MacDermid ColorSpan 5440UV Installation Instructions

Exhaust kit

Advertisement

These Installation Instructions are valid for the following Field
Replaceable Module Kits:
0901585
FMK,EXHAUST_KIT,N
ColorSpan is a registered trademark of MacDermid ColorSpan, Inc.
Other products mentioned herein are trademarks or registered
trademarks of their respective companies.
June 2007 © MacDermid ColorSpan, Inc. All rights reserved.
Part Number 0706436, Revision A
ColorSpan 5440
ColorSpan 5445
ColorSpan 5460
ColorSpan 5465
Installation Instructions for Exhaust Kit
UV
UV
UV
UV

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ColorSpan 5440UV and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for MacDermid ColorSpan 5440UV

  • Page 1 These Installation Instructions are valid for the following Field Replaceable Module Kits: 0901585 FMK,EXHAUST_KIT,N ColorSpan is a registered trademark of MacDermid ColorSpan, Inc. Other products mentioned herein are trademarks or registered trademarks of their respective companies. June 2007 © MacDermid ColorSpan, Inc. All rights reserved.
  • Page 2 Exhaust Vent This kit provides two exhaust vents that can be installed onto the top-middle enclosure. Once installed, two exhaust hoses can be attached for venting. Installation Ventilation For proper operation, the outlets should provide a minimum of 110 cfm (cubic feet per minute) at each port (220 cfm total).
  • Page 3 Remove Both Fans 4. Using a phillips screwdriver, remove the eight screws (four for each fan) that secure the two fan finger guards to the top enclosure. The arrows indicate the four screws that secure the finger guard Hold the light-blocking plate as the last of the four screws is removed. The light blocking plate and fan will fall free when the screws are removed.
  • Page 4 6. Insert the original screws through the fan. The screws should be inserted through the side of the fan that does not have a label as shown below. The air flows in the direction of the fan’s label. 7. Insert the fan screws through the enclosure and into the screw holes of the exhaust vent. The exhaust vent should be oriented so that the vent will point up when the enclosure installed on the printer.
  • Page 5 Exhaust Tube 1. Connect to each exhaust vent using tubing for 4-inch (10.16 CM) vents . Connection 4-inch vent 4-inch vent Part No. 0706436 Rev A ColorSpan CS54xx Exhaust Kit Page 5 of 5...
