Summary of Contents for Armstel MDA2120-A
- Page 1 User Manual LCD DISPLAY MDA2120-A/MDA2120-S...
-
Page 2: Table Of Contents
MDA2120-A/MDA2120-S User Manual Content SAFETY SYMBOLS & PRECAUTIONS ......................3 ............................3 AFETY YMBOLS ..............................3 RECAUTIONS INTRODUCTION .............................. 6 2.1. OSD ............................7 NTERFACE QUICK START ..............................8 ADJUSTMENT..............................10 4.1 H OSD M ........................... 10 OW TO 4.2 OSD .................... -
Page 3: Safety Symbols & Precautions
MDA2120-A/MDA2120-S User Manual 1. Safety Symbols & Precautions 1.1 Safety Symbols This manual uses below safety symbols. They denote critical information. Please read them carefully. WARNING Failure to abide by the information in a WARNING may result in serious injury and can be life threatening. - Page 4 MDA2120-A/MDA2120-S User Manual Set up the unit in an appropriate location. Not doing so may result in fire, electric shock, or equipment damage. Do not place the unit outdoors. Do not install the unit in transportation systems (ship, aircraft, trains, automobiles, etc.) Do not place the unit in a dusty or humid environment.
- Page 5 MDA2120-A/MDA2120-S User Manual CAUTION Handle with care when carrying the unit. Disconnect the power cord and signal cables and remove the optional unit. Moving the unit with the cord or the option attached is dangerous. It may result in injury.
-
Page 6: Introduction
DICOM Part 14 GSDF standard. In addition, a single CAL button push can enable the automatic DICOM Part 14 GSDF calibration and backlight adjustment with ARMSTEL's built-in front/backlight control sensor (MDA2120-A model only). The anti-reflection coated protective screen can prevent display from damage under hard using conditions, make the clean and disinfect easier. -
Page 7: Osd And Interface
MDA2120-A/MDA2120-S User Manual 2.1. OSD and Interface a. Front b. Back - 7-... -
Page 8: Quick Start
MDA2120-A/MDA2120-S User Manual 3. Quick start 1.Cable Connection Connect all cables to the appropriate connectors, as shown in below picture. 2.Adjust the height, position and angle of monitor. Screen Rotation Before rotating, the screen must be raised to the highest level to avoid knocking the screen on the desk or pinching with your fingers. - Page 9 MDA2120-A/MDA2120-S User Manual 3.Turn on the monitor, the power indicator light will become green. Start the computer and set mode of monitor as below: 1200 x 1600 (in portrait mode) or 1600 x 1200 (in landscape mode). NOTE: If no picture, please refer to the Troubleshooting section of this manual.
-
Page 10: Adjustment
(3) Auto Button (4) Menu Button (5) Increase Button (6) Reduce Button (7) Power button (8) Power Indicator NOTE: CAL is only for MDA2120-A. 4.1 How to Use OSD Menu Hot key Functions Action Adjust the brightness Adjust the contrast... -
Page 11: Osd Menu And Operation Menu Introduction
MDA2120-A/MDA2120-S User Manual Use the Control buttons to make all required adjustments and press the MENU button to save the settings. 4.Exiting the OSD MENU To return to the main menu, select the <Return> icon and press the MENU button. - Page 12 MDA2120-A/MDA2120-S User Manual Red/Green/Blue color adjustment: use to adjust the value of red, green and blue to change the image color so as to meet your needs. Color temperature: use to select desired color temperature (9300k, 6500k,U SER) Color adjustment: it can be adjusted if under shadow mode. If you are not satisfied with the color temperature set by manufacturer, you may set the color temperature to USER mode;...
-
Page 13: Dicom Gsdf Calibration
MDA2120-S is accurately DICOM Part 14 calibrated at the production. To adjust the display from shifting away from the DICOM characteristic display function, ARMSTEL provides a dedicated tool for user to calibrate the display lookup table whenever needed. The tool includes a calibration software package, ®... -
Page 14: Trouble Shooting
For the use of Calispector , please refer to ARMSTEL home page for Calispector User Manual. Note: user needs to make sure using the right luminance table and the corresponding BARTEN table generated by the software to set the LCD display in the calibration. -
Page 15: Package And Accessory
MDA2120-A/MDA2120-S User Manual 7. Package and Accessory ® Amedicom MDA2120-A/MDA2120-S Medical LCD Monitor DVI cable USB cable Power cable Power adapter User manual CD VGA Cable（Optional） -15-... -
Page 16: Specification
MDA2120-A/MDA2120-S User Manual 8. Specification 8.1 Specification Panel: 20.1″ active display Supported Color : 16,777,216 colors Native resolution: 1600 x 1200 Pixel pitch: 0.255 x 0.255 mm Brightness: 300cd/m Typ. Contrast ratio: 800:1. Response time: 14 ms Typ. Connections: DVI-D D-Sub Operating temperature: 0°... -
Page 17: Dvi-D Connector
MDA2120-A/MDA2120-S User Manual 8.3 DVI-D Connector Pin# Signal Pin# Signal Pin# Signal T.M.D.S Data1/3 T.M.D.S Data2- Shield T.M.D.S Data2+ T.M.D.S Clock Shield T.M.D.S T.M.D.S Clock+ Data2/4 Shield DDC +5V T.M.D.S Clock- DDC-Serial Clock(SCL) DDC-Serial T.M.D.S Data0- Data(SDA) T.M.D.S Data0+ T.M.D.S Data0/5 T.M.D.S Data1-... -
Page 18: Declaration Of Conformity
FCC Warning: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 19 ARMSTEL, Inc. 888 S. Greenville Ave. Suite 103, Richardson, TX U.S.A. 75081 Tel: +001 972-231-8793 Website: www.armstel.com...
