- Page 1 Instruction manual Aluminium radiator with ceramic heart Smart Electric Heaters READ THIS CAREFULLY BEFORE USING THIS DEVICE FOR THE FIRST TIME. PAY ATTENTION: to avoid overheating, do not cover the appliance. HYCD-1500T...
-
Page 2: Safety Advice
SAFETY ADVICE READ THIS NOTICE CAREFULLY BEFORE OPERATING THE APPLIANCE. This product is not intended to be used by persons (including children) whose physical, sensory or mental capacities are reduced or by persons without experience or knowledge, unless if they have been given help, from someone responsible for their safety, supervision or giving the instructions concerning the use of the device. -
Page 3: Specifications
Frost protection function - automatically switches on if temperature drops below 7° to protect pipes from frost Number of Insulation Model Power Voltage elements class Heat Design – E600 600W AC 230 50Hz Class II Heat Design – E900 900W AC 230 50Hz Class II Heat Design – E1200... - Page 4 How to install the device Make sure that the distance from walls and objects is respected. Figure 1a 1 – Drill holes in the wall by following the steps in Figure 1. Make sure they are all correct. Distance L and M between the fixation points. Radiator 900W 1500W...
- Page 5 Figure 1b 2 - Place all the Rawl plugs in the holes in the wall, as in the previous step 3 - Attach the upper brackets using screws 4 - Place the radiator on the brackets 5 – Attach the lower brackets with screws and place the radiator to the wall Warning: Before plugging in the unit make sure the radiator is properly attached to the wall.
- Page 6 - Mode selection and programs - Increase of the selected criterion - Decrease of the selected criterion 2.2 / LCD display 1 - Hour 2 - Day 3 - Program number 4 - Programmed temperature 5 - Comfort mode 6 - Economic mode 7 - Frost mode 8 - Sleeping mode 9 - Locking radiator...
- Page 7 3 / FREE OPERATING MODE 3.1 – Use : Connect the unit to the mains, press the power switch on the back of the unit. Press , the icon disappears. The device is now running free . Preset temperature of 10°C. 3.2 –...
- Page 8 3.3 – Temperature setting Press once . The temperature display flashes. Press again to adjust the desired temperature. (the temperature can be set over a range of 10ºC to 35ºC). After 5 seconds without action on buttons , the temperature is validated. 3.4 –...
- Page 9 Increase or decrease the temperature by using 1- Press once 2- Choose by using 3- Press once to confirm your choice NOTE : If after selecting the program, no button on the keyboard is activated for 5 seconds, the selection is confirmed automatically. 4.2 –...
- Page 10 4.3 – Personalisation of the operating modes comfort and economic 1- Press for 3 seconds, the icon flashes and also the temperature indicator. 2- Use to adjust the desired temperature for the comfort mode. 3- Press to confirm your selection, the icon flashes and also the temperature indicator.
- Page 11 4.4 – Personalisation of the Daily programs : Press , then choose the program you want to personalise from , using 1- Press for 3 seconds, the icon PROG appears on the display. 2- The first segment of 00 : 00 flashes. Example program P1 : to choose how to allocate this first hour.
- Page 12 1- Press for 3 seconds, the icon appears on the display. 2- The number 1, representing MONDAY and the program corresponding P1 will flash. 3- Assign by using a program (from P1 to P9) for Monday. Confirm your selection with .
- Page 13 This product is marked with the crossed wheelie bin symbol relating to waste electrical and electronic equipment. This means that this product should not be disposed of with household waste but must be supported by a system of collection in accordance with EU Directive 2002/96/EC. It will then be recycled or dismantled to minimize impacts on the environment.
- Page 14 Warranty This product has a warranty of two years on Electrics and 10 years on the body of the radiator from the date of purchase. The warranty covers failures and malfunctions of the device through a use consistent with the intended use and information of the user manual. To be covered under warranty, proof of purchase is required (receipt or invoice) and the product must be complete with all its accessories.
