- Page 1 MS3500E/3510E Remote ER Data Logger Metal Samples Company A Division of Alabama Specialty Products, Inc. 152 Metal Samples Rd., Munford, AL 36268 Phone: (256) 358-4202 Fax: (256) 358-4515 E-mail: msc@alspi.com Internet: www.metalsamples.com...
-
Page 3: Table Of Contents
Table of Contents Introduction ........................1 A. Instrument Function Overview ................. 1 B. Instrument Parts List ....................2 II. Installation ........................3 A. Enclosure and Mounting Details ................3 B. Battery Installation ....................4 C. 4-20mA Loop Installation ..................5 D. - Page 4 D. ER Probe Body Design ..................38 Appendix A - MS3500E Specifications ................... 41 Appendix B - Testing the MS3500E/MS3510E with the ER Meter Prover ......42 Appendix C - MS1500E Select Probe ID ................44 Appendix D - Returning an Instrument for Repair ..............47 Appendix E - Warranty ......................
-
Page 5: Introduction
The LCD screen, together with the 2-key membrane keypad, provides a user-friendly, interactive, prompting system that is used for both system setup and data review. This makes the MS3500E the most advanced unit of its type on the market. -
Page 6: Instrument Parts List
B. Instrument Parts List The MS3500E/MS3510E is supplied with the following accessories. Part no. Qty. Description ET0133 1.5V, AA Dry Cells (Installed) ET0612 4-20ma Loop Connector (MS3510E Only) IN3500-2 Optilink Cable IN3500-4 10 Ft. Probe Cable IN3500-5 Meter Prover IN3500-6... -
Page 7: Installation
II. Installation A. Enclosure & Mounting Details The MS3500E/3510E enclosure is fabricated in carbon steel with a baked-on, high-build epoxy coating. The unit has a hinged door that is secured, when shut, by screw-down clamps that discourage unauthorized tampering. The enclosure is constructed to NEMA 4X (IP 66) weatherproof standards, making it suitable for the most rigorous of outdoor environments. -
Page 8: Battery Installation
B. Battery Installation The MS3500E/3510E instrument uses six 1.5V, AA size batteries, connected in series, as a primary power source. While any AA size battery can be used, Duracell or Procell Type MN1500 or PC1500 batteries are required to meet the intrinsic safety certification requirements. Since the MS3500E/3510E operates in a low power consumption mode between readings, battery life will be a function of the reading interval and measurement time cycle set by the user. -
Page 9: 4-20Ma Loop Installation
C. 4-20mA Loop Installation The MS3510E is provided with a 4-20mA communication outlet that allows continuous, real-time integration of ER corrosion data with other process parameters in the main plant computer. The 4-20mA outlet port is a 2-pin military connector (MIL 1 4S-9SF) on the base of the unit, marked 4-20mA. -
Page 10: Probe-Instrument Connection
The female connector (MS3106E145-6S) mates with the probe, or HA700110-5 probe adaptor, and the male connector mates with the central terminal on the base of the MS3500E/3510E unit. -
Page 11: Data Download Connection(S)
If a serial port is unavailable on your PC and you wish to connect the MS3500E to your PC via a USB port, you may use a serial to USB converter. This converter is not included with the instrument, but may be purchased separately at major electronics retailers. -
Page 12: Setup And Operation
III. Setup and Operation A. Main Menu Overview Once the batteries are installed in the MS3500E/3510E, the instrument screen may be activated by pressing either of the keys on the front panel. The company name “METAL SAMPLES” and software version will appear, then after a few seconds will automatically change to the first of the function screens that constitutes the main menu. - Page 13 As explained, each function screen gives access to a submenu, the purpose of which is briefly described below: MEASURE PROBE. This will override the normal interval of logging readings to allow a spot check reading to be obtained on screen. MEASURE METER PROVER.
