Tabletop Scenics ORC SMACK BAR Assembly Instruction Manual

ORC SMACK BAR
Before assembling your model kit please read through the instructions carefully.
Next, prepare all the tools needed for the job. Modelling knife is required to remove the parts
safely from the frame. Do not remove the parts from the frame by pushing them forcefully
– some parts are fragile and can be easily damaged. After the removal, it is recommended to
sand the tabs and possible roughnesses left after cutting from the frame.
Please remember to always cut away from your body and fingers!
For gluing use PVA or cyanoacrylate glue. Always remember to dry fit before gluing to check if
all joints fit correctly. Cyanoacrylate glue allows for a faster assembly, however gives you less
time for possible corrections. PVA glue is slower, but will give you more time for altering
the position of the elements.
Before painting the model, undercoat it with matt acrylic spray paint to protect wood from
absorbing the water from your water-soluble paints. Matt acrylic car primer will do. Give it
plenty of time to dry. Afterwards, you can base coat your model with your standard hobby paints.
These instructions are available online at:
NOTE:
http://www.tabletopscenics.com/EN-H19/download.html
We would like to express our gratitude for your purchase and encourage to check many other
fantastic constructions from this series. If you are looking for an interesting wargames terrain
created with great attention to detail and production (guaranteed by Kromlech company) check
our web store: www.bitsofwar.com
Kromlech sells Heavy Duty Modelling Knife, PVA Glue, Superglue, Superglue Activator,
and cutting mat, but does not recommend to use these products by children under 16 years old
without adult supervision.

EXPLANATION OF SYMBOLS

CUT/TRIM
DRY TEST
WITH CARE

RECOMMENDED ACCESSORIES

KROMLECH
SUPER GLUE
HEAVY DUTY KNIFE
PAGE 1 / 7
ASSEMBLY INSTRUCTION
GLUE
KROMLECH
KROMLECH
SUPER GLUE
ACTIVATOR
!
PAY
DON'T GLUE
ATTENTION
KROMLECH
PVA GLUE
+
1
CONSTUCTION
EXTRA PART
KROMLECH
CUTTING MAT
ORC SMACK BAR
Construction Guide
2
ORDER
