TS-RA1, TS-RA2 and TS-RK
Tank Overfill Alarms
Installation Guide
franklinfueling.com
3760 Marsh Rd. • Madison, WI 53718, USA
Tel: +1 608 838 8786 • Fax: +1 608 838 6433
Tel: USA & Canada +1 800 225 9787 • Tel: UK +44 (0) 1473 243300
Tel: Mex 001 800 738 7610 • Tel: DE +49 6571 105 308 • Tel: CN +86 10 8565 4566
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Franklin Fueling Systems TS-RA1
- Page 1 TS-RA1, TS-RA2 and TS-RK Tank Overfill Alarms Installation Guide franklinfueling.com 3760 Marsh Rd. • Madison, WI 53718, USA Tel: +1 608 838 8786 • Fax: +1 608 838 6433 Tel: USA & Canada +1 800 225 9787 • Tel: UK +44 (0) 1473 243300...
-
Page 2: Important Safety Messages
This unit gives the tank filling attendant the means to silence a Tank Overfill Alarm at the filling site. The TS-RK is required when a TS-RA1 or TS-RA2 is connected to a T5 series Fuel Management System console or a Colibri Automatic Tank Monitor. -
Page 3: Installation
Installation Overview The mounting location of TS-RA1, TS-RA2, TS-RK units should be based on: cable run length, ease of conduit routing, alarm light visibility, alarm horn audible range limitations, and the distance away from hazardous areas. In addition, the following limitations and requirements must be met. -
Page 4: Mounting The Units
Mounting the Units Wiring the Units Materials Required • Mount the TS-RA1, and/or TS-RK units through the four (4) mounting holes provided in the case under the front cover. • Wire: 18 to 14 AWG, 300 Volt, type TFFN, THWN, or THHN (Note: THHN is not available in 18 AWG). - Page 5 2AG 3A Fuse 1-1 LINE To 110 VAC 1-2 NEUTRAL Power Supply 1-3 GROUND REMOTE ALARM SIGNAL ACKN 1-6 FLASH DRIVE SWITCH 1-7 FLASH SHUNT LATCH MODE 1-8 OUTPUT 1-9 OUTPUT RETURN Console Relay Outputs TS-RK TS-RK and TS-RA1 Wiring Schematic...
- Page 6 1 2 3 4 See Table below N AUD L TS-RA2 2AG 3A Fuse 1-1 LINE To 110 VAC 1-2 NEUTRAL Power Supply 1-3 GROUND REMOTE ALARM SIGNAL ACKN 1-6 FLASH DRIVE SWITCH 1-7 FLASH SHUNT LATCH MODE 1-8 OUTPUT 1-9 OUTPUT RETURN Console Relay Outputs TS-RK...
-
Page 7: Setup And Operation
Press the acknowledgment button on the TS-RK to silence the alarm. b. If the Overfill alarm is not activated, there is an issue with the wiring. Clear the Overfill Alarm Relay checkbox to deactivate the relay. Consult the TS-RA1, TS-RA2, TS-RK installation manual for information about proper wiring. - Page 8 © FFS 2018 000-1027 r7...
