Summary of Contents for Aerospace Innotech SAAT-F805
- Page 1 RFID Reader User Manual Version: V2.0.0 ...
- Page 2 Thanks for your trust and support! We will be happy to provide you with comprehensive service and technical support. This manual will introduce the specific using methods of our reader SAAT-F805 to you you. In order to operate the readers safely & efficiently and make full use of the functions &...
- Page 3 This manual is suitable for the following readers: When this manual is written it is supposed that readers have basic knowledge over RFID and computer. The technical words, such as RFID, Radio Frequency & Ethernet etc in this manual, are not specifically introduced. Please refer to other reference books or consult our technical department for support.
-
Page 4: Table Of Contents
Table of Contents Part I Reader Introduction ................1 1. F805 Reader Introduction ................... 1 2. Technical Parameter ................... 2 3. Reader Function Introduction ................2 3.1 System Function ........................2 3.2 Tag Operation Function ......................5 Part II Reader Structure and Interface ............ - Page 5 3.3. Application in special situation .................... 34 Part VI Transportation and Storage ............35 1 Transportation Requirements ................35 2 Storage Require ....................35 Part VII Packaging and Accessory ............36 1 Product Packaging .................... 36 2 ...
-
Page 6: Part I Reader Introduction
Part I Reader Introduction F805 Reader Introduction F805 RFID reader is independently developed by Shenzhen Academy of Aerospace Technology, aiming for ISO18000-6B and ISO1800-6C (EPC Class1 Gen2) protocol standard. With the characteristics of long reading-range, stability & reliability, massive functions and expandability, F805 could be applied in many applications: logistic control, transportation management, asset management and plant supervision, and so on. -
Page 7: Technical Parameter
Technical Parameter F805 Reader parameters as following: Technical Parameters Description Operating Frequency 920.75~927.25MHz, frequency band adjustable Tag Protocol ISO18000-6B、ISO18000-6C (EPC Class1 Gen2) FM Mode FHSS Frequency Points 50 points (frequency points adjustable) Data Transmission Ratio 40kbps Antenna Port 4 SMA RF interface(Professional Installation) They have the same structure and circuit and at any time there is only a antenna for transmitting and receiving. - Page 8 F805 reader provides multiple communication interfaces catering for different application environments: Standard RS-232 serial port, support speed range 9600~115200bps Standard 10M /100M Base-T Ethernet interface, support AUOTO-MIX function, identify cross-line or straight line and automatically switches send/receive channels. Standard USB2.0 interface Status Indicator F805 reader provides the following status indicators: power, antenna selection and antenna port carrier output, reading tag, data communication indications.
- Page 9 Independent Antenna Port Cycling Query Time Configuration The four antenna ports of F805 reader could be set with different query time. This feature enables users to configure appropriate working time for different antenna, when they are using cycling query for tag operation to optimize the system. Modify Ethernet Configuration Parameter In Real-time After modify the Ethernet configuration parameters of reader such as IP address, the reader would simultaneously update the parameter.
-
Page 10: Tag Operation Function
and return to the computer. 3.2 Tag Operation Function Tag Filtering Reader can be configured to support the label filtering. After start the tag filtering function, if reader gets a tag ID and sends to host computer successfully, within the configured time reader would filter the same tag ID, and it will send the tag ID again when the configured time out. -
Page 11: Part Ii Reader Structure And Interface
Part Reader Structure and Interface This chapter explains F805 reader structure, the external reader interface type and function definitions in details. Reader Structure F805 reader casing is aluminum-magnesium alloy die cast, with better strength and EMC. RF interface and communication interface work in a different panel, which is easy for wiring and operation. -
Page 12: Front Panel
contents of the nameplate etc. Front Panel Front panel is RF interface panel, 4 of them is used for RF output antenna ports, using standard SMA connectors. Pic. 2-2 F805 Reader Front Panel Sketch Map Interface Definition: “1”－Antenna Port 1 “2”－Antenna Port 2 “3”－Antenna Port 3 “4”－Antenna Port 4... - Page 13 Pic. 2-3 F805 Reader Rear Panel Sketch Map Interface Definition: “1”－ DC power input port, standard XS-12 air connector “2”－Ethernet interface, standard RF-45, with network status indicator Yellow: Ethernet interface connection is normal; Green: Flashing indicates Ethernet interface is sending and receiving data “3”－USB interface, standard Type-B USB interface block “4”－RS-232 interface, standard DB9(female type) interface block.
