MA NEO MP18X Series Quick Start Manual

NEO
MP18X Series
Quick Start Guide
mPower Electronics Inc.
3046 Scott Blvd. Santa Clara, CA 95054
www.mpowerinc.com
info@mpowerinc.com
Warning
⚫ Never operate the monitor when the cover is removed.
⚫ Remove the monitor cover only in area known to be non-hazardous.
⚫ Substitution of components will impair suitability for intrinsic safety and void
warranty.
⚫ Always bump test with a known concentration gas to confirm the instrument is
functioning properly before use.
⚫ Before use, ensure that the ESD film on the display is not damaged or peeling.
Avertissement
⚫ N'utilisez jamais le moniteur lorsque le couvercle est enlevé.
⚫ Retirer le couvercle du moniteur et la batterie uniquement dans une zone connue
comme non dangereuse.
⚫ La substitution de composants compromettra l'aptitude à la sécurité intrinsèque
et annulera la garantie.
⚫ Il est recommandé de tester avec un gaz de concentration connu pour confirmer q
ue l'instrument fonctionne correctement avant de l'utiliser.
⚫ Avant de l'utiliser, assurez-vous que le film ESD sur l'écran n'est pas endommagé
ou épluché.
Precautions
⚫ For maximum safety, the accuracy of the instrument should be checked by
exposing it to a known concentration calibration gas before each day's use.
⚫ Ensure that the gas inlet is not blocked.
⚫ When replacing batteries, dispose of old ones properly.
⚫ For optimal accuracy, allow the unit to warm up for 2 minutes after the start-up
cycle is complete.
⚫ Make sure the water-trap filter is clean & replaced timely.
⚫ Remove the sensor only if absolutely necessary. Zero & span calibration are
required if the sensor is moved.
The Neo's User's Guide must be carefully read by
all individuals who have or will have the
responsibility of using, maintaining or servicing this
V1.0
product. The product will perform as designed only
if it is used, maintained and serviced in accordance
with the manufacturer's instructions.
⚫
⚫
⚫
⚫
Four key operation, one big LCD with LED
backlight, four red alarm LEDs, and one buzzer.
Left Key
(Esc/Move
Cursor Left)
Down Key
(Power/Number
Decrease)
Charge/Comm Port
2
WARNINGS
Read Before Operating
Caution
Change battery only in area known to be
non-hazardous.
Use only mPower's
12.02.02.0017 and 12.02.02.0019 .
Attention:
Changez la batterie uniquement dans
une zone connue
dangereuse.
Utiliser uniquement la batterie mPower
PN: 12.02.02.0017, 12.02.02.0019.

User Interface

Gas Inlet
Sensor
battery PN:
pour être non
1
Water-trap Filter
LED Alarm
LCD
UP Key
(Confirm/
Number Increase)
Right Key
(Enter/Move
Cursor Right)
Buzzer
3
