- Page 1 Aria-24/A Aria-24/D Digital Key Telephone System Installation Manual Aria Technologies 895 Wellington Rd. Rowville VIC 3178 ABN : 22 090 723 925...
- Page 2 CONFIDENTIALITY The information contained in this manual is the property of Aria Communications Pty. Limited. The contents of this manual must not be copied, distributed or made available to any third party without the prior written consent of Aria Communications Pty. Limited. Every effort has been made to ensure that this manual documents the operation of the Aria-24ipe Digital Key Telephone System.
- Page 3 Aria-24 ipe Digital Key Telephone System Installation Manual Issue 1.4 Revision History ISSUE DATE Contents of Changes REMARK Field Trial Initial Document 2004.09 Jan 2005 CPCU4 March 2005 Add Aria-24/D ipe October 2005 Add Expansion KSU April 2006 Add VMIBE/AAFBE Feb.
-
Page 4: Table Of Contents
3.1 Installation of the boards ............... 23 3.2 MBU (Main Board Unit) ................24 3.2.1 Aria-24/A ipe ......................24 3.2.2 Aria-24/D ipe ....................... 25 3.2.3 Aria-24/A ipe Modular Jack Connections ............26 3.2.4 Aria-24/D ipe Modular Jack Connections ............. 29 Common Facility ......................33 Aria Technologies... - Page 5 5.3.3 Rack Mounting ....................65 5.4 VOIM (Voice over Internet Protocol Interface Module) Installation..67 5.4.1 Pin assignment ...................... 69 5.4.2 VOIU(Voice over Internet Protocol Interface Unit) ..........70 Section 6. Connection of the Terminal ......71 Aria Technologies...
- Page 6 7.2.4 Permanent update procedure ................79 7.2.5 How to reset the system ..................79 7.2.6 Pre-programming ....................80 7.2.7 RACK SLOT ASSIGNMENT (PGM 101) .............. 83 7.2.8 LOGICAL SLOT ASSIGNMENT (PGM 103) ............84 Section 8. Troubleshooting ..........89 Aria Technologies...
-
Page 7: Important Safety Instructions
If the product exhibits a distinct change in performance. 13. Avoid using a telephone during an electrical storm. They may be a remote risk of electric shock from lightning. 14. Do not use the telephone to report a gas leak in the vicinity of the leak. Aria Technologies... -
Page 8: Precaution
3. The correct disposal of your old appliance will help prevent potential negative consequences for the environment and human health. 4. For more detailed information about disposal of your old appliance, please contact your city office, waste disposal service or the shop where you purchased the product. Aria Technologies... -
Page 9: The Structure Of Manual
Describe the kinds of Terminal, maximum distance, and the other device connection of Terminal. Section 5. Starting the Aria-24ipe System Provides general information of starting the system and basic preprogramming. Section 6. Troubleshooting Provides information on the Aria-24ipe System and Terminal troubleshooting. Aria Technologies... -
Page 10: The List Of Abbreviations
R.F: Radio Frequency RAM: Random Access Memory RD: Received Data ROM: Read Only Memory RSSI: Received Signal Strength Indicator RTC: Real Time Clock RTS: Request To Send RX: Receive Signal SG: Signal Ground SLIB4: SLT interface Board 4 ports Aria Technologies... - Page 11 SMDI: Station Message Detailed Information STIB: Basic Rate S/T Interface TD: Transmitted Data TDM: Time Division Multiplexing TERM: Termination TX: Transmitting signal UCD: User Call Distribution UTP: Unshielded Twisted Pair VMIB: Voice Mail Interface Board VOIP: Voice over IP Aria Technologies...
