- Page 1 ATEK Intelligence Platform Model TSU1000 Instruction Guide www.tankscan.com...
-
Page 2: Table Of Contents
Edit Existing Tank ....................25 h. Provision Tank ....................... 26 i. Duplicating Tanks ....................32 j. Administration (Admin) ..................34 1. Districts ......................34 2. Users ........................ 36 3. Configure Asset Types..................39 ATEK Customer Care Team (CCT) ........... 40... -
Page 3: Aip (Atek Intelligence Platform)
AIP (ATEK Intelligence Platform) AIP is a web-based portal designed to set up, provision, and manage assets and data. Throughout this guide there are references to ATEK Customer Care Team (CCT). They can be reached at 800-523-6996 or CCT@tankscan.com. Log In Open an internet browser and type in URL mytankscan.com to bring up AIP login page or www.TankScan.com... -
Page 4: Aip Navigation
Instruction Guide for AIP Navigation a. Menu Tabs These menu tabs can be used to navigate within AIP. Select Views then Tanks on landing page to get started. Views Menu Views menu items provide following services: a. Home – Brings user back to landing page b. -
Page 5: Actions Menu
Instruction Guide for Actions Menu Actions menu items provide the following services: Refresh – Refreshes page to display updated information g. Select Columns – Allows user to select which columns are displayed h. Export to Excel – Exports displayed information to Excel® Show all on Map –... -
Page 6: Drag & Drop Column Order
Instruction Guide for Sorting again (ascending). Drag & Drop Column Order • Click on desired column heading and drag to a new position then release. After repositioning. Add and Remove Columns Click on Actions menu then click Select Columns. •... -
Page 7: Filtering The View
Instruction Guide for • Check box to add the field /column, uncheck box to remove it. Changes will apply and save automatically. Click X button to remove Select fields menu. • c. Filtering the View • Click on filter icon in column header to open a drop-down menu. Menu items vary depending on data type in column. - Page 8 Instruction Guide for Click on Show Items with value that parameter drop-down menu and select type of filter. • • Select a conjunction to use if needed. Enter filter value(s) and click on Filter. • • Notice that display table is now filtered and filter button’s background color is white.
-
Page 9: Viewing Tank Details
Instruction Guide for Remove filters by clicking on Filter icon and clicking on Clear. • d. Viewing Tank Details Select Tanks from Grids menu. • • Click on Rotating Triangle icon on left side of a row to show additional information about tank. •... - Page 10 Instruction Guide for g. Update Monitor – Allows users to modify tank monitor reporting settings • Select Update Monitor. • Update Monitor page appears. • Report Interval – Number of hours between monitor reports to AIP, values: 1 – 24. This has a direct impact on battery life, less frequent reporting results in longer battery life.
- Page 11 Instruction Guide for • Note table to right of tank picture which displays last readings uploaded by tank’s monitor. Click on graph button under History column to quickly view readings. Clicking on multiple • graph buttons will display multiple graph lines. For a more detailed history report, see Reporting section.
-
Page 12: View All Tanks
Instruction Guide for View all Tanks. All tanks at a location can be viewed in one table. • Click on Rotating Triangle icon of a location or tank then click View All. • A new screen page appears showing all tanks for that location. Tanks with alerts are shown first. •... -
Page 13: View On Map
Instruction Guide for View on Map. To view map positions of Locations, Gateways, or Tanks, a validated address or longitude and latitude coordinates must be entered for Location associated with that Gateway and Tank. Click on Rotating Triangle icon of a Location, Gateway, or Tank then click on Map button. •... -
Page 14: Reporting
Instruction Guide for e. Reporting Generating Reports • Click on Views menu then click Reporting. This opens a new browser tab - Reports window will open. Select type of report from Report drop-down box. • a. Customer List – provides a listing of customers for this account b. - Page 15 Instruction Guide for • When a type of report is chosen, this view refreshes with menu options appropriate for that type of report.. Select which district from the Districts drop-down box. • • Select which Alert Status to report on from drop-down box. a.
-
Page 16: Account Setup & Editing
Instruction Guide for Click on Show Report button to generate a report. • - Tank history report example. - Note toolbar at top of each report. For data exporting, choose format from drop-down box and click on Export. • From Reports tab, click on web browser’s back button to be returned to Reporting home page or close •... -
Page 17: Create New Location
Instruction Guide for To access Administration Console: • Click on user name in upper right corner and select Administration Console. This will open a new Administration tab. b. Create New Location A new location must be created before creating gateways or tanks. Select Assets from Admin menu. - Page 18 Instruction Guide for Click on New button for Locations. • - A New Location window opens. • Fill out Name, Location type, Contact Information and Address portions of form. - For Location type and District (if applicable), select a type from drop-down box. Selection is determined from Assets menu and Configure Types submenu.
-
Page 19: Edit Existing Location
Instruction Guide for c. Edit Existing Location b. Create New Location • Select Assets from Admin menu. Click on All Locations drop-down, select desired location and click Edit to display • Edit Locations window. a. Modify as needed and select OK button. b. -
Page 20: Create A New Gateway
Instruction Guide for d. Create a New Gateway b. Create New Location Note: TSU1000 monitors serve as their own gateway. A new location must be created before creating a gateway. Select Admin, then Assets. • • Click on New button for Gateways. - New Gateway window will open. - Page 21 Instruction Guide for Fill in Key using serial number information from monitor label. • - Use the following format: TSU00000xxxx (Example: TSU00000500) Note: All information below Location is optional. Fill out Manufacturer and Notes field sections if desired. • • Fill out Install Date field when gateway is installed.
