- Page 1 BLAUAIR AUTOMATIC CONTROL SYSTEM S30 (KVENT, TH-TUNE) S31 (KVENT) S32 (KVENT, PGDE) USER’S MANUAL...
-
Page 2: Table Of Contents
Control ........................................ 10 This user’s manual is a main operating document intended for technical, maintenance, and operating staff. The manual contains information about purpose, technical details, operating principle, design, and installation of the S30, S31, S32 unit and all its modifications. -
Page 3: Safety Requirements
S30, S31, S32 www.blaubergventilatoren.de SAFETY REQUIREMENTS • Please read the user’s manual carefully prior to installing and operating the unit. • All user’s manual requirements as well as the provisions of all the applicable local and national construction, electrical, and technical norms and standards must be observed when installing and operating the unit. -
Page 4: Purpose
S30, S31, S32 www.blaubergventilatoren.de PURPOSE The automatic control system is designed for controlling ventilation systems of various configurations. The control system controls basic ventilation system components, such as supply and extract fans, heat exchanger, air heater, air cooler, air humidifier, air mixing chamber, air dampers. The automation unit has a configurable controller with installed software. The controller can be individually configured for each ventilation system. -
Page 5: Technical Data
S30, S31, S32 www.blaubergventilatoren.de TECHNICAL DATA Value Parameter th-Tune pGDE Storage temperature [°C] -20...+70 -20...+70 Storage humidity [%] 10...90 (no condensation) 10...90 (no condensation) Operation temperature [°C] -10...+60 -20...+60 Operation humidity [%] 10...90 (no condensation) 10...90 (no condensation) Telephone cable max. 50 m; twisted pair... -
Page 6: Installation And Set-Up
S30, S31, S32 www.blaubergventilatoren.de INSTALLATION AND SET-UP INSTALLATION OF TH-TUNE CONTROL PANEL For installation of the back side of the control panel use a mounting box with a minimum diameter 65 mm and installation depth 31 mm. 1. Detach the front side of the control panel from the back side using 2. - Page 7 S30, S31, S32 www.blaubergventilatoren.de INSTALLATION OF PGDE CONTROL PANEL Connect the pGDE control panel to the connector on the controller using the 6P6C phone connector (PLUG-6P6C-P-C2). The maximum telephone cable length is 50 m. Lay the telephone cable to the installation place of the control panel.
- Page 8 S30, S31, S32 www.blaubergventilatoren.de CONNECTION TO POWER MAINS DISCONNECT THE UNIT FROM POWER MAINS PRIOR TO ANY OPERATIONS. THE UNIT MUST BE CONNECTED TO POWER SUPPLY BY A QUALIFIED ELECTRICIAN. THE RATED ELECTRICAL PARAMETERS OF THE UNIT ARE GIVEN ON THE MANUFACTURER’S LABEL.
- Page 9 S30, S31, S32 www.blaubergventilatoren.de Designation Description Type Cable*** SW1* Remote turning on/off 2x0.75mm DPT*/CO2* Pressure sensor/CO sensor 3x0.75mm PK1* NC contact of fire alarm panel 2x0.75 mm 2x0.75mm P1** External control panel thTUNE thTUNE 5x0.25mm PD1* Filter clogging sensor 2x0.75mm * Not supplied with the unit.
-
Page 10: Control
S30, S31, S32 www.blaubergventilatoren.de CONTROL S31 controller (KVENT) inputs/outputs... - Page 11 S30, S31, S32 www.blaubergventilatoren.de Position Description Digital inputs Analogue inputs Analogue outputs Digital outputs Micro USB for updating applications, import and export of settings, alarm log Power source for external sensors Ethernet port Connection port for PGDe control panel Display port BMS/Fieldbus2 port BMS/Fieldbus1 port.
- Page 12 S30, S31, S32 www.blaubergventilatoren.de TH-TUNE CONTROL PANEL BUTTON FUNCTIONS Standby/auto mode. Boost function deactivation. (MODE) Editing operation settings: ECO, PRECOMFORT, COMFORT, STOP. (FAN) Schedule mode on/off: press once shortly. To get access to the schedule menu press and hold for 2 seconds.
- Page 13 S30, S31, S32 www.blaubergventilatoren.de TO reset the alarms synchronously press and hold the FAN and ON/OFF buttons for 3 seconds Schedule setup Th-Tune enables setup of scheduled operation and temperature settings. To enter the menu turn off the schedule mode and press the CLOCK button for 2 seconds.
- Page 14 S30, S31, S32 www.blaubergventilatoren.de PGDE CONTROL PANEL The control panel has 6 buttons: (ALARM): manual reset of alarm signals. (PRG): operation mode editing. (ESC): return to previous display. (UP, DOWN): moving between displays screens or increasing/decreasing values (ENTER): data validation and reset to parameter list UNIT START After connection of the unit to power mains the controller is loaded and the home page opens.
- Page 15 S30, S31, S32 www.blaubergventilatoren.de 5. Main temperature control (air temperature in the supply air duct). 6. Set indoor air or supply duct temperature point (depending on settings). 7. Indicates access to the user menu with UP, DOWN and ENTER buttons.
- Page 16 S30, S31, S32 www.blaubergventilatoren.de ALARMS In case of alarm the alarms are displayed on the display. Position Description Alarm number / total alarms Alarm date and time Alarm code Alarm description Alarmed sensor value The alarms can be reset manually, automatically or repeated automatically.
- Page 17 S30, S31, S32 www.blaubergventilatoren.de A020 Supply filters alarm Automatic reset A021 th-Tune clock not working Automatic reset A022 th-Tune temperature sensor not working Automatic reset Deactivation of indoor air temperature regulation mode A023 th-Tune humidity sensor not working Automatic reset...
- Page 18 S30, S31, S32 www.blaubergventilatoren.de A064 Supply fan - Internal circuit high temperature Automatic reset Unit shutdown A065 Supply fan - Motor high temperature Automatic reset Unit shutdown A066 Supply fan - Low DC-link voltage Automatic reset Unit shutdown A067 Supply fan - Limited mains power...
- Page 19 PLEASE ASK THE UNIT SUPPLIER FOR THE MANUAL TO THE CONTROLLER SOFTWARE. The engineering menu enables to set operation of the automation unit with the control panels S30 and S32 both individually and jointly. The automation system is operable also without control panel.
- Page 20 www.blaubergventilatoren.de B201EN-01...