-
Page 12: Section 1. Introduction
Simple installation & efficient system management Remote admin through BRI connection Remote admin through PSTN modem Remote admin through LAN connection Value-added features Distinctive voice mail CID (CO & SLT) 1.2 System connection diagram Internal MODEM Admi LAN:10M Ethernet CTI, EzPhone. Aria Technologies... -
Page 13: System Components
Auto Attendant Function Board, 3 channels LANU LAN interface Unit(10Mbase-T only) MODU MODEM unit(33Kbps) PLLU Phase Locked Loop Unit(for STIB) VOIM Voice over Internet protocol interface module (4 channels) Expansion Voice over Internet protocol interface unit (4 channels) VOIU Aria Technologies... -
Page 14: Specifications
Expansion KSU VOIM: 0.58Kg LAN Interface 10 Base -T Ethernet(IEEE 802.3) Speed 10 Mbps Duplex Half duplex or Full duplex (Auto-Negotiation) Bell, ITU-T, V.34, V.32BIS, V.90 MODU Analogue modem 300bps up to 30Kbps speed rate Automatic rate negotiation Aria Technologies... -
Page 15: System Capacity
1/MBU External Paging 1/MBU External Control Contact 2/MBU * Power Failure Transfer * 1/MBU (Aria-24/A only) Alarm Input 1/MBU RS-232C Port 1/MBU DTMF Receiver 3/MBU, 2/SLIB Auto Fax detection 1/MBU * PFTU is not Available on the Aria-24/D Aria Technologies... -
Page 16: Section 2. Installation Of The Ksu
6. If an extension does not operate properly, disconnect the telephone from the extension line and then connect again, or turn the power of the Aria-24ipe System off and on again. 7. Use twisted pair cable for co line connection. Aria Technologies... -
Page 17: Installation Of The Ksu
Aria-24 ipe Digital Key Telephone System Installation Manual Issue 1.5 2.2 Installation of the KSU 2.2.1 Unpacking Open the box and check the items below: Key service unit Mounting template Power cord Battery cable Tie cable Anchor plug Fuse Screw Aria Technologies... -
Page 18: Ksu Exterior And Dimension
Aria-24 ipe Digital Key Telephone System Installation Manual Issue 1.5 2.2.2 KSU exterior and dimension Aria Technologies... -
Page 19: Ksu With Expansion Module Exterior And Dimension
Aria-24 ipe Digital Key Telephone System Installation Manual Issue 1.5 2.2.3 KSU with expansion module exterior and dimension Figure 2.2.3 shows the exterior and dimensions of the KSU: Figure 2.2.3 KSU with expansion module exterior and dimension Aria Technologies... -
Page 20: Opening And Closing The
Aria-24 ipe Digital Key Telephone System Installation Manual Issue 1.5 2.2.3 Opening and closing the front cover Opening the front cover 1. Turn the screw anticlockwise to loosen. 2. Lift the front cover in the direction of the arrow. Aria Technologies... - Page 21 1. Insert the front cover into the receptacle of KSU. Then put the front cover down on the KSU in the direction of the arrow. 2. Turn the screw clockwise to tighten. Note For safety reasons, close the front cover and tighten the screw when the Aria-24ipe system is in operation. Aria Technologies...
-
Page 22: Frame Earth Connection
3. Proper earthing is very important to protect the Aria-24ipe system from the effects of external noise or to reduce the risk to the user of electrocution in the case of lightning strike. 4. The equipment shall be connected to a socket-outlet with a protective earth connection. Aria Technologies... -
Page 23: Power Supply Unit Installation
Before installation, assure that the AC plug is not plugged into the AC outlet. The PSU is located at the left-most area of the KSU as a basic unit and provides three kinds of power sources to MBU through the 7PIN connector, CN19. Aria-24/A ipe The AC input voltage and the fuse rating The Range of Input Voltage... - Page 24 Aria-24 ipe Digital Key Telephone System Installation Manual Issue 1.5 2. Place PSU cover on the PSU as shown below. Then turn the screws clockwise to tighten. Aria Technologies...
