Summary of Contents for JASTEC von-S2
- Page 1 Manual Instruction...
- Page 2 Information Certified Business Name: Jastec Co.,Ltd. • Device (model): Vehicle Fleet Management Service System • Manufacture date: Jan, 2013 • Manufacturer/country : Jastec Co,Ltd./Korea • Certified code : JS0 • A radio interference of this wireless module is not providing a service related the safety of life.
-
Page 3: Cautions For Safety
Cautions For Safety We kindly recommend you to be fully aware of using a product accurately and for safety of user. All liabilities by uncomplying cautions are not supposed to be responsible to manufacturer. 1. This product into water or prolonged exposure to moisture can cause failure resulting in no charge for broken A/S. 2. - Page 4 1.1 Overview Von-S2 von-S2 as vehicle Fleet Management Service System designed to collect a vehicle driving information from ECU(Electronic Control Unit) By OBD standard protocol communication and can be saved a driving logs by connecting to PC. This confidential information is not supposed to disclosed and misused to the third party...
-
Page 5: Specifications
1. von-S2 Descriptions 1.2 Specifications Item Description CPU Processor 32-bit ARM Cortex-M3(256KB Flash, 64KB SRAM) External Memory 4MB Serial Flash Memory In-Vehicle Protocol ISO 9141-2, ISO 14230-4(KWP-2000), ISO 15765-4(CAN), SAE J1850(PWM/VPWM) Status 2-LEDs (Power, CDMA) Supported Functions SAE J1979 Mode $01~$0A... - Page 6 1. von-S2 Descriptions 1.3 Functions Saving vehicle information. Collecting and saving driving logs information. Vehicle identification information / module certification / module serial number information / driving Driving logs record data starting time and ending time / ignition On and Off time /...
- Page 7 Connection to vehicle OBD diagnostic port. USB cable Firmware Update Quick Start Manual Quick guide manual Program installation CD von-S2 PC Manager installation program This confidential information is not supposed to disclosed and misused to the third party...
- Page 8 1. von-S2 Descriptions 1.5 Body description display LED 2-Indicator display LED DLC connector Connect to vehicle OBD diagnostic port. USB Connector F/W Update Connector This confidential information is not supposed to disclosed and misused to the third party...
-
Page 9: Product Instructions
2. Product Instructions 2.1 von-S2 module installation von-S2 module installation is following below order. 1. von-F module installation requires after vehicle parking in safety area. ** Caution : A side brake or foot brake should be locked and shift also checked on the parking position. - Page 10 2. Product Instructions 2.3 von-S2 module separation ** Caution : von-F module separation should be performed at safety area after parking. ** Caution : The separation from vehicle is prohibited if not the purpose of driving data saving or transmitting.
-
Page 11: Warranty & After Sale Service
3. Warranty & After Sale Service 3.2 Warranty Service 1. Warranty Period : 1 year 2. Warranty Details 1) Any defective or damage within warranty period can be repaired free A/S service or exchanged as free of charge. 2) Any damage or defective by customer’s misuse is not allowed free exchange or free charged A/S service. 3. - Page 12 FCC ID : UK4JTCM1000 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications (including the antennas) made to this device that are not expressly approved by the manufacturer may void the user's authority to operate the equipment.