- Page 14 Pic.2-4 F805 Reader Expansion Interface Sketch Map 1, 2, 3 are serial bus interfaces for expansion, marked "BUS". Expansion board is installed according to the internal differences can be configured for RS-485, CAN bus and Wiegand interface, it can also be expanded according to user needs to other interfaces, the corresponding marks as shown in Table2-2.
-
Page 15: Top Panel
Please note that when using this interface to connect the device's internal circuitry and load, avoiding connecting output interfaces directly to ground for short-circuit or overload. When use the output interface supply power to other devices, please take care of the output power. When power beyond the limit, reader would auto-cut off for circuit protection. -
Page 16: Bottom Panel
Pic.2-5 F805 Reader Top Panel Sketch Map There are 6 LED indicators on the top panel of F805 reader. Each indicator has a corresponding icon. Meaning of the numbers corresponding to the icon as follows: “1”－Power indicator, red and green, red means reader is using an external power supply, and green means remaining unused. - Page 17 There are 4 mounting interfaces on the bottom panel, for installing the reader on the mounting bracket. There are nameplate, reader model, product serial number and manufacturer information, etc on the bottom panel.
-
Page 18: Installation And Debugging
Part III Installation and Debugging Please carefully read this chapter before installation and debugging F805 reader. Installation Notes To ensure your personal & property security and equipment running well, before installing F805 reader, do the following preparations: Understanding of local power supply parameters; check the whether the voltage and frequency range comply with local power line. -
Page 19: Installation Preparation
installation, and check whether there are some special restrictions on wireless equipments (such as hospital, airport). Knowing what are the devices working range within 900~960MHz (such as GSM base station), in order to reasonably configure the frequency and power of reader, if necessary it is recommended to use additional filtering components. If user has no sufficient experience at this, please feel free to contact HTRFID or its agent. -
Page 20: Connection Components
1．Desktop Installation Put the reader on the work table, as Pic. 3-1 Be noted before choosing this installation method: The reader and its cables would not be cut down by accident, and causing disconnection or power cut off by incident. If there's vibration or possibility of tilt, please take some fixing measures. - Page 21 This section will illustrate how to connect reader, antenna and computer with data cable and RF cable. 1．Antenna Installation The antenna beam coverage is the valid read range for tag identifying. According the requirements of working environment, the reader antennae could use top horizontal installation (in vehicle passage, gantry) or vertical side installation (installed on holding pole);...
- Page 22 There are SMA RF connectors on F805 reader front panel, while the connector of general low power consumption coaxial-cable is N type. Thus it needs the RF switch cable to switch, which connects one end to reader and the other to RF cable. Pic.
- Page 23 Pic.3-6 F805 reader connecting computer through serial port There is one 1.5m RS-232 data cable in F805 reader accessories. The connection of data cable is as following: F805 Pic.3-7 RS-232 data cable connection USB interface is used for short distance connection (less than 3m). Through the dedicated USB data cable to connect reader USB port with computer directly, as Pic.3-8.
- Page 24 If user selects USB data cable on his own, please try to choose the USB2.0 specialized data cable with magnetic ring. Ethernet is used for long distance connection (10m), through reticle to connect switch (exchange) or hub, as Pic.3-9. It can also connect directly with PC TCP/IP interface. The reader can auto-identify crosswire and through straight wire, hence user can use any of the cables to connect computer or switch equipments.
- Page 25 AC150~240V/50Hz; 2) Plug one end of the power cable to the power adaptor AC input port, and the other end to AC power outlet. The power indicator turns on. 3) Plug the power adaptor DC output port into reader power input port; The interface of reader uses aerial connector, with high reliability, easy to plug in/out.
-
Page 26: Reader Parameter Configuration
initialization, the buzzer in reader would sound three short beeps. All the indicators would light for one second, and then only power indicator is on. The whole process of initialization is completed and the reader is standby. If the reader self-detects failed, the buzzer would sound 5 short beeps. - Page 27 please refer to <RFID Reader Data Stream Controlling Protocol>. (CD-ROM does not come with this protocol, unless there is a special requirement).
