Summary of Contents for Joa Telecom GPS-100MVPA
- Page 1 GPS Device (Model : GPS-100MVPA) User Manual Revision 1.0 RM1007 Sicoxtower, 513-14, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea TEL: +82-31-777-9009 FAX: +82-31-719-1969 www.joatelecom.Co.kr...
-
Page 2: Table Of Contents
1-3. Charging Battery - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5 2. Using GPS-100MVPA - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -6 2-1. -
Page 3: Getting Started
Antenna type Dual PIFA Intenna (CDMA + GPS) Operation temp. -20°C ~ +60°C Dimension 65mm x 33mm x 13.2mm (L x W x T) Weight R-UIM Not-Support Battery Polymer 650mA Standby time 24 Hours JOA Telecom Co., Ltd Proprietary and Confidential... -
Page 4: Appearance
GPS-100MVPA 1-2. Appearance Microphone Mode Button Power Button Emergency Button Speaker Reset Charging Adaptor JOA Telecom Co., Ltd Proprietary and Confidential... -
Page 5: Charging Battery
GPS-100MVPA 1-3. Charging Battery Use 24pin power adaptor included with the package. JOA Telecom Co., Ltd Proprietary and Confidential... -
Page 6: Using Gps-100Mvpa
Emergency (S.O.S) mode In an emergency, user can report the situation to protector by pressing Emergency (S.O.S) button. Answering an incoming call Making a call to the registered phone number JOA Telecom Co., Ltd Proprietary and Confidential... -
Page 7: Button Functions
To wake up Sleep mode, press the button (any button). End a call Press the button to end a call. Reject an incoming call Press the button to reject an incoming call. JOA Telecom Co., Ltd Proprietary and Confidential... - Page 8 (After installing JOA Map Service in your PC, you can register phone number of protector.) Release Emergency (S.O.S) mode In Emergency (S.O.S) mode, press Emergency (S.O.S) button longer to release emergency status. JOA Telecom Co., Ltd Proprietary and Confidential...
-
Page 9: Lcd Images
GPS-100MVPA 2-3. LCD Images Idle screen Phone number Emergency (S.O.S) mode Power On Power Off Fail to receive GPS signal Normal receiving GPS signal Needs battery charging Normal battery charging JOA Telecom Co., Ltd Proprietary and Confidential... -
Page 10: Normal Care And Maintenance
Please do not keep the product in the following environments: 1. Unventilated and humid locations. 2. In a car window that is exposed to excessive amounts of sunlight. 3. In an environment where humidity is over 90%. JOA Telecom Co., Ltd Proprietary and Confidential... - Page 11 This device was tested for typical body-worn operations with 10mm distance between the user`s body and this device. In order to meet RF Maximum permissible Exposure Safety Guidelines, a minimum distance of 10mm shall be maintained between this device and personnel during transmitter operation. JOA Telecom Co., Ltd Proprietary and Confidential...