-
Page 14: Program Setup
B. Program Setup Having installed the batteries, the MS3500E is ready for start-up programming which compromises the following sequence: • SET TIME AND DATE • ENTER PROBE ID • START LOGGING 1.Set Time and Date This operation is illustrated below: The screen of the instrument is initially activated by pressing either key. -
Page 15: Enter Probe Id
2. Enter Probe ID This function will allow the user to identify the particular probe type or installation location with a unique, 4-digit tag number. Additionally, it allows the selection of correct probe element geometry, which is necessary for the instrument’s calculation of metal loss and corrosion rate. Finally, it allows the user to select the data collection rate. -
Page 16: Start Data Logging
now required to access the “PROBE ID” function and reset/correct the probe ID, the element ID, and the reading frequency prior to commencing with the data logging process. Upon entry of the probe element ID, the screen will automatically change to the data collection rate screen. -
Page 17: Measure Probe Function
C. Measure Probe Function The “MEASURE PROBE” function allows the user to make a spot-check probe reading at any time, without constraint of the normal logging interval. The submenu sequence is illustrated below: The first screen of the “MEASURE PROBE” submenu displays the probe ID number, element geom- etry and thickness. -
Page 18: View Stored Data Functions
D. View Stored Data Functions This facility allows all data stored in the MS3500E/3510E to be called up on the screen for review. The submenu sequence is shown below: After pressing either key to access the MS3500E/3510E screen, KEY l is used to scroll to the “VIEW STORED DATA”... -
Page 19: Set Reading Interval Function
E. Set Reading Interval Function This function permits the reading interval to be changed at any time during logging without disrupting the logging process or deleting the stored data. The operation sequence is as follows: After any key is used to activate the screen, KEY 1 is used to scroll to the “SET READING INTER- VAL”... -
Page 20: Downloading Data
F. Downloading Data Data stored in the MS3500E/3510E unit may be downloaded, via the Opti-Link port, directly to a PC. Alternatively, data may be downloaded to Metal Samples’ MS1500E Hand-Held Data Logger, and subsequently transferred to a PC. Direct downloading is usually preferred in a control room or laboratory environment. - Page 21 The Instrument Download Center is a simple tool for retrieving data from Metal Samples ER and LPR data logger instruments. To download data from an instrument: • Connect the instrument to an available PC serial port or USB port (see page 7.) • Turn the MS3500E on. • Run the Corrosion Data Management Software...
- Page 22 • Open the Instrument Download Center • Select the serial port and instrument • Click the Download button (ensure that Part Status toggles to “On”). • From the main menu of the instrument, select UPLOAD TO PC. Data will begin to transfer from the instrument to the PC, and will appear in the data window of the Instrument Download Center as shown above.
- Page 23 Saving Data To save the data in the data window, click the Save button. The data is comma-delimited ASCII text. It can be saved to a standard text (.txt) file, or it can be saved to a comma-separated values (.csv) file, which greatly simplifies the process of importing the data into some spreadsheet programs such as ®...
- Page 24 Loading a Data File After selecting a data file (or clicking the Chart Data button from the Instrument Download Center) a status window will display the progress of the file being opened, along with the Instrument Type, Probe Type, and Probe ID for the data file. Data Table After a file has been successfully loaded, the data will be displayed in the Data Table for review.
- Page 25 Creating A Chart To chart the selected data, click the Chart Data button, or select Chart Data from the Options menu. The chart will be displayed in a new window. Printing a Chart A chart can be printed using the Print Chart option in the File menu. A print dialog box will be dis- played to allow printer selection and setup.
- Page 26 • Finding A Data Points Value While viewing the chart, the value of any data point can be determined by simply clicking it. The value will be displayed in the charts tool-tip box (a small text box that is displayed near the mouse pointer).
- Page 27 o Trend Line Show Trend Line toggles the trend line on and off. o Title/Footnote Setup Title/Footnote Setup displays a window that allows the chart title and footnotes to be toggled on and off, and to be modified. o Plot Setup Plot Setup displays a window that allows configuration of Y-axis scaling, and of the chart type.