-
Page 22: Edit Existing Gateway
Instruction Guide for e. Edit Existing Gateway b. Create New Location • Select Admin, then Assets. Select Gateway from drop-down menu and then click on Edit to make changes to this gateway. •... -
Page 23: Create A New Tank
Instruction Guide for • If changes are made to gateway Key, then Key value must be updated for all tank parameters on each tank asset’s Provisioning window, refer to next section. Click on OK to keep changes • f. Create a New Tank A new gateway must be created before creating a tank. - Page 24 Instruction Guide for Click on New. • - New Tank window will open. Enter customer’s tank Name. • • Specify a Tag, to display extra information about the tank, if desired. • Fill in Description if desired. Select tank Type from drop-down box (list is created from menu item Assets/Configure Types). •...
-
Page 25: Edit Existing Tank
Instruction Guide for g. Edit Existing Tank b. Create New Location • Select Admin, then Assets. Select Tank from drop-down menu and then click on Edit. • Modify fields in Edit Tank window as needed. • Click on OK after editing tank details. •... -
Page 26: Provision Tank
Instruction Guide for h. Provision Tank b. Create New Location Provisioning allows users to map incoming monitor parameters to actual tank, specify alerts for each parameter, and to apply strapping tables to tank level readings. Failure to provision monitors properly could resort in loss of report information. Select Admin, then Assets. - Page 27 Instruction Guide for • Reading keys are assigned to monitor’s reported parameters in order to display them. TSU Monitors have 7 parameters that can be assigned to Reading Keys: % Full, Full (UOM), and Empty (UOM) created from “Range” Battery (V) created from “BV” Temperature (F) or (C) created from “DegC”...
- Page 28 Instruction Guide for • Select Asset Name of tank this monitor belongs to from drop-down box. Select Source Key (i.e. serial number) of tank’s monitor from drop-down box, source keys were • set up in Create a New Gateway section. Type in Reading Key 1.
- Page 29 Instruction Guide for Scroll down edit window to Processing section: • Input unit of measurement into Input UOM field. • a. % Full (%), Full (UOM), and Empty (UOM) use “inches” for TSU1000 b. Battery uses “volts” for TSU1000 c. Temperature uses “celsius” for TSU1000 d.
- Page 30 Leave Apply Lookup Table check box unchecked until monitor is installed; • Important: contact ATEK CCT to apply a lookup table to each monitor after installation. This is required to convert raw monitor readings into tank level readings. Adjust Output checkbox - Do Not Use.
- Page 31 Instruction Guide for • In example on previous page, alert levels are in terms of % Full reading key with a scale of 0 – 100%. • Activate any alert level by clicking on check box next to desired alert, then type in its value. Note that while there are many alert options to choose, none, some, or all can be utilized.
-
Page 32: Duplicating Tanks
Instruction Guide for i. Duplicating Tanks b. Create New Location Tanks can be duplicated to make copies with similar provisioning set ups. Before copying, a new tank’s location and ]monitor gateway must have been set up. Click on tank’s Edit button. •... - Page 33 Instruction Guide for - A new window will pop up to create a new tank asset. • Fill out Name for new tank. • Select gateway associated with new tank from Gateway drop-down menu. Enter serial number of new monitor into Key 1 Modifier field. •...
-
Page 34: Administration (Admin)
Instruction Guide for j. Administration (Admin) b. Create New Location It is common for AIP users to have to monitor multiple locations of tanks and have groups of locations called Districts. An account owner can view all districts and locations associated with their account. Users in AIP can be associated with Districts or Locations. - Page 35 Instruction Guide for - A district set up window will open. Fill in district Name and Description. • • Fill in district Contact information. • Fill in Notes if needed. Fill in Address information. • Click on Ok. • • Once created locations can be assiged to Districts by editing each location and selecting a district from District drop-down menu.
-
Page 36: Users
Instruction Guide for Users Create users with roles that dictate their permissions for districts and locations. Click Admin/Users to begin setup for each user. • • Click New to create a user or select a user and click on Edit and a form will pop up. - Page 37 Select security level from Role drop-down box. • Security hierarchy is as follows: a. Master Administrator – reserved for ATEK Access Technologies personnel b. Owner Administrator – can create locations and provision gateways and tanks for all owner’s districts and locations c.
- Page 38 Instruction Guide for Enter in Names. • • Assign User Name (write this down as it will need to be passed along to user). Assign Password (write this down as it will need to be passed along to user). • Select Time Zone from drop-down box to select time zone for data time stamps that are displayed.
-
Page 39: Configure Asset Types
Instruction Guide for Configure Asset Types. Assets such as Locations, Gateways, and Tanks can have types created with icons associated with them. These types are selected from drop-down box when locations, gateways, and tanks are created or edited. Asset Type icons will appear on map for assets with validated addresses. •... -
Page 40: Atek Customer Care Team (Cct)
No licenses to patents or other intellectual property of ATEK are granted by the Company in connection with the sale of TankScan products, expressly or by implication.
