PPPoE Point to Point Protocol over Ethernet. Supported on BHSs for operators who use PPPoE in other parts of their network operators who want to deploy PPPoE to realize per-subscriber authentication, metrics, and usage control. PPTP Point to Point Tunneling Protocol.
  • Page 179 PMP 450 Configuration and User Guide Glossary RSSI Radio Signal Strength Indicator. A relative measure of the strength of a received signal. An acceptable link displays an RSSI value of greater than 700. RxBabErr Field This field displays how many receiver babble errors occurred. RxOverrun Field This field displays how many receiver overrun errors occurred on the Ethernet controller.
  • Page 180 PMP 450 Configuration and User Guide Glossary SYN/1 Second-from-right LED in the module. In the BHM Module or in a registered Subscriber, this LED is continuously lit to indicate the presence of sync. In the operating mode for a Subscriber Module, this LED flashes on and to indicate that the module is not registered.

Table of Contents