- Page 28 o Zoom Out Zoom Out restores the initial view of the chart, which displays the full data set. o Calculate Corrosion Rate If the chart contains ER data, the Calculate Corrosion Rate option will become available under the Tools menu. This option allows the corrosion rate to be calculated between any two data points on the chart.
-
Page 29: Upload To Ms1500E
Once the communication connection is made between the MS3500E and the MS1500E instruments, switch on the MS1500E and select a probe ID that corresponds to the probe ID of the MS3500E/ 3510E in question. The user must now scroll to the communication menu on the MS1500E, and press enter. -
Page 30: System Shutdown Function
G. System Shutdown Function This function allows the user to suspend the logging process for any period of time without data loss. The menu screen sequence to operate the function is as shown below: To activate the “SYSTEM SHUTDOWN” function, the user should scroll through the main function screens using KEY 1 until the “SYSTEM SHUTDOWN”... -
Page 31: Data Interpretation
I. Data Interpretation The MS3500E supplies corrosion data in several formats: • Probe Reading (‘Probe Life Units’) • Metal Loss • Corrosion Rate • 4-20 mA (MS3510E) 1. Probe Reading This information is available through the “MEASURE PROBE” (see p. 13) menu for current reading, and through the “VIEW STORED DATA”... -
Page 32: Metal Loss
If a partially consumed probe is attached to an MS3500E/3510E to perform a logging sequence, the MILS value shown will be an overestimation of metal loss at the present locations by an amount equivalent to the thickness loss prior to the commencement of logging operations. -
Page 33: 20Ma Output
4. 4-20mA Output The current loop on the MS3510E unit will send a continuous measure of the current probe reading. This is a linearized signal that can easily be converted to ‘probe life units’ (PLU) at the receiving device by applying the following simple algorithm: (A-4) 1000 PLU = ...... -
Page 34: Er Technique - General
IV. ER Technique - General A. Measurement Theory The reduction in cross-sectional area of an element of metal or alloy as it corrodes is accompanied by a corresponding increase in the electrical resistance of the element. The relationship is given by: R = p x L/A ........(6) R = element resistance P = specific resistivity of the element alloy... - Page 35 Figure 5. Temperature Compensated Element The resistance of both the exposed element (R ) and reference element (R ) are equally influenced by temperature. Consequently, the resistance ratio of the exposed to reference elements is a function only of the loss in metal thickness on the exposed element, and therefore of corrosion. This resistance ratio (R ) is measured either periodically with a portable instrument, or continu- ously with a variety of continuous, automatic recording/data logging instruments and read as percentage...
-
Page 36: Er Sensing Elements
B. ER Sensing Elements Electrical resistance probe elements are offered in a variety of thicknesses and geometries. The most common are illustrated below: Wire Loop Cylindrical Tube Loop Flush Figure 7. Element Styles Tubular loop elements are constructed from thin-walled tubing. Their small cross-section allows fast response at low corrosion rates. - Page 37 The mechanism for sealing elements into probe bodies varies. For example, the cylindrical type elements are sealed with an all metal weld, whereas flush elements are sealed with an epoxy seal. The sealing mechanism of the element is a primary factor in determining the temperature and pressure rating of an ER probe.
-
Page 38: Er Element Performance
C. ER Element Performance The basic ER measurement gives percentage of metal thickness loss and is a function of the original element thickness. Essentially, total metal loss and corrosion rate are given by the following functions: X x K ............(7) 1000 ) x K x 365 .......... - Page 39 Table 3. K Factors Some of the newer instruments, the MS1500E and MS3500E/3510E in particular, perform metal loss and corrosion rate calculations automatically and display these as a direct reading. These instruments contain a selectable library of element geometries that, once selected, are automatically fed into metal loss corrosion rate calculations.
