Superwinch Certus Wireless Owner's Manual

Wireless remote control
Hide thumbs
Table of Contents

Advertisement

Available languages

Available languages

Quick Links

SPANISH
WIRELESS REMOTE CONTROL
OWNER'S MANUAL
CAUTION
!
READ AND UNDERSTAND THIS MANUAL BEFORE
INSTALLATION AND OPERATION OF YOUR
SUPERWINCH PRODUCT
Superwinch LLC.
359 Lake Road
Dayville, CT 06241, USA
tel: 1.860.928.7787
fax: 1.860.963.0811
info@superwinch.com
www.superwinch.com
98-17449 Rev - 01/24/2012
*+ # i
TM
Superwinch LTD.
Union Mine Road
Tavistock, Devon PL19 0NS
England
tel: +44 (0) 1822 614101
fax: + 44 (0) 1822 615204
sales@superwinch.net
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Certus Wireless and is the answer not in the manual?

Questions and answers

Summary of Contents for Superwinch Certus Wireless

  • Page 1 SPANISH WIRELESS REMOTE CONTROL OWNER’S MANUAL CAUTION READ AND UNDERSTAND THIS MANUAL BEFORE INSTALLATION AND OPERATION OF YOUR SUPERWINCH PRODUCT Superwinch LLC. Superwinch LTD. 359 Lake Road Union Mine Road Dayville, CT 06241, USA Tavistock, Devon PL19 0NS tel: 1.860.928.7787 England fax: 1.860.963.0811...

  • Page 2: General Information

    CERTUS WIRELESS REMOTE SYSTEM – CONSUMER VERSION Read and understand the manual thoroughly before installing or using the radio remote control. Improper installation or improper use of the remote unit by the user WARNING could result in injury or destruction of property. Keep this manual for future reference.

  • Page 3: Power Button

    AVERTISSEMENT Misuse or abuse of this equipment could result in injury to the user or others and/or damage to property. 1. Never leave the transmitter unattended. 2. The transmitter is only to be used where there is a clear view of the operating machinery.

  • Page 4: Programming The Transmitter

    OPERATION INSTRUCTIONS LED 1 Power Button Green Button Green Button (Fig. 2) Front of Transmitter SPANISH Programming the Transmitter Note: Transmitters supplied with the unit are pre-programmed at the factory - DO NOT RE-PROGRAM THEM. Should a new transmitter be purchased it will require programming. To program, follow the instructions below: NOTE: Each of the three (3) buttons needs to be programmed individually Program Green Button 1:...
  • Page 5 Program Green Button 2: • Press the learn button 1 time Wait for the red LED on receiver to flash 1 time • Press the learn button 1 more time Wait for the red LED on receiver to flash 2 times •...
  • Page 6 The transmitter and receiver utilize an internal antenna. This antenna cannot be shortened, moved or otherwise altered. Alteration will void warranty and may cause erratic operation. Battery To change the battery, open the back of the transmitter by removing the two (2) small screws.

  • Page 7: Installation Instructions

    INSTALLATION INSTRUCTIONS Do not attempt to install wiring when the battery is connected. DANGER Do not lean over battery while making connections. Automotive batteries contain flammable and explosive gases. Wear eye protection during installation and remove all metal jewellery. Ensure that the wiring harness does not interfere or come in CAUTION contact with any hot or moving engine, suspension, steering, braking or exhaust parts.

  • Page 8: Operation Test

    Check to ensure that the ground and positive leads from WARNING the battery are disconnected before performing any electrical work. RED Wire from BLACK Wire Harness from Assembly Harness Assembly YELLOW Wire from BLUE Wire from Harness Assembly Harness Assembly (closed off side of (closed off side of connector used)

  • Page 9: Maintenance

    MAINTENANCE Depending on use, the batteries in the remote transmitter will need replacement after a period of time. No other regular maintenance is required. TROUBLESHOOTING Problem Possible Cause Solution Check polarity / Receiver shows no Supply current not reaction after supply Test current available / into receiver /...

  • Page 10: Technical Data - Transmitter

    Technical Data - Transmitter Frequency FM 433 MHZ Number of Functions 2, plus Power function Antenna Multilayer Chip LED Light for transmission Dimensions 3.3” x 2.1”x .07” (84mm x 53mm x 18mm) Ingress Protection Level IP66 Operational Temperature -4° F to 122° F (-20° C to + 50° C) SPANISH Technical Data - Receiver Frequency...
  • Page 11 (2) this device must accept any interference received, including interference that may cause undesired operation. NOTICE: Changes or modifications made to this equipment not expressly approved by, SUPERWINCH LLC, may void the FCC authorization to operate this equipment. NOTE: SPANISH This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
  • Page 12 SPANISH MEMBER...
  • Page 13 TELECOMMANDE SANS FIL MANUEL DU PROPRIETAIRE PRUDENCE LIRE ET COMPRENDRE CE MANUEL AVANT INSTAL- LATION ET L’OPERATION DE VOTRE PRODUIT DE SUPERWINCH Superwinch LLC. Superwinch LTD. 359 Lake Road Union Mine Road Dayville, CT 06241, USA Tavistock, Devon PL19 0NS tel: 1.860.928.7787...

  • Page 14: Informations Générales

    FM. Pendant qu’un signal de FM est beaucoup moins susceptible à l’intervention électrique qu’un SUIS le signal, il ne peut jamais y avoir la pas expressément Approuvé par, SUPERWINCH LLC, peut annuler protection totale contre l’intervention extérieure. L’intervention peut résulter de l’allume et de l’autorisation de FCC pour fonctionner cet équipement.

  • Page 15: Bouton D'alimentation

    Les Données techniques - l’Emetteur AVERTISSEMENT Fréquence FM 433 MHZ Employer improprement ou l’abus de cet équipement pourrait avoir pour résul- Le nombre de Fonctions 2, plus la fonction de Pouvoir tat la blessure à l’utilisateur ou d’autres les dommages de et/ou à la propriété. Antenne Puce multicouche 1.

  • Page 16: Instructions D'operation

    INSTRUCTIONS D’OPERATION ENTRETIEN LED 1 Dépendre de l’usage, les piles dans l’émetteur éloigné auront besoin du remplacement après une période de temps. Aucun autre entretien régulier est exigé. Rouge Bouton d’alimentation DEPANNAGE Bouton vert Problème Cause possible Solution Fournir le courant pas Vérifier la polarité...
  • Page 17 Programmer le Bouton Vert 2: AVERTISSEMENT Le contrôle pour garantir que le sol et les avances positifs de • Appuyer l’apprendre le bouton 1 fois la pile sont débranchés avant de n’importe lequel exécuter electrical work. Attendre la LED rouge sur le récepteur pour clignoter 1 fois •...

  • Page 18: Instructions D'installation

    L’émetteur et le récepteur utilisent une antenne interne. Cette antenne ne peut INSTRUCTIONS D’INSTALLATION pas être raccourcie, déplacé ou autrement changé. Le changement annulera la garantie et peut causer Ne pas se pencher sur la pile en faisant des connexions. Les DANGER Pile piles automotrices contiennent des gaz inflammables et explosifs.
