Summary of Contents for ELPRO RT2e
- Page 1 Wireless Sensor RT2e Operation Manual Wireless Sensor RT2e EL6107E...
- Page 2 2 - EN Wireless Sensor RT2e EL6107E...
-
Page 3: Table Of Contents
Maintenance ......................9 4. Status and error messages ..............10 5. Technical data ....................11 Radio settings .......................11 Environment......................12 Wireless Sensor RT2e - 2 external temperature sensors ........12 Part no. System & Accessories ................13 5.4.1 Wireless Sensor RT2e................13 5.4.2 Accessories ..................13 Label Locations.....................14 Dimensional drawing ....................15... - Page 4 As a result, images, descriptions and scope of delivery are not binding! The release of this document is available on the printed and archived original only. This manual is valid for firmware version 1.02 elproLOG ANALYZE 3.63 4 - EN Wireless Sensor RT2e EL6107E...
-
Page 5: Product Description
P r o d u c t d e s c r ip t i o n Product description The Wireless Sensor RT2e works autonomously and is supplied with power via internal batteries. On the front side there is a status display (green/red LED) and a type label which documents the wireless sensor designation and the ID number of the sensor. -
Page 6: General Application And Safety Information
- IR radiation (heat) and superheated steam can damage the surface coating of the casing - There is a risk that the battery may explode if the logger is used under microwave radiation Initial startup THE WIRELESS SENSOR MUST BE AT ROOM TEMPERATURE BEFORE INITIAL STARTUP! 6 - EN Wireless Sensor RT2e EL6107E... -
Page 7: Precautionary Measures For Handling Units Containing Lithium Batteries
- Do not heat battery operated units to temperatures exceeding 100°C: Explosion hazard - Avoid excessive impact - Follow the manufacturer specifications for storing batteries - Return batteries to the supplier for correct waste disposal Wireless Sensor RT2e EN - 7 EL6107E... -
Page 8: Wireless Sensor Rt2E
The wireless sensor casing contains various operating equipment, 3 batteries and the sensor connections. Technical data and the assignment of terminals in the :SENSORS" field 5.3 Wireless Sensor RT2e - 2 external temperature sensors. Batteries The wireless sensor uses 3 lithium 3.6V batteries. The battery capacity is sufficient for operation time of 2 - 3 years. -
Page 9: Operation
The use of third party batteries or removal of batteries will produce incorrect status information at the battery indicator. AFTER THE BATTERIES ARE CHANGED, THE SET KEY MUST BE PRESSED AND HELD FOR 6 SECONDS, OTHERWISE THE ENERGY COUNTER WILL NOT FUNCTION Wireless Sensor RT2e EN - 9 EL6107E... -
Page 10: Status And Error Messages
10 seconds. Reestablishing the radio connection can take up to 1 minute. Connection test Blinks green / red 3.1.1 Transmitted frequency & radio channel In the housing: This LED lights up red when if one of batteries is inserted incorrectly. BATTERY ERROR 10 - EN Wireless Sensor RT2e EL6107E... -
Page 11: Technical Data
This example makes the dramatic relation between free space damping and transmission frequency very clear. The damping factor for solid materials is 4 - 6 times higher than the factor for free space damping (air). Wireless Sensor RT2e EN - 11 EL6107E... -
Page 12: Environment
Protective class IP30 external power supply 10 ...30VDC 24VDC; up to 1.6A startup current, 70mA operation 5.3 Wireless Sensor RT2e - 2 external temperature sensors Ambient temperature -30°C ...55°C, non-condensing Protective clase IP54 Power supply / operating 3 internal lithium batteries / 2-3 years... -
Page 13: Part No. System & Accessories
T e c h n i c a l d a t a 5.4 Part no. System & Accessories 5.4.1 Wireless Sensor RT2e Part no. Function 3454-US RT2e wireless sensor - 2 x external temperature 5.4.2 Accessories Part no. Name 2760-US Aerial 915 MHz band FCC, yellow... -
Page 14: Label Locations
T e c h n ic a l d a t a 5.5 Label Locations 14 - EN Wireless Sensor RT2e EL6107E... -
Page 15: Dimensional Drawing
T e c h n i c a l d a t a 5.6 Dimensional drawing Wireless Sensor RT2e EN - 15 EL6107E... -
Page 16: Approvals
- Installation requirements Risk assessment The Elpro wireless system is made up of a receiver and a transmitter function in the wireless datalogger for Receivers and and in each radio sensor. The receivers are divided into three classes, each having its own set of minimum Transmitters performance criteria. -
Page 17: Fcc
- The maximum allowed 20 dB bandwidth of the hopping channel is 500 kHz. - Maximum peak conducted output power is 1W in the 902-928MHz band if more than 50 hopping channels are used. The limit is 0.125W for 25 to 50 hopping channels. Wireless Sensor RT2e EN - 17 EL6107E... -
Page 18: Industry Canada
ETSI standards are found at: http://www.etsi.org The CEPT/ERC rec 70-03 are found at: http://www.ero.dk The ARIB STD-T66 regulation is found at: http://www.arib.or.jp/english/index.html The Australian/New Zealand Standard AS/NZS 4268:2003 are found at: http://www.standards.org.au 18 - EN Wireless Sensor RT2e EL6107E... - Page 19 A p p r o v a l s Wireless Sensor RT2e EN - 19 EL6107E...
- Page 20 Revision History Author Date Version Description A. Gubler 26.06.2012 First edition Wireless Sensor RT2e EN - 20 EL6107E...
-
Page 21: Index
PT100 2/3 lead 12 Radio channel 8 Radio connection 8 Replacing battery 9 Sensor cable 12 Sensor connection 12 SET key 8 Signal weakening 11 Special environmental conditions 6 Status indicator 8 Temperature influence 6 21 - EN Wireless Sensor RT2e EL6107E... - Page 22 (Head Office) ELPRO-BUCHS AG Langäulistrasse 62 CH-9470 Buchs SG Switzerland email: swiss@elpro.com For local representatives see: www.elpro.com www.pdf-datalogger.com Operation Manual Wireless Sensor RT2e EL6107E 08.2012...
