DESCRIPTION: An electronic control panel used in conjunction with
one pulse meter (a water meter with pulse output proportional to
flow rate) which is installed on the incoming water supply at the site
boundary or at the building intake - in accordance with BREEAM
requirements.
The control monitors the flow of water through the meter over a
preset period of time and raises an alarm in the following situation:
When a continuous flow of water passes through the Main (M1)
water meter above a preset maximum for a preset period of time.
By setting realistic flows and time periods (allowing for usual
fluctuations in consumption) any increase above these norms may
be detected and dealt with – saving water and limiting damage
caused by a major leaks.
sales@watersavers.co.uk www.watersavers.co.uk
WLDS-10 Mk3
MAJOR WATER LEAK DETECTION SYSTEM
INSTALLATION & COMMISSIONING
Sales/Technical 01603 720999
Watersavers Limited
Rackheath Industrial Estate
Norwich Norfolk NR13 6NT
Earl Road
Advertisement
Summary of Contents for Watersavers WLDS-10 Mk3
- Page 1 WLDS-10 Mk3 MAJOR WATER LEAK DETECTION SYSTEM INSTALLATION & COMMISSIONING DESCRIPTION: An electronic control panel used in conjunction with one pulse meter (a water meter with pulse output proportional to flow rate) which is installed on the incoming water supply at the site boundary or at the building intake - in accordance with BREEAM requirements.
- Page 2 NOTES...
- Page 3 TABLE OF CONTENTS Section 1 – Introduction & important information Section 2 – Installation instructions Section 3 – LCD screens & navigation map Section 4 – Main screen Section 5 – Entering parameters & commissioning Setting the time and date Setting pulse meter K factor High flow times for days of the week Setting maximum High and Low flow rates...
- Page 4 1-INTRODUCTION & IMPORTANT INFORMATIO N IMPORTANT INFORMATION! This Water Leak Detection System will not provide protection unless it is set up and commissioned as detailed in section 5 For correct and effective operation the following must be completed: a) Appoint a person responsible for: i) Understanding how the system works, setting and monitoring the parameters and keeping records accordingly ii) Being aware of the implications of the alarm and the inability to...
- Page 5 When the above steps have been completed turn on the electricity supply. After a brief welcome screen showing ‘Watersavers WLDS-10 Mk3’ the Main screen will show – see section 4 CHECK TIME & DATE AND SET IF NECESSARY – see section 5...
- Page 6 3 – LCD DISPLAY & KEYPAD – QUICK GUIDE 2x 16 CHARACTER LCD DISPLAY SOME USEFUL FUNCTIONS Alarm Test – press 2 key for 4 seconds Manual Override – press 6 key for 4 seconds Valve service – press 8 key for 4 seconds Serial Number of the WLDS-20 mk3 - press 1 and INFO (i) keys together The MAIN screen will be return after 3 seconds.
- Page 7 T I M E 0 0 : 0 0 0 0 : 0 0 S U N T I M E 0 0 : 0 0 0 0 : 0 0 MAIN MAIN MAIN WLDS-10 Mk3 LCD SCREENS NAVIGATION MAP...
- Page 8 -MAIN SCREEN This is the default screen M A I N 0 0 0 0 0 0 Example only T U E 1 0 : 5 7 The top line shows TOTAL LITRES registered by the Main meter (M1) at the site boundary or main intake (similar to a car’s milometer).
- Page 9 5-ENTERING PARAMETERS & COMMISSIONING TO ENTER OR CHANGE A PARAMETER in a particular screen press Enter. You will then see a flashing cursor to prompt you to enter the required value using the keypad. Press Enter again to confirm. Press Enter again and repeat to make further changes.
- Page 10 SETTING PULSE METER K FACTOR (LITRES PER PULSE) M A I N F A C T O R Example only (default setting 10) P U L S E To reach this screen scroll through the setup screens by pressing ◄ key from the MAIN screen.
- Page 11 SETTING MAXIMUM HIGH FLOW RATE M A X H H : M M Example only (default setting 9999) 0 0 2 0 0 0 0 : 3 0 To reach this screen scroll through the setup screens by pressing ◄ key from the MAIN screen.
- Page 12 PROTECTION OFF (MANUAL OVERRIDE) P R O T E C T I O N O F F Example only (default setting 1 hour) T I M E O U T 0 1 : 0 0 This function is used when for example drawing off large volumes of water in order that the alarm is not raised.
- Page 13 5 - SOLENOID VALVE SETUP The WLDS-20 mk3 has new features that enable the installer to select either a Normally Closed (default) or a Normally Open solenoid shutoff valve to be used in conjunction with the panel. Furthermore an optional regular servicing routine may be used in order to prolong the active life of the solenoid valve and to reduce the risk of the valve sticking open or closed due to inactivity and/or possible calcification.
- Page 14 5 - SOLENOID VALVE SETUP - CONTINUED ENTER THE VALVE SERVICE TIME S E R V I C E T I M E 0 1 : 0 0 H O U R S Choose a time of the day when there will be least disruption from the valve being opened and closed eg in the early hours of the morning.
- Page 15 6-MONITORING SCREENS PEAK NUMBER OF LITRES P E A Example only P E A This screen stores the peak value measured during both High flow and Low flow time periods. The asterisk shows the current HF/LF status. Press ▼ or ▲ key to return to the Main screen. NB THESE READINGS WILL REMAIN UNTIL RESET –...
- Page 16 An external alarm input is available for the connection of ancillary equipment such as tape leak sensing to be interfaced to the WLDS-10 mk3 panel. Input I3 is located at terminal 12 on the upper green terminal block. When this input is connected to +24v for 1 second the above screen will show and the alarm will be raised.
- Page 17 8-TROUBLESHOOTING BLANK LCD SCREEN Check power is present, check wiring, check mains fusing. Green light on PSU indicates 24v is OK. Check DC fuse. This is located at right hand side of PSU in grey housing. Lift grey lid at top edge to reveal fuse. Replace if necessary with spare 20x5mm 1A quick blow fuse located in upper compartment.
- Page 18 9-WIRING DIAGRAM...
- Page 19 10-NOTES Installation details Contact name/s ……………………………………………………………………………………………………… Mobile number ………………………………………………………………………………………………………… Installation date ………………………………………… Serial number ………………………………… Main (M1) meter K factor ……………………… Alarm details …………………………………………………………………………………………………………… Settings High Flow (HF) max litres Time period _ _ : _ _ Low Flow (LF) max litres Time period _ _ : _ _ M1-M2 Boundary max litres...
- Page 20 Enclosure: Steel wall mounting overall dimensions 300 x 300 x 150mm (W x H x D) RAL7035 powder coated Protection: to IP65 (nearest NEMA 4X) overall weight 5kg Sales/Technical 01603 720999 Watersavers Limited Earl Road Rackheath Industrial Estate Norwich Norfolk NR13 6NT sales@watersavers.co.uk www.watersavers.co.uk...
