2. ASSEMBLY INSTRUCTIONS.

1. Remove all packaging and ensure all parts are correct (see parts list). Insert the
seat into the seat post. Using the nut and bolt, screw driver and spanner, secure the
post tightly (fig.1).
2. Insert the handle bars into the seat section. Using the nut and bolt, screw driver
and spanner, secure the handle bars tightly (fig.2).
CAUTION! ENSURE THE SCREWS ARE SECURED TIGHT BEFORE USE.
3. Unscrew the knob from the bottom of the seat post (fig. 3).
4. Unfold the connector blocks and extension arms from underneath the non slip
board. Insert the handle bar and seat section into the base of the sit & ride (fig. 4).
5. Attach the knob back onto the seat post from the underside of the sit & ride and
ensure it is secured tightly (fig. 5).
6. Press the button on the connector blocks to release the connector straps (fig. 6).
7. Attach the connector straps around the upright rear legs of the chassis and push
back into the connector block until tight (fig. 7).
CAUTION! ENSURE THE CONNECTOR STRAPS ARE SECURE BEFORE USE. ALWAYS
ATTACH THE CONNECTOR STRAPS TO THE REAR UPRIGHT LEGS OF THE CHASSIS.
8. Adjust the sit & ride base using the adjusters located at the front side of the base
(fig. 8) until the sit & ride is level (fig. 9).
11. The sit & ride can be unattached from the chassis without having to remove
the connector blocks for ease of use. Press the button on the side of the connector
block to release the clip and remove the board (fig. 10).
