- Page 1 SMART GLUCOSE METER USER MANUAL Brand Name: IGLUCOSE FCC ID: 2ACEUSGM-03 © 2014 Smart Meter Corp.
-
Page 2: Table Of Contents
3. Charging the Battery ............................ 2 Part II: Features and Functions Highlights ......................3 Part III: Smart Meter Parts ........................... 4 1. Smart Meter at a Glance ..........................4 2. Smart Meter Functions ..........................5 Part IV: Operating Smart Meter ........................... 6 1. -
Page 3: Part I: Safety And Precautions
SMART GLUCOSE METER USER MANUAL ___________________________________________________________________________________________ Part I: Safety and Precautions To ensure your safety and wellbeing, and the optimal functioning of your Smart Meter unit, please familiarize yourself withthe followingsafety measures and precautions before using Smart Meter. 1. Safety Measures 1. -
Page 4: Interference With Medical Equipment
If you do not intend to use Smart Meter for a long time e.g. more than 1 month, remove the battery from the Smart Meter so as to prevent damage to the battery or the unit. -
Page 5: Part Ii: Features And Functions Highlights
Dispose of batteries safely according to local regulations. Do not dispose of as household waste.Please recycle when possible. Part II: Features and Functions Highlights The Smart Meter is a new brand of glucose meter, with the following special features and functions: High quality color display ... -
Page 6: Part Iii: Smart Meter Parts
SMART GLUCOSE METER USER MANUAL ___________________________________________________________________________________________ Part III: Smart Meter Parts 1. Smart Meter at a Glance Figure 1: Front and reverse views of the Smart Meter unit Please see the following page for descriptions of the functions of the parts numbered above. Page... -
Page 7: Smart Meter Functions
Smart Meter Corporation SMART GLUCOSE METER USER MANUAL ___________________________________________________________________________________________ 2. Smart Meter Functions Note: Several keys perform different functions depending on the mode of use. The normal mode is indicated first; where applicable,anotherfunctionis indicated by the “in standby” or “press and hold”mode. -
Page 8: Part Iv: Operating Smart Meter
Prepare some test strips and test solution to test the unit. 2. Getting started To turn Smart Meter on, press and hold the middle key. A brief animation appears and the screen lights up. Note: 1) When the meter is turned on for the first time, it automatically connects to GSM to synchronize the time and date (This may take few seconds to 3 minutes!), and the network name will show at the top of the screen. - Page 9 Smart Meter Corporation SMART GLUCOSE METER USER MANUAL ___________________________________________________________________________________________ Notes: Whenever the unit is turned on, it will synchronize the time and date; however,it must connect to network. In areas with poor network coverage, this maytake a long time, or fail to connect.
-
Page 10: Selecting Menu Options
Smart Meter Corporation SMART GLUCOSE METER USER MANUAL ___________________________________________________________________________________________ 4. Selecting Menu Options The following table indicates the first level of menu options that are available when you select “menu” and then the second level of options, and where applicable, the third level of options,... -
Page 11: Obtaining Information
Smart Meter Corporation SMART GLUCOSE METER USER MANUAL ___________________________________________________________________________________________ 6. Obtaining Information 1) To go to Information, press and hold the key on the left (#1 in Figure 1).The following information appears: IMEI: International Mobile Equipment Identity number of the device ... -
Page 12: Appendix: Models
Smart Meter Corporation SMART GLUCOSE METER USER MANUAL ___________________________________________________________________________________________ Appendix 1: Models The Smart Meter models can be identified by model number as follows: Page | 10... - Page 13 Smart Meter Corporation SMART GLUCOSE METER USER MANUAL ___________________________________________________________________________________________ APPENDIX 2: SGM-03 Specification Main Details Hardware GSM Platform MT6260 Frequency GSM850/900/1800/1900 Antenna Interior on the bottom Type Module mounted NEC 78F0593 Test Sample Fresh Capillary Whole Blood Test Result Plasma / Serum glucose...
- Page 14 Smart Meter Corporation SMART GLUCOSE METER USER MANUAL ___________________________________________________________________________________________ Capacity 3.7V, 1,000mAh Li-Ion Battery Last time 25-30 days for normal use (2-3 tests per day) Software function Data entry Storage 1,000 entries Main standby GSM signal strength, battery level, carrier name, date/time etc...
- Page 15 Smart Meter Corporation SMART GLUCOSE METER USER MANUAL ___________________________________________________________________________________________ APPENDIX 3 Trouble Shooting Problem Possible reason Solution Cannot turn on meter No battery Fix a battery Battery connection error Check the connection Battery running out fast Meter in normal mode during...
- Page 16 Smart Meter Corporation SMART GLUCOSE METER USER MANUAL ___________________________________________________________________________________________ Use only the supplied or an approved replacement antenna. Unauthorized antennas, modifications, or attachments could damage the phone and may violate FCC regulations. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