-
Page 25: External Backup Batteries Connection
Dispose of used batteries according to the manufacturer‟s instructions. 4. It is recommended to use a fuse(5A @250V) between battery and system. 5. Recommended battery capacity is 24V/10AH MF battery. The Aria-24ipe system will operate more than 5 hours with this battery. Aria Technologies... -
Page 26: Wall Mounting
2.2.7 Wall mounting 1. Install 3 anchor plugs in the wall with using mounting template. Fix the mounting template with 3 screws. 2. Hook the KSU onto the screw, making sure that the system slides down and check it securely. Aria Technologies... - Page 27 Aria-24 ipe Digital Key Telephone System Installation Manual Issue 1.5 * Note Be careful not to drop the KSU. Aria Technologies...
-
Page 28: Optional Mounting Rack
2.2.8 Optional mounting Rack 1. Attach the rack bracket to the bottom of the Aria-24ipe system as shown below. And to fix the system securely, tighten the screw clockwise. 2. To hook the Aria-24ipe system, fix the bracket with 4 screws. Aria Technologies... -
Page 29: Section 3. Installation Of Boards
1. Before inserting the board, remove the dummy. 2. Holding the board as shown, insert the board in the direction of the arrow carefully so that the board is made to engage with the connector on the main board securely. Aria Technologies... -
Page 30: Mbu (Main Board Unit)
PCM tone generation and PCM Gain control. The MBU is installed in the KSU basically. It provides various kinds of connectors and RJ45 modular jacks for the connection of peripheral boards and miscellaneous functions. 3.2.1 Aria-24/A ipe CPCU4 Aria Technologies... -
Page 31: Aria-24/D Ipe
Aria-24 ipe Digital Key Telephone System Installation Manual Issue 1.5 3.2.2 Aria-24/D ipe MBUB Aria Technologies... -
Page 32: Aria-24/A Ipe Modular Jack Connections
Aria-24 ipe Digital Key Telephone System Installation Manual Issue 1.5 3.2.3 Aria-24/A ipe Modular Jack Connections Connector/Modular jack/Switch functions Switch/Connector Functions Remark CN3 & CN4 PLLU installation For STIB CO board(LCOB, STIB) installation Extension board(DTIB, SLIB) installation CN7 & CN8... - Page 33 SIGNAL NAME RJ45 DKT-R, DKT-T Reserved SLT-R, SLT-T 6,7,8 Reserved MBU MJ3(Extension) Connector Socket Pin Number SIGNAL NAME RJ45 1,2,3 Reserved SLT-R, SLT-T 6,7,8 Reserved Terminal DKT Connector Type Socket Pin Number SIGNAL NAME RJ11 RESERVED RING RESERVED Aria Technologies...
- Page 34 Aria-24 ipe Digital Key Telephone System Installation Manual Issue 1.5 Terminal SLT Socket Pin Connector Type SIGNAL NAME Number RJ11 RESERVED RING RESERVED MJ4 Pin assignment Socket Pin Connector SIGNAL NAME Number RJ45 Relay1-R, Relay1-T Relay2-R, Relay2-T EXT_PAGE-R, EXT_PAGE-T Alarm-R, Alarm-T Aria Technologies...
-
Page 35: Aria-24/D Ipe Modular Jack Connections
External Relays, External Paging, & Alarm sense PJ1 (Red) External MOH connection Lithium Battery ON/OFF switch for Memory and RTC Database back-up System reset button 4 poles DIP switch for software usage 1 pole DIP switch for JTAG reset Reserved Aria Technologies... - Page 36 RJ45 type jack Max. 1000 meters CN21 OFF : T mode NT1(NT - BOX) BRI Port2 Only T interface From/to PX TX - RX - RX - TX - RJ45 type jack Max. 1000 meters ON : Termination Aria Technologies...
- Page 37 Line 1 Default T Only * NOTE 1. SW5(Pin3, 4) : -40V Power Feeding. 2. SW7 : The mode Change of the BRI transceiver. 3. CN21 : Set four 2pin jumpers like the above figure according to each mode. Aria Technologies...
- Page 38 MBUB MJ3-3,4(Extension) Connector Pin Number SIGNAL NAME RJ45 1,2,3 Reserved SLT-R, SLT-T 6,7,8 Reserved Terminal DKT Connector Type Pin Number SIGNAL NAME RJ11 RESERVED RING RESERVED Terminal SLT Connector Type Pin Number SIGNAL NAME RJ11 RESERVED RING RESERVED Aria Technologies...
