GST Bluetooth Headset - GL2BHS83
1.
Product Description-------------------------------------------------------------------1
2.
Product General Specifications ---------------------------------------------------1
2.1 General specifications -------------------------------------------------------------1
2.2 Function Button/Indicators --------------------------------------------------------2
2.3 User Interface ------------------------------------------------------------------------3
2.4 Figures --------------------------------------------------------------------------------4
3.
Regulation Compliance---------------------------------------------------------------5
4.
Environment Requirement-----------------------------------------------------------5
4.1 Drop and Vibration Test------------------------------------------------------------5
4.2 Usage Condition---------------------------------------------------------------------5
5.
Getting Started---------------------------------------------------------------------------6
5.1 Charging-------------------------------------------------------------------------------6
5.2 Normal operation position---------------------------------------------------------6
5.3 Turning the headset on and off---------------------------------------------------7
6.
Instructions-------------------------------------------------------------------------------7
6.1 Pairing the headset------------------------------------------------------------------7
6.2 Answering incoming calls----------------------------------------------------------8
6.3 Earphone volume control----------------------------------------------------------8
6.4 Ending a call--------------------------------------------------------------------------8
6.5 Making a call--------------------------------------------------------------------------8
CONTENTS
Advertisement
Table of Contents
Summary of Contents for Global Sun Tech GL2BHS83
-
Page 1: Table Of Contents
GST Bluetooth Headset - GL2BHS83 CONTENTS Product Description-------------------------------------------------------------------1 Product General Specifications ---------------------------------------------------1 2.1 General specifications -------------------------------------------------------------1 2.2 Function Button/Indicators --------------------------------------------------------2 2.3 User Interface ------------------------------------------------------------------------3 2.4 Figures --------------------------------------------------------------------------------4 Regulation Compliance---------------------------------------------------------------5 Environment Requirement-----------------------------------------------------------5 4.1 Drop and Vibration Test------------------------------------------------------------5 4.2 Usage Condition---------------------------------------------------------------------5 Getting Started---------------------------------------------------------------------------6 5.1 Charging-------------------------------------------------------------------------------6... -
Page 2: Product Description
1. Product Description GL2BHS83 is a wireless portable headset which enables users to answer incoming calls wirelessly from Bluetooth devices, which support Audio Gateway role, Headset Profile or Hands Free Profile, such as GST Bluetooth Audio Gateway (GL2BAG52) and Bluetooth mobile phones in proximity. -
Page 3: Function Button/Indicators
2.2 Function button/ indicators Symbol Functions TALK button Pairing; Answer a phone call forwarded from Bluetooth Audio Gateway device; Power on/off; Forward calls to phone Volume Up button (+) Adjust volume up Volume Down button (-) Adjust volume down Green LED Flashes 5 times when headset is turned on;... -
Page 4: User Interface
2.3 User Interface Source: CSR BlueCore2 – Headset Extra User Guide The profile that is in use depends on the profile the Bluetooth device supports or is currently operating. During each connection, there is only one profile is in use. Both profiles can not exist at the same time in a connection. Please refer to the user’s manual of the Bluetooth device. -
Page 5: Figures
2.4 Figures - 4 -... -
Page 6: Regulation Compliance
3. REGULATION COMPLIANCE300 Compliant with FCC Part 15 Class B, ETS 300 328, ETS300 826 Bluetooth Test Specification v1.1 compliant. 4. ENVIRONMENT REQUIREMENT 4.1 Drop and Vibration Test Anti-Static Voltage 4KV of static voltage testing onto the body should not cause system fail. Vibration Test The vibration test is performed under the frequency of 5 ~ 500Hz and the pressure of 1.3g in vertical and horizontal directions for 30 minutes, and... -
Page 7: Getting Started
5.1 Charging The GL2BHS83 is powered by a built-in rechargeable battery and the battery is not fully charged when the headset was packaged. Therefore, before using the headset in the first time, please charge the battery using the enclosed 5.0VDC power adapter. -
Page 8: Turning The Headset On And Off
5.3 Turning the headset ON and OFF Turning the headset ON Press and hold the TALK button for at least 3 seconds until 2 beeps are heard At the same time, Green LED flashes 5 times rapidly for a few times The headset is now turned on. -
Page 9: Answering Incoming Calls
6.2 Answering incoming calls When a call is forwarded from the paired device to the headset, a ring tone will be heard at the earphone. Press TALK button to answer the call. Green LED will then flashes 4 times for every 3 seconds periodically. NOTE: If your headset is paired with NOKIA cellular phone. - Page 10 Federal Communications Commission (FCC) Statement 15.21 You are cautioned that changes or modifications not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment. 15.105(b) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules.
