Summary of Contents for Global Sun Tech GL2554MP-1A
- Page 1 54Mbps Wireless Network Mini PCI Adapter USER’S MANUAL GL2554MP-1A Model Name: Version: Date: 15/10/03...
-
Page 2: Driver Installation
Please make sure TURN OFF your computer and remove the power cord from your PC. Open the computer case and then please insert the 54Mbps Wireless mini PCI Adapter. Once the 54Mbps Wireless mini PCI Adapter is installed, place the computer case back. - Page 3 3. Please click “Finish” 4. To make sure if the installation is successful, you could check it through the device management.
- Page 4 5. Once the installation is successful, a utility program icon will show on your desktop. To lunch the utility, just double click the icon.
-
Page 5: Important Note
Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 6 20 cm may be maintained between the antenna and users. The final end product must be labeled in a visible area with the following: “Contains TX FCC ID:O7J-GL2554MP-1A ”. Manual Information That Must be Included...
- Page 7 Global Sun Technology Inc. Installation Manual for Mini PCI Card...
- Page 8 Step 1 Take the Mini PCI card connector for aux antenna connector for Main antenna bottom...
- Page 9 Card Slot connecting with the bottom of the Mini PCI Card Right clip Left Clip Main Antennae Aux Antennae...
- Page 10 Step 2 Insert the Mini PCI card into the card slot with downside toward the slot Top side bottom side...
- Page 11 Step 3 Press down the top upperside of the card doward. A click sound made by the clippers on both left and right side of the slot signals that the card is firmly inserted to its position top side Left Clip Right Clip...
- Page 12 Step 4. Connecting the main antenna to the main connector. Connector for the main antenna...
- Page 13 Step 5 Connecting aux antennae to the aux connector. When both antennae are connected to the connectors as the picture shown below, the Mini PCI Card installation is completed. Aux connector...
- Page 14 Notification on Antennae Please be notice that the antennae must be firmly located inside the TFT-LCD panel. According to FCC regulation, to ensure the antenna will be kept at 20 cm away from users, the tip of the antennae must be firmly installed inside the top part of the TFT-LCD panel !