-
Page 39: Common Facility
Dispose of used batteries according to the manufacturers instruction.” 2. The 4th pole (switch 4) of SW3 should be OFF to protect the variety features by Admin programming after the system power up and initialization. Aria Technologies... - Page 40 Signal Ground Data Terminal Ready Clear To send Request To Send RESERVED Connector Pin Number SIGNAL NAME FUNCTION RS-232C RESERVED Received Data Transmitted Data Data Terminal Ready Signal Ground Data Set Ready Request To Send Clear To Send RESERVED Aria Technologies...
-
Page 41: Installation Of The Co Line Board
LCOB can be optionally equipped with a CPCU4 (FSK CID, & Call Progress Tone detection Unit 4) to detect FSK signal for the incoming Caller-ID. The LCOB can be installed on the „LCOB/STIB‟ connector. Add-on board: CPCU4 CPCU4 Aria Technologies... - Page 42 Provides four call progress tone detection to support ACNR feature (Auto Called Number Redial) and four FSK CID signal detection. It also provides four on-hook connection paths for SMS. The CPCU4 can be optionally mounted on LCOB. NOTE: CPCU4 does not provide Polarity Reversal functions.(Reversal on Idle) Aria Technologies...
-
Page 43: Stib (Basic Rate Interface Board : Selectable S/T Interface )
# SW4 : The default is 1, 2 pin‘s ON position and 3, 4 pin‘s OFF position - BRI2(Ch2) provides T interface only. # SW1 : The default is ON position Refer to PGM 203 to set the TEI type. Aria Technologies... - Page 44 STIB(Port1) T interface F ro m /t o P X RJ45 type jack Max. 1000 meters OFF : T mode NT1(NT-BOX) STIB(Port2) Only T interface From /to P X RJ45 type jack Max. 1000 meters ON : Termination Aria Technologies...
- Page 45 The line connector and terminating resistors SW 1and SW4‟s 1, 2 pin setting : the default is all ON position. Terminating Resistors Line No RJ45 type jack Remark Pin3, 4 Switch Pin1, 2 ON Termination Open Line 1 Termination Open Line 2 Aria Technologies...
- Page 46 Line 2 T Only * NOTE 4. SW4(Pin3, 4) : -40V Power Feeding. 5. SW2 : The mode Change of the BRI transceiver. 6. CN1 : Set four 2pin jumpers like the above figure according to each mode. Aria Technologies...
-
Page 47: Installation Of The Extension Board
DTIB4 can be installed on the „SLIB/DTIB‟ connector. Pin assignment DTIB4 Connector Type Socket Pin Number SIGNAL NAME FUNCTION RJ45 1,2,3,6,7,8 Reserved DKT_RX Receive Data DKT_TX Transmit Data Socket Pin Connector Type SIGNAL NAME Number RJ11 RESERVED RING RESERVED Aria Technologies... -
Page 48: Dtib8 (Digital Terminal Interface Board)
DTIB8. DTIB8 can be installed the „SLIB/DTIB‟ connector. Pin assignment DTIB8 Connector Socket Pin Number SIGNAL NAME FUNCTION RJ45 1,2,3,6,7,8 Reserved DKT_RX Receive Data DKT_TX Transmit Data Socket Pin Connector Type SIGNAL NAME Number RJ11 RESERVED RING RESERVED Aria Technologies... -
Page 49: Slib4 (Single Line Interface Board)
SLIB4 and Single Line Telephone is performed through RJ45 Modular Jack, MJ3. SLIB4 can be installed the „SLIB/DTIB‟ connector. Pin assignment SLIB4 Connector Socket Pin Number SIGNAL NAME FUNCTION RJ45 1,2,3,6,7,8 Reserved SLT_RX Receive Data SLT-TX Transmit Data Socket Pin Connector Type SIGNAL NAME Number RJ11 RESERVED RING RESERVED Aria Technologies... -
