Summary of Contents for Cassida Omni-ID
- Page 2 This manual contains important information on safety measures and operational features of the Cassida Omni-ID. Please read it carefully before operating your counterfeit detector and ID verifier. Keep this manual handy for future reference.
-
Page 3: Table Of Contents
Table of contents: 1. INTRODUCTION 1.1 About the Cassida Omni-ID _______________________________________________ 2 1.2 Box contents _____________________________________________________________ 2 1.3 Front and rear views ______________________________________________________ 3 1.4 Specifications ____________________________________________________________ 5 1.5 Important safety notes ___________________________________________________ 5 2. GETTING STARTED 2.1 Powering up _____________________________________________________________ 6 2.2 Checking a bill’s condition________________________________________________ 6... -
Page 4: Introduction
UV security markings that cannot be seen with the naked eye. The Omni-ID features an array of ultraviolet (UV) LEDs to allow for checking the UV security features on ID cards, credit cards or any other item that has UV markings. -
Page 5: Front And Rear Views
1.3 Front and rear views 1 PASS/FAIL indicator 2 Front slot 3 UV power indicator 4 UV LEDs 5 UV viewing area 6 UV automatic on/off sensor Cassida Omni-ID Counterfeit Detector / UV Verifier... - Page 6 1 Rear slot 2 PC connection jack 3 AC adaptor power jack 4 ON/OFF power switch ®...
-
Page 7: Specifications
Do not operate the unit in areas with high temperatures or high humidity. These conditions may prevent it from working properly. • When not in use for an extended period of time, remove the power plug from the wall outlet. Cassida Omni-ID Counterfeit Detector / UV Verifier... -
Page 8: Powering Up
Connect the AC/DC adapter to the Cassida Omni-ID unit and plug the adapter plug into the power outlet. Turn the Cassida Omni-ID on by pressing the ON/OFF switch on the rear of the unit (see 1.3, rear view). The unit will emit a beep and conduct a short self-test. -
Page 9: Authenticating A Bill
1. The red FAIL light will illuminate and flash three times 2. The detector will emit a triple warning beep 3. The bill will be rejected through the insertion slot at the front of the unit Cassida Omni-ID Counterfeit Detector / UV Verifier... -
Page 10: Authenticating An Id
2.4 Authenticating an ID Position the ID card into the ID reader area. Once the ID is inserted, the green indicator light will illuminate above the ID insertion area signaling that UV lights are activated. The card will only need to be inserted approximately 1/2 inch into the unit for the UV lights to activate. -
Page 11: Maintenence And Warranty
Omni-ID unit. Use a soft cloth to clean the start sensor on the ID reader area. Follow up with canned air to blow any dust or lint out of the ID reader area. Cassida Omni-ID Counterfeit Detector / UV Verifier... -
Page 12: Troubleshooting
• Extended period of non-use. If the Omni-ID does not show UV security marks, first check that the ID is from one of the four states that do not currently use UV security marks on their IDs: Maine, New Hampshire, North Dakota and Tennessee. -
Page 13: Warranty
Warranty Our goal is to make Cassida your lifetime work partner. That’s why Cassida products are subject to stringent quality control measures and are backed by a solid one year parts and labor warranty. Warranty information is available at www.CassidaUSA.com/support.html... - Page 14 ®...
- Page 15 Cassida Omni-ID Counterfeit Detector / UV Verifier...
