Summary of Contents for BlueStar BBB36R/L
- Page 1 USE & CARE MANUAL Built-in Refrigerator Part # 799934 revision 0 © Prizer Painter Stove Works, Blandon, PA 19510...
- Page 2 Thank You and Welcome ® Thank you for your purchase and welcome to the BlueStar family! ® BlueStar refrigerators are designed for discerning home chefs who demand restaurant-quality results in their own ® kitchens. As the owner of a new BlueStar refrigerator you can look forward to years of cooling excellence.
-
Page 3: Table Of Contents
Troubleshooting If service is required under the warranty, it must be Warranty performed by authorized service personnel. BlueStar also recommends using authorized service personnel if service is required after the warranty expires. To locate authorized service personnel in your area, call customer service at (877) 427-3290. -
Page 4: Safety Information
Safety Information DANGER Please read and obey the following types of safety messages to ensure your refrigerator is installed and Suffocation Hazard operated as safely as possible: Remove doors from old refrigerators. Failure to follow these instructions can cause death or brain damage. DANGER Will cause serious injury or death if instructions are not followed. - Page 5 Renseignements sur la sécurité DANGER Veuillez lire et observer les types suivants de messages de sécurité pour vous assurer que votre réfrigérateur est Risque d'étouffement installé et utilisé de la façon la plus sécurisée possible: Déposer les portes des anciens réfrigérateurs. Le non- respect de ces instructions peut entraîner la mort ou des DANGER lésions cérébrales.
-
Page 6: Site Preparation
Site Preparation Opening Dimensions Electrical Height: 84” Location: The electrical outlet should be located in Width: 35 1/2” the area marked “Electrical” in Fig. 1. Depth: 24” minimum The electrical outlet may also be located For more specific installation options and drawings, go to above the enclosure. - Page 7 Site Preparation Plumbing Location: The water line should be located in the area marked “Water” in Fig 1. This area 35 1/2” also extends 10” forward on the floor. 3” If it is outside this area, it may be Top Anchor Bracket damaged during installation and 6 1/2”...
-
Page 8: Installation Instructions
Installation Instructions Tools and Materials WARNING Phillips screwdriver Tip Over Hazard Flat blade screwdriver Refrigerator is top heavy and tips easily when not Power drill and drill bits (for anchor bracket) completely installed. Use two or more people to move and install refrigerator. - Page 9 Installation Instructions Step 2 — Install Anchor Bracket (continued) Step 3 — Route Water Line Locate the household water line as shown below prior WARNING to moving the refrigerator into position. It may be helpful to tape the water line to the floor to avoid Tip Over Hazard damaging it as the refrigerator is rolled into position.
- Page 10 Installation Instructions Step 4 — Move Refrigerator into Position Lift the top grille and align the slots in the upper cabinet with the holes in the anchor bracket. Install Remove the wood base with a 1/2” socket or open anchor bolts and any washers (from Step 2) with a end wrench and discard the shipping bolts and 1/2”...
- Page 11 Installation Instructions Step 6 — Level Refrigerator Step 7 — Align Doors The height adjustment for the front and back can be Only adjust the doors if necessary to achieve uniform made from the front of the refrigerator. Turn the hex gaps and proper alignment.
-
Page 12: Models
Installation Instructions Step 7 — Align Doors (continued) Step 8 — Align Top Grille Retighten the five bolts with a 5/16” hex head socket. Only adjust the top grille if necessary to achieve uniform Bolts need to be tightened to 50 in. lb. It is normal for gaps and proper alignment. - Page 13 BBB36R/L Electronic Control Air Filter Glass Shelves Pull-out Tray Deli Drawer Crisper Drawer Dairy Bins Door Bins Ice Maker (inside freezer) 10 Freezer Bins (inside freezer) 11 Water Filter (behind top grille) bluestarcooking.com...
- Page 14 BBBF36 Electronic Control Air Filter Glass Shelves Pull-out Tray Deli Drawer Crisper Drawer Dairy Bins Door Bins Ice Maker (inside freezer) 10 Freezer Bins (inside freezer) 11 Water Filter (behind top grille) (877) 427-3290...
