Summary of Contents for SANDIA aerospace SAE5-35
- Page 1 SAE5-35 Altitude Data System Installation Manual SANDIA aerospace, Inc. SANDIA aerospace, Inc. SANDIA aerospace, Inc. SANDIA aerospace, Inc. SANDIA aerospace, Inc. 3700 Osuna Rd. NE, Suite 711 305186-00 Albuquerque, NM 87109 Rev. 3...
-
Page 2: Record Of Revisions
This document and the information contained herein is the proprietary data of SANDIA aerospace, Inc. No part of this document may be transmitted, reproduced, or copied in any form or by any means without the prior written consent of SANDIA aerospace, Inc. Due to SANDIA aerospace’s continued product and quality improvement programs, information contained in this document is subject to change without prior notice. -
Page 3: Table Of Contents
3.6.2 Calibration Procedures ................. 15 3.6.3 Placarding ....................16 3.7 Continued Airworthiness ..................16 List Of Illustrations Figure 3-1 SAE5-35 Outline Dimensions (with tray) ............9 Figure 3-2 J4/J5 Connector Wiring ................11 Figure 3-3 J4/J5 Connector Hood Assembly ..............11 Figure 3-4 J4 Pinout ...................... -
Page 4: Section 1 General Description
This manual describes the installation of the SANDIA aerospace SAE5-35 Altitude Data System. It is intended for use by FAA certified repair stations to install the SAE5-35 Altitude Data System and includes both the mechanical and electrical installation information for the SAE5-35. Calibration and checkout procedures are included. -
Page 5: Gillham Grey Code Output
1.2.3 Gillham Grey Code Outputs a. 10 Bits available: D4, A4, A2, A1, B4, B2, B1, C4, C2, C1 b. Bit On Impedance: Less than 5 ohms c. Bit Off Leakage: Less than 10uA d. Maximum Current per bit: 20 mA e. -
Page 6: Extended Mode
1.2.6.2 Extended Mode When the Mode pin (J5 pin 4) is grounded: a. Baud: 1200 b. Data bits: 8 c. Stop bit: 1 d. Parity: None e. Output rate: 1 +/- .2 seconds f. Message length: 17 bytes g. Altitude resolution: 10 foot h. -
Page 7: Environmental Qualification Form
Environmental Qualification Form for the SAE5-35 Altitude Data System NOMENCLATURE: SAE5-35, Altitude Data System TYPE/MODEL/PART NO: SAE5 – 35 / 305154-00 TSO NUMBER: C88a MANUFACTURER’S SPECIFICATION AN/OR OTHER APPLICABLE SPECIFICATION: SAE5-35 INSTALLATION MANUAL P/N 305186-00 QUALIFICATION TEST PLAN, SAE5-35 ALTITUDE ENCODER. P/N AENC0051 MANUFACTURER: SANDIA AEROSPACE ADDRESS: 5445 EDITH BLVD. -
Page 8: Section 2 Installation Considerations
The SAE5-35 does not require warm up unless the outside temperature is below 20 degrees C. When warm up time is required, the internal heater is capable of warming the SAE5-35 from -20 degrees C to operating temperature in less than two minutes. -
Page 9: Section 3 Installation Procedures
The SAE5-35 is supplied with a mounting tray and solder type mating connectors. It is important that proper solder techniques be observed in attaching wires to the mating connectors. Failure to do so could result in a failure in the connection and cause intermittent or non operation of the SAE5-35. EQUIPMENT REQUIRED 3.2.1... -
Page 10: Static Port Connection
“D” shaped hole is used to mount the brass fitting into the front panel. Upon completion of installation of the SAE5-35, a Case Leak test is to be performed per FAR Part 43 Appendix E... - Page 11 SAE5-35 power input to the transponder circuit breaker. Alter- natively, the two power pins, 8 and 14, are internally connected in the SAE5-35. Only one of these connections is necessary to supply power to the unit. The unused connection can be used to drive a panel-mounted indicator if desired.
-
Page 12: Figure 3-2 J4/J5 Connector Wiring
The SAE5-35 uses Sub-D solder cup connectors with screw lock assemblies. Proper wire attachment and assembly of the screw locks and connector hood are shown in Figure 3-2 and 3-3. It is recom- mended that each wire and solder cup be covered with a piece of shrink tubing or other insulator. -
Page 13: Figure 3-4 J4 Pinout
6. If the AIM function uses annunciator 4. Pin 8 and 14 are internally connected in the lamps provided by the installer, they SAE5-35. Only one line is necessary to supply should be appropriately labeled. The power to the unit. The unused power pin may lamp connected to pin 9 should be be used as a power loss indicator if desired. -
Page 15: Calibration
4. See Figure 3-5 for AIM function interconnect wiring. 3.6 CALIBRATION The SAE5-35 is calibrated at the factory to a pressure datum traceable to the National Bureau of Standards. However, when the encoder is installed in the aircraft it must be recalibrated to corre- spondence to the primary flight altimeter, refer to FAR 91.217 and FAR 91.413 for details. -
Page 16: Calibration Procedures
43 section E. Verify compliance with AC-43.13 as appli- cable. 1. Connect the pitot-static test set to the aircraft static system. The SAE5-35 must be connected to the aircraft static line near the flight altimeter and the two altitude adjust- ments buttons must be accessible. -
Page 17: Placarding
Figure 3-8 SAE5-35 Adjustment 3.6.3 Placarding We recommend that the altimeter used for flight reference and the SAE5-35 be placarded with the following information: Replacement or re-calibration of the altimeter used for flight reference requires re-calibration of SAE5-35 Altitude Encoder. -
Page 18: Figure 3-9 Gillham Grey Code Chart
Altitude D4 A1 A2 A4 B1 B2 B4 C1 Altitude D4 A1 A2 A4 B1 B2 B4 C1 C2 C4 -1000 4800 -900 4900 -800 5000 -700 5100 -600 5200 -500 5300 -400 5400 -300 5500 -200 5600 -100 5700 5800 5900 6000... - Page 19 Altitude D4 A1 A2 A4 B1 B2 B4 C1 C2 C4 Altitude D4 A1 A2 A4 B1 B2 B4 C1 C2 10600 16700 10700 16800 10800 16900 10900 17000 11000 17100 11100 17200 11200 17300 11300 17400 11400 17500 11500 17600 11600 17700...
- Page 20 Altitude D4 A1 A2 A4 B1 B2 B4 C1 C2 C4 Altitude D4 A1 A2 A4 B1 B2 B4 C1 22800 28900 22900 29000 23000 29100 23100 29200 23200 29300 23300 29400 23400 29500 23500 29600 23600 29700 23700 29800 23800 29900 23900...