Page 50: Slib8 (Single Line Interface Board)
SLIB8 and Single Line Telephone is performed through RJ45 Modular Jacks, MJ2 & MJ3. SLIB8 can be installed the „SLIB/DTIB‟ connector. Pin assignment SLIB8 Connector Socket Pin Number SIGNAL NAME FUNCTION RJ45 1,2,3,6,7,8 Reserved SLT_RX Receive Data SLT-TX Transmit Data Socket Pin Connector Type SIGNAL NAME Number RJ11 RESERVED RING RESERVED Aria Technologies... -
Page 51: Installation Of Other Boards
User Greeting is not lost by system power off or reset because of this message is stored in FLASH memory. MBU SW3-4 controls the protection of recorded messages. LD1 gets turned on when any RECORD/PLAY channel is activated. The VMIB can be installed on the ‗VMIB/AAFB‘ connector. Aria Technologies... -
Page 52: Aafb(Auto Attendant Function Board)
User Greeting is not lost by system power off or reset because of this message is stored in FLASH memory. MBU SW3-4 controls the protection of recorded messages. The AAFB can be installed on the ‗VMIB/AAFB‘ connector. NOTE LD1 gets turned on when any RECORD/PLAY channel is activated. Aria Technologies... -
Page 53: Vmibe (Voice Mail Interface Board Enhanced)
User Greeting is not lost by system power OFF or reset because the message is stored in FLASH memory. MBUB SW3-4 controls the protection of recorded messages. LD1 gets turned on when any RECORD/PLAY channel is activated. Aria Technologies... -
Page 54: Aafbe(Auto Attendant Function Board Enhanced)
RECORD/PLAY Channel 3 channels Max record time: 28 Min System/time stamp 28 Min User record time Not Possible NOTE: AAFBE is supported from software Version 2.1Bb. LD1 gets turned on when any RECORD/PLAY channel is activated. Aria Technologies... -
Page 55: Lanu(Lan Interface Unit)
Transmit Data Transmit Data Receive Data Receive Data The LED indication of MJ1 Meaning LED1 (Green) OFF: No Link ON: Link, Toggle: Data Transfer LED2 (Orange) OFF: Link and activity at 10MBps ON: Link and activity at 100MBps Aria Technologies... -
Page 56: Modu (Modem Function Unit)
3.5.6 MODU (MODEM function Unit) Description MODU provides analog modem connection. Supports Bell, ITU-T, V.34, V.32BIS, V.90 Protocol 300bps up to 33Kbps speed rate Automatic rate negotiation MODU should be installed on the „MODU‟ connectors. Aria Technologies... -
Page 57: Pllu Aria-24/A Ipe (Phase Locked Loop Unit)
The status of PLL ( ON : ACT, OFF : INACT ) 3.5.8 PLLU Aria-24/D (Phase Locked Loop Unit) PLLU provides system clock, 32MHz, phase locked to BRI line to system clock generation circuits. PLLU module is not required in the Aria-24/D it is onboard the MBUB Aria Technologies... -
Page 58: Section 4. Dect Installation
Base station Specifications(GDC-400B) Item Specification Power feeding +30V DC Transmission Max Power 250mW Access Method/Duplex TDMA/TDD Frequency Band 1,880 ~ 1,900MHz Channel Spacing 1.728MHz Modulation GFSK Data rate 1.152Mbps Max. Base Station distance from the WTIB(WDIB) 600m (twisted 2-pair cable) Aria Technologies... - Page 59 Maximum registered terminals Max. Simultaneous Wireless calls * The number of maximum channel is limited by the number of maximum registered terminals Important NOTE: Max total Station capacity 12 wired 16 DECT IP handsets total must not exeed 28 Stations. Aria Technologies...
