Using the Beer Check: Quick Start Guide

Connect the adaptor

and tube to the

Beer Check by twisting the Luer Lock fittings

clockwise until snug. (The tubing should be

pushed on the adaptor.)

Read

The threads on

Caution on the Back Page!

the adaptor are 7/8" - 14 threads like the

connections on a typical keg coupler. Turn off

the gas to the keg and release the handle

of the coupler. Reduce the outlet pressure

of the Secondary regulator to 5 to 10 psi.

Disconnect the gas supply from the coupler and attach to the

adaptor.

Turn on the Beer Check

by touching the screen. It will open in

the CO2/N2 mode within 10 seconds. Turn on the gas to the Beer

Check.

The most accurate reading is when the numbers

first stop flashing for more than a few seconds.

The Beer Check will

turn itself off but you'll increase times between battery charges if

you turn it off after you have taken a reading.

Turning the Beer Check Off:

Touch "Main" and then "Off".

Gas Supply ON

Gas Supply OFF

Table of Contents

Need help?

Do you have a question about the Beer Check and is the answer not in the manual?

Page 1 Using the Beer Check: Quick Start Guide Connect the adaptor and tube to the Beer Check by twisting the Luer Lock fittings clockwise until snug. (The tubing should be pushed on the adaptor.) Connect to the gas system: Read The threads on Caution on the Back Page! the adaptor are 7/8”...
Page 2 (1 to 2 scfh @ 5 to 10 psig). (Same thread as keg couplers) attach gas line nut here. 1/4 hose barb attach 0.022” Ø Hole here allows flow of Beer Check tube here. (8 to 15 scfh @ 5 to 10 psig)
Page 3 To turn it off manually touch the Main icon and then the Off icon. The Beer Check cannot be calibrated in the field. It is ideal to keep a known, accurate calibration gas to test the unit from time to time, ensuring the accuracy of your readings.
Page 4 This is true whenever working on a gas supply system. The Beer Check is intended to work in the modes described in the Beer Check Instructions. It will not work accurately with other gas combinations.
