Firstech 2W902R-SP User Manual

Firstech 2W902R-SP User Manual

2 way 5 button led remote & 2 way antenna
Hide thumbs Also See for 2W902R-SP:
Table of Contents

Advertisement

Quick Links

See also: User Manual
User Manual
By Firstech LLC, Version: 1.0
Applicable to the following remote(s);
2W902R-SP 2 Way 5 Button LED Remote
&
ANT-2WSP 2Way Antenna
Remote & Antenna
FCC ID Number (US Only)
IC ID Number (International Only)
2W902R-SP
VA5REC500-2WSP
7087A-2WREC500SP
ANT-2WSP
VA5A1000-2WSP
7087A-2WA1000SP
This device complies with Part 15 of the FCC rules. Operation is subject to the following conditions;
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following conditions;
(1) This device may not cause harmful interference.
(2) This device may accept any interference received, including interference that may cause undesired operation.
CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate this device.
WWW.COMPUSTAR.COM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2W902R-SP and is the answer not in the manual?

Questions and answers

Related Manuals for Firstech 2W902R-SP

Summary of Contents for Firstech 2W902R-SP

  • Page 1 User Manual By Firstech LLC, Version: 1.0 Applicable to the following remote(s); 2W902R-SP 2 Way 5 Button LED Remote & ANT-2WSP 2Way Antenna Remote & Antenna FCC ID Number (US Only) IC ID Number (International Only) 2W902R-SP VA5REC500-2WSP 7087A-2WREC500SP ANT-2WSP...

  • Page 2: Table Of Contents

    Introduction ..............................3  Warranty Coverage ............................3  Quick Reference ............................4  Button Lock ..............................4  Full or Half Paging Mode ..........................4  Valet Mode..............................4  Remote Maintenance – Battery Replacement ...................4  2 Way Remote Button Functions .......................5  Function Button Menu ..........................6  Remote Option Menu Table ........................6  Remote LED Functions and Descriptions ....................6 ...

  • Page 3: Introduction

    Introduction Thank you for purchasing a Firstech system for your vehicle. In order to truly enjoy the benefits of this system, we recommend that you thoroughly review the following manual. Please note that this manual applies to the 2 Way 5 Button LED Remote (2W902R-SP) Regardless of whether you purchased the ALARM IT, START IT, or MAX IT system.

  • Page 4: Quick Reference

    Full or Half Paging Mode The 2W902R-SP is shipped in Half Paging Mode. This means that the remote will only receive 2 Way LED confirmations for remote start and lock and unlock. It will not receive 2 Way LED confirmations when the alarm is triggered.

  • Page 5: Way Remote Button Functions

    Carefully pry off the back cover using caution that you do not damage the circuit board. Your battery size should be listed on the battery. Battery size: Two (2) CR2016) Replacements can be purchased from your local Firstech dealer or an electronics store.

  • Page 6: Function Button Menu

    When turned off, the LED will flash red twice. Full Paging Important: The 2W902R-SP is defaulted in HALF for START IT systems. It must be changed to FULL for alarm systems. <insert Unlock Half One On | Two Turns the silent mode on or off.

  • Page 7: Alarm Led Notifications

    Alarm LED Notifications In the event that your alarm has been triggered, your remote will receive notifications based on what zone has been violated. Please see the following table for details and a short description of each notification. Please note that these notifications are only available with MAX IT and ALARM IT systems. Zone LED Color Chirp(s)

  • Page 8: General System Functions

    2.5 seconds Option programming menu 2 - Installers Only. Half second Activates passive arming (vehicle will arm/lock 30 seconds after the vehicle is disarmed) Activates timer start mode. Timer start mode has multiple programmable settings: Half second duration settings, temperature settings and self start settings. Activates the built in Turbo Timer function.

  • Page 9: Automatic Transmission Remote Start Function

    The remote start run time can be programmed for 3, 15, 25, or 45 minutes - ask your local Firstech dealer to adjust Option 2-7 if you would like a run time other than 15 minutes (default).

  • Page 10: Trunk Release

    These outputs can be configured for pulsed, timed or latched settings. Your authorized Firstech dealer can set these outputs up accordingly. Using auxiliary outputs to control additional vehicle functions will require additional parts and can be rather labor extensive.

  • Page 11: Remote Mute

    simultaneously for a half second. IMPORTANT: Even when the siren is muted, it will still go off in the event the alarm is triggered. Remote Mute To silent your remote you must turn on Remote Mute on; STEP 1: Enter remote programming mode by holding the Trunk and Key/Start buttons simultaneously for 2.5 seconds.

  • Page 12: Advanced System Functions

    Advanced System Functions The following section reviews advanced system functions. Many of these functions require multiple steps or additional programming by your local authorized Firstech dealer to be active. Drive Lock/Ignition Controlled Door Locks Tap the Function button <insert icon> once followed by the Lock button to turn the Drive Lock on and off.

  • Page 13: Rps Touch And Rps (Remote Paging Sensor)

    RPS Touch and RPS (Remote Paging Sensor) The RPS is an optional feature. The car call/RPS feature uses a small sensor that is mounted on the inside of your windshield. RPS Touch (Remote Paging Sensor) The new RPS touch has multiple features including: remote paging, 4 digit pin unlock/disarm, and arm/lock.
  • Page 14 STEP 1: Enter remote programming mode by holding down the Trunk and Key/Start buttons <insert icon> simultaneously for 2.5 seconds. The remote will beep once and the LCD will read “REMOTE MENU” indicating that you have entered programming mode. STEP 2 : Scroll through the remote options by taping the Function button <insert icon>. Once the LCD reads “RPS-ON”...

  • Page 15: Secure Valet Switch

    If you purchased an Alarm or Alarm and Remote Start system you have the ability to add optional sensors from Firstech. You have the ability to protect your investment by adding a battery back up system to protect main power to your alarm or a tilt sensor to protect expensive rims and tires.

  • Page 16: Remote Coding / Programming Routine

    Remote Coding / Programming Routine IMPORTANT: Every Firstech remote must be coded to the system prior to performing any operations. All remotes must be coded at the same time. Programming 2 Way 5 Button Remotes: STEP 1: Activate Valet/Programming mode by manually turning the ignition key on and off (between the Acc &...

  • Page 17: Alarm Diagnostic

    Alarm Diagnostic While the alarm is armed, the LED will blink slowly. While the siren is going off, the LED will indicate which specific zone was triggered. Priority Situation LED On Duty Door/Hood/Trunk/Key Triggered 2 flash, rest, then repeat Shock Triggered 3 flash, rest, then repeat Optional Sensor Triggered 4 flash, rest, then repeat...

  • Page 18: Limited Lifetime Warranty

    Limited Lifetime Warranty Firstech, LLC Warrants to the original purchaser that this product shall be free of defects in material and workmanship under normal use and circumstances for the period of time that the original owner of this product owns the vehicle in which it is installed; except that the remote controller unit for the period of one year from the date of installation to the original owner of this product.
