- Page 1 SPYDER BLUETOOTH USER MANUAL SPBT20A...
- Page 2 At WEB Biotechnology, we take the responsibility to provide the best medical products to our users. This User Manual, although sufficient, will be constantly updated as our products are im- proved. Do keep a look out at: www.web-biotech.com/downloads/spyderBT/usermanuals Last update 18/June/2012...
-
Page 3: Table Of Contents
Table of Contents Intended use of Spyder Bluetooth Complementary Products Detachable Parts Product Technical Specifications Safety Precautions and Warnings Storage Conditions Using Spyder Bluetooth Replacing the Batteries Using Spyder App Troubleshooting Service Information Certification Statements Legend For Logos Legal Information... -
Page 4: Intended Use Of Spyder Bluetooth
Introduction: Intended use of Spyder Bluetooth Spyder Blutooth Intended Use: Spyder Bluetooth is a ECG sensor for monitoring of heart rhythm with bluetooth devices. It is attached to the chest with a specially-designed adhesive pad. The device is practically inconspicuous when worn, providing remarkable quality of life to user. -
Page 5: Complementary Products
The Doctor Spyder is our server which stores the encrypted ECG data. The server can be accessed by authorised medical professionals at the url provided below. www.doctorspyder.com Adhesive Electrode Pad: For users’ safety, we advise users to use the official adhesive pad provided by WEB Biotechnology Pte Ltd only. -
Page 6: Detachable Parts
Detachable Parts Cover: The cover can be removed for easy changing of batteries by sliding the cover upwards gently. -
Page 7: Product Technical Specifications
Product Technical Specifications Function: Real-time ECG monitoring with Bluetooth devices Acquisition: 3 leads Sample Rate: 125 per second Dynamic Range: -2.5 to 7.7mV Resolution: 10µV Freq. Response: 0.01 to 150Hz Common Mode Rejection: > 100dB @ 50Hz Input Impedence: > 10MΩ @ 10HzΩ Patient Leakage: <... - Page 8 Product Technical Specifications Operating Relative Humidity: 25 to 95% Operating Pressure: 700 to 1060hPa Data Analysis: Signal Measurements & Arrhythmia Detection Doctor Spyder Website Data Access: User Manual, Spyder App for mobile devices Accessories: Ver 1.0 (release date 1/Sep/2011.) Firmware version: Should there be any further update in firmware version, user may upgrade the product via WEB-Bio online site by downloading the latest...
-
Page 9: Safety Precautions And Warnings
Safety Precautions and Warnings Remove the batteries inside Spyder Bluetooth when the device is not likely to be used for some time to avoid risk of leakage from batteries. Avoid having Spyder Bluetooth in contact with water. To clean Spyder Bluetooth, always use a clean and dry cloth. - Page 10 If the product is received in a damage state, do not use. Return the product according to service information section in user manual. If the on/off switch does not work, or if the cover of Spyder Bluetooth becomes loose, there is no risk to the patient. However, return the parts according to service information section in user manual.
-
Page 11: Storage Conditions
Storage Conditions Temperature: -15 to 42˚C Relative Humidity: 25 to 95% Pressure: 700 to 1060 hPa Users are advised to store Spyder Bluetooth in a cool and dry place. -
Page 12: Using Spyder Bluetooth
Using Spyder Bluetooth To Turn “On” Spyder Bluetooth Step 1: Turn on Spyder Bluetooth by pushing the switch to the “ON” position. Step 2: A green light will illuminate for 2 seconds to indicate that Spyder Bluetooth has been successfully switched on. - Page 13 Using Spyder Bluetooth Step 4: Peel off the plastic cover from the adhesive pad and affix Spyder Bluetooth on chest. To Turn “Off” Spyder Bluetooth Step 1: Switch Spyder Bluetooth off by pushing the switch to the “OFF” position.
-
Page 14: Replacing The Batteries
Replacing the Batteries Step 1: A red light will flash once every 5 seconds to indicate that the batteries need to be replaced soon. Step 2: Push open the top cover of Spyder Bluetooth. - Page 15 Replacing the Batteries Step 3: Replace 2 AAA batteries as shown. Step 4: Replace the top cover of Spyder Bluetooth.
-
Page 16: Using Spyder App
Using Spyder App Step 1: Launch the Spyder App. The Application displays the following information. Server Connectivity Battery Indicator Heartbeat Rate Time 71 BPM 11:28 Settings Marker Step 2: server connectivity icon will turn red if there is a problem with the server connection. - Page 17 ‘Marker’. A red line will appear on the screen to indicate successful creation of the marker. Step 4: Do not exit the application or the detected ECG may not be trans- mitted to the phone and server. Simply ‘hide’ the application while the Spyder Bluetooth is in use.
- Page 18 Using Spyder App Step 5: The phone will sound when Bluetooth connection with the Spyder Bluetooth device is lost. Step 6: Start or re-enter the application by tapping on the Spyder Application. Step 7: To terminate the session, simply exit the application.
-
Page 19: Troubleshooting
Check the Bluetooth connection between your android smartphone and Spyder Bluetooth. Ensure the Spyder Bluetooth has working batteries. Restart the application by exiting and launching it again. The notification alarm will stop ringing when the waveform appears on the phone screen. - Page 20 Ensure that the batteries are inserted according to the indicated polarities.” If Spyder Bluetooth indicator light still does not turn on after checking with point (1) & (2), please return the product according to service information section in user manual.
- Page 21 2-3 seconds when the switch is in “on” position? Do Not do anything. This indicate Spyder Bluetooth in normal operating condition. [Refer to user manual – Using SPYDER Bluetooth Step 2 highlighted the indicator light is design to turn off after 2~3 seconds.
-
Page 22: Service Information
Service Information In the case where the device is not functioning as it should be, inform your doctor immediately or otherwise, contact WEB Biotechnology Pte Ltd at: Tel: +65 6223 2723 Fax: +65 6220 0833 Email: info@web-biotech.com... -
Page 23: Certification Statements
Certification Statements FCC Statement For Spyder Bluetooth: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 24 Certification Statements CE Statement For Spyder Bluetooth: EN 300 328 V1.7.1 -- Electromagnetic compatibility and Radio spectrum Mat- ters (ERM); Wide-band transmission systems; Data transmission equipment operating in the 2,4 GHz ISM band and using wide-band modulation techniques; Harmonised EN covering essential requirements under Article 3.2 of the R&TTE Directive.
-
Page 25: Legend For Logos
Legend For Logos An applied part that includes a patient connection that is intended to deliver electrical energy or an electrophysiological signal to or from the patient. Refer to User Manual for operating instructions Turn “On” Turn “Off” Direct current... -
Page 26: Legal Information
Manual necessitated by typographical errors, inaccuracies of current information, or improvements to equipment, may be made by WEB Biotechnology Pte. Ltd. at any time and without notice. Such changes will, however, be incorporated into new editions of this User Manual. - Page 28 WEB Biotechnology Pte Ltd 35B Mosque Street Singapore 059513 Telephone: +65 6223 2723 Fax: +65 6220 0833...
