Summary of Contents for PreView Sentry ST87 Series
- Page 1 PreView Sentry ® ™ ST82 & ST87 Series Sensor Operating Manual...
-
Page 2: Table Of Contents
Keep Out/Interference Zones ................10 Sensor Mounting Procedure ................10 Troubleshooting ....................12 Object Detection Capability ................... 13 Notes on Safety and Risks..................15 Owner Responsibilities ..................15 PreView Sentry Daily Maintenance..............16 ® ™ Warranty Information .................... 18 Figures Figure 1. - Page 3 FCC STATEMENT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
-
Page 5: Overview
Overview This document describes the PreView Sentry radar sensor manufactured ® ™ by PRECO Electronics , located in Boise, Idaho, USA. The document does ® not claim to cover all the possible applications or deployment areas for these devices. This document may be amended, corrected, and enhanced in keeping with the sensor development progress. -
Page 6: Figure 2. Adjustable Detection Zone
Figure 2. Adjustable Detection Zone The Sentry has multiple models with preconfigured detection zones: both ™ www.preco.com range and width of detection zone. Note: the website contains the most current data on radar sensor models. Sentry ST87 Series radar sensors include an 8-pin Deutsch connector ™... -
Page 7: Other Sensor Features
Figure 4. Detection Zone 30 m The sensor is active and starts reporting detections within 300 milliseconds (ms) after power up. The Sentry performance is not affected by other PreView Sentry ™ ® ™ similar sensors operating in close proximity with each other. -
Page 8: Sensor Interfaces And Configuration
The maximum operating current is approximately 1 amp, including any inrush current. Sensor Input The PreView Sentry ST87 series radar sensor provides an auxiliary input ®... -
Page 9: Figure 5. Deutsch Connector Pin Out (St87 Series)
Figure 5. Deutsch Connector Pin Out (ST87 Series) Figure 6 shows the pin out for the Conxall connector (ST82 Series). The mate for the Conxall connector is the 6280-8SG-XXX. Figure 6. Conxall Connector Pin Out (ST82 Series). Tel: +386 3 4900 800 3702008A http://radar-electronics.com/ Copyright 2016... -
Page 10: Technical Data
PRECO Electronics provides a variety of different cable lengths and ® configurations for the PreView Sentry radar sensor, as well as solution ® ™ kits of radar, cabling, and displays. Please contact PRECO Electronics ® a list of available cables and kits. -
Page 11: Figure 9. Sensor Specifications
Measuring Performance Range: 0 – 30 m (10 dBsm target) depending on model number Range Accuracy: 0.3 m Azimuth Field of View: ±75 degrees (10 dBsm target) Elevation Field of View: ±10 degrees (10 dBsm target) Angle Accuracy: ±2° @ ±10° FOV, ±5 @ ±30° FOV, ±10 @ ±75° Velocity Range: ±... -
Page 12: Regulatory Compliance
Regulatory Compliance The Sentry is compliant with the following countries/regions and their ™ regulations as of the published date of this manual. The sensor may be compliant in other countries/regions. Please check your local regulations. United States - FCC- Part 15.249 FCCID: OXZJCKP2016 ... -
Page 13: Installation
Installation Sensor Mounting The Sentry mounting location is important for proper system operation. ™ Ideally the sensor should be mounted on the rear of the vehicle as close to the center as possible at roughly 36” (1 m) above the ground. The sensor face should be perpendicular to the ground with the small end of the “V”... -
Page 14: Keep Out/Interference Zones
The performance of the sensor can be negatively impacted if the sensor is angled down, causing false detection from the ground. Any time the sensor is not perpendicular to the ground, the performance should be tested. In some instances, mainly with longer range models, the sensor may need to be angled upward to reduce false detections from the ground. -
Page 15: Figure 12. Provided Sd-Bk90 (90° Mounting Bracket)
Figure 12. Provided SD-BK90 (90° Mounting Bracket) If mounting to the vehicle using the provided bracket, follow the procedure outlined below. 1. Select the appropriate sensor mounting location. 2. The standard mounting configuration is with the small end of the “V” graphic pointing down, as shown below. -
Page 16: Troubleshooting
Troubleshooting The troubleshooting below is for the most common PreView display. ® Refer to the particular display manual for errors code descriptions. Display Status LED is not illuminated. Verify that DC power (9-33 V) is applied to the sensor. -
Page 17: Object Detection Capability
The Sentry operates by ™ transmitting low power electromagnetic energy. Any energy that strikes an object reflects a certain amount of this energy back to the PreView ® Sentry radar sensor. If the returned energy is of sufficient magnitude, it is ™... -
Page 18: Figure 14. Object Reflection
Figure 14. Object Reflection 3702008A Tel: +386 3 4900 800 http://radar-electronics.com/ Copyright 2016 Page 14... -
Page 19: Notes On Safety And Risks
Notes on Safety and Risks Owner Responsibilities The owner is responsible for ensuring that the device (and equipment) are used for their intended purpose, for the actions of the employees, for giving instruction to the employees, and for the operational safety of the equipment. -
Page 20: Preview ® Sentry ™ Daily Maintenance
PreView Sentry Daily Maintenance ® ™ Detach this page and place with daily operator maintenance procedures. Safety Message to Operators of Vehicles with PreView Sentry Systems ® ™ The PreView Sentry system is intended as an Object Detection System and ®... - Page 21 Set the park brakes, start the vehicle, depress and hold the vehicle brake, and place the vehicle in reverse. Verify the green “POWER” light is illuminated on the in-cab display, or if using an in-cab video monitor, verify that the radar indicator is showing a green (operating) status.
-
Page 22: Warranty Information
Warranty Information MANUFACTURER STANDARD LIMITED WARRANTY AND LIMITATION OF LIABILITY Manufacturer warrants that on the Date of Purchase this Product will conform to Manufacturer's published specifications for the product, which are available from Manufacturer on request, and Manufacturer warrants that the product is free from defects in materials and workmanship. - Page 23 Tel: +386 3 4900 800 3702008A http://radar-electronics.com/ Copyright 2016 Page 19...