-
Page 15: Electronic Control
Electronic Control Home Screen Main Options Displays the freezer and refrigerator temperatures. The Swipe right or left to access the main options. recommended freezer factory setting is 0°F. The temperature can be set from -5°F to 5°F.The Max Ice recommended refrigerator factory setting is 38°F. The Increases ice production by 50%. -
Page 16: Refrigerator Features
Refrigerator Features Electronic Control Alarms Spillproof Glass Shelves Door Alarm Important: Glass shelves and drawers are heavy as they are made of glass and metal. Use special care when Sounds continuously when the refrigerator and/or freezer removing them to avoid impact from dropping. Do not door(s) are open for more than five minutes. - Page 17 Refrigerator Features Pull-Out Tray Dairy and Door Bins Remove: Pull the tray forward until it stops. Remove Remove: Lift the bin up and pull it out. the glass by lifting it from underneath the tray. Remove the Phillips screws from both sides of the tray (near the front).
-
Page 18: Freezer Features
Freezer Features Upper Drawer Ice Maker Important: Drawers are heavy as they are made of metal. The ice maker will produce approximately 2 1/2 pounds of Use special care when removing them to avoid impact ice every 24 hours. The Max Ice feature increases ice from dropping. -
Page 19: Operation
Operation Water Filter (continued) Top Grille The top grille lifts up for easy access to the power switch The water filter, AP2-200G supplies filtered water to the (on the right) and the water filter (on the left). Lift the top ice maker and is located behind the top grille. - Page 20 Operation Lighting Water Filter (continued) Interior lighting is provided by LEDs. If one needs to be 3. Remove the water filter from the packaging. replaced, call customer service at (877) 427-3290 to schedule a service call. 4. Insert the new water filter and rotate it clockwise a half turn.
-
Page 21: Care And Cleaning
Care and Cleaning Condenser Before cleaning, turn the refrigerator off using the power switch, located behind the top grille. When finished CAUTION cleaning, turn the refrigerator on. Electrical Shock Hazard Stainless Steel Doors and Interior Turn power off before cleaning condenser. Failure to Use a non-abrasive stainless steel cleaner and a soft follow these instructions can result in death, electrical cloth. -
Page 22: Troubleshooting
Troubleshooting The ice maker is not making ice. The refrigerator makes unusual noises. Confirm the ice maker setting on the electronic control The following noises are normal: is on and the bale arm on the ice maker is in the ... -
Page 23: Warranty
Warranty service in areas beyond a 30 mile radius from an authorized BlueStar retailer or service What Products Does this Warranty Not Cover? This provider may require certain costs to the consumer. - Page 24 Warranty How Can An Owner Obtain Warranty Service? All Where Can Any Legal Remedies Be Pursued? Please warranty claims must be submitted to Prizer Painter read carefully the Arbitration Clause and its Provisions, customer service by calling (877) 427-3290 prior to the which affect your legal rights.
- Page 25 Warranty 10. Costs of the Arbitration: Each party is responsible for 5. SMALL CLAIMS COURT OPTION: YOU MAY its own attorney, expert and other fees, unless awarded CHOOSE TO LITIGATE ANY DISPUTE BETWEEN YOU by the arbitrator(s) under applicable law. Prizer-Painter AND ANY OF US IN SMALL CLAIMS COURT, RATHER will pay your share of the fees charged by the arbitration THAN IN ARBITRATION, IF THE DISPUTE MEETS ALL...
- Page 26 For Dealer’s Only Enable showroom mode by swiping the main screen left or right to access the main options. Press the settings icon to access the settings options. Press the Alarm icon and the blank space at the same time for three seconds. An S with a circle around it will appear in the upper left corner on the main screen.
- Page 27 bluestarcooking.com...
- Page 28 Tested and Certified in System Model BS-AP2-200G against NSF/ANSI Standards 42 and 53 for the reduction of the claims specified on the Performance Data Sheet.
