Maxa Technologies Ltd
Test Procedure
MAXATEC
MT150/MT200
Creating an Ethernet Port
Configuring Ethernet Board
This document is the Maxatec™ procedure to creating the Ethernet port for use with the
MT150/200 printer. Please read through these instructions from start to finish following the
instructions given to fully setup the Ethernet port.
DOCUMENT NO: DSXXXX
AUTORISATION NO: XXXX
PAGE 1 OF 6
Advertisement
Table of Contents
Summary of Contents for Maxa Technologies Ltd MAXATEC MT150
- Page 1 Maxa Technologies Ltd Test Procedure MAXATEC MT150/MT200 Creating an Ethernet Port Configuring Ethernet Board This document is the Maxatec™ procedure to creating the Ethernet port for use with the MT150/200 printer. Please read through these instructions from start to finish following the instructions given to fully setup the Ethernet port.
-
Page 2: Adding The Printer
Setup Procedure Introduction: This document has been created to help you create and setup Ethernet communications to the Maxatec MT-150/MT-200 printers. Please follow the instructions below to complete the setup process. Please note that although this document contains screen images from a Windows XP system, the same procedure applies to Windows 2000/Vista/Win7. - Page 3 Then reboot your PC Select the Settings option from within the Start menu, and then select the Printers/Faxes option as shown in the image below: DOCUMENT NO: DSXXXX AUTORISATION NO: XXXX PAGE 3 OF 6...
- Page 4 After selecting the printer to be connected, click on the right hand mouse button, from the menu that appears select the properties option. Select the Ports tab from within the Properties window and click on configure port. Make sure that settings are; Protocol RAW and port number 9100. DOCUMENT NO: DSXXXX AUTORISATION NO: XXXX PAGE 4 OF 6...
- Page 5 Select the port of the installed printer, and then select the OK option Configuring printer IP Address: There are two versions of Ethernet board. Depends of what chipset is on the board, we will use different software for changing IP address. Latest version has ARM chipset, and we will use LKEtherconfig_v110 to configure IP address, for ATMEL chipset we will use TCPIPCFG100v110.
- Page 6 Configuring LKEtherconfig_v110 Click on search button and utility will find the printer MAC address, port number and IP address. Make your own configuration and press save to store settings to the printer. Configuring TCPIPCFG100v110. The same, click on search button and utility will find the printer. Set your own IP address and click on save button to store data to the printer.