-
Page 60: Wtib / Wdib Installation
2. The modular connectors, WTI1 to WTI4, are connected to Base Stations using 2-pair unshielded twisted pair cable. WTIB LEDs LED No. LED On HDLC Interrupt LED 1 10ms task interrupt operation LED 2 Voice channel active LED 3 Echo canceller enable LED 4 Aria Technologies... -
Page 61: Wdib Installation
One base reset Base reset mode 4.2.2 WDIB Installation The WDIB connects to Base Stations using 2 pair of an RJ45 connector ass shown in Figure 6.2 and wiring charts below. Figure 4.2.2 WDIB, Wireless Terminal Interface Board Aria Technologies... - Page 62 Digital Key Telephone 4 WDIB Switches Default Switch 3-1 Normal service TBR6 mode Operation mode Switch 3-2 Echo canceller on Echo canceller off Echo canceller Control Switch 3-3 Reserved Reserved Switch 3-4 All base reset One base reset Base reset mode Aria Technologies...
-
Page 63: Base Station Installation
Insert anchors into the drilled holes. Then insert screws in the anchors, leaving a 3mm gap between the wall and screw head. Mount the base station eyelets on the screws. Aria Technologies... -
Page 64: Mounting Base Station - 2 (Using Wedge)
The number of base stations used in a system depends on the area to be covered and the traffic density. The typical in-house coverage is a 40m radius. In practice the cell size may vary between 10 meters indoor in worst cases situation and up to 200m outdoor in free space Aria Technologies... -
Page 65: Installation Of The Ferrite Core And Wiring
Ferrite core is provided in the package of Base station for EMI. Ferrite core should be installed when WTIB/WDIB is installed in the key telephone system. One Ferrite core in the package of base station is for line cord between base station and each port of WTIB/WDIB. Aria Technologies... -
Page 66: Expansion Module Installation
Single Line Telephone interface: 8SLTs 2 wire 2SLTs/port DTIM 4 ports RJ45 Digital Terminal interface: 8DKTs 2 wire 2DKTs/port 5.1 Unpacking Open the box and verify the items shown in Figure 5.1 are included: VOIM Cord cover(Optional) Screw Module Aria Technologies... -
Page 67: Opening And Closing The Front Cover
Issue 1.5 Opening and closing the front cover 5.2.1 Opening the front cover 1. Turn the screw counter-clockwise to loosen as shown in Figure 5.2.1. 2. Lift the front cover in the direction of the arrow as shown: Aria Technologies... -
Page 68: Closing The
2. Then put the front cover down on a module in the direction of the arrow, as shown. 3. Turn the screws clockwise to tighten, as in the Figure. NOTE For safety reasons, close the front cover and tighten the screws prior to operating the Aria-24ipe System. Aria Technologies... -
Page 69: Mounting Expansion Module
Issue 1.5 5.3 Mounting Expansion Module 5.3.1 Connecting Expansion Module to KSU 1. Insert the expansion module into the slot of basic KSU as show in Figure 5.3.1. 2. Turn the screws clockwise to tighten, as in the Figure. Aria Technologies... -
Page 70: Wall Mounting
The KSU with an expansion module is mounted on the wall in the same way with basic KSU and an expansion module itself is not mounted on the wall as shown in Figure 4.3.2. 4.3.2 W IGURE ALL MOUNTING OF WITH AN EXPANSION MODULE Note : Be careful not to drop the KSU. Aria Technologies... -
Page 71: Rack Mounting
1. Attach the rack bracket to the bottom of an expansion module as shown in Figure 5.3.3.1. Figure 5.3.3.1 Rack Bracket 2. Attach it to a module securely by tightening the screws clockwise, as shown in the Figure below. Figure 5.3.3.2 Tightening Rack Bracket Aria Technologies... - Page 72 Connect an expansion module to basic KSU with the flat cable packed in the bracket package, IP LDK-20 ERB(Expansion Rack mounting Bracket), as shown in the figure below. Figure 5.3.3.3 Module Rack Mounting Note: The flat cable is supplied with Aria-24 ERB(Expansion Rack mounting Bracket) package. Aria Technologies...
