Komodo II CoaXPress Frame Grabber
Hardware Reference and Installation
Guide
(Part-No. KY-FGKII)
2 0 a M e s i l a S t . , N e s h e r 3 6 8 8 5 2 0 , I s r a e l
December 2018
P O B 2 5 0 0 4 , H a i f a 3 1 2 5 0 0 1 , I s r a e l
T e l : ( + 9 7 2 ) - 7 2 - 2 7 2 3 5 0 0 F a x : ( + 9 7 2 ) - 7 2 - 2 7 2 3 5 1 1
w w w . k a y a i n s t r u m e n t s . c o m
Advertisement
Table of Contents
Summary of Contents for KAYA Komodo CoaXPress II
- Page 1 Komodo II CoaXPress Frame Grabber Hardware Reference and Installation Guide (Part-No. KY-FGKII) 2 0 a M e s i l a S t . , N e s h e r 3 6 8 8 5 2 0 , I s r a e l December 2018 P O B 2 5 0 0 4 , H a i f a 3 1 2 5 0 0 1 , I s r a e l T e l : ( + 9 7 2 ) - 7 2 - 2 7 2 3 5 0 0 F a x : ( + 9 7 2 ) - 7 2 - 2 7 2 3 5 1 1...
-
Page 2: Table Of Contents
Contents Figures and Tables ..........................2 Introduction............................3 Safety Precautions ..........................3 Disclaimer ............................4 Key Features ............................6 Overview .............................. 6 Features ..............................6 Product Applications ..........................7 Related documents and accessories ..................... 8 System Description ..........................9 Example System Block Diagram ......................9 External View of the Board........................ -
Page 3: Figures And Tables
Figures and Tables Figures 1: C .................... 9 IGURE RESS SYSTEM BLOCK DIAGRAM 2: K ....................10 IGURE OMODO BOARD EXTERNAL VIEW 3: E ..................12 IGURE XTERNAL OWER SUPPLY CONNECTOR 4: PCB M ....................13 IGURE ECHANICAL IMENSIONS LED’ 5: K II B .................. -
Page 4: Introduction
Introduction Safety Precautions With your Komodo II CoaXPress Frame Grabber board in hand, please take a minute to read carefully the precautions listed below in order to prevent unnecessary injuries to you or other personnel or cause damage to property. ... -
Page 5: Disclaimer
CoaXPress video streams. KAYA Instruments assumes no responsibility for any damages resulting from the use of this product for purposes other than those stated. Even if the product is used properly, KAYA Instruments assumes no responsibility for any damages caused by the following: - Earthquake, thunder, natural disaster or fire resulting from the use beyond our responsibility, acts caused by a third party or other accidents, the customer’s willful or... - Page 6 Introduction KAYA Instruments assumes no responsibility or liability for: - Erasure or corruption of data arising from use of this product. - Any consequences or other abnormalities arising from use of this product, or damage of this product not due to our responsibility or failure due to modification.
-
Page 7: Key Features
Key Features Overview Komodo II is best in its class Frame Grabber supporting CoaXPress standard. The Komodo II is capable of receiving video streams from up to 4 CoaXPress links in single, dual or quad modes. It is used for simultaneous capture from up to two dual link cameras. Each link supports standard CoaXPress bitrates up to 12.5 Gbps. -
Page 8: Product Applications
Key Features Supporting Windows and Linux OS API for developing custom applications Plug-ins modules for Matlab, HALCON and Labview Gen<i>Cam compliant GenTL support 4Gb image buffer Data rates up to 12.5 Gbps per link ... -
Page 9: Related Documents And Accessories
Vision Point App User Manual Vision Point API Reference Book CoaXPress standard 2.0 KAYA Frame Grabbers Programming Guide Accessories: CoaXPress cables (Micro-BNC to Micro-BNC) CoaXPress cables (Micro-BNC to BNC) CoaXPress cables (Micro-BNC to DIN) -
Page 10: System Description
System Description Example System Block Diagram The Komodo II Frame Grabber supports multiple modes of configuration and system topology. Few of these are presented in following diagrams. Single Camera Topology: Single, Dual or Quad CoaXPress links with up to 12.5 Gb per link topology. Maximum throughput to PCIe of 55 Gb/sec. -
Page 11: External View Of The Board
System Description External View of the Board Figure 2: Komodo II board external view Komodo II CoaXPress Frame Grabber Hardware and Installation Guide... -
Page 12: Mechanical Specifications
An availably x4 (or x8 or x16) PCIe slot. Gen 3 support is recommended to faster data transfer. Vision Point Application installation KAYA Instruments doesn’t guarantee compatibility with all computers that have the above specifications. Please, consult KAYA representative for any specific issue. Power supplies The Komodo II board receives its power directly from PCIe connector of the motherboard. -