- Page 40 Figure 8. Element Selection Guide (Element Life)
-
Page 42: Er Probe Body Design
D. ER Probe Body Design ER probe bodies may be made in almost any design and material. Metal Samples frequently supplies custom probe designs for atypical applications. However, a standard range of designs are available that will cover the majority of uses. These standard designs are discussed in the following paragraphs. The fixed length probe, which has a body constructed in 316L stainless steel, is a general purpose probe construction. - Page 43 Retractable probes are the industry standard in refinery and petrochemical plants. The probe body is constructed in 316L stainless steel and compromises a one inch FNPT packing gland with a cylindrical probe shaft. Four basic probe lengths are available: 18", 24", 30", and 36". The actual insertion depth into the system varies depending on the mating pipe.
- Page 44 The retrievable probe is widely used in the oil and gas production and transmission industry and is part of a specially designed retrievable system. The probe is carried on a specially designed plug and in- serted through a welded or flanged access fitting as shown in Figure 12. The retrievable probe, which is normally constructed in AISI 316L stainless steel, can be inserted and removed from systems operating up to 3600 psi without system shutdown.
-
Page 45: Appendix A - Ms3500E Specifications
Appendix A - MS3500E Specifications Model MS3500E - Remote ER Data Logger (Ordering # IN3500) MS3510E - Remote ER Data Logger w/ 4-20mA Current Loop Output (Ordering # IN3510) Physical Data Instrument Weight: 11.94 lb. (5.42 Kg) Total Weight w/ Accessories: 13.64 lb. -
Page 46: Appendix B - Testing The Ms3500E/Ms3510E With The Er Meter Prover
ER Meter Prover An ER Meter Prover is provided to allow routine checks of the MS3500E/MS3510E instrument. The ER Meter Prover simulates a Wire Loop type ER probe at a fixed value which is printed on the Meter Prover label (as shown below.) - Page 47 It is important to note that the ER Meter Prover is only a check probe used to verify general instrument operation. It is not a calibration standard. The measured value may differ from the listed value as explained in step 3 above. It is also important to note that each ER Meter Prover is serialized to match the instrument it is shipped with, and its measured value may differ if it is used with another meter.
-
Page 48: Appendix C - Ms1500E Select Probe Id
ENTER or DELETE a probe ID or to select a probe ID from those already in memory for which you wish to make measurements. When transferring data from an MS3500E unit, the user will invariably select a new Probe ID. SELECT PROBE ID... - Page 49 Entering information To enter a number, type it using the keypad numbers. If you make an error, press the down arrow which allows you to type the number again. Pressing the up arrow retains the ID number you typed in. Entering probe type The MS1500E has a list of probe types in memory.
- Page 50 • when the memory bank is full • when a probe is no longer used • when MS3500E/3510E probe data has been downloaded from the MS1500E to a PC To delete the ID of a probe in memory, select DELETE PROBE.
-
Page 51: Appendix D - Returning An Instrument For Repair
Appendix D - Returning the Instrument for Repair A. Returning an Instrument for Repair If it is necessary to return any Metal Samples instrument for repair, the following procedure is recom- mended to ensure the fastest possible repair and return cycle. You may contact Metal Samples to verify that returning the instrument is necessary. - Page 52 Maintenance and Repair Instructions This form may be photocopied for use when returning instruments to Metal Samples for repair. Please fill in all known information. Enclose a copy of the filled in form with the instrument. 1. Check one: Repair this instrument under warranty. Repair this instrument regardless of problem or cost of repair.
-
Page 53: Appendix E - Warranty
Appendix E - Warranty Metal Samples warrants that any part of their corrosion rate instruments and accessories which proves to be defective in material or workmanship within one year of the date of original shipment to Purchaser will be repaired or replaced, at the option of Metal Samples, free of charge. This warranty does not cover (1) probe assemblies, (2) items expendable in nature, or (3) items subject to damage from normal wear, misuse or abuse, or failure to follow use and care instructions.