-
Page 28: Part Iv Routine Maintenance And Repair
Part IV Routine Maintenance and Repair This chapter is used to introduce the problem may encounter when using F805 reader and the simple fault diagnosis method. If the consumer has problem or doubt in self -software control,please use the "reader management software" for test to confirm whether it is caused by software or by the reader.The configuration of the "reader management software"and the demo function have almost cover all the consumer functions.You can ask... - Page 29 Check whether using the line from the accessories. If not, please check whether the line can satisfy the requirement described in section 3.4.2. Following the method: Use the multimeter to test whether pin 2 is conducted with pin 3; similarly, test whether pin 3 is conducted with pin 2;...
- Page 30 The reader has "AUTO-MIX" function, it can auto identify the TX/RX data line and auto switchover send-receive access. But some accident may happen to cause identification fault (Such as disturbance by the overlength of the reticle). It's suggested to use the right connect way.
- Page 31 antenna port actually using. Check whether using the linearly polarized antenna. If it is, please rotate 90 degree and then test. Check the plane of tag is parallel with the plane of antenna. Because most antennae need parallel position for good long-distance Reading ability. Vertical position is not allowed. Make sure whether the tag is intact.
- Page 32 the distance to confirm this factor.
-
Page 33: Rfid Integration Application
Part V RFID Integration Application Application assembly explain A whole RFID integration application system is consist of reader, RFID tag, antenna, computer system and software. Please refer to the specific requirements of components as following: 1.1. Computer Computer system is used to run the consumer system integration software. So it should at least satisfy the basic requirement for running the system integration software. -
Page 34: Antenna
RF cable is one of the most important parts in the RFID system. Its quality can directly affect the reader performance. So the RF cable in RFID application should satisfy the following requirement: Using RF coaxial cable, such as SYV (Solid polyethylene insulated) series model. The total length of the RF cable should no more than 10 meters. -
Page 35: Communication Cable
1.5. Hopping Information 1. The operating frequancy of system is jumped randomly. and then, the next frequency start to operate , so this is a true frequency hopping system. 2. system operating frequency change by internal random number generator, it can not know external frequency occupancy, so it can not avoid frequency interference. -
Page 36: Integration Application Reference
Integration Application Reference RFID reader belongs to wireless communication device, which has a great relationship between the system performance and signal disturbance and attenuation. The chapter will give some advice about the F805 reader optimizing usage. Signal disturbance issue Signal disturbance means when the reader and RFID Tag exchanging information, there are other RF signal or disturbance signal coming from other communication devices, strength of which to a fixed range around the tag working frequency range. -
Page 37: Optimization Method
Signal reflex means wireless signal reflex when transmitted in the space encounter with another medium (metal, liquid) .Reflex from the RFID Tag back metal or metallized plane can also affect the signal quality. In some condition, this effect can enlarge the reading distance, meanwhile it can get a dead angle in the reading range..When the RFID tag locates in these dead angles, the communication between the tag and the reader will very bad. -
Page 38: Special Remind
2. The change of the antenna port or antenna type can cause serious damage to the system permanence. 3. Environmental RF features including architectural space, building materials, around huge device and metal frame work, should be taken fully consideration. The difference of the RF features can both reduce and enhance the Reader working performance. -
Page 39: Disturbance By Other Devices
The design of F805 can satisfy the National requirement about wireless device damage to human body. But in actual integration application, user should not stay in the Reader RF range for a long time. 3.2. Disturbance by other devices The reader works in UHF frequency range. There are other working frequency ranges... -
Page 40: Transportation And Storage
Part VI Transportation and Storage Transportation Requirements The design and packaging of the F805 Reader can satisfy the requirement of common electronic devices in road, railway, aviation, water transport. Storage Require The long-term storage house for F805 Reader should be provided the following conditions: Ambient temperature:40~+80℃；... -
Page 41: Packaging And Accessory
Part VII Packaging and Accessory Product Packaging With internal anti-shock material box packaging, F805 reader can use large IBC for transportation Accessories Including F805 principal machine, the packaging box also contains the necessary accessories and spare parts. Please check details in the following table. Table 7-1 Product packaging box list Serial Name... -
Page 42: After Sales Service
Integrated Application Information: Such as the conditions of installation, antenna type in use, the tag type, the application software and computer configuration, and so on… 2 Contact Information Shenzhen Aerospace Innotech Corporation Limited Address: Floor 8, Block B, SZAAT Building,10th Road Kejinan,Hi-Tech Park,Nanshan District, Shenzhen City, Guangdong Province of China... - Page 43 FCC Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