-
Page 73: Voim (Voice Over Internet Protocol Interface Module) Installation
10 / 100 Base-T Ethernet (IEEE 802.3) Speed 10 Mbps or 100 Mbps (Auto-Negotiation) Duplex Half Duplex or Full Duplex (Auto-Negotiation) VoIP Protocol H.323 Revision 3 Voice Compression G.711/G.726/G729/G.723.1 Voice/Fax Switching T.38 Echo cancellation G.165 5.4.1 VOIM IGURE Aria Technologies... - Page 74 Default: Off VOIB Reset Switch for CPU (S32500C) Pole1: Trace function disable, others: reserved Default: ON JTAG(Joint Test Action Group) for debug VOIU Board Connection VOIU Board Connection Basic KSU Connection RS232C Trace Tool Connection Network(RJ-45) Cable Connection Aria Technologies...
-
Page 75: Pin Assignment
Link Status LED (ON: Link, Toggle: Data transfer, OFF: No MJ1-LD1 Link) MJ1-LD2 Speed Status LED (ON: 100Mbps operation, OFF: 10Mbps) 5.4.1 Pin assignment Connector Pin Number SIGNAL NAME FUNCTION RJ45 4,5,7,8 Reserved Transmit Data Transmit Data Receive Data Receive Data Aria Technologies... -
Page 76: Voiu(Voice Over Internet Protocol Interface Unit)
Issue 1.5 5.4.2 VOIU(Voice over Internet Protocol Interface Unit) Description The VOIU can be installed on the VOIB through CN2 and CN3 and provides the Ethernet interface for S/W applications and 4 VoIP channels. Figure 5.4.2.1 VOIU Installation Aria Technologies... -
Page 77: Section 6. Connection Of The Terminal
Various types of digital terminals are used with Aria-24ipe MBU/DTIB4/DTIB8 as below: Model Description LDP-7008D 8 Flexible Button Display LDP-7016D 16 Flexible Button Display LDP-7024D 24 Flexible Button Display LDP-7024LD 24 Flexible Button Large Display LDP-7048DSS 48 Button DSS Console LDP-7008D LDP-7016D LDP-7024D LDP-7024LD Aria Technologies... -
Page 78: Maximum Cabling Distance Of The Terminal
Aria-24 ipe Digital Key Telephone System Installation Manual Issue 1.5 6.2 Maximum cabling distance of the Terminal Aria Technologies... -
Page 79: Connection Of The Keyset
Issue 1.5 6.3 Connection of the keyset 6.3.1 Digital keyset Pin assignment Connector Socket Pin SIGNAL NAME Type Number RJ11 RESERVED RING RESERVED 6.3.2 SLT Pin assignment Connector Socket Pin SIGNAL NAME Type Number RJ11 RESERVED RING RESERVED Aria Technologies... -
Page 80: Lip-7000 Series Keyset
LAN AND VOIM PORT CONNECTOR PIN NUMBER SIGNAL NAME FUNCTION RJ45 4,5,7,8 RESERVED Transmit Data Transmit Data Receive Data Receive Data PC PORT CONNECTOR PIN NUMBER SIGNAL NAME FUNCTION RJ45 4,5,7,8 RESERVED Receive Data Receive Data Transmit Data Transmit Data Aria Technologies... -
Page 81: Connection Of The Additional Terminals
MBU provides an external alarm detection input, which can be used to notify to extensions when the external switch is closed or opened. This alarm detection input is provided through pin No.7-8 of MJ4. Close or open detection is programmable by ADMIN. Programming. Aria Technologies... -
Page 82: Section 7. Starting The Aria-24Ipe System
The Aria-24ipe System can be programmed to meet each customer's individual need. This section contains the following topics : Before ADMIN programming Button explanation How to enter the programming mode Permanent update procedure How to reset the system Aria Technologies... -
Page 83: Before Admin Programming
Sometimes the [SPEED] or [Delete] button is used to delete the data or “ ” to indicate end of data input. The [REDIAL] button is used to delete one digit or character from the end of entered digits or characters. Aria Technologies... -
Page 84: Button Explanation