Page 13: Figure 3: External Power Supply Connector
Mechanical Specifications External Power Supply Connector Figure 3: External Power supply connector Komodo II CoaXPress Frame Grabber Hardware and Installation Guide... -
Page 14: Mechanical Dimensions
The Komodo II board is a half-length PCIe card according to PCI Express Card Electromechanical Specification. The exact board mechanical dimensions are as defined in Figure 4. For more detailed information please, contact KAYA Instruments representative. Figure 4: PCB Mechanical Dimensions Komodo II CoaXPress Frame Grabber Hardware and Installation Guide... -
Page 15: Installation And Configurations
Installation and Configurations Installation instructions Komodo II board is standard PCIe card with 8 lanes connector. It can be installed in any PCIe Gen3 connector of the motherboard with 8 lanes and up. Note: Board should be installed before you install your software. 1. -
Page 16: Komodo Ii Leds
Installation and Configurations Komodo II LEDs Each CoaXPress link of the Frame Grabber is equipped with indication bi-color LED. The LEDs behave according to definition in section 5.4 of the CXP standard. The LEDs’ different states are described in Table 1. LED state Description Solid orange... -
Page 17: Komodo Ii Hardware Reference
Installation and Configurations In additional to CoaXPress links LEDs, the Komodo II Board is equipped with status LEDs. LED 0 LED 1 LED 2 LED 3 CH 0 LED CH 1 LED CH 2 LED CH 3 LED Figure 5: Komodo II Board LED’s locations Board Status LEDs functionality is described in Table 2: LED # Description... -
Page 18: Komodo Ii Board Block Diagram
Installation and Configurations Komodo II Board Block Diagram External GPIO power PoCXP connector GPIO Video stream Micro-BNC Equalizer channel Controller Control channel Video stream Micro-BNC Equalizer channel Processing Control channel SODIMM DDR4 64 bit Unit Video stream Micro-BNC Equalizer channel Control channel Video stream Micro-BNC... -
Page 19: Video Stream Acquisition
Installation and Configurations Video stream acquisition Komodo II is designed to acquire different video streams compliant with CoaXPress standard 2.0 over up to 4 CoaXPress links. When connected to transmitting device, the frame grabber communicates with Camera device to determine link parameters, such as data rate. For different options please refer to Vision Point Application User Manual. -
Page 20: Figure 7: Gpio Connectors Location
Installation and Configurations Figure 7: GPIO connectors location Komodo II CoaXPress Frame Grabber Hardware and Installation Guide... -
Page 21: Figure 8: Gpio Connectors Schematic
Installation and Configurations The electrical connection of the GPIO connectors is described following principal schematic diagram: 3.3V GPIO_LVDS_EN GPIOE_LVDS_IN0n RIN1n GPIOE_LVDS_IN0p RIN1p GPIO_LVDS_IN0 GPIOE_LVDS_IN1p ROUT1 RIN2p GPIO_LVDS_IN1 GPIOE_LVDS_IN1n ROUT2 RIN2n GPIOE_LVDS_OUT1n DOUT2n GPIO_LVDS_OUT1 GPIOE_LVDS_OUT1p DIN2 DOUT2p GPIO_LVDS_OUT0 GPIOE_LVDS_OUT0p DIN1 DOUT1p GPIOE_LVDS_OUT0n DOUT1n DS90LV049H... - Page 22 Installation and Configurations The pinout of each of these connectors is as described in Error! Reference source not found. Signal Name Function Electrical Description Number Standard LVDS Input 0p LVDS input LVDS Positive signal of LVDS pair LVDS Input 0n LVDS input LVDS Positive signal of LVDS pair...
-
Page 23: Electrical Characteristics For Board Io's
Signal Name Function Electrical Description Number Standard LVDS Input 0p LVDS input LVDS Positive signal of LVDS pair LVDS Input 0n LVDS input LVDS Positive signal of LVDS pair LVDS Input 1p LVDS input LVDS Negative signal of LVDS pair LVDS Input 1n LVDS input LVDS... -
Page 24: Absolute Maximum Ratings
Installation and Configurations Absolute maximum ratings Specification Values 3.3V power supply -1.0V to +7.0V 12V power supply -0.3V to 14V Storage temperature -55°C to 125°C Operating ambient temperature 0°C to 50°C Table 4: Absolute maximum ratings Specification Minimum voltage [V] Maximum voltage [V] LVDS -0.3... -
Page 25: Table 6: Lvds Output Dc Specifications (Driver Outputs)
Installation and Configurations Current = 0 V or OUT+ = GND, D = 0 V OUT- Differential Output Short ENABLED, V = 0 V -5.8 -9.0 Circuit Current Power-off Leakage = 0 V or 3.6 V ±1 µA = 0 V or Open Output TRI-STATE EN = 0 V and EN = V ±1... -
Page 26: Table 10: Ttl Input Specifications
Installation and Configurations Symbol Parameter Test condition (note 1) Units ≥ V Input High Voltage OH (min) ≤ V Input Low Voltage OL (max) Input Current = 0 V or V ±1 µA Note: Vdd = 5V, unless specified otherwise Table 10: TTL input specifications Symbol Parameter...
