Summary of Contents for Pfeiffer OPS 400
- Page 1 OPS 400 Integrated Power Supply Operating Instructions...
-
Page 2: Table Of Contents
Table of contents Table of contents About this manual ..........3 1.1 Validity. -
Page 3: About This Manual
About this manual Validity This operating manual is for customers of Pfeiffer Vacuum. It describes the functioning of the designated product and provides the most important information for safe use of the unit. The description follows applicable EU guidelines. All information provided in this operating manual refers to the current state of the product's development. - Page 4 About this manual Pictographs Prohibition of an action or activity in connection with a source of danger, the disregarding of which may result in serious accidents Warning of a displayed source of danger in connection with operation of the unit or equipment Command to perform an action or task associated with a source of dan- ger, the disregarding of which may result in serious accidents Important information about the product or this document...
-
Page 5: Safety
Do not independently modify or change the pump and electrical equipment. Make sure that the system is integrated in an emergency off safety circuit. Consult Pfeiffer Vacuum for special requirements. WARNING Danger due to lack of power disconnection device Pump and electronic drive unit are not equipped with a power disconnection device. -
Page 6: Proper Use
Safety Proper use ● Pfeiffer Vacuum power supply units OPS 400 only serve to the integrated voltage sup- ply of Pfeiffer Vacuum turbopumps. ● Only operate Pfeiffer Vacuum power supply units OPS 400 directly mounted on the pump. ● Only operate Pfeiffer Vacuum power supplies in the available specification. -
Page 7: Product Description
Product description Product description Product identification The power supply unit OPS 400 forms a single unit with the turbopump and the electronic Product characteris- drive unit. The power supply is mounted to the pump and connected to the electronic tics drive unit ex factory. -
Page 8: Connecting The Power Supply
Fig. 3: Connecting the mains supply Electronic drive unit 10.1 Connecting plug Power supply OPS 400 WARNING Danger of electric shock In case of defect, the parts connected to the mains supply are under voltage. Always keep the mains connection freely accessible so you can disconnect it at any time. -
Page 9: Operation
Operation Operation Switching on CAUTION Automatic start After bridging the contacts Pin 1, 3, 4, 14 on the connection "remote" or using the mating plug supplied and setting up the supply voltage, the turbopump will run up immediately. Switch on the mains supply on the turbopump immediately before operation. ... -
Page 10: Replacing The Integrated Power Supply
Remove the power supply from the pump. Unscrew and remove the connecting plug 10.1 from the electronic drive unit. The power supply OPS 400 is fixed with an adapter plate to the bore holes in the bottom Particularities in part of the pump HiPace 300. -
Page 11: Assembly
Exclusively use the fixing holes which are shown in in the figure. Screw cable with connecting plug 10.1 to the electronic drive unit (DC in). Mount OPS 400 with provided bore holes to the bottom part of the pump. -
Page 12: Service
Service The power supply OPS 400 and the bottom part of the HiPace 300 pump with the elec- Particularities in tronic drive unit differ in length. This gives two possibilities to fix the power supply flush HiPace 300 to the pump (see figure). -
Page 13: 10 Technical Data
Technical data 10 Technical data Parameter OPS 400 Ambient temperature 5-50 °C Protection category IP 54 Mains requirement: frequency (range) 50/60 Hz Mains requirement: power consumption 450 VA Mains requirement: voltage (range) 115-230 (-20-+15 %) V AC Output voltage 48 (± 2 %) V DC Output current 8.4 A... -
Page 14: Declaration Of Conformity
We hereby declare that the product cited below satisfies all relevant provisions accord- ing to the following EC directives: ● Electromagnetic Compatibility 2004/108/EC ● Low Voltage 2006/95/EEC OPS 400 Harmonised standards and national standards and specifications which have been ap- plied: DIN EN 61000-3-2 : 2008... - Page 15 Vacuum solutions Pfeiffer Vacuum stands for innovative and custom from a single source vacuum solutions worldwide, technological perfection, competent advice and reliable service. Complete range From a single component to complex systems: of products We are the only supplier of vacuum technology that provides a complete product portfolio.