There are many kinds of DKTU connecting to the Aria-24ipe system. This model of LDP-7024D is a sample that just shows each button. The detailed information about DKTU and other keyset is described in ―DKTU USER GUIDE and INSTALLATION MANUAL‖. Aria Technologies... -
Page 85: How To Enter The Programming Mode
If there were any errors in the entry, then an error tone is presented and data is not stored in the permanent memory. 7.2.5 How to reset the system To reset the system, enter PGM 450 – FLEX 15 and press [HOLD/SAVE] button. Or press Reset button on MBU/MBUB, located near the VMIB/AAFB Slot. Aria Technologies... -
Page 86: Pre-Programming
7 – 70 9 - 90 7 – 70 9 - 90 *1 - Blank *1 - Blank *2 - : 0-00 *2 - : 0-00 *3 - , *3 - , LKD (Aria select) Type Handsets LDP-7000 series handsets Aria Technologies... - Page 87 Monaco Morocco Netherlands New Zealand Nigeria Norway Oman Pakistan Panama P.N.G Paraguay Peru Philippines Portugal Qatar Saudi Arabia Senegal Singapore South Africa Spain Sri Lanka Swaziland Sweden Switzerland TELKOM Thailand Tunisia Turkey U.A.E. United Kingdom Uruguay Venezuela Y.A.R. Aria Technologies...
- Page 88 Type 4 Number Set 200 – 227 Type 5 Number Set 10 – 37 Type 6 Number Set 100 – 137 Type 7 Number Set The station number can be 10 – 37 Type 8 changed within 99. Aria Technologies...
-
Page 89: Rack Slot Assignment (Pgm 101)
Slot 5: CO board on MBUB. Slot 6: optional CO slot. Slot 7: VMIB slot. Slot 8: Slot 9: VOIM slot. Slot 10: WTIB/WDIB Note: The system will auto detect all the boards installed prior Boot-up and programming. Aria Technologies... -
Page 90: Logical Slot Assignment (Pgm 103)
(01: Hybrid slot on MBUB, 04:Optional, 99: Virtual slot for RSG/IP phone) Press [HOLD/SAVE] to accept change. VMIB Board Press [Trans/PGM] + 103. Press [FLEX3]. Enter logical slot number(VMIB slot : fixed 07 in LDK-20 ). Press [HOLD/SAVE] to accept change. Aria Technologies... - Page 91 If you want to change next 4 station numbers then press [▼] button. If you want to change previous 4 station numbers, then press [▲] button. (2) Press the [HOLD/SAVE] button for saving database permanently. (Ex: Press FLEX 2, dial 400 and press [HOLD/SAVE] button.) Aria Technologies...
- Page 92 Flash Command to CO Line Last Number Redial (LNR) Do-Not-Disturb Call Forward Speed Dial Program MSG Wait/Call-Back Enable MSG Wait/Call-Back Answer Speed Dial Access Cancel DND/CFW/Pre-selected MSG Features SLT Hold Forced Log In Forced Log Out SLT Program Mode Select ACD Reroute Aria Technologies...
- Page 93 Access Held Individual CO Line (8# + CO Line Number) Access to CO line in the 1st available CO Line Group Attendant Call Door Open – 1 Door Open – 2 VM MSG Wait Enable VM MSG Wait Cancel Aria Technologies...
- Page 94 (PGM NUMBER) (Range: 12 digits) -. Gateway Address (Use the # to skip) Enter Gateway Address (PGM NUMBER) (Range: 12 digits) -. Subnet Mask Address (Use the # to skip) Enter Subnet Mask (PGM NUMBER) (Range: 12 digits) Aria Technologies...
-
Page 95: Section 8. Troubleshooting
Exchange the board for normal one. SLT does not Bad connection between It should be checked that the board connection is operate the MBU/SLIB and SLT right and there is the mismatch of the lines of SLT and DKT on the MDF. Aria Technologies... - Page 96 A short shield cable is recommended. Distorted Excessive input level Decrease the output level of the external music External from external music source by using the volume control on the music source source. Aria Technologies...
