- Page 1 SM-R400 USER’S MANUAL V2.4.16 April 2012...
- Page 2 SM-R400 User’s Manual Company Date Version V2.4.16 Revision history Version Revision Date Revision page Revision Description V2.4.16 1012-04-16 Draft Identification with Radio and Optical...
-
Page 3: Table Of Contents
Reader Description ......................8 Reader Specification....................10 UHF RFID Reader Performance...................... 10 Interface..............................10 Physical Dimension..........................10 Bluetooth Setting Parameter ......................11 Mechanical Dimension........................12 How to Run SM-R400 Sample Program ..............13 Identification with Radio and Optical... -
Page 4: Introduction & System Composition Diagram
SM-R400 User’s Manual Company Date Version V2.4.16 1. Introduction & System composition diagram Introduction This product, as a Bluetooth embedded UHF RFID Reader, is designed for short distance application using the Bluetooth, USB Interface with PC and SMART PHONE, and it provides customers with Compact size, low cost, high performance functions. - Page 5 SM-R400 User’s Manual Company Date Version V2.4.16 *RFID Functional Description The transmitter supports both in-phase quadrature (IQ) vector modulation and polar modulation. The direct IQ up- conversion is intended for phase reversal amplitude shift keying (PR-ASK). The polar modulation is intended for double sideband amplitude shift keying (DSB-ASK).
- Page 6 SM-R400 User’s Manual Company Date Version V2.4.16 Identification with Radio and Optical...
-
Page 7: Composition Parts
SM-R400 User’s Manual Company Date Version V2.4.16 2. Composition parts RFID Reader USB Cable Reader Software & User Document CD-ROM Identification with Radio and Optical... -
Page 8: Reader Description
SM-R400 User’s Manual Company Date Version V2.4.16 3. Reader Description S/W & STATUS LED POWER S/W Battery charging LED, Low-battery LED POWER LED, READ LED Bluetooth LED (paring) RESET S/W POWER S/W : Power on/off Switch Battery charging LED : When the battery is being charged, the Red Led is turned on ... - Page 9 SM-R400 User’s Manual Company Date Version V2.4.16 ANT PART & USB USB : It is used Battery charging and USB interface with PC Identification with Radio and Optical...
-
Page 10: Reader Specification
SM-R400 User’s Manual Company Date Version V2.4.16 4. Reader Specification UHF RFID Reader Performance Description Value MODEL SM-R400 Architecture UHF RFID Reader Module Protocol EPC Gen2(ISO 18000-6C), Frequency 902.75MHz to 927.25MHz(USA) Max. Tx Power 27dBm±1dBm (0.5W) Power control 5dBm to 27dBm(1dB step) -
Page 11: Bluetooth Setting Parameter
SM-R400 User’s Manual Company Date Version V2.4.16 Bluetooth Setting Parameter Parameter Value Local Device Name “Blue Angel” Bluetooth Service Name “Serial Port Profile” Bluetooth Device Address “123456000000 ~ 123456ffffff”(HEX) PIN Code “0000”(ASCII) UART Baud Rate 115200bps UART Parity None... -
Page 12: Mechanical Dimension
SM-R400 User’s Manual Company Date Version V2.4.16 Mechanical Dimension Identification with Radio and Optical... -
Page 13: How To Run Sm-R400 Sample Program
SM-R400 User’s Manual Company Date Version V2.4.16 5. How to Run SM-R400 Sample Program 1. Windows XP/7 1.1 File name : Reader@Express V3.2.24.zip 1.2 Simple use : 0. Add bluetooth device (Reader), and confirm relevant communication port in device manager. - Page 14 SM-R400 User’s Manual Company Date Version V2.4.16 You can connect with bluetooth reader in following method. 1. If you select [Search] in [Option menu], then the window to select bluetooth device appears. Already paired devices are appeared on upper part.
